LEXUS LS500 2021 Owners Manual

5019-1. For owners
9
For owners
1À l'aide d'un tournevis cruciforme,
tournez le boulon A dans n'importe
quel sens.
Mémorisez le sens dans lequel vous avez
tourné et le nombre de tours.
2 Tournez le boulon B du même
nombre de tours dans le même
sens qu'à l'étape 1 .
Si vous n'arrivez pas à régler le phare en
procédant de la sorte, confiez le véhicule à
votre concessionnaire Lexus pour qu'il
règle le faisceau des phares.
Réglage du faisceau des phares

5029-1. For owners

503
Index
.What to do if... (Troubleshooting)........................................................ 504
Alphabetical Index.................... 507

504What to do if... (Troubleshooting)
1-1.What to do if... (Troubleshooting)What to do if... (Troubleshooting)
If you lose your mechanical keys,
new genuine mechanical keys can
be made by your Lexus dealer.
( P.441)
 If you lose your electronic keys, the
risk of vehicle theft increases signifi-
cantly. Contact your Lexus dealer
immediately. ( P.441)
 Is the electronic key battery weak or
depleted? ( P.410)
 Is the engine switch in IGNITION
ON mode?
When locking the doors, turn the engine
switch off. ( P.177)
 Is the electronic key left inside the
vehicle?
When locking the doors, make sure that
you have the electronic key on your per-
son.
The function may not operate prop-
erly due to the condition of the radio
wave. ( P.115)
 Is the child-protector lock set?
The rear door cannot be opened from
inside the vehicle when the lock is set.
Open the rear door from outside and then
unlock the child-protector lock. ( P.105)
 The function to prevent the elec-
tronic key from being left inside the
trunk will operate and you can open
the trunk as usual. Take the key out
from the trunk. ( P.111)
 Did you press the engine switch
while firmly depressing the brake
pedal? ( P.174)
 Is the electronic key anywhere
detectable inside the vehicle?
( P.114)
 Is the steering wheel unlocked?
( P.174)
 Is the electronic key battery weak or
depleted?
If you have a problem, check the
following before contacting your
Lexus dealer.
The doors cannot be locked,
unlocked, opened or closed
You lose your keys
The electronic key does not
operate properly
The doors cannot be locked or
unlocked
The rear door cannot be opened
The trunk lid is closed with the
electronic key left inside
If you think something is wrong
The engine does not start

505What to do if... (Troubleshooting)
In this case, the engine can be started in a
temporary way. (P.443)
Is the battery discharged?
( P.444)
 It is locked automatically to prevent
theft of the vehicle. ( P.174)
 Is the window lock switch pressed?
The power window except for the one at
the driver’s seat cannot be operated if the
window lock switch is pressed. ( P.155)
 The auto power off function will be
operated if the vehicle is left in
ACCESSORY mode for a period of
time. ( P.177)
 The seat belt reminder light is flash-
ing
Are the driver and the front passenger
wearing the seat belts? ( P.430)
 The parking brake indicator is on
Is the parking brake released? ( P.186)
Depending on the situation, other
types of warning buzzer may also sound. (
P.427, 436)
 Did anyone inside the vehicle open
a door during setting the alarm?
The sensor detects it and the alarm sounds.
( P.66)
Do one of the following to deactivate
or stop the alarms:
 Except for Canada: Unlock the
doors.
 Except for Canada: Open the trunk.
 For Canada: Unlock the doors or
open the trunk using the entry func-
tion or wireless remote control.
 Turn the engine switch to ACCES-
SORY or IGNITION ON mode, or
start the engine. (The alarm will be
deactivated or stopped after a few
seconds.)
 Is the message displayed on the
multi-information display?
Check the message on the multi-informa-
tion display. ( P.436)
 When a warning light turns on or a
warning message is displayed, refer
to P.427, 436.
The steering wheel cannot be
turned after the engine is
stopped
The windows do not open or
close by operating the power
window switches
The engine switch is turned off
automatically
A warning buzzer sounds during
driving
An alarm is activated and the
horn sounds
A warning buzzer sounds when
leaving the vehicle
A warning light turns on or a
warning message is displayed

506What to do if... (Troubleshooting)
Slow down the vehicle, drive with
extra caution, and take your vehicle
to the nearest Lexus dealer or
authorized tire dealer as soon as
possible to have the tire replaced.
( P.438)
 Try the procedure for when the vehi-
cle becomes stuck in mud, dirt, or
snow. ( P.452)
When a problem has occurred
If you have a flat tire
The vehicle becomes stuck

507Alphabetical Index
Alphabetical Index
A
A/CAir conditioning filter ...............................409
Front automatic air conditioning system......................................................................... 323
Front seat concentr ated airflow mode
(S-FLOW).................................................330
Micro dust and pollen filter...................330
Rear automatic air conditioning system ......................................................................... 333
ABS (Anti-lock Brake System).............. 304 Warning light ............................................... 429
Active stabilizer suspension system .... 304
Adaptive Front-lighting System (AFS) .192
Adaptive Variable Suspension System304
AFS (Adaptive Front-lighting System) .192
AHB (Automatic High Beam) .................193
Air conditioning filter ................................. 409
Air conditioning system Air conditioning filter ...............................409
Front automatic air conditioning system......................................................................... 323
Front seat concentr ated airflow mode
(S-FLOW).................................................330
Micro dust and pollen filter...................330
Rear automatic air conditioning system ......................................................................... 333
Airbags Airbag operating conditions..................... 31
Airbag precautions for your child ........ 34
Correct driving posture .............................23
Curtain shield airbag operating condi- tions ...................................................................32
Curtain shield airbag precautions ....... 34
Front passenger occupant classification system ............................................................. 40
General airbag precautions ................... 34
Locations of airbags.................................... 29
Modification and disposal of airbags . 36
Side airbag operating conditions ..........32
Side airbag precautions ............................ 34 Side and curtain shie
ld airbags operating
conditions ...................................................... 32
Side and curtain shield airbags precau- tions .................................................................. 34
SRS airbags...................................................... 29
SRS warning light.......................................428
Alarm ................................................................... 66 Warning buzzer ......................................... 427
Anchor brackets ..................................... 46, 55
Antennas (smart acc ess system with
push-button start)........................................ 113
Anti-lock Brake System (ABS).............. 304 Warning light ............................................... 429
Approach warning...................................... 260
Armrest............................................................ 353
Assist grips ..................................................... 353
Audio system-linked display ...................... 87
Automatic headlight leveling system ..... 191
Automatic High Beam ................................193
Automatic light control system................. 191
Automatic transmission ..............................178 M mode ........................................................... 183
Paddle shift switches .......................182, 183
Snow mode.................................................... 182
Auxiliary boxes ................................. 348, 350
Average fuel economy................................. 84
Average vehicle speed ................................ 84
B
Back-up lights Replacing light bulbs ................................. 416
Battery Battery checking ......................................... 391
If the battery is discharged .................... 444
Preparing and checking before winter......................................................................... 309
Warning light ...............................................428
Blind Spot Monitor (BSM)....................... 264
Boost gauge...................................................... 86
Brake Brake hold ......................................................188
Fluid........................................................ 389, 461

508Alphabetical Index
Parking brake ............................................... 186
Warning light ............................................... 427
Brake assist .................................................... 304
Break-in tips.....................................................165
Brightness control Instrument panel light control ......... 77, 81
BSM (Blind Spot Monitor)....................... 264
Buzzer Hands off steering wheel warning (LTA)......................................................................... 249
C
Card key ............................................................ 98
Care Exterior ...........................................................368
Interior ............................................................... 371
Seat belts.......................................................... 371
Wheels and wheel ornaments............368
Cargo capacity............................................... 172
Cargo net ....................................................... 349
Center Display ...............................................316
Chains ............................................................... 310
Child restraint system Fixed with a LATCH system .................. 53
Fixed with a seat belt...................................50
Front passenger occupant classification system ............................................................. 40
Points to remember .................................... 45
Riding with children ..................................... 45
Types of child restraint system installation method ........................................................... 46
Using an anchor bracket .......................... 55
Child safety Airbag precautions...................................... 34
Battery precautions ....................... 391, 448
Child restraint system................................. 46
Heated steering wheel and seat heater precautions................................................ 336
How your child should wear the seat belt ............................................................................ 25
Moon roof precautions ............................ 157
Panoramic moon roof precautions ..... 161 Power window lock switch .................... 155
Power window precautions .................. 154
Rear door child-protectors ................... 105
Removed electronic key battery precau-
tions .................................................................. 411
Seat belt extender precautions.............. 25
Seat belt precautions .................................. 45
Trunk precautions....................................... 106
Child-protectors........................................... 105
Cleaning Exterior........................................................... 368
Interior ...............................................................371
Radar sensor ................................... 203, 209
Seat belts ..........................................................371
Wheels and wheel ornaments ........... 368
Clock ................................................75, 78, 354
Clock light ...................................................... 340
Coat hooks..................................................... 353
Coin holder .................................................... 346
Condenser ..................................................... 389
Console box .................................................. 347
Consumption screen .................................... 93
Cooling system.............................................388 Engine overheating...................................449
Cornering lights .............................................192
Cruise control Dynamic radar cruise control with full-speed range ........................... 251, 254
Cup holders ................................................... 346
Current fuel consumption .......................... 84
Curtain shield airbags .................................. 29
Customizable features ...............................476
D
Daytime running light system .................. 190
Defogger Outside rear view mirrors..................... 324
Rear window ................................................ 324
Windshield .................................................... 324
Differential Front differential oil............. ...................... 460
Rear differential oil. ..................................... 461

509Alphabetical Index
Digital Rearview Mirror..............................143
Dimension ...................................................... 456
Dinghy towing................................................. 173
DisplayCenter Display..............................................316
Dynamic radar cruise control with full-speed range ...................................... 254
Head-up display ........................................... 89
Intuitive parking assist...............................272
LTA (Lane Tracing Assist).................... 244
Multi-information display .......................... 82
Parking Support Brake function (rear pedestrians) .............................................. 296
RCD (Rear Camera Detection) ..........281
RCTA .............................................................. 279
Warning message..................................... 436
Distance until next engine oil change76, 81
Do-it-yourself maintenance .................... 375
Door courtesy lights ................................... 340
Door lock Doors.................................................................102
Smart access system with push-button start ................................................................... 113
Wireless remote control......................... 100
Doors Automatic door lock ing and unlocking
system ........................................................... 106
Door closer ................................................... 105
Door glasses ..................................................153
Door lock.........................................................102
Open door warning bu zzer ...... 103, 105
Outside rear view mirrors ....................... 151
Rear door child-protectors ................... 105
Drive distance .................................................. 84
Drive info 1/Drive info 2 .............................. 84
Driver’s seat position memory Driving position memory.........................133
Memory recall function ............................135
Power easy access system .....................133
Drive-Start Control (DSC) .......................170
Driving Break-in tips .................................................. 165 Correct driving posture ............................ 23
Driving mode select switch ..................299
Procedures .................................................... 164
Winter drive tips ........................................ 309
Driving information display ........................ 84
Driving position memory............................133 Memory recall function............................ 135
Power easy access system .................... 133
Driving range ................................................... 84
Driving support system information display ............................................................................. 87
DRS (Dynamic Rear Steering) .............. 304
DSC (Drive-Start Control) .......................170
Dynamic radar cruise control with full-speed range .............................. 251, 254Warning message .....................................263
Dynamic Rear Steering (DRS) .............. 304
E
ECB (Electronically Controlled Brake Sys-
tem) ................................................................ 304
Eco Driving Indicator............................85, 93
Eco Driving Indicator Light ........................ 85
EDR (Event data recorder) ........................... 8
Elapsed time ..................................................... 84
Electric Power Steering (EPS) .............. 304 Warning light .............................................. 430
Electronic key .................................................. 98 Battery-saving function.............................. 114
If the electronic key does not operate properly ....................................................... 442
Replacing the battery ................................ 410
Electronic roof sunshade Jam protection function ........................... 160
Operation ....................................................... 158
Electronically Controlled Brake System (ECB) ............................................................ 304
Electronically modulated air suspension ........................................................................... 301
Emergency flashers ..................................... 418
Emergency, in case of If a warning buzzer sounds................... 427

510Alphabetical Index
If a warning light turns on ...................... 427
If a warning message is displayed..... 436
If the battery is discharged .................... 444
If the electronic key does not operate properly....................................................... 442
If the engine will not start ....................... 439
If the fuel filler door cannot be opened ........................................................................... 441
If the vehicle is trapped in rising water ...........................................................................419
If you have a flat tire ..................................438
If you lose your keys................................... 441
If you think something is wrong ......... 425
If your vehicle becomes stuck............. 452
If your vehicle has to be stopped in an
emergency ................................................. 418
If your vehicle needs to be towed ....... 421
If your vehicle overheats ........................ 449
Engine ACCESSORY mode ............................... 177
Compartment .............................................383
Engine compartment cover .................384
Engine cover................................................384
Engine switch................................................. 174
Fuel pump shut off system .................... 426
Hood................................................................. 381
How to start the engine............................ 174
Identification number ............................... 457
If the engine will not start ....................... 439
If your vehicle has to be stopped in an
emergency ................................................. 418
Ignition switch (engine switch) ............. 174
Overheating................................................. 449
Tachometer ............................................ 75, 78
Engine compartment cover .................... 384
Engine coolant Capacity .........................................................459
Checking ...................................................... 388
Preparing and checking before winter.........................................................................309
Engine coolant temperature gauge 75, 78
Engine cover ................................................. 384 Engine immobilizer system ........................ 64
Engine oil
Capacity ........................................................ 458
Checking ...................................................... 386
Preparing and checking before winter......................................................................... 309
Warning light ...............................................428
Engine oil maintenance data .................. 387
Engine switch .................................................. 174 Auto power off function............................ 177
Changing the engine switch modes .. 177
If your vehicle has to be stopped in an emergency .................................................. 418
EPS (Electric Power Steering) .............. 304 Warning light .............................................. 430
Event data recorder (E DR) ........................... 8
F
FCTA (Front Cross Traffic Alert) ......... 235
First-aid kit storage belt ............................350
Flat tire
Tire pressure warning system ............ 395
Floor mats ...........................................................22
Fluid Automatic transmission ......................... 460
Brake ................................................................. 461
Washer .......................................................... 390
Footwell light ................................................. 340
Front automatic air conditioning system .......................................................................... 323
Front Cross Traffic Alert (FCTA) ......... 235
Front passenger occupant classification system .............................................................. 40
Front seats Adjustment ....................................................... 121
Cleaning ...........................................................371
Correct driving posture ............................ 23
Driving position memory ........................ 133
Head restraints............................................. 138
Memory recall function............................ 135
Power easy access system .................... 133
Refresh system ..............................................126
