LEXUS LX470 2006 Owners Manual

AUDIO
219
1Stopping and ejecting a CD
(See page 239 for details.)
2CD slot
(See page 238 for details.)
3Display of functions in TAPE mode
RPT: Automatic repeat
(See page 236 for details.)
:DOLBY NR
(See page 235 for details.)
:
Side change
(See page 236 for details.)
 :Rewinding or Fast forwarding
 :(See page 236 for details.)
3
Display of functions in CD mode
RAND: Random access
(See page 242 for details.)
RPT: Automatic repeat
(See page 241 for details.)
:CD selection
(See page 240 for details.)
 :Reversing or Fast forwarding
 :(See page 241 for details.)
4
Scan button
(See page 226, 231 or 240 for details.)
5Load button
(See page 238 for details.)
6TEXT button
(See page 227, 232 or 242 for details.)
7AUDIO·TUNE knob
(See page 221 or 225 for details.)
8 Traffic announcement button
(See page 227 for details.)
9 Program type button
(See page 226 for details.)
10 Mode selectors
(See page 220 for details.)
11 AM·FM mode: Seek tuning
(See page 224 or 225 for details.)
SAT mode: Manual tuning
(See page 230 for details.)
TAPE or CD Direct access to a desired program
mode: (See page 237 or 241 for details.)
12Cassette tape slot
(See page 235 for details.)
13Stopping and ejecting a cassette tape
(See page 235 for details.)
14Turning the system on and adjusting the volume
(See page 220 for details.)
15Function buttons
1 6: Station selector buttons
(See page 225 for details.)

AUDIO
220
Using your audio system: some basics
This section describes some of the basic features of the Lexus
audio system. Some informat ion may not pertain to your
system.
Your audio system works when the ignition key is in the “ACC”
or “ON” position.
NOTICE
To prevent the battery from being discharged, do not
leave the audio system on longer than necessary when
the engine is not running.
(a) Turning the system on and off
21X506b
Push this knob to turn the audio system on and off. Turn
this knob to adjust the volume.
The system turns on in the last mode used.
21X507a
Push “AM·SAT”, “FM”, “TAPE” or “DISC” to turn on that
mode. The selected mode turns on directly.
Push these buttons if you want to switch from one mode to
another.
If the tape or CD is not set, the cassette player or CD player
does not turn on.
You can turn off the cassette player by ejecting the cassette
tape. If the audio system was previously off, then the entire
audio system will be turned off when you eject the cassette
tape. If another function was previously playing, it will come on
again.

AUDIO
221
21X553
In the “TAPE” or “CD” mode, the applicable functions are
shown in the lowest part of the display. Push the switch
just below to turn on each function.
(b) Tone and balance
How good an audio program sounds to you is largely
determined by the mix of the treble, mid −range, and bass
levels. In fact, different kinds of music and vocal programs
usually sound better with different mixes of treble, mid− range,
and bass.
A good balance of the left and right stereo channels and of the
front and rear sound levels is also important.
Keep in mind that if you are listening to a stereo recording or
broadcast, changing the right/left balance will increase the
volume of one group of sounds while decreasing the volume
of another.
22X612
Each time you push the “AUDIOTUNE” knob, the display
changes as in the following. To adjust the tone and
balance or turn on or off the automatic sound levelizer,
turn the knob.
BAS: Adjusts low− pitched tones.
MID: Adjusts mid− pitched tones.
TRE: Adjusts high− pitched tones.
FAD: Adjusts the sound balance between the front and rear
speakers.
BAL: Adjusts the sound balance between the right and left
speakers.
ASL: Turns on or off the automatic sound levelizer.
Automatic Sound Levelizer (ASL): When the audio sound
becomes difficult to be heard due to road noise, wind noise,
etc. during driving, the system adjusts to the optimum volume
and tone quality according to the noise level. While the
Automatic Sound Levelizer (ASL) is on, “ASL” appears on the
display.

AUDIO
222(c) Your power antenna
The antenna automatically extends when the radio is on, and
retracts
when the radio mode is off. However, even if you turn
off the radio when the radio on the rear seat audio system is on,
the antenna does not retract.
21X509
To adjust the height of the antenna manually, push the
switch at either side, this may be performed during
antenna extension. The maximum extension length is 850
mm (33.5 in.).
Every time you turn the radio on, the antenna will extend to its
previous position.
Clean the antenna mast periodically with a clean dry cloth.
CAUTION
Before extending the antenna, confirm that no one is
close enough to get injured.
NOTICE
 Retract the antenna when entering or passing
through low structures, such as a garage or an
automatic car wash. Failure to do so may damage the
antenna.
 The antenna mast has to be extended higher than 100
mm (3.94 in.) length when the audio is on. Extend the
antenna mast when the radio signal is weak.
 Putting a film (especially a conductive or metallic
film) on the righthand rear quarter window may
affect the reception of radio or mobile telephone. For
the installation of the film, consult with your Lexus
dealer.

AUDIO
223
(d) Your cassette player
When
you insert a cassette, the exposed tape should be to the
right.
NOTICE
Never try to disassemble or oil any part of the cassette
player. Do not insert anything except a cassette tape
into the slot.
(e) Your CD player with changer
22x647
Your changer can store up to 6 CDs and play selected CDs or
continuously play all the CDs set in the player.
When you set CDs into the player, make sure their labels face
up. If not, the player will display “ERROR1” and the CD
number.
NOTICE
 Never try to disassemble or oil any part of the CD
player. Do not insert anything other than CDs into the
slot.
 Do not insert a CD upon another one, or it will damage
the changer. Insert only one CD into the slot at a time.
The player is intended for use with 12 cm (4.7 in.) CDs only.

AUDIO
224
Radio operation
(a) Listening to the radio
21X511a
Push these buttons to choose either an AM or FM station.
“AM”, “FM1” or “FM2” appears on the display.
If your vehicle is equipped with satellite radio broadcast
system, when you push the “AM·SAT” button, “AM”,
“SAT1”, “SAT2” or “SAT3” station appears on the display. For
details about satellite radio broadcast, see “Radio operation
(XM satellite radio broadcast)” on page 228
21X554
Turn this knob to the right to step up the station band or
to the left to step down.
Your radio automatically changes to stereo reception when a
stereo broadcast is received. “ST” appears on the display. If
the signal becomes weak, the radio reduces the amount of
channel separation to prevent the weak signal from creating
noise. If the signal becomes extremely weak, the radio
switches from stereo to mono reception. In this case, “ST”
disappears from the display.

AUDIO
225
(b) Presetting a station
21X555
1. Tune in the desired station.
2. Push
one of the station selector buttons ( 16 ) and hold
it until a beep is heard. This sets the station to the button
and the button number ( 16 ) appears on the display.
Each button can store one AM station and two FM stations. To
change the preset station to a different one, follow the same
procedure.
The preset station memory is cancelled when the power
source is interrupted by battery disconnection or a blown fuse. (c) Selecting a station
Tune in the desired station using one of the following methods.
21X556b
Preset
tuning: Push the button ( 1− 6 ) for the station you want.
The button number ( 1− 6 ) and station frequency appear on the
display.
Manual tuning: Turn the “AUDIO− TUNE” knob. The radio will
step up or down to another frequency.
Seek tuning: Push the “SEEK” button. The radio will begin
seeking up or down for a station of the nearest frequency and
will stop on reception. Each time you push the button, the
stations will be searched automatically one after another.

AUDIO
226
21X572
To scan all the frequencies: Push the “SCAN” button briefly.
“SCAN” appears on the display. The radio will find the next
station up the band, stay there for a few seconds, and then
scan again. To select a station, push the “SCAN” button a
second time.
To scan the preset stations: Push the “SCAN” button until
you hear a beep. “SCAN” appears on the display. The radio
will tune in the next preset station up the band, stay there for
a few seconds, and then move to the next preset station. To
select a station, push the “SCAN” button a second time. (d) RDS (Radio Data System)
TYPE (Program type):
22X613
When you push the “TYPE” button, the current program type
receiving from RDS station appears on the display.
If the system receives no RDS stations, “NO PTY” appears on
the display.

AUDIO
227
Each time you push the
“
” or “” button, the program type
changes as in the following:
 ROCK
 EASY LIS (Easy listening)
 CLS/JAZZ (Classical music and jazz)
 R&B (Rhythm and Blues)
 INFORM (Information)
 RELIGION
 MISC
 ALERT (Emergency message)
Push the “SEEK TRACK” or “SCAN” button with the program
type shown on the display and the radio seeks or scans the
station in the relevant program type.
TRAF (Traffic) function: A station that regularly
broadcasts traffic information is automatically located.
When you push the “TRAF” button, “TRAF SEEK” appears on
the display and the radio will start seeking any traffic program
station.
If no traf fic program station is found, “NO TRAF INFO” appears
on the display for a few seconds and the display returns to the
previous mode. Radio text message:
21x557
If the radio receives a radio text from RDS station, “MSG”
appears on the display. Push the “TEXT” button, and a text
message is displayed.
If the entire the message is not displayed, “
” will appear on
the display. To display the rest of the message, push and hold
the “TEXT” button until you hear a beep.
After the entire message has been displayed, the message will
disappear.
In case a text message is not accepted on the display, you can
push the “TEXT” button and hold it to display the rest of the
message.
When the system can show the station name, “RDS” appears
on the display. Each time you push the “TEXT” button,
indication on the display changes from the band to the station
name, a radio text in this order. After 6 seconds passes,
indication returns to the band.

AUDIO
228
Radio operation (XM satellite radio broadcast)
To listen to a satellite radio broadcast in your vehicle, an
additional genuine Lexus satellite receiver and antenna (or
equivalents) must be purchased and installed. A subscription
to the XM satellite radio service is also necessary.
(a) How to subscribe to an XM satellite radio
An XM satellite radio is a tuner designed exclusively to receive
broadcasts provided under a separate subscription.
Availability is limited to the 48 contiguous states.
How to subscribe:
You must enter into a separate service agreement with the XM
radio in order to receive satellite broadcast programming in the
vehicle. Additional activation and service subscription fees
apply that are not included in the purchase price of the vehicle
and optional digital satellite tuner. For complete information on
subscription rates and terms, or to subscribe to the XM radio,
visit XM on the web at www.xmradio.com
or call an XM’s
Listener Care at (800) 852 −9696. The XM radio is solely
responsible for the quality, availability and content of the
satellite radio services provided, which are subject to the terms
and conditions of the XM radio customer service agreement.
Customers should have their radio ID ready; the radio ID can
be found by tuning to “channel 000” on the radio. For details,
see “Displaying the radio ID” below.
All fees and programming are the responsibility of the XM
satellite radio and are subject to change. Satellite tuner technology notice:
Lexus satellite radio tuners are awarded Type Approval
Certificates from XM Satellite Radio Inc. as proof of
compatibility
with the services offered by the XM satellite radio.
(b) Displaying the radio ID
Each XM tuner is identified with a unique radio ID. You will
need the radio ID when activating XM service or when
reporting a problem.
If you select the “CH 000” using the “AUDIO −TUNE” knob, the
ID code of 8 alphanumeric characters appears. If you select
another channel, display of the ID code is canceled. The
channel (000) alternates the display between the radio ID and
the specific radio ID code.
