Page 471 of 493

LEXUS LX470 2006  Owners Manual ELECTRICAL COMPONENTS
449
45 A/C15Air conditioning systemNo.FuseAMPERECIRCUIT
46 STOP15Stop lights
47 OBD�27.5On−board diagnosis system
48 IDLE UP7.5Idle− up system
49 LH SEAT30Power seat system
5

Page 472 of 493

LEXUS LX470 2006  Owners Manual ELECTRICAL COMPONENTS
450
No.FuseAMPERECIRCUIT
63 SEATHTR15Seat heater
64 GAUGE 210Back− up lights
65 MET7.5Gauges and meters
66 IGN7.5Multiport fuel injection
system/Sequential multiport fuel
injec

Page 474 of 493

LEXUS LX470 2006  Owners Manual ELECTRICAL COMPONENTS
452
NOTICE
Make sure the engine and all accessories are turned
off before performing maintenance.
 When  checking the battery, remove the ground cable
first and reinstall it la

Page 479 of 493

LEXUS LX470 2006  Owners Manual ELECTRICAL COMPONENTS
457
64g104
Good Blown
If the headlights or other electrical components do not
work and the blade type fuses are O.K., check the
cartridge  type fuses.  If any of the cartridge

Page 480 of 493

LEXUS LX470 2006  Owners Manual ELECTRICAL COMPONENTS
458
ADDING WASHER FLUID
64X603a
If the washer tank becomes nearly empty, add washer
fluid.
You may use plain water as washer fluid.  However, in cold
areas where temperatures ran

Page 481 of 493

LEXUS LX470 2006  Owners Manual ELECTRICAL COMPONENTS
459
The inside of the lens of exterior lights such as headlights may
temporarily
fog up when the lens becomes wet in the rain or in
a car wash. This is not a pr oblem because th

Page 482 of 493

LEXUS LX470 2006  Owners Manual ELECTRICAL COMPONENTS
460
64X600a
Light BulbsBulb No. W Type
1 Stop/tail lights −6.2/0.5 G
2 Tail lights −0.4 G
3 License plate lights 168 5 D
4 Back− up lights 921 18 D
5 Rear turn signal light

Page 483 of 493

LEXUS LX470 2006  Owners Manual ELECTRICAL COMPONENTS
461
A: HB3 halogen bulbs
B: H1 halogen bulbs
C: H3 halogen bulbs
D: Wedge base bulbs
E: Double end bulbs
F: Single end bulbs
G: LEDs (Light−
emitting Diodes)

Page 488 of 493

LEXUS LX470 2006  Owners Manual BODY
4661. Rinse off loose dirt with a hose.  Remove any mud or road
salt from the underside of the vehicle or the wheel wells.
2. Wash with a mild car
−wash soap, mixed according to the
manufacture

Page 489 of 493

LEXUS LX470 2006  Owners Manual BODY
467
Waxing your Lexus
Polishing and waxing is recommended to maintain the
original beauty of your Lexus’ finish.
Apply wax once a month or if  the vehicle surface does not repel
water well.
1.
