maintenance reset LEXUS LX570 2016 Owners Manual

96
LX570_OM_OM60N01U_(U) 2. Instrument cluster
The settings of some features can be changed by using the meter control
switches. ■
Setting procedure
For functions that can be enabled or disabled, the function switches between
on and off each time is pressed. ■
Setting items ●
LDA (Lane Departure Alert)
*Select to set up LDA. (  P. 585)
•Alert method
• Alert sensitivity
•Sway warning
• Sway sensitivity ●
BSM (Blind Spot Monitor)
*Select to set up BSM. (  P. 585)
•BSM on/off
• RCTA (Rear Cross Traffic Alert) on/off ●
Head-up display
*Select to set up Head-up display. (  P. 585)
• Display brightness/location
• Display content ●
Scheduled maintenance
Select to reset the message indicating maintenance is required. ●
Oil maintenance
Select to reset the engine oil maintenance informationSettings display

LX570_OM_OM60N01U_(U) 4656-2. Maintenance
6
Maintenance and care ■
Repair and replacement
It is recommended that genuine Lexus parts be used for repairs to ensure performance
of each system. If non-Lexus parts are used in replacement or if a repair shop other than
a Lexus dealer performs repairs, confirm the warranty coverage. ■
Resetting the message indicating main tenance is required (U.S.A. only)
After the required maintenance is performed according to the maintenance schedule,
please reset the message.
To reset the message, follow the procedures described below:
Press or of the meter control switches, select .
Press or of the meter control switches, select “Scheduled Maintenance” and
then press .
Select the “Yes” and press .
A message is displayed on the multi-information display. ■
Allow inspection and repairs to be performed by a Lexus dealer ●
Lexus technicians are well-trained specialists an d are kept up to date with the latest ser-
vice information. They are well informed about the operation of all systems on your
vehicle. ●
Keep a copy of the repair order. It proves that the maintenance that has been per-
formed is under warranty coverage. If any problem should arise while your vehicle is
under warranty, your Lexus dealer will promptly take care of it.
WA R N I N G ■
If your vehicle is not properly maintained
Improper maintenance could result in seriou s damage to the vehicle and possible seri-
ous injury or death. ■
Handling of the battery ●
Engine exhaust, some of its constituents , and a wide variety of automobile compo-
nents contain or emit chemicals known to th e State of California to cause cancer and
birth defects and other reproductive harm. Work in a well ventilated area. ●
Oils, fuels and fluids contained in vehicles as well as waste produced by component
wear contain or emit chemicals known to the State of California to cause cancer and
birth defects or other reproductive harm. Avoid exposure and wash any affected area
immediately. ●
Battery posts, terminals and related accessories contain lead and lead compounds
which are known to cause brain damage. Wash your hands after handling. (  P. 4 8 2 )1
2
3
4

476
LX570_OM_OM60N01U_(U) 6-3. Do-it-yourself maintenance■
Adding engine oil
If the oil level is below or near the
low level mark, add engine oil of the
same type as already in the engine.
Make sure to check the oil type and prepare the items needed before adding
oil.
Remove the oil filler cap by turning it coun terclockwise.
Add engine oil slowly, checking the dipstick.
Install the oil filler cap by turning it clockwise. ■
Engine oil consumption
A certain amount of engine oil will be consum ed while driving. In th e following situations,
oil consumption may increase, and engine o il may need to be refilled in between oil
maintenance intervals. ●
When the engine is new, for example directly after purchasing the vehicle or after
replacing the engine ●
If low quality oil or oil of an inappropriate viscosity is used ●
When driving at high engine speeds or with a heavy load, when towing, or when driving
while accelerating or de celerating frequently●
When leaving the engi ne idling for a long time, or when driving frequently through
heavy traffic ■
After changing the engine oil
The engine oil maintenance da ta should be reset. Perform the following procedures:
Press or of the meter control switches, select .
Press or of the meter control switch es, select “Oil Maintenance” and then
press .
Select the “Yes” and press .
A message is displayed on the multi-information display.Engine oil selection  P. 5 6 4
Oil quantity (Low  Full) 1.6 qt. (1.5 L, 1.3 Imp.qt.)
Items Clean funnel1
2
3
1
2
3
4

488
LX570_OM_OM60N01U_(U) 6-3. Do-it-yourself maintenance■
How to initialize the tire pressure warning system
Park the vehicle in safe place and turn the engine switch to OFF. Initialization cannot be performe d while the vehicle is moved.
Adjust the tire inflation pressure to the specified cold tire inflation pressure
level. (  P. 5 6 9 )Make sure to adjust the tire pressure to the specified cold tire inflation pressure
level. The tire pressure warning system w ill operate based on this pressure level.
Turn the engine switch to IGNITION ON mode.
Push and hold the tire pressure
warning reset switch until the tire
pressure warning light blinks
slowly 3 times. “--” will be displayed for inflation
pressure of each tire on the multi-
information display while the tire
pressure warning system determines
the position on the multi-information
display.
When position of each tire is determined, the inflation pressure of each tire will be
displayed on the multi-information display.
Drive the vehicle at approximately 25 mph (40 km/h) or more for approx-
imately 10 minutes. When initialization is complete , the inflation pressure of each tire will be displayed
on the multi-information display.
Initialization will take long er than approximately 10 minutes if the vehicle is
stopped for a long time, su ch as at traffic signals.
◆ Registering ID codes
The tire pressure warning valve and transmitter is equipped with a unique ID
code. When replacing a tire pressure warning valve and transmitter, it is nec-
essary to register the ID code of tire pressure warning valve and transmitter.
Have the ID code registered by your Lexus dealer. 1
2
3
4
5

490
LX570_OM_OM60N01U_(U) 6-3. Do-it-yourself maintenance■
Tire types ●
Summer tires
Summer tires are high-speed performance tires best suited to highway driving under
dry conditions. Since summer tires do not have the same traction performance as
snow tires, summer tires are inadequate for driving on snow-covered or icy roads. For
driving on snow-covered roads or icy roads, the use of snow tires is recommended.
When installing snow tires, be sure to replace all four tires. ●
All season tires
All season tires are designed to provide better traction in snow and to be adequate for
driving in most winter conditions, as well as for use year round. All season tires, how-
ever, do not have adequate traction performance compared with snow tires in heavy
or loose snow. Also, all season tires fall short in acceleration and handling perfor-
mance compared with summer tires in highway driving. ●
Snow tires
For driving on snow-covered roads or icy roads, we recommend using snow tires. If
you need snow tires, select tires of the same size, construction and load capacity as the
originally installed tires. Since your vehicle has radial tires as original equipment, make
sure your snow tires also have radial cons truction. Do not install studded tires without
first checking local regulations for possible re striction. Snow tires should be installed
on all wheels. (  P. 3 8 4 )■
Initializing the tire pressure warning system
Initialize the tire pressure warning system with the tire inflation pressure adjusted to the
specified level. ■
If the tread on snow tires wears down below 0.16 in. (4 mm)
The effectiveness of the tires as snow tires is lost. ■
If you press the tire pressure warning reset switch accidentally
If initialization is performed, adjust the tire inflation pressure to the specified level and ini-
tialize the tire pressure warning system again. ■
Situations in which the tire pressure warning system may not operate properly ●
In the following cases, the tire pressure warning system may not operate properly.
• If non-genuine Lexus wheels are used.
• A tire has been replaced with a tire that is not an OE (Original Equipment) tire.
• A tire has been replaced with a tire that is not of the specified size.
• Tire chains etc. are equipped.
• An auxiliary-supported run-flat tire is equipped.
• If a window tint that affects the radio wave signals is installed.
• If there is a lot of snow or ice on the vehicle, particularly around the wheels or wheel
housings.
• If the tire inflation pressure is extremely higher than the specified level.
• If the spare tire is in a location subject to poor radio wave signal reception.
• If a large metallic object wh ich can interfere with signal reception is put near the
spare tire.
• If tires not equipped with the tire pressure warning valves and transmitters are used.
• If the ID code on the tire pressure warning valves and transmitters is not registered
in the tire pressure warning computer.

LX570_OM_OM60N01U_(U) 4916-3. Do-it-yourself maintenance
6
Maintenance and care ●
Performance may be affected in the following situations.
• Near a TV tower, electric power plant, gas station, radio station, large display, air-
port or other facility th at generates strong radio waves or electrical noise
• When carrying a portable radio, cellular phone, cordless ph one or other wireless
communication device
If tire position information is not correctl y displayed due to the radio wave conditions,
the display may be corrected by driving and changing the radio wave conditions. ●
When the vehicle is parked, the time taken for the warning to start or go off could be
extended. ●
When tire inflation pressure declines rapidly for example when a tire has burst, the
warning may not function. ■
The initialization operation ●
Make sure to carry out initialization after adjusting the tire inflation pressure.
Also, make sure the tires are cold before carry ing out initialization or tire inflation pres-
sure adjustment. ●
If you have accidentally turned the engine swit ch off during initialization, it is not neces-
sary to press the reset switch again as init ialization will restart automatically when the
engine switch has been turned to IG NITION ON mode for the next time.●
If you accidentally press the reset switch when initialization is not necessary, adjust the
tire inflation pressure to the specified leve l when the tires are co ld, and conduct initial-
ization again. ●
While the position of each tire is being de termined and the inflation pressures are not
being displayed on the mu lti-information display, if the in flation pressure of a tire drops,
the tire pressure warning light will come on.

492
LX570_OM_OM60N01U_(U) 6-3. Do-it-yourself maintenance■
When the initialization of the tire pressure warning system has failed
Initialization can be completed in a few minutes. However, in the following cases, the set-
tings have not been recorded and the system will not operate properly. If repeated
attempts to record tire inflation pressure settings are unsuccessful, have the vehicle
inspected by your Lexus dealer. ●
When operating the tire pressure warning reset switch, the tire pressure warning light
does not blink 3 times and the setting mess age does not appear on the multi-informa-
tion display. ●
After carrying out the initializat ion procedure, the tire pressure warning light blinks for 1
minute then stays on after driving for about 20 minutes.
If the inflation of each tire is not displaye d after driving for approximately 1 hour, perform
the following procedure. ●
Park the vehicle in a safe place for approxim ately 20 minutes. Then drive straight (with
occasional left and right turns) at approximately 25 mph (40 km/h) or more for
approximately 10 to 20 minutes.
However, in the following situations, the tire inflation pressure will not be recorder and
the system will not operate properly. Perform initialization. ●
When operating the tire pressure warning reset switch, the tire pressure warning light
does not blink 3 times. ●
After performing initialization, the tire pres sure warning light blinks for 1 minute then
stays on after driving for about 20 minutes.
If the inflation pressure of each tire is st ill not displayed, have the vehicle inspected by
your Lexus dealer. ■
Tire pressure warning system certification 
For vehicles sold in the U.S.A., Hawaii, Guam and Puerto Rico

LX570_OM_OM60N01U_(U) 4936-3. Do-it-yourself maintenance
6
Maintenance and care 
For vehicles sold in Canada
WA R N I N G ■
Tire pressure warning system operation
The tire pressure warning system may not provide warning immediately if a tire bursts
or if sudden air leakage occurs. ■
When inspecting or replacing tires
Observe the following precautions to prevent accidents.
Failure to do so may cause damage to parts of the drive train, as well as dangerous han-
dling characteristics, which may lead to an accident resultin g in death or serious injury.●
Do not mix tires of different makes, models or tread patterns.
Also, do not mix tires of remarkably different treadwear. ●
Do not use tire sizes other than those recommended by Lexus. ●
Do not mix differently constructed tires (radial, bias-belted or bias-ply tires). ●
Do not mix summer, all season and snow tires. ●
Do not use tires that have been used on another vehicle.
Do not use tires if you do not know how they were used previously. ■
When initializing the tire pressure warning system
Do not operate the tire pressure warning reset switch without first adjusting the tire
inflation pressure to the specified level. Otherwise, the tire pressure warning light may
not come on even if the tire inflation pressu re is low, or it may come on when the tire
inflation pressure is actually normal.

5357-2. Steps to take in an emergency
LX570_OM_OM60N01U_(U) 7
When trouble arises ■
If a following message is shown, take appr opriate action and confirm that the message
has disappeared. (  P. 3 0 9 )●
“Crawl Not Available Select L4 an d Shift to [D] or [R] Position”●
“Crawl Not Available Check System Operation Conditions” ●
“Turn Assist Function Not Available Check System Operation Conditions” ●
“Turn Assist Function Not Available Activate Crawl Control”■
If “Maintenance Required Soon” is shown (U.S.A. only)
Indicates that all maintenance according to the driven distance on the maintenance
schedule
* should be performed soon.
Comes on approximately 4500 miles (7200 k m) after the message has been reset.
If necessary, perform maintenance.
* : Refer to the separate “Scheduled Maintenance Guide” or “Owner’s Manual Supple-
ment” for the maintenance interval applicable to your vehicle.■
If “Maintenance Required Visit Your Dealer” is shown (U.S.A. only)
Indicates that all maintenance is required to correspond to the driven distance on the
maintenance schedule
* .
Comes on approximately 5000 miles (8000 k m) after the message has been reset.
(The indicator will not work properly unless the message has been reset.)
Perform the necessary maintenance. Please reset the message after the maintenance is
performed (  P. 4 6 5 )
* : Refer to the separate “Scheduled Maintenance Guide” or “Owner’s Manual Supple-
ment” for the maintenance interval applicable to your vehicle.■
If “Oil Maintenance Required Soon” is shown
Indicates that the engine oil is scheduled to be changed. (The indicator will not work
properly unless the message has been reset.)
Check the engine oil, and change if necessar y. After changing the engine oil, the mes-
sage should be reset. (  P. 4 7 5 )■
If “Oil Maintenance Required Visit Your Dealer” is shown
Indicates that the engine oil should be chan ged. (The indicator will not work properly
unless the message has been reset.)
Check and change the engine oil, and oil filter by your Lexus dealer. After changing the
engine oil, the message should be reset. (  P. 4 7 5 )■
If “Visit Your Dealer” is shown
The system or part shown on the multi-info rmation display is malfunctioning. Have the
vehicle inspected by your Lexus dealer immediately. ■
Warning buzzer
In some cases, the buzzer may not be heard due to being in a noisy location or audio
sound.
NOTICE ■
While the engine oil level warning is displayed
Continued engine operation with low engine oil will damage the engine.

626 Alphabetical index
LX570_OM_OM60N01U_(U) Personal lights..........................................419
Switch.........................................................421
Wattage ................................................. 570
Power back door ....................................123
Power easy access system .................. 151
Power outlet ........................................... 434
Power steering
Fluid.......................................................... 568
Power windows .......................................165
Jam protection function ................... 165
Operation ............................................... 165
Window lock switch.......................... 165
Radar cruise control (dynamic
radar cruise control with
full-speed range) ................................. 271
Radiator .................................................... 479
Radio
* Rear air conditioning system .............412
Rear seat ....................................................142
Adjustment ..............................................142
Folding the third seats ...................... 145
Tumbling the second seats ............ 143
Rear side marker lights ...................... 220
Light switch ...........................................220
Replacing light bulbs ......................... 510
Rear turn signal lights ...........................216
Replacing light bulbs ......................... 510
Turn signal lever .................................. 216
Rear view mirror
Inside rear view mirror ..................... 160
Outside rear view mirrors .............. 162
Rear view monitor system
*Rear window defogger ...................... 407 Rear window wiper ............................. 235
Refueling.................................................. 239
Capacity ................................................. 564
Fuel types............................................... 564
Opening the fuel tank cap ............ 239
Remote touch/12.3-inch
display .................................................... 394
Replacing
Electronic key battery .....................503
Fuses ....................................................... 505
Light bulbs............................................ 508
Tires ..........................................................536
Reporting safety defects for
U.S. owners ......................................... 600
Resetting the message indicating
maintenance is required ................ 465
Safety Connect ....................................... 451
Scheduled maintenance ....................464
Seat belts .................................................... 30
Adjusting the seat belt........................ 33
Automatic Locking Retractor ........ 34
Child restraint system
installation ............................................. 63
Cleaning and maintaining the
seat belt ............................................... 462
Emergency locking retractor ......... 34
How to wear your seat belt............. 28
How your child should wear
the seat belt .......................................... 34
Pregnant women, proper seat
belt use ................................................... 35
Reminder light and buzzer ........... 526
Seat belt extender ................................ 34
Seat belt pretensioners ...................... 33
SRS warning light .............................. 524R
S
