861-3. Adjustable components (s eats, mirrors, steering wheel)
LX570_OM_OM60L96U_(U) ■
Retained accessory power ●
Each memorized position (except for the steering wheel position) can be acti-
vated within 3 minutes after the driver’s door is opened, even if the “ENGINE
START STOP” switch is turned off. ●
Each memorized position (except for the steering wheel position) can be acti-
vated within 60 seconds after the driver’s door is closed, even if the “ENGINE
START STOP” switch is turned off.■
To cancel seat position recall
Perform any one of the following operations. ●
Press the “SET” button ●
Press button “1”, “2” or “3”. ●
Adjust the seat using the switches (only cancels seat position recall)●
Adjust the steering wheel using the tilt and telescopic steering control switch
(only cancels steering wheel position recall) ■
If the battery is disconnected
The memorized positions must be reset because the computer’s memory is erased
when the battery is disconnected.
CAUTION■
Seat adjustment caution
Take care during seat adjustment that the seat does not strike the rear passenger or
squeeze your body against the steering wheel.

1001-3. Adjustable components (seats, mirrors, steering wheel)
LX570_OM_OM60L96U_(U) Steering wheel
Auto tilt away
When the “ENGINE START
STOP” switch is turned OFF and
the driver’s seat belt is unfastened,
the steering wheel returns to its
stowed position by moving up and
away to enable easier driver entry
and exit. Switching to ACCESSORY or
IGNITION ON mode or fasten-
ing the driver’s seat belt will return
the steering wheel to the original
position.The steering wheel can be adjusted to a comfortable position while the
“ENGINE START STOP” switch is in ACCESSORY or IGNITION ON
mode or when the driver’s seat belt is fastened.
Up
Down
Toward the driver
Away from the driver

1021-3. Adjustable components (seats, mirrors, steering wheel)
LX570_OM_OM60L96U_(U) Anti-glare inside rear view mirror Adjusting the height of the rear view mirror
Adjust the height of the rear view
mirror by moving it up and down.
Automatic anti-glare function
Changing automa tic anti-glare
function mode
ON
OFF When the automatic anti-glare
function is in ON mode, the indica-
tor illuminates.
The function will be set to ON
mode each time the “ENGINE
START STOP” switch is turned to
IGNITION ON mode.
Pressing the button turns the func-
tion to OFF mode. (The indicator
also turns off.)The rear view mirror’s position can be adjusted to enable sufficient confir-
mation of the rear view in accordan ce with the driver’s seating posture.

1061-3. Adjustable components (s eats, mirrors, steering wheel)
LX570_OM_OM60L96U_(U) ■
Mirror angle can be adjusted when
The “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON
mode. ■
When the mirrors are fogged up
The outside rear view mirrors can be cl eared using the mirror defoggers. Turn on
the rear window defogger to turn on the outside rear view mirror defoggers.
(  P. 460)■
Auto anti-glare function
When the anti-glare inside rear view mi rror is set to auto mode, the outside rear
view mirrors will activate in conjunction wi th the anti-glare inside rear view mirror
to reduce refle cted light. (  P. 102)■
Automatic adjustment of the mirror angle
A desired mirror face angle can be entered to memory and recalled automatically
by the driving position memory. (  P. 83)

108
LX570_OM_OM60L96U_(U) 1-4. Opening and closing th e windows and moon roof
Power windows
Lock switch
Press the switch down to lock pas-
senger window switches. Use this switch to prevent children
from accidentally opening or clos-
ing a passenger window.The power windows can be opened and closed using the following
switches.
Closing
One-touch closing
*Opening
One-touch opening
*
*: To stop the window partway,
operate the switch in the oppo-
site direction.
■
The power windows can be operated when
The “ENGINE START STOP” switch is in IGNITION ON mode. ■
Door lock linked window operation
The following functions can be used if customized at your Lexus dealer. ●
The power windows can be opened and closed using the mechanical key.
(  P. 872)●
The power windows can be opened us ing the wireless remote control.
(  P. 49)●
The power windows can be closed using the entry function. (  P. 36)

1091-4. Opening and closing the windows and moon roof
1
Before driving
LX570_OM_OM60L96U_(U) ■
Operating the power windows after tu rning the “ENGINE START STOP” switch
OFF
The power windows can be operated for ap proximately 45 seconds even after the
“ENGINE START STOP” switch is turned to ACCESSORY mode or turned OFF.
They cannot, however, be operated once either front door is opened. ■
Jam protection function
If an object becomes caught between th e window and the window frame, window
travel is stopped and the window is opened slightly. ■
When the power window does not close normally
If the jam protection function is oper ating abnormally and a window cannot be
closed, perform the following operations using the power window switch on the rel-
evant door. ●
After stopping the vehicle, the window can be closed by holding the power win-
dow switch in the one-touch closing position while the “ENGINE START
STOP” switch is turned to IGNITION ON mode.●
If the window still cannot be closed even by carrying out the operation
explained above, initialize the function by performing the following procedure.
Hold the power window switch in the one-touch closing position. Con-
tinue holding the switch for a further 6 seconds after the window has
closed.
Hold the power window switch in the one-touch opening position. Con-
tinue holding the switch for a furt her 2 seconds after the window has
opened completely.
Hold the power window switch in the one-touch closing position once
again. Continue holding the switch for a further 2 seconds after the win-
dow has closed.
If you release the switch while the window is moving, start again from the beginning.
If the window continues to close but then re-open slightly even after performing the
above procedure correctly, have the vehicle inspected by your Lexus dealer. STEP 1
STEP 2
STEP 3

1101-4. Opening and closing the windows and moon roof
LX570_OM_OM60L96U_(U) ■
Customization
Settings (e.g. linked door lock operation) can be changed.
(Customizable features  P. 912)
CAUTION■
Closing the windows
Observe the following precautions.
Failing to do so may result in death or serious injury. ●
The driver is responsible for all the powe r window operations, including the oper-
ation for the passengers. In order to preven t accidental operation, especially by a
child, do not let a child op erate the power windows. It is possible for children and
other passengers to have body parts caught in the power window. Also, when
riding with a child, it is recommended to use the window lock switch. (  P. 108)●
Check to make sure that all passengers do not have any part of their body in a
position where it could be caught when a window is being operated. ●
When using the smart access system, wireless remote co ntrol or mechanical key
and operating the power windows, operat e the power window after checking to
make sure that there is no possibility of any passenger having any of their body
parts caught in the window. Also, do not let a child operate window by the smart
access system, wireless remote control or me chanical key. It is possible for chil-
dren and other passengers to get caught in the power window. ●
When exiting the vehicle, turn the “ENG INE START STOP” switch off, carry the
key and exit the vehicle along with the child. There may be accidental operation,
due to mischief, etc., that may possibly lead to an accident.■
Jam protection function ●
Never try jamming any part of your body to activate the jam protection function
intentionally. ●
The jam protection function may not work if something gets caught just before
the window fully closes.

1121-4. Opening and closing the windows and moon roof
LX570_OM_OM60L96U_(U) ■
The moon roof can be operated when
The “ENGINE START STOP” switch is in IGNITION ON mode. ■
Door lock linked moon roof operation
The following functions can be used if customized at your Lexus dealer. ●
The moon roof can be opened and cl osed using the mechanical key. (  P. 872)●
The moon roof can be opened usin g the wireless remo te control. (  P. 49)●
The moon roof can be closed using the entry function. (  P. 36)■
Operating the moon roof after turning the “ENGINE START STOP” switch OFF
The moon roof can be operated for approximately 45 seconds even after the
“ENGINE START STOP” switch is turned to ACCESSORY mode or turned OFF.
It cannot, however, be operated on ce either front door is opened.■
Jam protection function
If an object is detected between the moon roof and the frame while closing or tilting
down, travel is stopped and the moon roof opens slightly. ■
If the moon roof cannot be closed automatically
Keep the switch depressed. ■
To reduce moon roof wind noise
When the moon roof is opened automaticall y, it will stop slightly before the fully
open position. Driving with the moon roof in this position can help reduce wind
noise. ■
Sunshade
The sunshade can be opened and closed manually. However, the sunshade will
open automatically when th e moon roof is opened.

1151-4. Opening and closing the windows and moon roof
1
Before driving
LX570_OM_OM60L96U_(U) CAUTION■
Closing the moon roof
Observe the following precautions.
Failing to do so may result in death or serious injury. ●
The driver is responsible for moon roof opening and closing op erations. In order
to prevent accidental operation, especially by a child, do not let a child operate
the moon roof. It is possible for children and other passengers to have body parts
caught in the moon roof. ●
Check to make sure that all passengers do not have any part of their bodies in a
position where they could be caught when the moon roof is being operated. ●
When using the smart access system, wireless remote co ntrol or mechanical key
and operating the moon roof , operate the moon roof after checking to make sure
that there is no possibility of any passenger having any of their body parts caught
in the moon roof. Also, do not let a child operate moon roof by the smart access
system, wireless remote contro l or mechanical key. It is possible for children and
other passengers to get caught in the moon roof. ●
When exiting the vehicle, turn the “ENG INE START STOP” switch off, carry the
key and exit the vehicle along with the child. There may be accidental operation,
due to mischief, etc., that may possibly lead to an accident.■
Jam protection function ●
Never try jamming any part of your body to activate the jam protection function
intentionally. ●
The jam protection function may not work if something gets caught just before
the moon roof fully closes.

116
LX570_OM_OM60L96U_(U) 1-5. Refueling
Opening the fuel tank cap Perform the following steps to open the fuel tank cap.
■ Before refueling the vehicle
● Turn the “ENGINE START STOP” switch OFF and ensure that
all the doors and windows are closed.
● Confirm the type of fuel. (  P. 117)
■ Opening the fuel tank cap
Pull the lever.
Turn the fuel ta nk cap slowly to
open.
Hang the fuel tank cap on the
back of the fuel filler door.STEP 1
STEP 2
STEP 3
