lexus LS400 2000 Engine / LEXUS 2000 LS400 (OM50533U) Owners Manual

GAUGES, METERS AND SERVICE REMINDER INDICATORS
74
W30W30
The driving distance after being refueled with more
than 10 L (2.6 gal., 2.2 lmp.gal.) is displayed.
When refueling, be sure to stop your vehicle and turn the
ignition switch off.
 Elapsed time
W31W31
The total time during the engine running is
displayed.
When the engine is started again after the ignition is off,
the driving time is added to the previous value. Up to 99
hours 59 minutes can be displayed. When the driving
time exceeds 99 hours 59 minutes, the display returns
to 0 and recounting starts.
To count from the beginning, push the ºRESETº button.
Average vehicle speed
W32W32
The average vehicle speed is calculated and
displayed based on the total driving distance and
the total driving time with the engine running.
The displayed value is updated every 10 seconds.
To calculate from the beginning, push the ºRESETº
button.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
75
(b) Warning messages
13L052

Reminder light
W40W40
When the engine oil pressure becomes too low, the
above message appears, the reminder light flashes
and the warning tone sounds.
If this message appears while you are driving, pull off the
road to a safe place and stop the engine immediately.
Call a Lexus dealer or qualified repair shop for
assistance.
The message may appear when the oil level is extremely
low. It is not designed to indicate low oil level, and the
oil level must be checked using the oil level dipstick.NOTICE
Do not drive the vehicle with the warning messagedisplayed ± even for one block. It may ruin theengine.
W41W41

GAUGES, METERS AND SERVICE REMINDER INDICATORS
76When your brake pads are worn enough to require
replacement, the above message appears, the
reminder
light flashes and the warning tone sounds.
If this message appears while you are driving, have the
brake pads checked and replaced by your Lexus dealer
as soon as possible.
W43W43
W42W42
W45±1
W44W44
W46W46
When any door or trunk is open with the ignition
switch turned on, the message which door or trunk
is open appears, and the reminder light comes on. If you continue driving with any door or trunk open, the
reminder light starts flashing and the warning tone
sounds to remind you to close the door or trunk.
W52W52
If the driver's door is opened with the ignition switch
turned off and the moon roof opened, the above
message appears and the reminder light flashes.
W48W48

GAUGES, METERS AND SERVICE REMINDER INDICATORS
77
In the following cases, the warning message
appears and the reminder light next to the warning
message and the ºVSC OFFº indicator light come
on. And the warning tone also sounds.
(a) After
the removal of the battery terminals (See ºInitial
adjustment of vehicle skid control systemº on page 318.)
(b) If the vehicle skid control system malfunctions
If the message appears, the brake assist system does
not work, however, there is no problem to continue your
driving. If the message appears for the cause of (b),
have your vehicle checked by Lexus dealer as soon as
possible.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
78
W49W49
In the following cases, the above message appears,
the reminder light comes on and the warning tone
sounds.
When the headlight switch is turned to the first or
second clickstop with one or more of tail light bulbs
burned out.
 When the brake pedal is held down with one or more
of stop light bulbs burned out.
Have defective bulbs replaced as soon as possible.
W50W50
When the engine oil level is too low, the above
message appears, the reminder light comes on and
the warning tone sounds.
Add oil as soon as possible. (For instructions, see
ºChecking the engine oil levelº on page 413.)
NOTICE
Continued engine operation with low engine oil will damage the engine.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
79
W51W51
When the fluid level in the tank becomes nearly
empty, the above message appears, the reminder
light comes on and the warning tone sounds.
Fill the tank as soon as possible.
W53W53
When there is a problem somewhere in the
automatic headlight leveling system, the above
message appears, the reminder light comes on and
the warning tone sounds.
If this message appears, have your vehicle checked by
your Lexus dealer.
INSTRUMENT PANEL LIGHTCONTROL
13L005
To adjust the brightness of the instrument panel
lights, turn the knob.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
80

SECTION 1 ± 4
81
INSTRUMENTS AND CONTROLS
Interior equipment
Vanity mirrors81
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior lights 83
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Personal lights 85
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition switch light 87
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clock 88
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . .
Outside temperature display 89
. . . . . . . . . . . . . . . . . . . . .
Cigarette lighter and ashtray 90
. . . . . . . . . . . . . . . . . . . . .
Power outlet 92
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear console box 94
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Glove box 94
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\

Garage door opener 96
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cup holder 99
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coin box 102
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\

Penlight 103
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
.
Floor mat 103
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Luggage stowage precautions 106
. . . . . . . . . . . . . . . . . .
VANITY MIRRORS

INTERIOR EQUIPMENT
82
14L001b
To use the vanity mirrors, swing the sun visor down
and open the cover.
The vanity light comes on when you open the cover.Sun visors
14L025

INTERIOR EQUIPMENT
83
1To block out glare from the front , swing the sun
visor down.
2To block out glare from the side, remove the
sun visor from the hook and swing it to the side.
3To block out glare coming obliquely from
behind you, slide the visor backwards.
At this position, the vanity light does not come on.
INTERIOR LIGHTS
Front
