seat memory LEXUS LX570 2016 Owners Manual

TABLE OF CONTENTS2
LX570_OM_OM60N01U_(U)
For your information ................................... 8
Reading this manual................................... 12
How to search ..............................................13
Pictorial index ............................................... 14
1-1. For safe useBefore driving................................. 26
For safety drive............................... 28
Seat belts .......................................... 30
SRS airbags ..................................... 38
Front passenger occupant classification system....................51
Safety information for children ...........................................57
Child restraint systems ............... 58
Installing child restraints............. 63
Exhaust gas precautions .............75
1-2. Theft deterrent system Engine immobilizer system........ 76
Alarm ................................................. 78
2. Instrument cluster Warning and indicators lights ................................................ 82
Gauges and meters .....................88
Multi-information display ............91
Head-up display .......................... 100
Fuel consumption information ................................. 105 3-1. Key information
Keys .................................................... 110
3-2. Opening, closing and locking the doors
Side doors........................................ 115
Back door ....................................... 122
Smart access system with push-button start ......................132
3-3. Adjusting the seats Front seats...................................... 140
Rear seats........................................ 142
Driving position memory........... 151
Head restraints .............................155
3-4. Adjusting the steering wheel and mirrors
Steering wheel ............................. 158
Inside rear view mirror ............. 160
Outside rear view mirrors........ 162
3-5. Opening, closing the windows and moon roof
Power windows.............................165
Moon roof ...................................... 168
1For safety and security
2Instrument cluster
3Operation of each
component

109
LX570_OM_OM60N01U_(U)
3
Operation of
each component
3-1. Key information
Keys ....................................................110
3-2. Opening, closing and locking the doors
Side doors ........................................ 115
Back door........................................122
Smart access system with push-button start...................... 132
3-3. Adjusting the seats Front seats ...................................... 140
Rear seats ........................................142
Driving position memory ........... 151
Head restraints ............................ 155
3-4. Adjusting the steering wheel and mirrors
Steering wheel ............................. 158
Inside rear view mirror.............. 160
Outside rear view mirrors ........162
3-5. Opening, closing the windows and moon roof
Power windows ............................ 165
Moon roof ...................................... 168

151
LX570_OM_OM60N01U_(U)3-3. Adjusting the seats
3
Operation of each component
Driving position memory
The seat and steering wheel are automatically adjusted to allow the driver to
enter and exit the vehicle easily.
When all of the following have been
performed, the driver’s seat and steer-
ing wheel are automatically adjusted to
a position that allows driver to enter
and exit the vehicle easily.
• The shift lever has been shifted to P.
• The engine switch has been turned off.
• The driver’s seat belt has been unfas- tened.
When any of the following has been perf ormed, the driver’s seat and steering
wheel automatically return to their original positions. • The engine switch has been turn ed to ACCESSORY mode or IGNITION
ON mode.
• The driver’s seat belt has been fastened.
■Operation of the power easy access system
When exiting the vehicle, the power easy acc ess system may not operate if the seat is
already close to the rearmost position, etc.
■Customization
The seat movement amount settings of the power easy access system can be custom-
ized. (Customizable features: P. 585)
This feature automatically adjusts the dr iver’s seats, steering wheel and out-
side rear view mirrors to make enteri ng and exiting the vehicle easier or to
suit your preferences.
Power easy access system

152
LX570_OM_OM60N01U_(U)3-3. Adjusting the seats
Your preferred driving position (the posi
tion of the driver’s seat, steering wheel
and outside rear view mirrors) can be entered into the computer’s memory and
recalled with the touch of a button. It is also possible to set this function to acti-
vate automatically when the doors are unlocked.
Three different driving positions can be recorded into memory.
■Recording procedure
Check that the shift lever is in P.
Turn the engine switch to IGNITION ON mode.
Adjust the driver’s seat, steering wheel, and outside rear view mirrors to the
desired positions.
While pressing the “SET” button,
or within 3 seconds after the
“SET” button is pressed, press
button “1”, “2” or “3” until the
buzzer sounds.
If the selected button has already
been preset, the previously recorded
position will be overwritten.
■Recall procedure
Check that the shift lever is in P.
Turn the engine switch to IGNITION ON mode.
Press one of the buttons for the
driving position you want to recall
until the buzzer sounds.
Driving position memory
1
2
3
4
1
2
3

LX570_OM_OM60N01U_(U)
1533-3. Adjusting the seats
3
Operation of each component
■To stop the position recall operation part-way through
Perform any of the following:
●Press the “SET” button.
●Press button “1”, “2” or “3”.
●Operate any of the seat adjustment switches (only cancels seat position recall).
●Operate the tilt and telescopic steering co ntrol switch (only cancels steering wheel
position recall).
■Operating the driving position memory after turning the engine switch off
Recorded seat positions can be activated up to 180 seconds after the driver’s door is
opened and another 60 seconds after it is closed again.
■If the battery is disconnected
The memorized positions must be reset beca use the computer’s memory is erased when
the battery is disconnected.
Each electronic key can be registered to recall your preferred driving position.
■Registering procedure
Record your driving position to button “1”, “2” or “3” before performing the
following:
Carry only the key you want to regist er, and then close the driver’s door.
If 2 or more keys are in the vehicle, the driving position cannot be recorded
properly.
Check that the shift lever is in P.
Turn the engine switch to IGNITION ON mode.
Recall the driving position that you want to record.
While pressing the recalled but-
ton, press and hold the door lock
switch (either lock or unlock) until
the buzzer sounds.
If the button could not be registered,
the buzzer sounds continuously for
approximately 3 seconds.
Memory recall function (driver’s side only)
1
2
3
4

154
LX570_OM_OM60N01U_(U)3-3. Adjusting the seats
■Recall procedure
Carry the electronic key that has been registered to the driving position,
and then unlock and open the driver’s door using the smart access system
with push-button start or wireless remote control.
The driving position will move to the reco rded position (not including the steering
wheel). However, the seat will move to a po sition slightly behind the recorded posi-
tion in order to make entering the vehicle easier.
If the driving position is in a position th at has already been recorded, the seat and
outside rear view mirrors will not move.
Turn the engine switch to ACCESSORY mode or IGNITION ON mode,
or fasten a seat belt.
The seat and steering wheel will move to the recorded position.
■Cancelation procedure
Carry only the key you want to cancel and then close the driver’s door.
If 2 or more keys are in the vehicle, the driving position cannot be canceled
properly.
Turn the engine switch to IGNITION ON mode.
While pressing the “SET” button, press and hold the door lock switch
(either lock or unlock) unt il the buzzer sounds twice.
If the button could not be canceled, the buzzer sounds continuously for approxi-
mately 3 seconds.
■Recalling the driving position using the memory recall function
●Different driving positions can be registered for each electronic key. Therefore, the
driving position that is recalled may be different depending on the key being carried.
●If a door other than the driver’s door is unlocked with the smart access system with
push-button start, the driving position cannot be recalled. In this case, press the driving
position button which has been set.
■Customization
The unlock door settings of the memory recall function can be customized.
(Customizable features: P. 585)
WA R N I N G
■Seat adjustment caution
Take care during seat adjustment so that th e seat does not strike the rear passenger or
squeeze your body against the steering wheel.
1
2
1
2

1593-4. Adjusting the steering wheel and mirrors
3
Operation of each component
LX570_OM_OM60N01U_(U)
■The steering wheel can be adjusted when
The engine switch is in ACCESSORY or IGNITION ON mode
*.
*: If the driver’s seat belt is fastened, the steering wheel can be adjusted regardless of
engine switch mode.
■Automatic adjustment of the steering position
A desired steering position can be entered to memory and recalled automatically by the
driving position memory system. ( P. 1 5 1 )
■Power easy access system
The steering wheel and driver’s seat move in accordance with engine switch mode and
the driver’s seat belt condition. ( P. 1 5 1 )
WA R N I N G
Do not adjust the steering wheel while driving.
Doing so may cause the driver to mishandle the vehicle and cause an accident, result-
ing in death or serious injury.

592
LX570_OM_OM60N01U_(U)8-2. Customization
■Rear window wiper and washer (
P. 2 3 5 )
■Driving position memory ( P. 151)
■Outside rear view mirrors ( P. 1 6 2 )
FunctionDefault settingCustomized
setting
Drip prevention functionOnOff——O
Rear window wiper opera-
tion linked with washerOnOff——O
Linked operation when the
shift lever in R positionOnOff——O
Times of the linked opera-
tion when the shift lever in R
position
OnceContinuously——O
123
FunctionDefault settingCustomized setting
Driver’s seat movement
when exiting the vehicleStandardOffO—OPa r t i a l
Selection the door linking
driving position memory
with door unlock operation
Driver’s doorAll doors——O
123
FunctionDefault settingCustomized setting
Automatic folding/extend-
ing operationLinked to locking/unlocking of the doorsOff
——OLinked to engine switch operation
Linked mirror function
when reversingOnOff——O
123

620Alphabetical index
LX570_OM_OM60N01U_(U)
Drive information .................................... 94
Driver’s seat belt reminder light ..... 526
Driver’s seat position memory ........... 151
Driving......................................................... 174Break-in tips .......................................... 175
Correct posture..................................... 28
Driving in the rain ................................ 175
Driving mode select switch ......... 286
Off-road precautions.......................387
Procedures .............................................174
Winter drive tips ................................ 384
Driving position memory...................... 151 Driving position memory .................. 151
Memory recall function.................... 152
Power easy access system .............. 151
DVD player
*
Dynamic radar cruise control with full-speed rangeFunction .................................................... 271
Eco Driving Indicator Light ................. 87
EDR (Event data recorder) ...................10
Electronic key ........................................... 110 Battery-saving function .................... 134
If the electronic key does not operate properly............................ 550
Replacing the battery ...................... 503 Emergency, in case of
If a warning buzzer sounds .......... 524
If a warning light turns on .............. 524
If a warning message is displayed ............................................ 532
If the electronic key does not operate properly ........................... 550
If the engine will not start ............... 547
If the shift lever cannot be shifted from P ................................... 549
If the vehicle battery is discharged.........................................553
If you have a flat tire ..........................536
If you lose your keys.................... 112, 114
If you think something is wrong................................................... 522
If your vehicle becomes stuck.....559
If your vehicle has to be stopped in an emergency.............................. 515
If your vehicle needs to be towed .....................................................516
If your vehicle overheats ................556
Emergency flashers .............................. 514
E

622Alphabetical index
LX570_OM_OM60N01U_(U)
Front passenger occupant classification system ..............................51
Front passenger’s seat belt reminder light ..................................... 526
Front seats ................................................ 140 Adjustment ............................................. 140
Cleaning .................................................. 461
Correct driving posture .................... 28
Driving position memory .................. 151
Head restraints ..................................... 155
Power easy access system .............. 151
Seat heaters ............................................417
Seat ventilators ......................................417
Front side marker lights ..................... 220 Light switch ...........................................220
Replacing light bulbs ......................... 510
Front turn signal lights ..........................216 Turn signal lever .................................. 216
Replacing light bulbs ......................... 510
Fuel ............................................................... 571 Capacity ................................................ 564
Fuel gauge ............................................... 88
Fuel pump shut off system.............523
Gas station inform ation ..................632
Information ............................................. 571
Refueling.................................................239
Type ......................................................... 564
Warning light .......................................526 Fuel consumption information..........105
Fuel filler door........................................ 239
Opener ................................................... 240
Refueling ................................................ 239
Fuel pump shut off system ................ 523
Fuses.......................................................... 505
Gas station information ......................632
Garage door opener...........................446
Gauges........................................................ 88
Glove box ................................................423
Hands-free system (for cellular phone)
*
Head restraints........................................ 155
Headlight cleaner ................................ 238
Headlights ............................................... 220 Automatic headlight leveling ....... 223
Automatic High Beam system ... 224
Light switch........................................... 220
Replacing light bulbs ........................ 510
Wattage ................................................. 570
Head-up display .................................... 100
Heated steering wheel ........................ 416
Heaters Front automatic air conditioning system ....................................................401
Outside rear view mirrors ............ 407
Seat heaters ............................................ 417
High mounted stoplight Replacing ................................................ 510
G
H
