language LEXUS LX570 2015 User Guide

5243-3. Using the audio system
LX570_OM_OM60L96U_(U) ■ Setting audio language
Touch “Audio Language” on the “DVD Settings” screen.
Touch the desired language to be heard on the “Audio Lan-
guage” screen. If you cannot find the desired lang uage, touch “Other” and input the
desired language code. (  P. 526)
■ Setting subtitle language
Touch “Subtitle Language” on the “DVD Settings” screen.
Touch the desired language to be read on the “Subtitle
Language” screen. If you cannot find the desired lang uage, touch “Other” and input the
desired language code. (  P. 526)
■ Setting menu language
Touch “Menu Language” on the “DVD Settings” screen.
Touch the desired language to be read on the “Menu Language”
screen. If you cannot find the desired lang uage, touch “Other” and input the
desired language code. (  P. 526)
■ Setting angle mark
If the DVD has angle options, you can turn the angle mark on or off.
Touch “Angle Mark” on the “DVD Settings” screen.
Select “On” or “Off”.
■ Parental lock
Touch “Parental Lock” on the “DVD Settings” screen.
Input the 4-digit personal code on the “Key Code” screen. If you enter wrong numbers, touch to delete the numbers.
Select a parental level (1-8) on the “Select Restriction Level”
screen. (  P. 532)STEP 1
STEP 2
STEP 1
STEP 2
STEP 1
STEP 2
STEP 1
STEP 2
STEP 1
STEP 2
STEP 3

5253-3. Using the audio system
3
Interior features
LX570_OM_OM60L96U_(U) ■ Setting the auto start
Discs that are inserted while the ve hicle is in motion will automatically
start playing.
Touch “Auto Start Playback” on the “DVD Settings” screen.
Select “On” or “Off”.
■ Setting sound dynamic range
The difference between the lowest vo lume and the highest volume can
be adjusted.
Touch “Sound Dynamic Range” on the “DVD Settings” screen.
Select “MAX”, “STD” or “MIN”.
■ Entering a language code
If you touch “Other” on the “A udio Language” screen, “Subtitle
Language” screen or “Menu Lang uage” screen you can select a
language by entering the 4-digit la nguage code if that language is
available.
Input the 4-digit language code
and then touch “OK”. : Deletes the last input digit
: Returns to the previous
screenSTEP 1
STEP 2
STEP 1
STEP 2

5263-3. Using the audio system
LX570_OM_OM60L96U_(U) ● Language codes Code Language Code Language Code Language
0514 English 0207 Bulgarian 0712 Galician
0618 French 0208 Bihari 0714 Guarani
0405 German 0209 Bislama 0721 Gujarati
0920 Italian 0214 Bengali,
Bangla 0801 Hausa
0519 Spanish 0215 Tibetan 0809 Hindi
2608 Chinese 0218 Breton 0818 Croatian
1412 Dutch 0301 Catalan 0821 Hungarian
1620 Portuguese 0315 Corsican 0825 Armenian
1922 Swedish 0319 Czech 0901 Interlingua
1821 Russian 0325 Welsh 0905 Interlingue
1115 Korean 0401 Danish 0911 Inupiak
0512 Greek 0426 Bhutani 0914 Indonesian
0101 Afar 0515 Esperanto 0919 Icelandic
0102 Abkhazian 0520 Estonian 0923 Hebrew
0106 Afrikaans 0521 Basque 1001 Japanese
0113 Amharic 0601 Persian 1009 Yiddish
0118 Arabic 0609 Finnish 1023 Javanese
0119 Assamese 0610 Fiji 1101 Georgian
0125 Aymara 0615 Faroese 1111 Kazakh
0126 Azerbaijani 0625 Frisian 1112 Greenlandic
0201 Bashkir 0701 Irish 1113 Cambodian
0205 Byelorussian 0704 Scottish-
Gaelic 1114 Kannada

5273-3. Using the audio system
3
Interior features
LX570_OM_OM60L96U_(U) Code Language Code Language Code Language
1119 Kashmiri 1415 Norwegian 1914 Shona
1121 Kurdish 1503 Occitan 1915 Somali
1125 Kirghiz 1513 (Afan)
Oromo 1917 Albanian
1201 Latin 1518 Oriya 1918 Serbian
1214 Lingala 1601 Panjabi 1919 Siswati
1215 Laothian 1612 Polish 1920 Sesotho
1220 Lithuanian 1619 Pashto,
Pushto 1921 Sundanese
1222 Latvian,
Lettish 1721 Quechua 1923 Swahili
1307 Malagasy 1813 Rhaeto-
Romance 2001 Tamil
1309 Maori 1814 Kirundi 2005 Telugu
1311 Macedonian 1815 Romanian 2007 Tajik
1312 Malayalam 1823 Kinyarwanda 2008 Thai
1314 Mongolian 1901 Sanskrit 2009 Tigrinya
1315 Moldavian 1904 Sindhi 2011 Turkmen
1318 Marathi 1907 Sango 2012 Tagalog
1319 Malay 1908 Serbo-
Croatian 2014 Setswana
1320 Maltese 1909 Sinhalese 2015 Tongan
1325 Burmese 1911 Slovak 2018 Turkish
1401 Nauru 1912 Slovenian 2019 Tsonga
1405 Nepali 1913 Samoan 2020 Tatar

5283-3. Using the audio system
LX570_OM_OM60L96U_(U) Setup operation from the rear seat (vehicles with rear seat entertain-
ment system)
Touch “Play” to cancel this setup
operation from the rear seat. This screen appears when a rear
passenger setting selects the setup
menu.Code Language Code Language Code Language
2023 Twi 2209 Vietnamese 2515 Yoruba
2111 Ukrainian 2215 Volapük 2621 Zulu
2118 Urdu 2315 Wolof
2126 Uzbek 2408 Xhosa
■
When a rear passenger selects set up menu
Follow the directions on the wa rning screen that is displayed.
Under the same condition, the rear passenger can cancel the set up operation from
the front seat. ■
Rear system lock
 P. 582■
Error messages
If “Region Code Error” is displayed, ch eck if the region code printed on the DVD
matches the player’s region code.
If a different message is displayed:  P. 529

5293-3. Using the audio system
3
Interior features
LX570_OM_OM60L96U_(U) CD/DVD player and DVD video disc information■ Error messages
If the following error messages appear on the screen, refer to the table
and take the appropriate measures. If the problem is not rectified, take
the vehicle to your Lexus dealer.
The error messages may differ from those shown below depending on
the language selected. Message Cause Correction
Procedures
No disc found. There is no disc in the
player. Insert a disc.
Check DISC • The disc is dirty or dam-
aged.
• The disc is inserted
upside down.
• The disc is not playable
with the player. • Clean the disc.
• Insert the disc correctly.
• Confirm the disc is play-
able with the player.
DISC Error • There is a malfunction
within the system.
• Operation is stopped
due to a high tempera-
ture inside the player. • Eject the disc.
• Eject the disc and allow
the player to cool down.
No music files
found. This indicates that no
playable data is included
in the disc. Eject the disc.

5303-3. Using the audio system
LX570_OM_OM60L96U_(U) ■ DVD video discs
● The DVD player conforms to NTSC/PAL color TV formats. DVD
video discs conforming to anoth er format such as SECAM cannot
be used.
● Region code: Some DVD video disc s have a region code indicating
the region in which you can use the DVD video d isc. If the DVD
video disc is not labele d as “ALL” or “1”, yo u cannot use it on this
DVD player. If you attempt to play an inapp ropriate DVD video disc
on this player, “Region Code Erro r” appears on the screen. Even if
the DVD video disc does not ha ve a region code, you may not be
able to use it. ■
Symbols shown on DVD video discs
Symbol Meaning
NTSC/PAL Indicates NTSC/PAL format of color TV
Indicates the number of audio tracks
Indicates the number of language subtitles
Indicates the number of angles
Indicates the screen display ratios available
Wide screen: 16:9
Standard: 4:3
Indicates the disc’s region code
ALL: in all countries
Number: region code

5323-3. Using the audio system
LX570_OM_OM60L96U_(U) ■
DVD video disc information ●
DVD video discs
A DVD video disc is a Digi tal Versatile Disc that ho lds video. DVD video discs
have adopted “MPEG2”, one of the world standards of digital compression
technologies. The picture data is comp ressed by 1/40 on average and stored.
Variable rate encoded technology in whic h the volume of data assigned to the
picture is changed depending on the picture format has also been adopted.
Audio data is stored using PCM and Dolby Digital, which enables higher quality
of sound. Furthermore, multi-angle and multi-language features will also help
you enjoy the more advanced technology of DVD video. ●
Viewer restrictions
This feature limits what can be viewed in conformity with the level of restrictions
of the country. The level of restrictions varies depending on the DVD video disc.
Some DVD video discs cannot be played at all, or violent scenes are skipped or
replaced with other scenes.
Level 1: DVD video discs for children can be played.
Level 2-7: DVD video discs for children and G-rated movies can be played.
Level 8: All types of DVD video discs can be played. ●
Multi-angle option
You can enjoy the same scene from different angles. ●
Multi-language option
You can select the subtitle and audio languages. ●
Region codes
The region codes are provided on DVD players and DVD discs. If the DVD
video disc does not have the same regi on code as the DVD player, you cannot
play the disc on the DVD player. (  P. 530)●
Audio
This DVD player can play linear PCM, Dolby Digital and MPEG audio format
DVDs. Other decoded types cannot be played. ●
Title and chapter
Video and audio programs stored in DVD video discs are divided into parts by
title and chapter.
Title: The largest unit of the video an d audio programs stored on DVD video
discs. Usually, one movie, one album, or one audio program is assigned as a title.
Chapter: A title is comprised of one or more chapters.

6013-4. Using the rear se at entertainment system
3
Interior features
LX570_OM_OM60L96U_(U) ■ Control icon screen
Press the “OPTION” button on the controller if no icons are shown
while watching a DVD video, and the following screen appears.
Hide the buttons
Setting screen appears
(  P. 605)
Menu screen appears
Rewind
Stop
Play/pause
Fast forward
If appears on the screen when you select an icon, the operation
relevant to that control is not permitted.
■ Settings screen
Select “Settings” on the control icon screen , the following screen
appears.
Change initial setting
Return to previous screen
Search by title
Display the predetermined
scene and start playing from
there
Change audio language
Change subtitle language
Change angle

6033-4. Using the rear se at entertainment system
3
Interior features
LX570_OM_OM60L96U_(U) Returning to the previous screen
Select “Return” to return to the prev ious screen. For the operation of the
menu screen, see the separate manual for the DVD disc.
Searching for a desired screen
■ Searching by title
Select “Search” on the control icon screen.
Input the desired title number and then select “OK”. : Deletes the last input number
: Returns to the previous screen
■ Searching by chapter
Press or to select a chapter.
Changing the subtitle language
Select “Subtitle” on the settings screen.
Select “Subtitle”. Each time you select “Subtitle”, the
next available language is selected.
“Hide”: Hides the control icons
: Returns to the previous
screenSTEP 1
STEP 2
STEP 1
STEP 2
