tow LEXUS LX570 2020 Owners Manual

3
1
8 7
6
5
4
3
2
LX570_OM_OM60R61U_(U)
9
3-1. Key information Keys .................................................... 116
3-2. Opening, closing and locking the doors
Side doors ........................................ 121
Back door ...................................... 128
Smart access system with push-button start...................... 138
3-3. Adjusting the seats Front seats ......................................146
Rear seats ...................................... 148
Driving position memory ..........157
Head restraints .............................. 161
3-4. Adjusting the steering wheel and mirrors
Steering wheel ..............................164
Inside rear view mirror ..............166
Outside rear view mirrors ...... 168
3-5. Opening, closing the windows and moon roof
Power windows ............................. 171
Moon roof ....................................... 174 4-1. Before driving
Driving the vehicle ..................... 180
Cargo and luggage ................... 188
Vehicle load limits .......................192
Trailer towing ................................193
Dinghy towing ...............................210
4-2. Driving procedures Engine (ignition) switch.............. 211
Automatic transmission ............ 217
Turn signal lever ......................... 224
Parking brake .............................. 225
4-3. Operating the lights and wipers
Headlight switch ........................ 228
Automatic High Beam...............231
Fog light switch ........................... 236
Windshield wipers and washer ......................................... 238
Rear window wiper and washer ......................................... 242
Headlight cleaner switch........ 245
4-4. Refueling Opening the fuel tank cap ..... 246
3Operation of each
component4Driving

TABLE OF CONTENTS6
LX570_OM_OM60R61U_(U)
7-1. Essential informationEmergency flashers ....................514
If your vehicle has to be stopped in an emergency..... 515
If the vehicle is trapped in rising water .............................516
7-2. Steps to take in an emergency If your vehicle needs to be towed .................................517
If you think something is wrong........................................... 523
Fuel pump shut off system ...... 524
If a warning light turns on or a warning buzzer
sounds ......................................... 525
If a warning message is displayed .................................... 533
If you have a flat tire .................. 537
If the engine will not start ........ 549
If the electronic key does not operate pr operly .............. 551
If the vehicle battery is discharged ................................. 554
If your vehicle overheats......... 557
If the vehicle becomes stuck ............................................. 560 8-1. Specifications
Maintenance data (fuel, oil level, etc.) .................. 564
Fuel information ......................... 572
Tire information .......................... 575
8-2. Customization Customizable features ............ 586
8-3. Initialization Items to initialize.........................600
Reporting safety defects for U.S. owners .................................... 602
Seat belt instructions for Canadian owners
(in French).............................................. 603
SRS airbag instructions for Canadian owners
(in French).............................................. 605
7When trouble arises8Vehicle specifications
9For owners

16Pictorial index
LX570_OM_OM60R61U_(U)
■Instrument panel
Engine switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 211
Starting the engine/changing the modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 211
Emergency stop of the engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 515
When the engine will not start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 549
Warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 533
Shift lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 217
Changing the shift position. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 217
Precautions against towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 517
When the shift lever does not move . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 222
Meters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 92
Reading the meters/adjusting the instrument panel light . . . . . . . . . . . . . . . . . P. 92
Warning lights/indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 86
When the warning lights come on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 525
1
2
3

321-1. For safe use
LX570_OM_OM60R61U_(U)
Push the release button on buckle A.
Push either the mechanical key or
tab A into buckle B.
When releasing and storing the seat
belt, hold the belt while winding it back
gently.
Put tabs A and B together and stow
them in the holder.
To reattach the seat belt, reverse the
above procedure, pulling out the tabs
and inserting tab B into buckle B.
Releasing and stowing the third center seat belt (if equipped)
Buckle A
1
Tab A
Buckle B
Buckle B
2
Tab A
Tab B
3

411-1. For safe use
LX570_OM_OM60R61U_(U)
1
For safety and security
Your vehicle is equipped with ADVA NCED AIRBAGS designed based on the
US motor vehicle safety standards (F MVSS208). The airbag sensor assembly
(ECU) controls airbag deployment based on information obtained from the sen-
sors etc. shown in the system compon ents diagram above. This information
includes crash severity and occupant information. As the airbags deploy, a
chemical reaction in the inflators quickly fills the airbags with non-toxic gas to
help restrain the motion of the occupants.
WARNING
■SRS airbag precautions
Observe the following precaution s regarding the SRS airbags.
Failure to do so may cause death or serious injury.
●The driver and all passengers in the vehicle must wear their seat belts properly.
The SRS airbags are supplemental devices to be us ed with the seat belts.
●The SRS driver airbag deploys with considerable force, and can cause death or seri-
ous injury especially if the driver is very close to the airbag. The National Highway
Traffic Safety Administration (NHTSA) advises:
Since the risk zone for the driver’s airbag is the first 2 - 3 in. (50 - 75 mm) of inflation,
placing yourself 10 in. (250 mm) from your driver airbag provides you with a clear
margin of safety. This distance is measured from the center of the steering wheel to
your breastbone. If you sit less than 10 in . (250 mm) away now, you can change your
driving position in several ways:
• Move your seat to the rear as far as you can while still reaching the pedals com- fortably.
• Slightly recline the back of the seat. Although vehicle designs vary, many drivers can achieve the 10 in. (250 mm) dis-
tance, even with the driver seat all the wa y forward, simply by reclining the back of
the seat somewhat. If reclining the back of your seat makes it hard to see the road,
raise yourself by using a firm , non-slippery cushion, or raise the seat if your vehicle
has that feature.
• If your steering wheel is ad justable, tilt it downward. This points the airbag toward
your chest instead of your head and neck.
The seat should be adjusted as recommended by NHTSA ab ove, while still maintain-
ing control of the foot pedals, steering whee l, and your view of the instrument panel
controls.

431-1. For safe use
LX570_OM_OM60R61U_(U)
1
For safety and security
WARNING
■SRS airbag precautions
●Do not lean against the door, the roof side rail
or the front, side and rear pillars.
●Do not allow anyone to kneel on the passen-
ger seats toward the door or put their head or
hands outside the vehicle.
●Do not attach anything to or lean anything
against areas such as the dashboard, steering
wheel pad and lower po rtion of the instru-
ment panel.
These items can become projectiles when the
SRS driver, front passeng er and knee airbags
deploy.

781-2. Lexus Enform
LX570_OM_OM60R61U_(U)
■Emergency Assistance Button (“SOS”)
In the event of an emergency on the road, push the “SOS” button to reach the
Safety Connect response center. Th e answering agent will determine your
vehicle’s location, assess the emergency, and dispatch the necessary assis-
tance required.
If you accidentally press the “SOS” button, tell the response-center agent that you
are not experiencing an emergency.
■Enhanced Roadside Assistance
Enhanced Roadside Assistance adds GP S data to the already included war-
ranty-based Lexus roadside service.
Subscribers can press the “SOS” button to reach a Safety Connect response-
center agent, who can help with a wide range of needs, such as: towing, flat
tire, fuel delivery, etc. For a descript ion of the Roadside Assistance services
and their limitations, please see the Safety Connect Terms and Conditions,
which are available at Lexus.com.
Important! Read this informatio n before using Safety Connect.
■Exposure to radio frequency signals
The Safety Connect system installed in your vehicle is a low-power radio\
transmitter and receiver. It receives and also sends out radio frequency (RF)
signals.
In August 1996, the Federal Commu nications Commission (FCC) adopted
RF exposure guidelines with safety levels for mobile wireless phones. Those
guidelines are consistent with the safe ty standards previously set by the fol-
lowing U.S. and internat ional standards bodies.
●ANSI (American National Stan dards Institute) C95.1 [1992]
●NCRP (National Council on Radiation Protection and Measurement)
Report 86 [1986]
●ICNIRP (International Commission on Non-Ionizing Radiation Protection)
[1996]
Those standards were based on comprehensive and periodic evaluations of
the relevant scientific literature. Over 120 scientists, engineers, and physi-
cians from universities, and governme nt health agencies and industries
reviewed the available body of rese arch to develop the ANSI Standard
(C95.1).
The design of Safety Connect complies wi th the FCC guidelines in addition to
those standards.
Safety information for Safety Connect

140
LX570_OM_OM60R61U_(U)3-2. Opening, closing and locking the doors
■Battery-saving function
The battery-saving function w
ill be activated in order to prevent the electronic key bat-
tery and the battery from being discharged while the vehicle is not in operation for a long
time.
●In the following situations, the smart acce ss system with push-button start may take
some time to unlock the doors.
• The electronic key has been le ft in an area of approximately 6 ft. (2 m) of the outside
of the vehicle for 10 minutes or longer.
• The smart access system with push-button st art has not been used for 5 days or lon-
ger.
●If the smart access system with push-button start has not been used for 14 days or lon-
ger, the doors cannot be unlocked at any doors except the driver’s door. In this case,
take hold of the driver’s d oor handle, or use the wireless remote control or the mechan-
ical key, to unlock the doors.
■Electronic Key Battery-Saving Function
When battery-saving mode is set, battery depletion is minimized by stopping the elec-
tronic key from re ceiving radio waves.
The smart access system with push-button st art uses weak radio waves. In the following
situations, the communication between the electronic key and the vehicle may be
affected, preventing the smar t access system with push-but ton start, wireless remote
control and engine immobilizer system from operating properly.
(Ways of coping: P. 551)
●When the electronic key battery is depleted
●Near a TV tower, electric power plant, gas st ation, radio station, large display, airport or
other facility that generates strong radio wave s or electrical noise
●When the electronic key is in contact with, or is covered by the following metallic
objects
• Portable radio, cellular phone, cordle ss phone or other wireless communication
device
• Cards to which aluminum foil is attached
• Cigarette boxes that have aluminum foil inside
• Metallic wallets or bags
•Coins
• Hand warmers made of metal
• Media such as CDs and DVDs
●When other wireless keys (that emit radio waves) are being used nearby
Press twice while pressing and holding
. Confirm that the electronic key indica-
tor flashes 4 times.
While the battery-saving mode is set, the smart
access system with push -button start cannot be
used. To cancel the function, press any of the
electronic key buttons.

LX570_OM_OM60R61U_(U)
1493-3. Adjusting the seats
3
Operation of each component
For easy access to the third seat (if equipped), perform in “Tumbling the sec-
ond seats” (P. 150).
■Before tumbling the second seats
Stow the seat belt buckles and
lower the head restraints to the
lowest position.
Pass the outer seat belts through
the seat belt hangers and secure
the seat belt plates.
This prevents the shoulder belt from
being damaged.
Make sure that th e seat belts are
removed from the hangers before
using them.
Vehicles with rear seat entertain-
ment system: Install the display
cover for the rear seat entertain-
ment system.
Pass the cover belt under the dis-
play and slide the cover up.
Slide the cover down from the top
of the display to cover it.
Tumbling the second seats and third seat entry
1
1
2
3

150
LX570_OM_OM60R61U_(U)3-3. Adjusting the seats
■Tumbling the second seats
Fold down the seatback while
pulling the seatback angle adjust-
ment lever, and swing the whole
seat up and forward.
Hook the holding strap to the
assist grip and secure the seat by
pulling its free end.
When returning the second seat to
its original position, stow the holding
strap.
Remove the seat hook covers
from the back of the seat cushion,
and install them on the seat
hooks.
When returning the second seat to
its original position, remove the seat
hook covers from the floor and install
them in the back of the seat cushion.
1
2
3
