For detailed information, refer to the description given in each section\
.
PICTORIAL INDEX
xi
Page
1 Engine coolant temperature gauge 59. . . . . . .
2 Tachometer 60
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 Turn signal indicator light 38
. . . . . . . . . . . . . . .
4 Headlight indicator light 35
. . . . . . . . . . . . . . . . .
5 Headlight high beam indicator light 38 . . . . . .
6 Automatic transmission indicator lights 281 .
7 Fuel gauge 57
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8 Low fuel level warning light 68
. . . . . . . . . . . . . .
9 Cruise control indicator light 297
. . . . . . . . . . .
10 Height control indicator light 304
. . . . . . . . . . .
11 Power mode indicator light 295
. . . . . . . . . . . . .
12 Snow mode indicator light 295
. . . . . . . . . . . . . .
13 Anti±lock brake system warning light 67 . . . . . Page
14 Vehicle skid control system off
indicator light 304 . . . . . . . . . . . . . . . . . . . . . . . . .
15 Malfunction indicator lamp 67
. . . . . . . . . . . . . .
16 Slip indicator light 304
. . . . . . . . . . . . . . . . . . . . .
17 Multi information display 70
. . . . . . . . . . . . . . . .
18 Odometer and trip meter 61
. . . . . . . . . . . . . . . .
19 Brake system warning light 64
. . . . . . . . . . . . . .
20 SRS warning light 66
. . . . . . . . . . . . . . . . . . . . . . .
21 Open door warning light 68
. . . . . . . . . . . . . . . . .
22 Driver's seat belt reminder light 66
. . . . . . . . . .
23 Discharge warning light 67
. . . . . . . . . . . . . . . . .
24 Instrument panel light control 79
. . . . . . . . . . . .
25 ODO/TRIP RESET button 61
. . . . . . . . . . . . . . . .

For detailed information, refer to the description given in each section\
.
PICTORIAL INDEX
xiii
Page
1 Engine coolant temperature gauge 59. . . . . . .
2 Tachometer 60
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 Turn signal indicator light 38
. . . . . . . . . . . . . . .
4 Tail light indicator light 35
. . . . . . . . . . . . . . . . . .
5 Headlight high beam indicator light 38 . . . . . .
6 Automatic transmission indicator lights 281 .
7 Fuel gauge 57
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8 Low fuel level warning light 68
. . . . . . . . . . . . . .
9 Cruise control indicator light 297
. . . . . . . . . . .
10 Power mode indicator light 295
. . . . . . . . . . . . .
11 Snow mode indicator light 295
. . . . . . . . . . . . . .
12 Anti±lock brake system warning light 67 . . . . . Page
13 Vehicle skid control system
off indicator light 304 . . . . . . . . . . . . . . . . . . . . . .
14 Malfunction indicator lamp 67
. . . . . . . . . . . . . .
15 Slip indicator light 304
. . . . . . . . . . . . . . . . . . . . .
16 Multi information display 70
. . . . . . . . . . . . . . . .
17 Odometer and trip meter 61
. . . . . . . . . . . . . . . .
18 Brake system warning light 64
. . . . . . . . . . . . . .
19 SRS warning light 66
. . . . . . . . . . . . . . . . . . . . . . .
20 Open door warning light 68
. . . . . . . . . . . . . . . . .
21 Driver's seat belt reminder light 66
. . . . . . . . . .
22 Discharge warning light 67
. . . . . . . . . . . . . . . . .
23 Instrument panel light control 79
. . . . . . . . . . . .
24 ODO/TRIP RESET button 79
. . . . . . . . . . . . . . . .

SWITCHES
44
HEADLIGHT CLEANER SWITCH(CANADA ONLY)
12L007a
To spray fluid on the headlights, push the switch
with the headlights on.
The ignition key must be in the ºONº position.
The warning message ºLOW WASHER FLUIDº is
displayed in the multi information display when the fluid
level in the tank becomes nearly empty. For information
on adding washer fluid, see ºAdding washer fluidº on
page 459.
NOTICE
Do not turn the headlight cleaner on with the tank
empty. It may cause the cleaner motor tooverheat.

SECTION 1 ± 3
57
INSTRUMENTS AND CONTROLS
Gauges, meters and service reminder
indicators
Fuel gauge57
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine coolant temperature gauge 59
. . . . . . . . . . . . . . .
Tachometer 60
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Odometer and trip meter 61
. . . . . . . . . . . . . . . . . . . . . . . .
Service reminder indicators and warning buzzers 62 . . .
Multi information display 70
. . . . . . . . . . . . . . . . . . . . . . . .
Instrument panel light control 79
. . . . . . . . . . . . . . . . . . . .
FUEL GAUGE
13L001±1

GAUGES, METERS AND SERVICE REMINDER INDICATORS
58

Low fuel level warning light
The gauge is displayed when the ignition switch is
on and indicates the approximate quantity of fuel
remaining in the tank.
It is a good idea to keep the tank over 1/4 full.
If the fuel level approaches ºEº or the low fuel level
warning light comes on, fill the fuel tank as soon as
possible.
On inclines or curves, due to the movement of fuel in the
tank, the fuel gauge needle may fluctuate or the low fuel
level warning light may come on earlier than usual.
If the fuel tank is completely empty, the malfunction
indicator lamp comes on. Fill the fuel tank immediately.
The indicator lamp goes off after driving several times.
If the indicator lamp does not go off, contact your Lexus
dealer as soon as possible.
See the inner back cover for fuel capacity and
recommended fuel selection.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
63
(a) If parking brake
is off, stop and
check.
(b) Fasten driver's seat belt.

(Indicator and buzzer)
(c) Fasten front passenger's
seat belt.
(Under the center vent)
(d) Take vehicle to Lexus dealer
immediately.
(e) Stop and check. (f) Take vehicle to
Lexus dealer.
(g) Take vehicle to Lexus dealer.
(h) Close all doors.
(i) Low fuel level Fill up tank. warning light
(j) Key reminder buzzer Remove key.
or
or

GAUGES, METERS AND SERVICE REMINDER INDICATORS
64
(a) Brake System Warning Light
This light has the following two functions:
Parking brake reminder
If this light is on, make sure the parking brake is fully
released. The light should go off.
Low brake fluid level warning
If this light comes on and stays on while you are driving,
slow down and pull off the road. Then stop the vehicle
carefully. Remember that stopping distance and pedal
effort may be increased. There may be a problem
somewhere in the brake system. Check the fluid level
of the see±through reservoir.
To make sure the parking brake has not caused the
warning light to come on, check to see that the parking
brake is fully released.
If the brake fluid level is low ...
At a safe place, test your brakes by starting and
stopping.
If you judge that the brakes still work adequately, drive
cautiously to your nearest dealer or shop for repairs.
 If the brakes are not working, have the vehicle towed
in for repairs. (For towing information, see page 366.)

GAUGES, METERS AND SERVICE REMINDER INDICATORS
66If the brake fluid level is correct ...
Have
the warning system checked by your Lexus dealer.
(b) Driver's Seat Belt Reminder Light
and Buzzer
Once the ignition key is turned to ºONº or ºSTARTº, the
reminder light flashes and buzzer sounds if the driver's
seat belt is not fastened. Unless the driver fastens the
belt, the light stays flashing and the buzzer stops after
about 4 to 8 seconds.
(c) Front Passenger's Seat BeltReminder Light
Once the ignition key is turned to ºONº or ºSTARTº, the
reminder light flashes if a passenger sits in the front
passenger seat and does not fasten the seat belt.
Unless the front passenger fastens the belt, the light
stays flashing.
If luggage load is placed on the front passenger seat,
depending on its weight and how it is placed on the seat,
built±in sensors in the seat cushion may detect the
pressure, causing the reminder light to come on.
(d) SRS Warning Light
The indicators come on when the ignition key is
turned to the ºACCº or ºONº position. It goes off
after about 6 seconds. This means the SRS is
operating properly.
The SRS warning light system monitors the airbag
sensor assemblies, inflators, seat belt pretensioners,
warning light, interconnecting wiring and power sources.
If either of the following conditions occurs, this indicates
a malfunction somewhere in the parts monitored by the
warning light system. Contact your Lexus dealer as
soon as possible to service the vehicle.
 The light does not come on as described above.
 The light stays on or flashes.
 The light comes on or starts flashing while driving.
If the light stays on, it indicates that the driver and front
passenger airbags fail. If the light flashes, the side
airbags and/or seat belt pretensioners fail.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
67
(e) Discharge Warning Light
This light warns that the battery is being discharged.
If it comes on while you are driving, stop the vehicle, turn
off the engine, and check for the cause. Look first at the
engine drive belt.
If it is loose or broken, the generator will not charge
the battery properly.
 If the belt is O.K., there is a problem somewhere in the
charging system.
The engine ignition will continue to operate, however,
until the battery is discharged. Turn off the air
conditioning, blower, radio, etc., and drive directly to the
nearest Lexus dealer or repair shop.
NOTICE
Do not continue driving if the engine drive belt is broken or loose.
(f) Malfunction Indicator Lamp
This lamp comes on in the following cases.
a. The fuel tank is completely empty. (See ºFuel gaugeº
on page 57 for instructions.)
b. The fuel tank cap is not tightened securely. (See
ºFuel tank capº on page 110 for instructions.)
c. There is a problem somewhere in your engine
electrical system, automatic transmission electrical
system or electronic throttle control system.
If it comes on while you are driving in case ªc.º, have your
vehicle checked/repaired by your Lexus dealer as soon
as possible.
(g) ºABSº Warning Light
This light warns that there is a problem somewhere in
your anti±lock brake system.
If the light comes on while you are driving, have your
vehicle checked by your Lexus dealer as soon as
possible.
The light will come on when the ignition key is turned to
ºONº, and will go off after about a few seconds.
When the ºABSº warning light is on (and the brake
system warning light is off), the brake system operates
conventionally but anti±lock brake system is not
assisting brake performance so that the wheels could
lock up during a sudden brake or braking on slippery

GAUGES, METERS AND SERVICE REMINDER INDICATORS
68road surfaces.
(h) Open Door Warning Light
This light remains on until all the doors are completely
closed.
(i) Low Fuel Level Warning Light
This light comes on when the fuel level in the tank
becomes
nearly empty. F ill the tank as soon as possible.
On inclines or curves, due to the movement of fuel in the
tank, the low fuel level warning light may come on earlier
than usual.
(j) Key Reminder Buzzer
This buzzer reminds you to remove the key when you
open the driver's door with the ignition key in the ºACCº
or ºLOCKº position.
How to check all the service reminder
indicators
(except the low fuel level warning light):
1. Apply the parking brake.
2. Open the door.
The following service reminder indicator should come
on. It goes off when you close the door completely.
3. Turn the ignition key to ºACCº.
The following service reminder indicator should come
on. It goes off after 6 seconds.
4. Turn the ignition key to ºONº.
The following service reminder indicators should come
on.
