oil type lexus LS400 1999 Electrical Components / LEXUS 1999 LS400 OWNER'S MANUAL (OM50514U)

AIR CONDITIONING AND AUDIO
241
(d) Your radio antenna
The wire antenna is mounted inside the rear window.
NOTICE
When
cleaning the inside of the rear window, be
careful not to scratch or damage the wire antenna.
Putting a window tint (especially, conductive ormetallic type) on the rear window may affect thereception of radio or m obile telephone. For the
installation of the window tint, consult with your Lexus dealer.
(e) Your cassette player
When you insert a cassette, the exposed tape should be
to the right.
NOTICE
Do not oil any part of the cassette player, and do not insert anything except a cassette tape into theslot.
(f) Your automatic changer

DRIVING TIPS
324
Do not rest your foot on the brake pedal while
driving. It can cause dangerous overheating,
needless wear, and poor fuel economy.
 To drive down a long or steep hill, reduce your
speed and downshift. Remember, if you ride
the brakes excessively, they may overheat and
not work properly. See page 288.
 Be careful when accelerating, upshifting,
downshifting or braking on a slippery surface.
The abrupt change in engine speed, such as
sudden acceleration or engine braking, could
cause the vehicle to spin or skid.
 Do not drive in excess of the speed limit. Even
if the legal speed limit permits it, do not drive
over 140 km/h (85 mph) unless your vehicle has
high±speed capability tires. Driving over 140
km/h (85 mph) may result in tire failure, loss of
control and possible injury. Be sure to consult
a tire dealer to determine whether the tires on
your vehicle are high±speed capability tires or
not before driving at such speeds.
 Do not continue normal driving when the
brakes are w et. If they are wet, your vehicle will
require a longer stopping distance, and it may
pull to one side when the brakes are applied.
Also, the parking brake will not hold the vehicle
securely.WINTER DRIVING TIPS
Make sure you have a proper freeze protection of
engine coolant.
Your coolant must contain ethylene±glycol type coolant
for a proper corrosion protection of aluminum
components. Use ºToyota Long Life Coolantº or
equivalent. See ºChecking the engine coolant levelº on
page 409 for instructions.
NOTICE
Do not use alcohol type antifreeze or plain water
alone.
When it is extremely cold, we recommend to use 60%
solution for your Lexus, to provide protection down to
about ±50 C (±58 F). Do not use more than 70%
solution for better coolant performance.
Check the condition of the battery and cables.
Cold temperatures reduce the capacity of any battery, so
it must be in top shape to provide enough power for
winter starting. Page 443 tells you how to visually
inspect the battery. Your Lexus dealer and most service
stations will be pleased to check the battery charge
level.
Make sure the engine oil viscosity is suitable for the
cold weather.

62L005±1
Temperature range anticipated before next oil change
ENGINE
397
Model
Type
Bore and stroke
Displacement
Valve clearance (engine cold)
Intake
Exhaust
Drive belt tension
1UZ±FE
8 cylinder V type, 4 cycle, gasoline
87.5 X 82.5 mm (3.44 X 3.25 in.)
3969 cm
3 (242.1 cu.in.)
0.15 ± 0.25 mm (0.006 ± 0.010 in.)
0.25 ± 0.35 mm (0.010 ± 0.014 in.)
Automatic adjustment
± LUBRICATION SYSTEM Oil capacity Drain and refillwith filter
without filter
Oil grade

Recommended oil viscosity (SAE):
5.6 L (5.9 qt., 4.9 lmp.qt.)
5.3 L (5.6 qt., 4.7 lmp.qt.)
API SJ, ºEnergy±Conservingº multigrade engine oil or
ILSAC multigrade engine oil

ENGINE
407
If the oil level is below or only slightly above the low
line,
add engine oil of the same type as already in the
engine. Remove the oil filler cap and add engine oil a little at a
time,
checking the dipstick. The approximate quantity of
oil needed to fill between the low line and the full line on
the dipstick is indicated below for reference.
When the level reaches within the correct range, return
the filler cap and turn the cap clockwise until you hear a
click.
Oil quantity. L (qt., lmp. qt.) 1.5 (1.6, 1.3)
NOTICE
Avoid overfilling, or the engine could be
damaged. Ch eck the oil level on the dipstick once
again after adding the oil.

CHASSIS
415
SPECIFICATIONS
± AUTOMATIC TRANSMISSIONFluid capacity Drain and refill
Fluid type
1.9 L (2.0 qt., 1.7 lmp.qt.)
Automatic transmission fluid Type T ± IV or
equivalent
± DIFFERENTIAL
Oil capacity
Oil type
Oil viscosity
1.3 L (1.4 qt., 1.1 lmp.qt.)
Hypoid gear oil API GL±5
Above ±18 C (0F): SAE 90
Below ±18 C (0F): SAE 80W or SAE 80W±90
± BRAKES
Pedal clearance
Pedal freeplay
Brake pad wear limit
Parking brake lining wear limit
Parking brake adjustment
Fluid type
70 mm (2.8 in.) Min. *1
1 ± 6 mm (0.04 ± 0.24 in.)
1.0 mm (0.04 in.)
1.0 mm (0.04 in.)
5 ± 7 clicks *
2
SAE J1703 or FMVSS No. 116 DOT 3
*1: Minimum pedal clearance when depressed with the pressure of 490 N (50 k\
gf, 110 lbf.) with the engine running
*
2: Parking brake adjustment when depressed with the pressure of 294 N (30 \
kgf, 66.1 lbf.)

BODY
477


Dirt or sand adhered to the leather may damage
the treated surface and cause it to wear earlier.Remove dirt or sand using a vacuum cleaner.

If a stain should fail to come out with a neutraldetergent, apply a cleaner that does notcontain an organic solvent.

Never use organic substances such asbenzine, alcohol or gasoline, or alkaline or acid
solutions for cleaning the leather as these could cause discoloring.

Use of a nylon brush or synthetic fiber cloth,etc. may scratch the fine grained surface of the
leather.

Mildew may develop on soiled leather upholstery. Be especially careful to avoid oil
spots. Try to keep your upholstery alwaysclean.

Long exposure to direct sunlight may causethe leather surface to harden and shrink. Keepyour vehicle in a shaded area, especially in thesummer.

The interior of your vehicle is apt to heat up onhot summer days, so avoid placing on theupholstery items made of vinyl or plastic orcontaining wax as these tend to stick to leather
when warm.

Improper cleaning of the leather upholstery could result in discoloration or staining.
Synthetic Leather Areas
(Dash and sun visors)
The synthetic leather areas may be easily cleaned
with a mild soap or detergent and water.
First vacuum over the upholstery to remove loose dirt.
Then, using a sponge or soft cloth, apply the soap
solution to the synthetic leather. After allowing it to soak
in for a few minutes to loosen the dirt, remove the dirt and
wipe off the soap with a clean damp cloth. If all the dirt
does not come off, repeat the procedure. Commercial
foaming±type cleaners are also available which work
well. Follow the manufacturer's instructions.
NOTICE
Do not use solvent, thinner, gasoline or windowcleaner on the interior.
Carpets, Windows and Seat Belts
Begin by vacuuming thoroughly to remove as much dirt
as possible. Several types of foam cleaners are
available; some are in aerosol cans and others are
powders or liquids which you mix with water to produce
a foam. To shampoo the carpets, use a sponge or brush
