DRIVING TIPS
332
BREAK±IN PERIOD
Drive gently and avoid high speeds.
You need not follow a break±in schedule with your new
Lexus. But following a few simple tips for the first 1600
km (1000 miles) can add to the future economy and long
life of your vehicle:
Do not drive over 88 km/h (55 mph).
 Avoid overrevving. Maintain engine speed between
2000 and 4000 rpm.
 Avoid full±throttle starts.
 Try to avoid hard stops during the first 300 km (200
miles).
 Do not drive for a long time at any single speed, either
fast or slow.
 Do not tow a trailer during the first 800 km (500 miles).
OPERATION IN FOREIGN
COUNTRIES
If you plan to drive your Lexus in another country ...
First, comply with the vehicle registration laws.
Second, confirm the availability of the correct fuel
(unleaded and minimum octane rating).
TIPS FOR DRIVING IN VARIOUS CONDITIONS
Always slow down in gusty crosswinds. This will
allow you much better control.
 Drive slowly onto curbs and, if possible, at a right
angle. Avoid driving onto high, sharp±edged objects
and other road hazards. Failure to do so can lead to
severe tire damage resulting in tire bursts.
 When parking on a hill, turn the front wheels until they
touch the curb so that the vehicle will not roll. Apply
the parking brake, and place the transmission in ºPº.
If necessary, block the wheels.
 Washing your vehicle or driving through deep water
may get the brakes wet. To see whether they are wet,
check that there is no traffic near you and then press
the pedal lightly. If you do not feel a normal braking
force, the brakes are probably wet. To dry them, drive
the vehicle cautiously while lightly pressing the brake
pedal with the parking brake applied. If they still do
not work safely, pull to the side of the road and call a
Lexus dealer for assistance.
CAUTION
 Before driving off, make sure the parking brake is
fully released and that the parking brake reminder
light is off.
 Do not leave your vehicle unattended while the
engine is running.

ENGINE
406± COOLING SYSTEM
Capacity
Coolant type
10.8 L (11.4 qt., 9.5 lmp.qt.)
ºToyota Long Life Coolantº or equivalent
With ethylene±glycol type coolant for a proper
corrosion protection of aluminum components
Do not use alcohol type antifreeze or plain water
alone.
± FUELFuel type
Octane rating
Only UNLEADED
91 (Research octane number 96) or higher
± IGNITION SYSTEMSpark plug ± Make DENSO NGK
± Gap
SK20R11
IFR6A11
1.1 mm (0.043 in.)
± ELECTRICAL SYSTEM
Battery Open voltage at 20 C (68F):
Charging rates
12.7V Fully charged
12.3V Half charged
11.9V Discharged
[Voltage that is checked 20 minutes after the key is
removed with all the lights turned off]
5A max.

ENGINE
407
FUEL
Fuel type
Your vehicle must use only unleaded gasoline.
To help prevent gas station mixups, your Lexus has a
smaller fuel tank opening. The special nozzle on pumps
with unleaded fuel will fit it, but the larger standard nozzle
on pumps with leaded gas will not.
At a minimum, the gasoline you use should meet the
specifications of ASTM D4814 in the U.S.A. and CGSB
3.5±M93 in Canada.
NOTICE
Do not use leaded gasoline. Use of leaded gasoline will cause the three±way catalyticconverter to lose its effectiveness and theemission control system to function improperly.Also, this can increase maintenance costs.
Octane rating
Select premium unleaded gasoline with an Octane
Rating of 91 (R esearch Octane Number 96) or higher
for optimum engine performance. However, if such
premium type cannot be obtained, you may
temporarily use unleaded gasoline with an Octane
Rating as low as 87 (Research Octane Number 91). Use of unleaded fuel with an octane number or rating
lower than stated above will cause persistent heavy
knocking. If severe, this will lead to engine damage.
If your engine knocks ...
If you detect heavy knocking even when using the
recommended
fuel, or if you hear steady knocking while
holding a steady speed on level roads, consult your
Lexus dealer.
However, now and then, you may notice light knocking
for a short time while accelerating or driving up hills. This
is no cause for concern.

ENGINE
408
Gasoline containing detergent additives
Lexus recommends the use of gasoline that
contains detergent additives to avoid build±up of
engine deposits.
However, all gasoline sold in the U.S. contains detergent
additives to keep clean and/or clean intake systems.
Quality gasoline
Automotive manufacturers in the U.S., Europe and
Japan have developed a specification for quality
fuel named W orld±Wide Fuel Charter (WWFC) that is
expected to be applied world wide. The WWFC
consists of three categories that depend on
required emission levels. In the U.S., category 3 has
been adopted. The WWFC improves air quality by
providing for better emissions in vehicle fleets, and
customer satisfaction through better vehicle
performance.
Cleaner burning gasoline
Cleaner burning gasoline, including reformulated
gasoline that contains oxygenates such as ethanol
or MTBE is available in many areas.
Lexus recommends the use of cleaner burning gasoline
and appropriately blended reformulated gasoline.
These types of gasoline provide excellent vehicle
performance, reduce vehicle emissions, and improve air quality.
Oxygenates in gasoline
Lexus
allows the use of oxygenate blended gasoline
where the oxygenate content is up to 10% ethanol or
15% MTBE. If you use gasohol in your Lexus, be
sure that it has an octane rating no lower than 87.
Lexus does not recommend the use of gasoline
containing methanol.
Sulfur in gasoline
If your vehicle is certified to California Emission
Regulation, the vehicle is designed to operate on
California cleaner burning gasoline (CBG) that
contains lower sulfur. If you cannot use California
CBG, your emission control system may suffer
damage and turn on the Malfunction Indicator Lamp.
If the malfunction is caused by the type of fuel used,
repairs may not be covered by your warranty.

ENGINE
409
Gasoline containing MMT
Some gasoline contain an octane enhancing
additive called MMT (Methylcyclopentadienyl
Manganese Tricarbonyl).
Lexus does not recommend the use of gasoline that
contains MMT. If fuel containing MMT is used, your
emission control system may be adversely affected.
The Malfunction Indicator Lamp on the instrument
cluster may come on. If this happens, contact your
Lexus dealer for service.
Gasoline quality
In a very few cases, you may experience driveability
problems caused by the particular gasoline that you are
using. If you continue to have unacceptable driveability,
try changing gasoline brands. If this does not rectify your
problem, then consult your Lexus dealer.
NOTICE
Do not use gasohol other than stated above. It will cause fuel system damage or vehicleperformance problems.
If drivability problems are encountered (poorhot starting, vaporizing, engine knock, etc.),discontinue its use.
Take care not to spill gasohol during refueling.Gasohol may cause paint damage.
Fuel tank capacity
83 L (21.9 gal., 18.3 lmp.gal.)
FACTS ABOUT ENGINE OIL CONSUMPTION
Functions of engine oil
Engine oil has the primary function of lubricating and
cooling the inside of the engine, and plays a major role
in maintaining the engine in proper working order.
Engine oil consumption
It is normal that an engine should consume some
engine oil during normal engine operation. The
causes of oil consumption in a normal engine are as
follows.
Oil is used to lubricate pistons, piston rings and
cylinders. A thin film of oil is left on the cylinder wall
when a piston moves downwards in the cylinder.
High negative pressure generated when the vehicle
is decelerating sucks some of this oil into the
combustion chamber. This oil as well as some part of
the oil film left on the cylinder wall is burned by the
high temperature combustion gases during the
