reset LEXUS LX570 2016 Owner's Manual

5297-2. Steps to take in an emergency
LX570_OM_OM60N01U_(U)
7
When trouble arises
■When the tire pressure warning light comes on
Inspect the tires to check if a tire is punctured.
If a tire is punctured: P. 5 3 6
If none of the tires are punctured:
Turn the engine switch off then turn it to IGNITION ON mode. Check if the tire pressure
warning light comes on or flashes.
If the tire pressure warning light comes on
After the temperature of the tires has lowere d sufficiently, check the inflation pressure
of each tire and adjust th em to the specified level.
If the warning light does not turn off even after several minutes have elapsed, check
that the inflation pressure of each tire is at the specified level and perform initialization.
(  P. 4 8 7 )
If the warning light does not turn off even after several minutes have elapsed, have the
vehicle inspected by your Lexus dealer immediately.
If the tire pressure warning light flashes for 1 minute then stay on
There may be a malfunction in the tire pressure warning system. Have the vehicle
inspected by your Lexus dealer immediately.
■The tire pressure warning light may turn on due to natural causes
The tire pressure warning light may turn on du e to natural causes such as natural air leaks
or tire inflation pressure changes caused by temperature. In this case, adjusting the tire
inflation pressure will turn off the warning light (after a few minutes).
■When a tire is replaced with a spare tire
The spare tire is also equipped with the tire pressure warning valve and transmitter. The
tire pressure warning light will turn on if the tire inflation pressure of the spare tire is low. If
a tire goes flat, even though the flat tire is replaced with the spare tire, the tire pressure
warning light does not turn off. Replace the spar e tire with the repaired tire and adjust the
proper tire inflation pressure. The tire pressu re warning light will turn off after a few min-
utes.
■Conditions that the tire pressure warning system may not function properly
 P. 4 9 0
■Changing the engine oil
Make sure to reset oil change system
■Warning buzzer
In some cases, the buzzer may not be heard due to being in a noisy location or audio
sound.
1
2

5357-2. Steps to take in an emergency
LX570_OM_OM60N01U_(U)
7
When trouble arises
■If a following message is shown, take appr opriate action and confirm that the message
has disappeared. ( P. 3 0 9 )
●“Crawl Not Available Select L4 an d Shift to [D] or [R] Position”
●“Crawl Not Available Check System Operation Conditions”
●“Turn Assist Function Not Available Check System Operation Conditions”
●“Turn Assist Function Not Available Activate Crawl Control”
■If “Maintenance Required Soon” is shown (U.S.A. only)
Indicates that all maintenance according to the driven distance on the maintenance
schedule
* should be performed soon.
Comes on approximately 4500 miles (7200 k m) after the message has been reset.
If necessary, perform maintenance.
*: Refer to the separate “Scheduled Maintenance Guide” or “Owner’s Manual Supple-
ment” for the maintenance interval applicable to your vehicle.
■If “Maintenance Required Visit Your Dealer” is shown (U.S.A. only)
Indicates that all maintenance is required to correspond to the driven distance on the
maintenance schedule
*.
Comes on approximately 5000 miles (8000 k m) after the message has been reset.
(The indicator will not work properly unless the message has been reset.)
Perform the necessary maintenance. Please reset the message after the maintenance is
performed ( P. 4 6 5 )
*: Refer to the separate “Scheduled Maintenance Guide” or “Owner’s Manual Supple-
ment” for the maintenance interval applicable to your vehicle.
■If “Oil Maintenance Required Soon” is shown
Indicates that the engine oil is scheduled to be changed. (The indicator will not work
properly unless the message has been reset.)
Check the engine oil, and change if necessar y. After changing the engine oil, the mes-
sage should be reset. ( P. 4 7 5 )
■If “Oil Maintenance Required Visit Your Dealer” is shown
Indicates that the engine oil should be chan ged. (The indicator will not work properly
unless the message has been reset.)
Check and change the engine oil, and oil filter by your Lexus dealer. After changing the
engine oil, the message should be reset. ( P. 4 7 5 )
■If “Visit Your Dealer” is shown
The system or part shown on the multi-info rmation display is malfunctioning. Have the
vehicle inspected by your Lexus dealer immediately.
■Warning buzzer
In some cases, the buzzer may not be heard due to being in a noisy location or audio
sound.
NOTICE
■While the engine oil level warning is displayed
Continued engine operation with low engine oil will damage the engine.

5457-2. Steps to take in an emergency
LX570_OM_OM60N01U_(U)
7
When trouble arises
Reinstall the wheel ornament.
Lay down the tire with the outer side
facing up, and install the spare wheel
cover and holding bracket.
Raise the tire.
Stow the tools and jack securely, and replace all covers.
■After completing the tire change
The tire pressure warning system must be reset. ( P. 4 8 7 )
5
20-inch tires21-inch tires
Remove the center wheel ornament
from the flat tire by pushing from the
reverse side, and reinstall it. Make sure to push the center part of
the wheel ornament.
Stowing the flat/spare tire, jack and tools
1
2
3

LX570_OM_OM60N01U_(U)
5958-2. Customization
8
Vehicle specifications
■Multi-information display (P. 9 1 )
*1: The default setting varies according to countries.
*2: Some status screens cannot be registered (indicated on the multi-information display)
*3: 2 of the following items: current fuel consumption, average fuel economy (after reset),
average fuel economy (after refuel), average fuel economy (after start), average vehi-
cle speed (after reset), average vehicle speed (after start), distance (driving range),
distance (after start), elapsed time (after reset), elapsed time (after start), blank
FunctionDefault settingCustomized setting
LanguageEnglishFrenchOO–Spanish
Units*1miles (MPG US)
miles
(MPG Imperial)
OO–km (L/100 km)
km (km/L)
Eco Driving Indicator Light On Off – O –
switch settingsDrive
information 1Desired status screen
*2–O–
Drive information screen dis-
played on the first screen of

(Drive information 1)Current fuel
consumption
*3–O–Average fuel economy
(after reset)
Drive information screen dis-
played on the second screen
of
(Drive information 2)Distance (range)
*3–O–Average speed
(after reset)
Po p - u p d i s p l a yOnOff–O–
Accent colorColor 1Color 2OO–
123

626Alphabetical index
LX570_OM_OM60N01U_(U)
Personal lights..........................................419Switch.........................................................421
Wattage ................................................. 570
Power back door ....................................123
Power easy access system .................. 151
Power outlet ........................................... 434
Power steering Fluid.......................................................... 568
Power windows .......................................165 Jam protection function ................... 165
Operation ............................................... 165
Window lock switch.......................... 165
Radar cruise control (dynamic radar cruise control with
full-speed range) ................................. 271
Radiator .................................................... 479
Radio
*
Rear air conditioning system .............412
Rear seat ....................................................142 Adjustment ..............................................142
Folding the third seats ...................... 145
Tumbling the second seats ............ 143
Rear side marker lights ...................... 220 Light switch ...........................................220
Replacing light bulbs ......................... 510
Rear turn signal lights ...........................216 Replacing light bulbs ......................... 510
Turn signal lever .................................. 216
Rear view mirror Inside rear view mirror ..................... 160
Outside rear view mirrors .............. 162
Rear view monitor system
*
Rear window defogger ...................... 407 Rear window wiper ............................. 235
Refueling.................................................. 239
Capacity ................................................. 564
Fuel types............................................... 564
Opening the fuel tank cap ............ 239
Remote touch/12.3-inch display .................................................... 394
Replacing Electronic key battery .....................503
Fuses ....................................................... 505
Light bulbs............................................ 508
Tires ..........................................................536
Reporting safety defects for U.S. owners ......................................... 600
Resetting the message indicating maintenance is required ................ 465
Safety Connect ....................................... 451
Scheduled maintenance ....................464
Seat belts .................................................... 30 Adjusting the seat belt........................ 33
Automatic Locking Retractor ........ 34
Child restraint system installation ............................................. 63
Cleaning and maintaining the seat belt ............................................... 462
Emergency locking retractor ......... 34
How to wear your seat belt............. 28
How your child should wear the seat belt .......................................... 34
Pregnant women, proper seat belt use ................................................... 35
Reminder light and buzzer ........... 526
Seat belt extender ................................ 34
Seat belt pretensioners ...................... 33
SRS warning light .............................. 524
R
S

629Alphabetical index
LX570_OM_OM60N01U_(U)
Rear window wiper and washer switch...................................235
Rear window and outside rear view mirror defoggers
switch....................................................407
Seat heater switches...........................417
Seat ventilator switches ....................417
“SOS” button......................................... 451
Talk switch
*
Telephone switches*
Tilt and telescopic steering control switch .................................... 158
Tire pressure warning reset switch................................................... 488
Vehicle-to-vehicle distance button ................................................... 277
VSC OFF switch .............................. 380
Window lock switch.......................... 165
Windshield wipers and washer switch.....................................231
Wireless charger power supply switch ....................................436
Tachometer ............................................... 88
Tail lights................................................... 220 Light switch ...........................................220
Replacing light bulbs ......................... 510
Talk switch
*
Telephone switch*
Theft deterrent system Alarm........................................................... 78
Immobilizer system .............................. 76 Tire inflation pressure......................... 569
Maintenance data..............................569
Warning light ....................................... 526
Tire information .....................................574 Glossary................................................ 580
Size ........................................................... 576
Tire identification number ............. 575
Uniform Tire Quality Grading.... 578
Tire pressure warning system ..........487 Function .................................................. 487
Initializing ............................................... 487
Installing tire pressure warning valves and transmitters................ 487
Registering ID codes ...................... 488
Tire pressure warning reset switch .................................................. 488
Warning light ....................................... 526
Tires ........................................................... 486 Chains .....................................................385
Checking ...............................................486
If you have a flat tire ..........................536
Inflation pressure................................ 495
Replacing ............................................... 536
Rotating tires ........................................486
Size ...........................................................569
Snow tires .............................................. 384
Spare tire................................... 536, 569
Tire pressure warning system ..... 487
Warning light ....................................... 526
Tools .......................................................... 536
Total load capacity............................... 562
T
*: Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.
