LEXUS LX570 2018 Owners Manual

LX570_OM_OM60Q78U_(U) 4816-3. Do-it-yourself maintenance
6
Maintenance and care ■
Fluid level
The fluid level should be within the appropriate range.
Full (when cold)
Add fluid (when cold)
Full (when hot)
Add fluid (when hot)
Hot: The vehicles has been driven around 50 mph (80 km/h) for 20 min-
utes, or slightly longer in frigid temperatures.
(Fluid temperature, 140 ° F - 175 ° F [60 ° C - 80 ° C]).
Cold: The engine has not been run for about 5 hours.
(Room temperature, 50 ° F - 85 ° F [10 ° C - 30 ° C]).■
Checking the fluid level
Make sure to check the fluid type and prepare the necessary items.
Clean all dirt off the reservoir.
Remove the cap by turnin g it counterclockwise.
Wipe the dipstick clean.
Reinstall the cap and remove it again.
Check the fluid level.Power steering fluid 1
2
3
4
Fluid type Automatic transmission fluid DEXRON ®
II or III
Items Rag or paper, clean funnel (only for adding fluid)1
2
3
4
5

482
LX570_OM_OM60Q78U_(U) 6-3. Do-it-yourself maintenance
Check the battery as follows. ■
Battery exterior
Make sure that the battery terminals are not corroded and that there are no
loose connections, cracks, or loose clamps.
Terminals
Hold-down clamp WARNING ■
When checking the reservoir
Take care as the reservoir may be hot.
NOTICE ■
When adding fluid
Avoid overfilling, or the powe r steering may be damaged.■
After replacing the reservoir cap
Check the steering box case, vane pump an d hose connections for leaks or damage.
Battery 1
2

LX570_OM_OM60Q78U_(U) 4836-3. Do-it-yourself maintenance
6
Maintenance and care ■
Before recharging
When recharging, the battery produces hydrogen gas which is flammable and explosive.
Therefore, observe the following before recharging: ●
If recharging with the battery installed on the vehicle, be sure to disconnect the ground
cable. ●
Make sure the power switch on the charge r is off when connecting and disconnecting
the charger cables to the battery. ■
After recharging/reconnecting the battery
The engine may not start. Follow the procedure below to initialize the system.
Shift the shift lever to P.
Open and close any of the doors.
Restart the engine. ●
Unlocking the doors using the smart access system with push-button start may not be
possible immediately after reconnecting the battery. If this happens, use the wireless
remote control or the mechanical key to lock/unlock the doors.●
Start the engine with the engine switch in ACCESSORY mode. The engine may not
start with the engine switch turned off. However, the engine will operate normally from
the second attempt. ●
The engine switch mode is recorded by the vehicle. If the battery is reconnected, the
vehicle will return the engine switch mode to the status it was in before the battery was
disconnected. Make sure to turn off the engine before disconnect the battery. Take
extra care when connecting the battery if the engine switch mode prior to discharge is
unknown.
If the engine will not start even after multiple attempts, contact your Lexus dealer.
WARNING ■
Chemicals in the battery
Batteries contain poisonous and corrosive sulfuric acid and may produce hydrogen
gas which is flammable and explosive. To redu ce the risk of death or serious injury, take
the following precautions while working on or near battery:●
Do not cause sparks by touching the battery terminals with tools. ●
Do not smoke or light a match near the battery. ●
Avoid contact with eyes, skin and clothes. ●
Never inhale or swallow electrolyte. ●
Wear protective safety glasses when working near the battery. ●
Keep children away from the battery. ■
Where to safely charge the battery
Always charge the battery in an open area . Do not charge the battery in a garage or
closed room where there is not sufficient ventilation. 1
2
3

484
LX570_OM_OM60Q78U_(U) 6-3. Do-it-yourself maintenance
WARNING ■
How to recharge the battery
Only perform a slow charge (5A or less). The battery may explode if charged at a
quicker rate. ■
Emergency measures regarding electrolyte ●
If electrolyte gets in your eyes
Flush your eyes with clean water for at least 15 minutes and get immediate medical
attention. If possible, continue to apply water with a sponge or cloth while traveling to
the nearest medical facility. ●
If electrolyte gets on your skin
Wash the affected area thoroughly. If you fe el pain or burning, get medical attention
immediately. ●
If electrolyte gets on your clothes
It can soak through clothing on to your s kin. Immediately take off the clothing and fol-
low the procedure above if necessary. ●
If you accidentally swallow electrolyte
Drink a large quantity of water or milk. Get emergenc y medical attention immedi-
ately.
NOTICE ■
When recharging the battery
Never recharge the battery while the engine is running. Also, be sure all accessories
are turned off.

LX570_OM_OM60Q78U_(U) 4856-3. Do-it-yourself maintenance
6
Maintenance and care If any washer does not work or “Wind-
shield Washer Fluid Low” appears on
the multi-information display, the
washer tank may be empty. Add
washer fluid.Washer fluid
WARNING ■
When adding washer fluid
Do not add washer fluid when the engine is hot or running as washer fluid contains
alcohol and may catch fire if spilled on the engine etc.
NOTICE ■
Do not use any fluid other than washer fluid
Do not use soapy water or engine antifreeze instead of washer fluid.
Doing so may cause streaking on the vehicle’ s painted surface, as well as damaging the
pump leading to problems of the washer fluid not spraying.■
Diluting washer fluid
Dilute washer fluid with water as necessary.
Refer to the freezing temperatures listed on the label of the washer fluid bottle.

486
LX570_OM_OM60Q78U_(U) 6-3. Do-it-yourself maintenance
Tires Check if the treadwear indicators are showing on the tires. Also check the tires
for uneven wear, such as excessive wear on one side of the tread. Check the
spare tire condition and pressure if not rotated.
New tread
Worn tread
Treadwear indicator The location of treadwear indicators is shown by a “TWI” or “ ” mark, etc., molded
on the sidewall of each tire.
Replace the tires if the treadwear indicators are showing on a tire.
Rotate the tires in the order shown. To equalize tire wear and extend tire life,
Lexus recommends that tire rotation is
carried out at the same interval as tire
inspection.
Do not fail to initialize the tire pressure
warning system after tire rotation.Replace or rotate tires in accordance with maintenance schedules and tread-
wear.
Checking tires
Tire rotation 1
2
3
Front

LX570_OM_OM60Q78U_(U) 4876-3. Do-it-yourself maintenance
6
Maintenance and care Your Lexus is equipped with a tire pressu re warning system that uses tire pres-
sure warning valves and transmitters to detect low tire inflation pressure before
serious problems arise. ●
If the tire pressure drops below a predet ermined level, the driver is warned by
a screen display and a warning light. ( → P. 522)●
The tire pressure detected by the
tire pressure warning system can be
displayed on the multi-information
display. ( → P. 91)
◆ Installing tire pressure warning valves and transmitters
When replacing tires or wheels, tire pr essure warning valv es and transmitters
must also be installed.
When new tire pressure wa rning valves and transmitters are installed, new ID
codes must be registered in the tire pressure warning computer and the tire
pressure warning system must be initia lized. Have tire pressure warning valve
and transmitter ID codes registered by your Lexus dealer. ( → P. 488)
◆ Initializing the tire pressure warning system ■
The tire pressure warning system must be initialized in the following circum-
stances: ●
When rotating the tires in above situation. ●
When the set tire pressure has been changed before towing. ( → P. 565)
When the tire pressure warning system is initialized, the current tire inflation
pressure is set as the benchmark pressure.Tire pressure warning system

488
LX570_OM_OM60Q78U_(U) 6-3. Do-it-yourself maintenance■
How to initialize the tire pressure warning system
Park the vehicle in safe place and turn the engine switch to off. Initialization cannot be performed while the vehicle is moved.
Adjust the tire inflation pressure to th e specified cold tire inflation pressure
level. ( → P. 565)Make sure to adjust the tire pressure to the specified cold tire inflation pressure
level. The tire pressure warning system will operate based on this pressure level.
Turn the engine switch to IGNITION ON mode.
Push and hold the tire pressure
warning reset switch until the tire
pressure warning light blinks
slowly 3 times. “--” will be displayed for inflation
pressure of each tire on the multi-
information displa y while the tire
pressure warning system determines
the position of each tire.
When position of each tire is determined, the inflation pressure of each tire will be
displayed on the mult i-information display.
Drive the vehicle at approximately 25 mph (40 km/h) or more for approx-
imately 10 minutes. When initialization is comple te, the inflation pressure of each tire will be displayed
on the multi-information display.
Initialization will take long er than approximately 10 minutes if the vehicle is
stopped for a long time, su ch as at traffic signals.
◆ Registering ID codes
The tire pressure warning valve and tran smitter is equipped with a unique ID
code. When replacing a tire pressure warning valve and transmitter, it is nec-
essary to register the ID code of tire pressure warning valve and transmitter.
Have the ID code registered by your Lexus dealer. 1
2
3
4
5

LX570_OM_OM60Q78U_(U) 4896-3. Do-it-yourself maintenance
6
Maintenance and care ■
When to replace your vehicle’s tires
Tires should be replaced if: ●
The treadwear indicators are showing on a tire. ●
You have tire damage such as cuts, splits, cracks deep enou gh to expose the fabric, and
bulges indicating internal damage ●
A tire goes flat repeatedly or cannot be properly repaired due to the size or location of
a cut or other damage
If you are not sure, consult with your Lexus dealer. ■
Replacing tires and wheels
If the ID code of the tire pressure warning valve and transmitter is not registered, the tire
pressure warning system will not work proper ly. After driving for about 20 minutes, the
tire pressure warning light comes on after blinking for 1 minute to indicate a system mal-
function. ■
Tire life
Any tire over 6 years old must be checked by a qualified technician even if it has seldom
or never been used or damage is not obvious.■
Routine tire inflation pressure checks
The tire pressure warning syst em does not replace routine tire inflation pressure checks.
Make sure to check tire inflat ion pressure as part of your routine of daily vehicle checks.■
Maximum load of tire
Check that the number given by dividing the maximum load by 1.10 of the replacement
tire is greater than 1/2 of the Gross Axle We ight Ratings (GAWR) of either the front axle
or the rear axle, wh ichever is greater.
For the GAWR, see the Ce rtification Label. For
the maximum load of the tire, see the load limit
at maximum cold tire inflation pressure men-
tioned on the sidewall of the tire. ( → P. 569)

490
LX570_OM_OM60Q78U_(U) 6-3. Do-it-yourself maintenance■
Tire types ●
Summer tires
Summer tires are high-speed performance ti res best suited to highway driving under
dry conditions. Since summer tires do not have the same traction performance as
snow tires, summer tires are inadequate for driving on snow-covered or icy roads. For
driving on snow-covered roads or icy road s, the use of snow tires is recommended.
When installing snow tires, be sure to replace all four tires.●
All season tires
All season tires are designed to provide better traction in snow and to be adequate for
driving in most winter conditions, as well as for use year round. All season tires, how-
ever, do not have adequate traction perfor mance compared with snow tires in heavy
or loose snow. Also, all season tires fall short in acceleration and handling perfor-
mance compared with summer tires in highway driving.●
Snow tires
For driving on snow-covered roads or icy roads, we recommend using snow tires. If
you need snow tires, select ti res of the same size, construction and load capacity as the
originally installed tires. Since your vehicle has radial tires as or iginal equipment, make
sure your snow tires also have radial cons truction. Do not install studded tires without
first checking local regulations for possible re striction. Snow tires should be installed
on all wheels. ( → P. 382)■
Initializing the tire pressure warning system
Initialize the tire pressure warn ing system with the tire inflat ion pressure adjusted to the
specified level. ■
If the tread on snow tires wears down below 0.16 in. (4 mm)
The effectiveness of the tire s as snow tires is lost.■
If you press the tire pressure warning reset switch accidentally
If initialization is performed, adjust the tire inflation pressure to the specified level and ini-
tialize the tire pressure warning system again.■
Situations in which the tire pressure warning system may not operate properly ●
In the following cases, the tire pressure warning system may not operate properly.
• If non-genuine Lexus wheels are used.
• A tire has been replaced with a tire that is not an OE (Original Equipment) tire.
• A tire has been replaced with a tire that is not of the specified size.
• Tire chains etc. are equipped.
• An auxiliary-supported run-flat tire is equipped.
• If a window tint that affects th e radio wave signals is installed.
• If there is a lot of snow or ice on the vehi cle, particularly around the wheels or wheel
housings.
• If the tire inflation pressure is extr emely higher than the specified level.
• If the spare tire is in a location subj ect to poor radio wave signal reception.
• If a large metallic object which can interfer e with signal reception is put near the
spare tire.
• If tires not equipped with the tire pressure warning valves and transmitters are used.
• If the ID code on the tire pressure warning valves and transmitters is not registered
in the tire pressure warning computer.
