361-2. Opening, closing and locking the doors
LX570_OM_OM60L21U_(U) Unlocking and locking the doors
Side door handle
Grip the driver’s door handle to
unlock the door. Grip the passen-
ger’s door handle to unlock all the
doors.
* Make sure to touch the sensor on
the back of the handle.
The door cannot be unlocked for 3
seconds after the door is locked.
* : The door unlock settings can be
changed. ( 
P. 4 0 )
Press the lock button to lock the
doors. Pressing and holding the button
closes the windows and moon roof.
(This setting must be customized at
your Lexus dealer.)
Back door
Press the unlock button to unlock
the doors. The door cannot be unlocked for 3
seconds after the door is locked.
Lock the back door again when
you leave the vehicle. The back
door will not lock automatically
after it has been opened and then
closed.

661-2. Opening, closing and locking the doors
LX570_OM_OM60L21U_(U) NOTICE■
To prevent back door closer malfunction
Do not apply excessive force to the back d oor while the back door closer is operat-
ing. ■
To prevent damage to the power back door ●
Make sure that there is no ice between the back door and frame that would pre-
vent movement of the back door. Operating the power back door when exces-
sive load is present on the back door may cause a malfunction. ●
Do not apply excessive force to the back door while the power back door is oper-
ating. ●
Take care not to damage the sensors (installed on the right and left edges of the
power back door) with a knife or other sharp object. If the sensor is disconnected,
the power back door will not operate in automatic operation.

971-3. Adjustable components (s eats, mirrors, steering wheel)
1
Before driving
LX570_OM_OM60L21U_(U) CAUTION■
Pregnant women
■
People suffering illness
Obtain medical advice and wear the seat belt in the proper way. ■
When children are in the vehicle
Do not allow children to play with the seat belt. If the seat belt becomes twisted
around a child’s neck, it may lead to choking or other serious injuries that could
result in death.
If this occurs and the buckle cannot be un fastened, scissors shou ld be used to cut
the belt. ■
Seat belt pretensioners ●
Do not place anything, such as a cushion, on the front passenger’s seat. Doing so
will disperse the passenger’s weight, wh ich prevents the sensor from detecting
the passenger’s weight properly. As a resu lt, the seat belt pretensioner for the
front passenger’s seat may not activ ate in the event of a a collision.●
If the pretensioner has activated, the SRS warning light will come on. In that case,
the seat belt cannot be used again and must be replaced at your Lexus dealer. Obtain medical advice and wear the seat belt
in the proper way. (  P. 9 1 )
Women who are pregnant should position
the lap belt as low as possible over the hips in
the same manner as other occupants. Extend
the shoulder belt completely over the shoul-
der and position the belt across the chest.
Avoid belt contact over the rounding of the
abdominal area.
If the seat belt is not worn properly, not only a
pregnant woman, but also the fetus could suf-
fer death or serious injury as a result of sud-
den braking, sudden swerving or a collision.

1031-3. Adjustable components (s eats, mirrors, steering wheel)
1
Before driving
LX570_OM_OM60L21U_(U) ■
To prevent sensor error
CAUTION■
While driving
Do not adjust the position of the mirror.
Doing so may lead to mishandling of the ve hicle and an accident, resulting in death
or serious injury. To ensure that the sensors operate properly,
do not touch or cover them.

1261-7. Safety information
LX570_OM_OM60L21U_(U) Airbag system components
Front passenger occupant
classification system
(ECU & sensors)
Knee airbags
Curtain shield airbags
Front passenger airbag
AIR BAG ON and AIR BAG
OFF indicator lights
Side impact sensors (front
door)
Side airbags (front seats)
SRS warning light and
“RSCA OFF” indicator light
Side impact sensors (rear) Side airbags
(second outboard seats)
Driver airbag
Driver’s seat position sensor
Driver’s seat belt buckle
switch
Safing sensor (rear)
Roll sensing of curtain shield
airbags off switch
Airbag sensor assembly
Front impact sensors
Front passenger’s seat belt
buckle switch
Seat belt pretensioners and
force limiters

1271-7. Safety information
1
Before driving
LX570_OM_OM60L21U_(U) Your vehicle is equipped with AD VANCED AIRBAGS designed based
on the US motor vehicle safety st andards (FMVSS208). The airbag sen-
sor assembly (ECU) controls airbag deployment based on information
obtained from the sensors etc. show n in the system components diagram
above. This information includes cras h severity and occupant informa-
tion. As the airbags deploy, a chemica l reaction in the inflators quickly fills
the airbags with nontoxic gas to help restrain the motion of the occu-
pants. ■
If the SRS airbags deploy (inflate) ●
Bruising and slight abrasions may result from contact with a deploying (inflating)
SRS airbag. ●
A loud noise and white powder will be emitted. ●
Parts of the airbag module (steering wheel hub, airbag cover and inflator) as
well as the front seats, second seats, and parts of the front, center and rear pil-
lars, and roof side rail, may be hot for several minutes. The airbag itself may also
be hot. ●
The windshield may crack. ●
For Safety Connect subscriber s, if the SRS airbags deploy or in the event of a
severe rear-end collision, the system is designed to send an emergency call to
the response center, notifying them of the vehicle’s location (without needing to
push the “SOS” button) and an agent will attempt to speak with the occupants
to ascertain the level of emergency and assistance required. If the occupants
are unable to communicate, the agent automatically treats the call as an emer-
gency and helps to dispatch the necessary emergency services. (  P. 7 2 2 )

2092-3. Operating the lights and wipers
2
When driving
LX570_OM_OM60L21U_(U) ■
Daytime running light system ●
To make your vehicle more visible to other drivers, the parking lights turn on
automatically (at an increased intensity) whenever the engine is started and the
parking brake is released. Daytime running lights are not designed for use at
night. ●
Compared to turning on th e headlights, the daytime running light system offers
greater durability and consumes less electricity, so it can help improve fuel
economy.■
Headlight control sensor
■
Automatic light off system ●
When the headlights are on: The headlights and tail lights turn off 30 seconds
after a door is opened and closed if the “ENGINE START STOP” switch has
been switched to AC CESSORY or OFF mode.●
When only the tail lights are on: The tail lights turn off automatically if the
“ENGINE START STOP” switch is switched to ACCESSORY or OFF mode
and driver’s door is opened.
To turn the lights on again, turn the “ENGINE START STOP” switch to IGNITION
ON mode, or turn the light switch off once and then back to the
or
position. The sensor may not function properly if an
object is placed on the sensor, or anything
that blocks the sensor is affixed to the wind-
shield.
Doing so interferes with the sensor detecting
the level of ambient light and may cause the
automatic headlight system to malfunction.

2102-3. Operating the lights and wipers
LX570_OM_OM60L21U_(U) ■
Automatic headlight leveling system
The level of the headlights is automatica lly adjusted according to the number of
passengers and the loading condition of the vehicle to ensure that the headlights do
not interfere with other road users. ■
If the “AFS OFF” indicator flashes
It may indicate a malfunction in the system. Contact your Lexus dealer. ■
Customization
Settings (e.g. light sensor sensitivity) can be changed.
(Customizable features  P. 9 0 6 )
NOTICE■
To prevent battery discharge
Do not leave the lights on longer than necessary when the engine is not running.

2112-3. Operating the lights and wipers
2
When driving
LX570_OM_OM60L21U_(U) Automatic High Beam 
 : If equippedThe Automatic High Beam uses an in-vehicle camera sensor to assess the
brightness of streetlights, the lights of oncoming and preceding vehicles,
etc., and automatically turns high beam on or off as necessary.
■ Activating the Automatic High Beam system Push the lever away from you with
the headlight switch in the “AUTO”
position when the “ENGINE
START STOP” switch is in IGNI-
TION ON mode.
The Automatic High Beam indi-
cator will come on when the
headlights are turned on auto-
matically to indicate that the sys-
tem is active.

2142-3. Operating the lights and wipers
LX570_OM_OM60L21U_(U) ■
Limitations of the Automatic High Beam
Do not rely on the Automatic High Beam . Always drive safely, taking care to
observe your surroundings and turning high beam on or off manually if necessary.■
Camera sensor detection information ●
High beam may not be automatically turned off in the following situations:
• When oncoming vehicles suddenly appear from a curve.
• When the vehicle is cut in front of by another. ●
High beam may be turned off if an oncoming vehicle that is using fog lights with-
out using the headlights is detected. ●
Houselights, streetlights, red traffic sign als, and illuminated billboards or signs
may cause the high beam to turn off. ●
The following factors may affect the amount of time taken to turn high beam on
or off:
• The brightness of headlights, fog lights , and tail lights of oncoming and pre-
ceding vehicles
• Road conditions (wetness, ice, snow etc.)
• The number of passengers and amount of baggage ●
High beam may be turned on or off when unexpected by the driver.
