LEXUS LS600H 2015 Owner's Guide

29Pictorial index
LS600hL_U(OM50E41U)Auxiliary boxes
*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 371
Ashtrays
*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 379
Power window switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 189
Retractable table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 393
Seat belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 36
Cup holders. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P . 368
Rear seat console
Rear seat relaxation system/pelvic suppor t seat controller . . . . . . P. 166, 167
Rear seat entertainment system controller
*2
Cigarette lighter*1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 380
Po w e r o u t l e t
*1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 382
A/V input port (VTR and HDMI port)
*2
Auxiliary box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 371
Auxiliary box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 371
Rear seat entertainment system player
*2
Disc slot*2
SD card slot*2
Headphone jacks*2
*1: If equipped
*2: Refer to “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
8
9
10
11
12
13
14
15

30Pictorial index
LS600hL_U(OM50E41U)
■Rear interior switches
Rear air conditioning switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 351
Rear sunshade switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 395
Rear door sunshade switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 398
Rear audio switches
*3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 357
Rear climate control seat switches. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 388
Power rear seat switches
*2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 162
Front passenger's seat control switches
*1, 2. . . . . . . . . . . . . . . . . . . P. 158, 165
Pelvic support seat switches
*2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 166
*1: If equipped
*2: Location of the switches varies according to the vehicle grade level.
*3: Refer to “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
1
2
3
4
5

31
For safety and security1
LS600hL_U(OM50E41U)1-1. For safe use
Before driving................................. 32
For safety drive............................... 34
Seat belts .......................................... 36
SRS airbags ..................................... 42
Front passenger occupant classification system.................. 55
Safety information for children...................................... 61
Child restraint systems ............... 62
Installing child restraints ............. 66
Exhaust gas precautions ............ 75
1-2. Hybrid system Hybrid system features................ 76
Hybrid system precautions ........ 81
1-3. Theft deterrent system Immobilizer system ......................88
Alarm ................................................. 90

32
LS600hL_U(OM50E41U)
1-1. For safe use
Use only floor mats designed specifically for vehicles of the same model
and model year as your vehicle. Fi x them securely in place onto the car-
pet.
Insert the retaining hooks (clips)
into the floor mat eyelets.
Turn the upper knob of each
retaining hook (clip) to secure the
floor mats in place.
*: Always align the marks.
The shape of the retaining hooks (clips) may differ from that shown in the illustra-
tion.
Before driving
Floor mat
1
*
2

331-1. For safe use
1
For safety and security
LS600hL_U(OM50E41U)
CAUTION
Observe the following precautions.
Failure to do so may cause the driver’s floor mat to slip, possibly interfering with the
pedals while driving. An unexpectedly high speed may result or it may become diffi-
cult to stop the vehicle. This could lead to an accident, resulting in death or serious
injury.
■When installing the driver’s floor mat
●Do not use floor mats designed for other models or different model year vehicles,
even if they are Lexus Genuine floor mats.
●Only use floor mats designed for the driver’s seat.
●Always install the floor mat securely using the retaining hooks (clips) provided.
●Do not use two or more floor mats on top of each other.
●Do not place the floor mat bo ttom-side up or upside-down.
■Before driving
●Check that the floor mat is securely fixed in
the correct place with all the provided
retaining hooks (clips). Be especially care-
ful to perform this check after cleaning the
floor.
●With the hybrid system stopped and the
shift lever in P, fully depress each pedal to
the floor to make sure it does not interfere
with the floor mat.

341-1. For safe use
LS600hL_U(OM50E41U)
Adjust the angle of the seatback
so that you are sitting straight up
and so that you do not have to
lean forward to steer. ( P. 1 5 6 )
Adjust the seat so that you can
depress the pedals fully and so
that your arms bend slightly at the
elbow when gripping the steering
wheel. ( P. 1 5 6 )
Lock the head restraint in place
with the center of the head
restraint closest to the top of your
ears. ( P. 1 7 9 )
Wear the seat belt correctly.
( P. 36)
Make sure that all occupants are we aring their seat belts before driving
the vehicle. ( P. 36)
Use a child restraint system appropriate for the child until the child
becomes large enough to properly wear the vehicle’s seat belt. ( P. 6 2 )
For safety drive
For safe driving, adjust the seat and mirror to an appropriate position
before driving.
Correct driving posture
1
2
3
4
Correct use of the seat belts

351-1. For safe use
1
For safety and security
LS600hL_U(OM50E41U)
Make sure that you can see backward clearly by adjusting the inside and
outside rear view mirrors properly. ( P. 183, 185)
Adjusting the mirrors
CAUTION
Observe the following precautions.
Failure to do so may result in death or serious injury.
●Do not adjust the position of the driver’s seat while driving.
Doing so could cause the driver to lose control of the vehicle.
●Do not place a cushion between the driver or passenger and the seatback.
A cushion may prevent correct posture from being achieved, and reduce the
effectiveness of the seat belt and head restraint.
●Do not place anything under the front seats.
Objects placed under the front seats may become jammed in the seat tracks and
stop the seat from locking in place. This may lead to an accident and the adjust-
ment mechanism may also be damaged.
●When driving over long distances, take regular breaks before you start to feel
tired.
Also, if you feel tired or sleepy while driving, do not force yourself to continue
driving and take a break immediately.

361-1. For safe use
LS600hL_U(OM50E41U)●
Extend the shoulder belt so that it
comes fully over the shoulder, but
does not come into contact with
the neck or slide off the shoulder.
●Position the lap belt as low as
possible over the hips.
●Adjust the position of the seat-
back. Sit up straight and well back
in the seat.
●Do not twist the seat belt.
To fasten the seat belt, push the
plate into the buck
le until a click
sound is heard.
To release the seat belt, press the
release button.
If the seat belt ca nnot be pulled out of
the retractor, firmly pull the belt and
release it.
Seat belts
Make sure that all occupants are wear ing their seat belts before driving
the vehicle.
Correct use of the seat belts
Fastening and releasing the seat belt
Release button
1
2

371-1. For safe use
1
For safety and security
LS600hL_U(OM50E41U)
Moves the seat belt shoulder
anchor up
Moves the seat belt shoulder
anchor down
For children or smaller-than-aver-
age people, slide the seat belt com-
fort guide forward so that the
shoulder belt does not sit close to
the person’s neck.
The pretensioners help the seat
belts to quickly restrain the occu-
pants by retracting the seat belts
when the vehicle is subjected to
certain types of severe frontal colli-
sion.
The front seat belt pretensioners also
activate when the vehicle is subjected
to certain types of severe side colli-
sion.
The pretensioners do not activate in
the event of a minor frontal impact, a
minor side impact, a rear impact or a
vehicle rollover.
Adjusting the seat belt shoulder anchor height (front seats)
1
2
Seat belt comfort guide (outer rear seats)
Seat belt pretensioners (front and outer rear seats)

381-1. For safe use
LS600hL_U(OM50E41U)
If the system determines that a collision is unavoidable, the front seat belts
will retract before the collision. ( P. 2 9 6 )
■Child seat belt usage
The seat belts of your vehicle were princi pally designed for persons of adult size.
●Use a child restraint system appropriate for the child, until the child becomes large
enough to properly wear the vehicle’s seat belt. ( P. 6 2 )
●When the child becomes large enough to properly wear the vehicle’s seat belt, fol-
low the instructions regarding seat belt usage. ( P. 3 6 )
■Automatic adjustment of the seat belt shoulder anchor height (front seats)
A desired seat belt shoulder anchor height can be entered to memory and recalled
automatically by the driving position memory and seat position memory. (P. 1 7 2 )
■Emergency locking retractor (ELR)
The retractor will lock the belt during a sudden stop or on impact. It may also lock if
you lean forward too quickly. A slow, easy motion will allow the belt to extend so that
you can move around fully.
■Automatic locking retractor (ALR)
When a passenger’s shoulder belt is comp letely extended and then retracted even
slightly, the belt is locked in that position and cannot be extended. This feature is used
to hold the child restraint system (CRS) firmly. To free the belt again, fully retract the
belt and then pull the belt out once more. ( P. 66)
■Replacing the belt after the pretensioner has been activated
If the vehicle is involved in multiple collisions, the pretensioner will activate for the
first collision, but will not activate for the second or subsequent collisions.
■Seat belt extender
Pre-collision seat belts (front sea ts of vehicles with pre-collision
system)
If your seat belts cann ot be fastened securely
because they are not long enough, a person-
alized seat belt extender is available from
your Lexus dealer free of charge.
