384
LX570_OM_OM60N01U_(U) 4-6. Driving tips
Winter driving tips ●
Use fluids that are appropriate to the prevailing outside temperatures.
•Engine oil
• Engine coolant
• Washer fluid ●
Have a service technician inspect the condition of the battery. ●
Have the vehicle fitted with four snow tires or purchase a set of tire chains for
the rear tires.
*Ensure that all tires are the same size and br and, and that chains match the size of the
tires.
* : Tire chains cannot be mounted on vehicles with 21-inch tires
Perform the following according to the driving conditions: ●
Do not try to forcibly open a window or move a wiper that is frozen. Pour
warm water over the frozen area to melt the ice. Wipe away the water imme-
diately to prevent it from freezing. ●
To ensure proper operation of the climate control system fan, remove any
snow that has accumulated on the air in let vents in front of the windshield.●
Check for and remove any excess ice or snow that may have accumulated on
the exterior lights, vehicle’s roof, chassis, around the tires or on the brakes. ●
Remove any snow or mud from the bottom of your shoes before getting in the
vehicle.Carry out the necessary preparations and inspections before driving the vehi-
cle in winter. Always drive the vehicle in a manner appropriate to the prevail-
ing weather conditions.
Pre-winter preparations
Before driving the vehicle

400
LX570_OM_OM60N01U_(U) 5-2. Lexus Climate Concierge
Lexus Climate Concierge “CLIMATE CONCIERGE” switch When the switch is pressed, the indica-
tor above the switch illuminates and all
of the following systems operate in auto-
matic mode.
If any of the system is operated manually,
the indicator turns off. However, all
other functions continue to operate in
automatic mode.
■
Automatic air conditioning system (  P. 4 0 1 , 4 1 2 )The temperature can be adjusted individually for the driver seat, passenger seat, and
rear seats.
When a passenger is detected in the second seat, the rear air conditioning operates
in automatic mode.■
Seat heaters and ventilators (if equipped) (  P. 4 1 5 )Heating or ventilation is automatically selected according to the set temperature of
the air conditioning system, the outside temperature, etc.
The seat heaters and ventilators of the front passenger seat and second outboard
seats operate in automatic mode if passengers are detected.■
Heated steering wheel (if equipped) (  P. 4 1 5 )Heated steering wheel operat es automatically according to the outside temperature
and cabin temperature. ■
Front air conditioning system operation
To improve air conditioning performance in the front seat area, the air outlets on the rear
of the console box may close when there is no passenger in the second seat. ■
Rear air conditioning system operation
The rear air conditioning system may stop automatically when there is no passenger in
the second seat. ■
Seat heater/ventilator operation
When automatic mode is selected using th e seat heater/ventilator switch, passenger
detection is not performed.The seat heaters, seat ventilators and heated steering wheel are each auto-
matically controlled according to the set temperature of the air conditioning
system, the outside and cabin temperature, etc. Lexus Climate Concierge
allows a comfortable condition to be maintained without adjusting each sys-
tem.

578
LX570_OM_OM60N01U_(U) 8-1. Specifications
This information has been prepared in acco rdance with regulations issued by the
National Highway Traffic Safety Administration of the U.S. Department of Trans-
portation.
It provides the purchasers and/or prospective purchasers of Lexus vehicles with
information on uniform tire quality grading.Your Lexus dealer will help answer any questions you may have as you read this infor-
mation.■
DOT quality grades
All passenger vehicle tires must conform to Federal Safety Requirements in
addition to these grades. Quality grad es can be found where applicable on
the tire sidewall between tread shoulder and maximum section width. For example: Treadwear 200 Traction AA Temperature A■
Tr e a d w e a r
The treadwear grade is a comparative rati ng based on the wear rate of the tire
when tested under controlled conditions on a specified government test
course. For example, a tire graded 150 would wear one and a half (1 - 1 /2) times as well on
the government course as a tire graded 100.
The relative performance of tires depends upon the actual conditions of their use.
Performance may differ significantly from the norm due to variations in driving
habits, service practices and differences in road characteristics and climate.■
Tr a c t i o n A A , A , B , C
The traction grades, from highest to lowest, are AA, A, B and C, and they rep-
resent the tire’s ability to stop on we t pavement as measured under controlled
conditions on specified government te st surfaces of asphalt and concrete.A tire marked C may have poor traction performance.
Warning: The traction grade assigned to th is tire is based on braking (straight
ahead) traction tests and does not include cornering (turning) traction.Uniform Tire Quality Grading

624 Alphabetical index
LX570_OM_OM60N01U_(U) Language (multi-information
display)................................................... 595
LATCH system ........................................ 64
LDA (Lane Departure Alert) .......... 263
Lever
Auxiliary catch lever ......................... 472
Hood lock release lever ................. 472
Shift lever ................................................. 210
Turn signal lever .................................. 216
Wiper lever ................................ 231, 235
Lexus climate concierge ...................400
Climate concierge switch............. 400
Lexus parking assist monitor
*Lexus Safety System+......................... 242
License plate lights............................... 220
Light switch ...........................................220
Replacing light bulbs ......................... 510
Light
Automatic High Beam system .... 224
Engine switch light.............................. 419
Fog light switch ................................... 229
Headlight switch.................................220
Illuminated entry system ...................421
Interior lights .........................................420
Luggage compartment light ......... 419
Personal lights .......................................421
Replacing light bulbs ....................... 508
Turn signal lever .................................. 216
Vanity lights .......................................... 432
Wattage ................................................. 570
Light bulbs
Replacing ..............................................508
Wattage ................................................. 570
Lock steering column ......................... 207 Maintenance
Do-it-yourself maintenance ......... 470
General maintenance ..................... 466
Maintenance data.............................. 562
Maintenance requirements .......... 464
Scheduled maintenance ................ 464
Malfunction indicator lamp ...............524
Meter............................................................ 88
Indicators .................................................. 82
Instrument panel light control ........ 89
Meters ........................................................88
Multi-information display.................... 91
Warning lights..................................... 524
Warning messages .......................... 532
Micro dust and pollen filter ...............407
Mirrors
Inside rear view mirror..................... 160
Outside rear view mirror
defoggers........................................... 407
Outside rear view mirrors .............. 162
Vanity mirrors ..................................... 432
Moon roof ................................................. 168
Jam protection function....................169
Operation............................................... 168
MP3 disc
*L M

628 Alphabetical index
LX570_OM_OM60N01U_(U) Snow tires ................................................ 384
“SOS” button............................................451
Spare tire
Inflation pressure ............................... 569
Storage location ................................ 536
Spark plug ............................................... 566
Specifications ......................................... 562
Speedometer ............................................ 88
SRS airbags................................................ 38
Steering
Column lock release ........................207
Fluid.......................................................... 568
Steering wheel ........................................ 158
Adjustment ............................................. 158
Audio switches
* Meter control switches ...................... 93
Power easy access system .............. 151
Telephone switches
*Stop/tail lights
Replacing light bulbs ......................... 510
Storage feature ..................................... 422
Stuck
If the vehicle becomes stuck ....... 559
Sun visors ................................................. 432
Sunshade
Roof............................................................ 169
Rear door...............................................444 Switch
Audio remote control switches
* Automatic High Beam switch ..... 225
Center differential lock/unlock
switch ...................................................306
Climate concierge switch ............ 400
Cruise control switch ............ 271, 283
Door lock switch....................................117
Driving mode select switch .......... 286
Driving position memory
switches ................................................ 152
Emergency flashers switch .............514
Engine switch ......................................205
Fog light switch ................................... 229
Four-wheel drive control
switch ...................................................305
Garage door opener
switches .............................................. 446
Headlight cleaner switch ............... 238
Interior light switch............................ 420
Intuitive parking assist...................... 289
Ignition switch......................................205
LDA (Lane Departure Alert)....... 265
Light switches ...................................... 220
Meter control switches ...................... 93
Moon roof switches .......................... 168
Outside rear view mirror
switches ................................................ 162
Paddle shift switches.......................... 212
Personal light switch .......................... 421
Power back door switch.................. 123
Power door lock switch ..................... 117
Power window switch .......................165
