bluetooth LEXUS LX570 2015 Owner's Guide

6263-5. Using the hands-free sy stem (for cellular phone)
LX570_OM_OM60L96U_(U) When this screen is displayed,
operate the Bluetooth ®
device.On the Bluetooth ®
device screen,
select the system displayed on the
system screen, and register the
Bluetooth ®
device.
For details about operating the
Bluetooth ®
device, see the manual
that comes with it.
A passcode is not required for SSP
(Secure Simple Pairing) compati-
ble Bluetooth ®
phones. Depend-
ing on the type of Bluetooth ®
phone being connected, a mes-
sage confirming registration may
be displayed on the Bluetooth ®
phone’s screen. Respond and
operate the Bluetooth ®
phone
according to the confirmation mes-
sage.
If you want to cancel it, touch
“Cancel”.
If a completion message is
displayed, registration is complete.
If an error message is displayed,
follow the guidance on the screen
to try again.STEP 3

6273-5. Using the hands-free system (for cellular phone)
3
Interior features
LX570_OM_OM60L96U_(U) Bluetooth ®
phone connection
There are two connection methods available — automatic and manual.
Automatic
When you register your phone,
auto connection will be activated.
Always set it to this mode and
leave the Bluetooth ®
phone on the
place where connection can be
established.
When the “ENGINE START
STOP” switch is turned to
ACCESSORY or IGNITION ON
mode, the system will search for a
nearby cellular phone you have
registered. The system will con-
nect with the ph one that was last
connected, if it is nearby.
When “Display Phone Status” is
set to “On”, the connection status
is displayed. (  P. 684)Depending on the type of
Bluetooth ®
phone being con-
nected, it may be necessary to per-
form additional steps on the phone.

6283-5. Using the hands-free sy stem (for cellular phone)
LX570_OM_OM60L96U_(U) Manual
When the auto connection has failed or “Bluetoot h* Power” is turned off,
you must connect Bluetooth ®
manually.
Display the “Phone” screen. (  P. 625)
Touch “Connect Phone”.
Touch the screen button corre-
sponding to the desired phone
connection. When the cellular phone’s device
name has not been able to be
obtained, “Device 1” to “Device 5”
will be displayed in the order the
phones were registered.
This screen is displayed. If a completion message is dis-
played, connection is complete.
* : Bluetooth is a registered tr ademark of Bluetooth SIG, Inc.STEP 1
STEP 2
STEP 3
STEP 4

6293-5. Using the hands-free system (for cellular phone)
3
Interior features
LX570_OM_OM60L96U_(U) ■
Reconnecting to the Bluetooth ®
phone
If the system cannot connect due to poor signal strength wi th the “ENGINE START
STOP” switch in ACCESSORY or IGNITION ON mode, the system will automat-
ically attempt to reconnect.
If the phone is turned off, the system wi ll not attempt to reconnect. In this case, it
must be connected manually, or the phon e must be re-selected or re-entered.■
Connecting the phone while Bluetooth ®
audio is playing●
Bluetooth ®
audio will stop temporarily.●
It may take time to connect.■
Connecting the phone while another Bluetooth ®
device is connected
When another Bluetooth ®
device is currently connected, a confirmation message
will be displayed. To di sconnect the Bluetooth ®
device, touch “Yes”.■
Connecting the phone while 5 Bluetooth ®
devices have already been registered
When 5 Bluetooth ®
devices have already been registered, a registered device
needs to be deleted. Touch “Y es” to delete one or more.
Touch the device to be deleted, then touch “Remove”, and “Yes”. ■
If the Bluetooth ®
phone has a Bluetooth ®
audio function
When the Bluetooth ®
phone to be registered has a Bluetooth ®
audio function, this
audio function will be registered automatically at the same time and confirmation
message may be displayed. If this screen is displayed, touch “Yes” to connect the
audio function or touch “No” to cancel the connection.

6303-5. Using the hands-free sy stem (for cellular phone)
LX570_OM_OM60L96U_(U) Making a call
Once the Bluetooth ®
phone is registered, you can make a call using the
following procedure:
■ Dialing
Display the “Phone” screen. (  P. 625)
Input the phone number. To delete the inputted phone num-
ber, touch .
Touch or press on the steering wheel. Depending on the type of Bluetooth ®
phone being connected, it may
be necessary to perform additional steps on the phone.STEP 1
STEP 2
STEP 3

6333-5. Using the hands-free system (for cellular phone)
3
Interior features
LX570_OM_OM60L96U_(U) Transfer the phonebook data to
the system using the Bluetooth ®
phone. This screen appears while transfer-
ring. To cancel this function, touch
“Cancel”.
Depending on the type of
Bluetooth ®
phone:
• It may be necessary to perform
additional steps on the phone
when transferring phonebook
data.
• The registered image on the
phonebook may not appear
when phonebook data is trans-
ferred.
Depending on the type of cellular
phone, OBEX authentication may
be required when transferring
phonebook data. Enter “1234” into
the Bluetooth ®
phone.
When the data transfer from a
PBAP incompatible but OPP
compatible model is complete,
“Done” will appear on the screen.
Touch “Done”.STEP 4
STEP 5

6453-5. Using the hands-free system (for cellular phone)
3
Interior features
LX570_OM_OM60L96U_(U) ■ Call waiting
When a connected call is interrupted by the third party, the incoming
call message will be displayed.
● To talk with the other party : Touch or press on the
steering wheel.
● To refuse the call: Touch or press on the steering wheel.
Everytime you touch or press on the steering wheel after
a call is interrupted, you will be switched to the other party.
If your cellular phone is not accepted in HFP Ver. 1.5, this function can-
not be used. ■
Incoming call ●
The ring tone that has been set in th e “Phone Sound Settings” screen sounds
when there is an incoming call. (  P. 649)●
Depending on the type of Bluetooth ®
phone, both the system and Bluetooth ®
phone may sound simultaneously wh en there is an incoming call.■
Transferring calls ●
It is not possible to transfer from hand s-free to a cellular phone while driving.●
If you transfer from a cellular phone to hands-free, the hands-free screen will be
displayed, and you can operate the system using the screen. ●
Transfer method and operation may vary according to the cellular phone used.●
For operation of the cellular phone in use, see the phone’s manual.■
Repeated tone symbols
When the “p” pause tone is used, after wait ing 2 seconds the tone data up until the
next pause tone will be automatically sent. When the “w” pause tone is used, the
tone data up until the next pause tone will be automatically sent after user opera-
tion.

6463-5. Using the hands-free sy stem (for cellular phone)
LX570_OM_OM60L96U_(U) Using a Bluetooth ®
phone message
Received messages can be forwarded from the connected Bluetooth ®
phone, enabling checking and replying (Quick reply).
■ Checking a message
Display the “Phone” screen. (  P. 625)
Touch “Messages” on the “Phone” screen. Depending on the type of Bluetooth ®
phone being connected, it
may be necessary to perform additional steps on the phone.
When “Message Transfer” is set to “Off”, a confirma tion screen will
be displayed. Touch “Yes”.
Touch the desired message to
check. The text of the message is not dis-
played while driving.
Touching “Previous” or “Next” dis-
plays the previous or next mes-
sage.
Touch “Play” to start reading out of the me ssage. Touch “Stop” to
stop the function. ■
While driving
Key input is unavailable. ■
Voice recognition during a call
“Send Tones” can be operated by voice recognition. (  P. 635)■
Interrupt call operation
Interrupt call operation may differ from depending on your phone company and the
cellular phone.
STEP 1
STEP 2
STEP 3
STEP 4

6483-5. Using the hands-free system (for cellular phone)
LX570_OM_OM60L96U_(U) ■
To check the message ●
Messages are displayed in the appropriate connected Bluetooth ®
phone’s reg-
istered mail address folder. Touch the tab of the desired folder to be displayed.●
Only received messages on the connected Bluetooth ®
phone can be dis-
played. ●
When the received message is an e-ma il and “Update Message Read Status on
Phone” is set to “On”, “Mark as Unread” or “Mark as Read” can be selected.
Touch “Mark as Unread” to mark mails that have been read on the Bluetooth ®
phone as unread. Conversely, touch “Mar k as Read” to mark mails that have
not been read on the Bluetooth ®
phone as read. (  P. 666)■
Calling using SMS/MMS message
You can call using the SMS (Short Me ssage Service)/MMS (Multimedia Messag-
ing Service) message sender’s phone number. (  P. 637)■
If the message delivery failed
If message delivery has fail ed, a notification will be displayed on the screen.
Touch “Retry” to attempt to send the message again or touch “Cancel” to cancel. ■
Editing a quick reply message
You can edit the “Quick Reply Messages”. (  P. 668)■
New message notification
If “New Message Pop-up” and “New Message Voice Notification” are set to “On”,
a notification appears on the screen and a voice notification will be heard when a
new message arrives, touch “Read” to ch eck the message , also to check the mes-
sage later, touch “Ignore”. When “Automat ic Message Readout” is set to “On”, the
message will be automatically read out. (  P. 666)

6523-5. Using the hands-free sy stem (for cellular phone)
LX570_OM_OM60L96U_(U) ■ Setting the phonebook
● Transferring a phone number
You can transfer the phone nu mbers in your Bluetooth ®
phone to the
system. Operation methods differ between PBAP compatible and
PBAP incompatible but O PP compatible Bluetooth ®
phones. If your
cellular phone is neither PBAP nor OPP compatible, the phonebook
cannot be transferred.
For PBAP compatible Bluetooth ®
phones
Display the “Phonebook Settings” screen. (  P. 650)
Touch “Manage Contacts” on th e “Phonebook Settings” screen.
Touch “Transfer Contacts”.
Touch “Update Contacts”.STEP 1
STEP 2
STEP 3
STEP 4
