STARTING AND DRIVING
361
31L336
The indicator light shows the high mode is selected.
CAUTION
For vehicles equipped with the height control switch, be
sure to turn the ignition switch off before jacking. If this
is not done, the vehicle height adjustment function will
operate, which may cause an accident.
Malfunction warning
If the system is malfunctioning, “Height Hi” appears on the
multi−information display, the master warning light comes on
and a warning tone sounds. Although it is no problem to
continue driving, have the s ystem checked by your Lexus
dealer at the first opportunity.
(b) Damping mode selection
31L144b
 1 Sports position 2Normal position
The damping effect on the shock absorbers is adjusted.
Select either of the following modes using a selector
switch.
Sports mode: Suitable for sporty type driving, such as on
winding mountain roads and high speed driving.
Normal mode: Suitable for ordinary driving.
To turn on the sports mode, push the selector switch on the
“SPORT” side. The indicator comes on in the instrument
cluster and a stronger damping effect than that in normal mode
is automatically provided.
To change to the normal mode, push the switch to the “NORM”
side.

IN CASE OF AN EMERGENCY
405
B: If no steam is coming from your engine:
Leave the engine running and turn off the air conditioning.
Check the following.

Is the cooling fan operating?
 Is the coolant in the acceptable range?
 Is the engine drive belt O.K.?
CAUTION
When the engine is running, keep hands and clothing
away from the moving fan and engine drive belt.
 Do not attempt to remove the radiator cap when the
engine and radiator are hot. Serious injury could
result from scalding hot fluid and steam blown out
under pressure.
If the cooling fan is not operating or the coolant is not in the
acceptable range, turn off the engine and call your Lexus
dealer.
If both conditions are O.K., after the engine coolant
temperature has cooled to normal, continue driving your
vehicle.
If the engine coolant temperature does not cool down, or your
vehicle overheats again, have it checked as soon as possible
by your Lexus dealer.
IF YOU HAVE A FLAT TIRE
1. Reduce your speed gradually, keeping a straight line.
Move cautiously off the road to a safe place − well away
from the traffic. Avoid stopping on the center divider of
a highway. Park on a level spot with firm ground.
2. Stop the engine and turn on your emergency flashers.
3. Firmly set the parking brake and put the transmission
in “P”.
4. Have everyone get out of the vehicle on the side away
from traffic.
5. Read the following instructions thoroughly.
CAUTION
When jacking, be sure to observe the following to
reduce the possibility of personal injury:
 Follow jacking instructions.
 Do not put any part of your body under a vehicle
supported by a jack. Otherwise, personal injury
may occur.
 Do not start or run the engine while your vehicle
is supported by the jack.

IN CASE OF AN EMERGENCY
406
Stop the vehicle on a level firm ground, firmly
set the parking brake and put the transmission
in “P”. Block the wheel diagonally opposite to
the one being changed if necessary.
 Make sure to set the jack properly in the jack
point. Raising the vehicle with jack improperly
positioned will damage the vehicle or may allow
the vehicle to fall off the jack and cause
personal injury.
 Never get under the vehicle when the vehicle is
supported by the jack alone.
 Use the jack only for lifting your vehicle during
wheel changing.
 Do not raise the vehicle with someone in the
vehicle.
 When raising the vehicle, do not put an object
on or under the jack.
 Raise the vehicle only high enough to remove
and change the tire.
 For vehicles equipped with the height control
switch, be sure to turn the ignition switch off
before jacking. If this is not done, the vehicle
height adjustment function will operate, which
may cause an accident.NOTICE
Do not continue driving with a deflated tire.
Driving even a short distance can damage a tire
and wheel beyond repair.

INTRODUCTION
441
POSITIONING THE JACK
61L047
Front
61L048
Rear
When jacking up your vehicle with the jack, position the
jack correctly as shown in the illustrations.
CAUTION
When jacking, be sure to observe the following to re-
duce the possibility of personal injury:
 Follow jacking instructions.
 Do not put any part of your body under the vehicle
supported by the jack. Otherwise, personal injury
may occur.
 Do not start or run the engine while your vehicle is
supported by the jack.
 Stop the vehicle on a level firm ground, firmly set the
parking brake and put the transmission in “P”. Block
the wheels on the opposite side of the jack up point
if necessary.
 Make sure to set the jack properly in the jack point.
Raising the vehicle with jack improperly positioned
will damage the vehicle or may allow the vehicle to fall
off the jack and cause personal injury.
 Never get under the vehicle when the vehicle is
supported by the jack alone; use vehicle support
stands.
 Do not raise the vehicle with someone in the vehicle
 When raising the vehicle, do not place any objects on
top of or underneath the jack.
 For vehicles equipped with the height control switch,
be sure to turn the ignition switch off before jacking.
If this is not done, the vehicle height adjustment func-
tion will operate, which may cause an accident.
