LEXUS LX570 2015 Owners Manual

5213-3. Using the audio system
3
Interior features
LX570_OM_OM60L96U_(U) Changing the angle (if the angle option is available)
Touch “Angle” on the “DVD Options” screen.
Each time you touch “Change”,
the next available angle is
selected. The angles available are restricted
to those available on the DVD disc.
: Returns to the previous
screen
Changing screen size
Touch “Wide” on the “DVD Options” screen.
Touch the desired display. After
setting, touch “Save”.
Displays a 3 : 4 screen, with
either side in black
Widens the 3 : 4 screen hori-
zontally to fill the screen
Widens the 3 : 4 screen verti-
cally and horizontally, in the
same ratio, to fill the screen : Returns to the previous
screenSTEP 1
STEP 2
STEP 1
STEP 2

5223-3. Using the audio system
LX570_OM_OM60L96U_(U) Adjusting the screen
Touch “Display” on the “DVD Options” screen.
Touch “<” or “>” to display the
desired item to be adjusted, and
then touch “OK”. The screen goes off when “Screen
Off” is touched. To turn the screen
back on, press any button. The
selected screen appears.STEP 1
STEP 2
R G
Color Red Green
- +
Tone Lighter Darker
Contrast Weaker Stronger
Brightness Darker Brighter

5233-3. Using the audio system
3
Interior features
LX570_OM_OM60L96U_(U) Initial DVD settings
■ Displaying “DVD Settings” screen
Touch “DVD Settings” on the “DVD Options” screen.
Touch the setting to be changed.
After you change the settings,
touch “Save”. “Default”: Restores default settings
: Returns to the previous
screenSTEP 1
STEP 2

5243-3. Using the audio system
LX570_OM_OM60L96U_(U) ■ Setting audio language
Touch “Audio Language” on the “DVD Settings” screen.
Touch the desired language to be heard on the “Audio Lan-
guage” screen. If you cannot find the desired lang uage, touch “Other” and input the
desired language code. (  P. 526)
■ Setting subtitle language
Touch “Subtitle Language” on the “DVD Settings” screen.
Touch the desired language to be read on the “Subtitle
Language” screen. If you cannot find the desired lang uage, touch “Other” and input the
desired language code. (  P. 526)
■ Setting menu language
Touch “Menu Language” on the “DVD Settings” screen.
Touch the desired language to be read on the “Menu Language”
screen. If you cannot find the desired lang uage, touch “Other” and input the
desired language code. (  P. 526)
■ Setting angle mark
If the DVD has angle options, you can turn the angle mark on or off.
Touch “Angle Mark” on the “DVD Settings” screen.
Select “On” or “Off”.
■ Parental lock
Touch “Parental Lock” on the “DVD Settings” screen.
Input the 4-digit personal code on the “Key Code” screen. If you enter wrong numbers, touch to delete the numbers.
Select a parental level (1-8) on the “Select Restriction Level”
screen. (  P. 532)STEP 1
STEP 2
STEP 1
STEP 2
STEP 1
STEP 2
STEP 1
STEP 2
STEP 1
STEP 2
STEP 3

5253-3. Using the audio system
3
Interior features
LX570_OM_OM60L96U_(U) ■ Setting the auto start
Discs that are inserted while the ve hicle is in motion will automatically
start playing.
Touch “Auto Start Playback” on the “DVD Settings” screen.
Select “On” or “Off”.
■ Setting sound dynamic range
The difference between the lowest vo lume and the highest volume can
be adjusted.
Touch “Sound Dynamic Range” on the “DVD Settings” screen.
Select “MAX”, “STD” or “MIN”.
■ Entering a language code
If you touch “Other” on the “A udio Language” screen, “Subtitle
Language” screen or “Menu Lang uage” screen you can select a
language by entering the 4-digit la nguage code if that language is
available.
Input the 4-digit language code
and then touch “OK”. : Deletes the last input digit
: Returns to the previous
screenSTEP 1
STEP 2
STEP 1
STEP 2

5263-3. Using the audio system
LX570_OM_OM60L96U_(U) ● Language codes Code Language Code Language Code Language
0514 English 0207 Bulgarian 0712 Galician
0618 French 0208 Bihari 0714 Guarani
0405 German 0209 Bislama 0721 Gujarati
0920 Italian 0214 Bengali,
Bangla 0801 Hausa
0519 Spanish 0215 Tibetan 0809 Hindi
2608 Chinese 0218 Breton 0818 Croatian
1412 Dutch 0301 Catalan 0821 Hungarian
1620 Portuguese 0315 Corsican 0825 Armenian
1922 Swedish 0319 Czech 0901 Interlingua
1821 Russian 0325 Welsh 0905 Interlingue
1115 Korean 0401 Danish 0911 Inupiak
0512 Greek 0426 Bhutani 0914 Indonesian
0101 Afar 0515 Esperanto 0919 Icelandic
0102 Abkhazian 0520 Estonian 0923 Hebrew
0106 Afrikaans 0521 Basque 1001 Japanese
0113 Amharic 0601 Persian 1009 Yiddish
0118 Arabic 0609 Finnish 1023 Javanese
0119 Assamese 0610 Fiji 1101 Georgian
0125 Aymara 0615 Faroese 1111 Kazakh
0126 Azerbaijani 0625 Frisian 1112 Greenlandic
0201 Bashkir 0701 Irish 1113 Cambodian
0205 Byelorussian 0704 Scottish-
Gaelic 1114 Kannada

5273-3. Using the audio system
3
Interior features
LX570_OM_OM60L96U_(U) Code Language Code Language Code Language
1119 Kashmiri 1415 Norwegian 1914 Shona
1121 Kurdish 1503 Occitan 1915 Somali
1125 Kirghiz 1513 (Afan)
Oromo 1917 Albanian
1201 Latin 1518 Oriya 1918 Serbian
1214 Lingala 1601 Panjabi 1919 Siswati
1215 Laothian 1612 Polish 1920 Sesotho
1220 Lithuanian 1619 Pashto,
Pushto 1921 Sundanese
1222 Latvian,
Lettish 1721 Quechua 1923 Swahili
1307 Malagasy 1813 Rhaeto-
Romance 2001 Tamil
1309 Maori 1814 Kirundi 2005 Telugu
1311 Macedonian 1815 Romanian 2007 Tajik
1312 Malayalam 1823 Kinyarwanda 2008 Thai
1314 Mongolian 1901 Sanskrit 2009 Tigrinya
1315 Moldavian 1904 Sindhi 2011 Turkmen
1318 Marathi 1907 Sango 2012 Tagalog
1319 Malay 1908 Serbo-
Croatian 2014 Setswana
1320 Maltese 1909 Sinhalese 2015 Tongan
1325 Burmese 1911 Slovak 2018 Turkish
1401 Nauru 1912 Slovenian 2019 Tsonga
1405 Nepali 1913 Samoan 2020 Tatar

5283-3. Using the audio system
LX570_OM_OM60L96U_(U) Setup operation from the rear seat (vehicles with rear seat entertain-
ment system)
Touch “Play” to cancel this setup
operation from the rear seat. This screen appears when a rear
passenger setting selects the setup
menu.Code Language Code Language Code Language
2023 Twi 2209 Vietnamese 2515 Yoruba
2111 Ukrainian 2215 Volapük 2621 Zulu
2118 Urdu 2315 Wolof
2126 Uzbek 2408 Xhosa
■
When a rear passenger selects set up menu
Follow the directions on the wa rning screen that is displayed.
Under the same condition, the rear passenger can cancel the set up operation from
the front seat. ■
Rear system lock
 P. 582■
Error messages
If “Region Code Error” is displayed, ch eck if the region code printed on the DVD
matches the player’s region code.
If a different message is displayed:  P. 529

5293-3. Using the audio system
3
Interior features
LX570_OM_OM60L96U_(U) CD/DVD player and DVD video disc information■ Error messages
If the following error messages appear on the screen, refer to the table
and take the appropriate measures. If the problem is not rectified, take
the vehicle to your Lexus dealer.
The error messages may differ from those shown below depending on
the language selected. Message Cause Correction
Procedures
No disc found. There is no disc in the
player. Insert a disc.
Check DISC • The disc is dirty or dam-
aged.
• The disc is inserted
upside down.
• The disc is not playable
with the player. • Clean the disc.
• Insert the disc correctly.
• Confirm the disc is play-
able with the player.
DISC Error • There is a malfunction
within the system.
• Operation is stopped
due to a high tempera-
ture inside the player. • Eject the disc.
• Eject the disc and allow
the player to cool down.
No music files
found. This indicates that no
playable data is included
in the disc. Eject the disc.

5303-3. Using the audio system
LX570_OM_OM60L96U_(U) ■ DVD video discs
● The DVD player conforms to NTSC/PAL color TV formats. DVD
video discs conforming to anoth er format such as SECAM cannot
be used.
● Region code: Some DVD video disc s have a region code indicating
the region in which you can use the DVD video d isc. If the DVD
video disc is not labele d as “ALL” or “1”, yo u cannot use it on this
DVD player. If you attempt to play an inapp ropriate DVD video disc
on this player, “Region Code Erro r” appears on the screen. Even if
the DVD video disc does not ha ve a region code, you may not be
able to use it. ■
Symbols shown on DVD video discs
Symbol Meaning
NTSC/PAL Indicates NTSC/PAL format of color TV
Indicates the number of audio tracks
Indicates the number of language subtitles
Indicates the number of angles
Indicates the screen display ratios available
Wide screen: 16:9
Standard: 4:3
Indicates the disc’s region code
ALL: in all countries
Number: region code
