AUX LEXUS LX570 2021 Owners Manual

5
1
8 7
6
5
4
3
2
LX570_OM_OM60T33U_(U)
9
5-5. Using the storage features List of storage features ............ 428• Glove box ............................... 429
• Console box .......................... 429
• Overhead console .............. 430
• Cup holders .............................431
• Bottle holders ........................ 432
• Card holder ........................... 432
• Auxiliary boxes ..................... 433
Luggage compartment features ....................................... 435
5-6. Using the other interior features
Other interior features ............ 438 • Cool box.................................. 438
• Sun visors ................................ 439
• Vanity mirrors ....................... 439
• Clock ........................................ 440
• Power outlets ........................ 440
• Wireless charger ................. 443
• Armrest......................................451
• Rear door sunshades ......... 452
• Coat hooks............................. 452
• Assist grips ............................. 453
Garage door opener ............... 454 6-1. Maintenance and care
Cleaning and protecting the vehicle exterior ................ 462
Cleaning and protecting the vehicle interior.................. 465
6-2. Maintenance Maintenance requirements ............................ 468
General maintenance.............. 470
Emission inspection and maintenance (I/M)
programs.................................... 473
6-3. Do-it-yourself maintenance Do-it-yourself service precautions ................................474
Hood ............................................... 476
Engine compartment ................477
Tires ................................................. 490
Tire inflation pressure .............. 499
Wheels ........................................... 503
Air conditio ning filter ...............505
Electronic key battery.............. 507
Checking and replacing fuses.............................................. 509
Light bulbs ......................................5126Maintenance and care

22Pictorial index
LX570_OM_OM60T33U_(U)
■Interior
SRS airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 38
Floor mats. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 26
Front seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 146
Rear seats. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 148
Head restraints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P . 161
Seat belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 30
Console box
*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 428
Cool box
*1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 438
Inside lock buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 123
Cup holders. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 428
Auxiliary boxes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 42 8
Rear air conditioning system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 418
Rear seat entertainment system
*1, 2
Assist grips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 453
1
2
3
4
5
6
7
8
9
10
11
12
13

190
LX570_OM_OM60T33U_(U)4-1. Before driving
WARNING
■Things that must not be carri
ed in the luggage compartment
The following things may cause a fire if loaded in the luggage compartment:
●Receptacles containing gasoline
●Aerosol cans
■Storage precautions
Observe the following precautions.
Failure to do so may prevent the pedals from being depressed properly, may block the
driver’s vision, or may result in items hittin g the driver or passengers, possibly causing
an accident.
●Stow cargo and luggage in the luggage compartment whenever possible.
●Do not stack cargo and luggage in the luggage compartment higher than the seat-
backs.
●Do not place cargo or luggage in or on the following locations.
• At the feet of the driver
• On the front passenger or re ar seats (when stacking items)
• On the luggage cover (if equipped)
• On the instrument panel
•On the dashboard
• On the auxiliary box or tray that has no lid
●Secure all items in the occupant compartment.
●When you fold down the rear seats, long items should not be placed directly behind
the front seats.
●Never allow anyone to ride in the luggage compartment. It is not designed for pas-
sengers. They should ride in their seats with their seat belts properly fastened. Other-
wise, they are much more likely to suffer de ath or serious bodily injury, in the event of
sudden braking, sudden swerving or an accident.
■Capacity and distribution
●Do not exceed the maximum axle weight rating or the total vehicle weight rating.
●Even if the total load of occupant’s weight and the cargo load is less than the total load
capacity, do not apply the load unevenly. Improper loading may cause deterioration
of steering or braking control whic h may cause death or serious injury.

399
LX570_OM_OM60T33U_(U)
5Interior features
5-1. Remote Touch screenRemote Touch/12.3-inch display ......................................... 400
5-2. Lexus Climate Concierge Lexus Climate Concierge ..... 406
5-3. Using the air conditioning system and defogger
Front automatic air conditioning system ...............407
Rear air conditioning system ........................................... 418
Heated steering wheel/seat heaters/seat ve ntilators......... 421
5-4. Using the interior lights Interior lights list..........................425• Interior lights ..........................426
• Personal lights ....................... 427 5-5. Using the storage features
List of storage features ............ 428
• Glove box ............................... 429
• Console box........................... 429
• Overhead console ..............430
• Cup holders ............................ 431
• Bottle holders ........................ 432
• Card holder............................ 432
• Auxiliary boxes ..................... 433
Luggage compartment features ....................................... 435
5-6. Using the other interior features
Other interior features ............438 • Cool box..................................438
• Sun visors ................................ 439
• Vanity mirrors ....................... 439
• Clock ........................................ 440
• Power outlets......................... 440
• Wireless charger ................. 443
• Armrest ..................................... 451
• Rear door sunshades ......... 452
• Coat hooks ............................. 452
• Assist grips.............................. 453
Garage door opener ............... 454

428
LX570_OM_OM60T33U_(U)5-5. Using the storage features
List of storage features
Auxiliary boxes (
P. 433)
Card holder ( P. 432)
Overhead console ( P. 430)
Glove box ( P. 429)
Bottle holders ( P. 432)
Door pockets
Cup holders ( P. 431) Console box (if equipped)
(
P. 429)
Cool box (if equipped) ( P. 438)
Auxiliary box (if equipped)
( P. 433)
Wireless charger (if equipped)
( P. 443)
WARNING
■Items that should not be left in the storage spaces
Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the
following when cabin temperature becomes high:
●Glasses may be deformed by heat or cracked if they come into contact with other
stored items.
●Lighters or spray cans may explode. If they come into contact with other stored items,
the lighter may catch fire or the spray ca n may release gas, causing a fire hazard.
1
2
3
4
5
6
7
8
9

LX570_OM_OM60T33U_(U)
4335-5. Using the storage features
5
Interior features
Your vehicle is equipped with either a front auxiliary box type B or wireless char-
ger.
For vehicles with wireless charger, refer to page 443.
■Front seats
Type A
Press the button to open.
Type B (if equipped)
Press the lid to open.
■Second seats
Pull down the armrest.
Auxiliary boxes
1

LX570_OM_OM60T33U_(U)
4375-5. Using the storage features
5
Interior features
■Removing the luggage cover
Retract the cover and release both
ends, then lift it out.
After removing the luggage cover,
place it somewhere other than the
passenger compartment.
■When installing the luggage cover (if equipped)
Keep the “TOP” mark on the luggage cover
ends upward.
WARNING
●To avoid injury, always return the cargo hooks to their positions when not in use.
●Keep the auxiliary box closed. In the event of sudden braking or sudden swerving, an
accident may occur due to an occupant bein g struck by an open auxiliary box or the
items stored inside.
●Vehicles with luggage cover: Do not allo w children to climb on the luggage cover.
Climbing on the luggage cove r could result in damage to the luggage cover, possibly
causing death or serious injury to the child.
NOTICE
■To prevent damage to the cargo net hooks
Avoid hanging things other than a cargo net on it.

494
LX570_OM_OM60T33U_(U)6-3. Do-it-yourself maintenance
■Tire types
●Summer tires
Summer tires are high-speed performance ti
res best suited to highway driving under
dry conditions. Since summer tires do not have the same traction performance as
snow tires, summer tires are inadequate for driving on snow-covered or icy roads. For
driving on snow-covered roads or icy road s, the use of snow tires is recommended.
When installing snow tires, be sure to replace all four tires.
●All season tires
All season tires are designed to provide better traction in snow and to be adequate for
driving in most winter conditions, as well as for use year round. All season tires, how-
ever, do not have adequate traction perfor mance compared with snow tires in heavy
or loose snow. Also, all season tires fall short in acceleration and handling perfor-
mance compared with summer tires in highway driving.
●Snow tires
For driving on snow-covered roads or icy roads, we recommend using snow tires. If
you need snow tires, select ti res of the same size, construction and load capacity as the
originally installed tires. Since your vehicle has radial tires as original equipment, make
sure your snow tires also have radial cons truction. Do not install studded tires without
first checking local regulations for possible re striction. Snow tires should be installed
on all wheels. ( P. 390)
■Initializing the tire pressure warning system
Initialize the tire pressure warn ing system with the tire inflation pressure adjusted to the
specified level.
■If the tread on snow tires wears down below 0.16 in. (4 mm)
The effectiveness of the tire s as snow tires is lost.
■If you press the tire pressure warning reset switch accidentally
If initialization is performed, adjust the tire inflation pressure to the specified level and ini-
tialize the tire pressure warning system again.
■Situations in which the tire pressure warning system may not operate properly
●In the following cases, the tire pressure warning system may not operate properly.
• If non-genuine Lexus wheels are used.
• A tire has been replaced with a tire that is not an OE (Original Equipment) tire.
• A tire has been replaced with a tire that is not of the specified size.
• Tire chains etc. are equipped.
• An auxiliary-supported run-flat tire is equipped.
• If a window tint that affects th e radio wave signals is installed.
• If there is a lot of snow or ice on the vehi cle, particularly around the wheels or wheel
housings.
• If the tire inflation pressure is extr emely higher than the specified level.
• If the spare tire is in a location subj ect to poor radio wave signal reception.
• If a large metallic object which can interfere with signal reception is put near the spare tire.
• If tires not equipped with the tire pressure warning valves and transmitters are used.
• If the ID code on the tire pressure warning valves and transmitters is not registered in the tire pressure warning computer.

605
LX570_OM_OM60T33U_(U)
◆Coussins gonflables SRS latéraux et en rideauCoussins gonflables SRS latéraux avant
Peuvent aider à protéger le torse des occupants des sièges avant
Coussins gonflables SRS latéraux arrière
Peuvent aider à protéger le torse des occupants des sièges latéraux de la
deuxième rangée de sièges
Coussins gonflables SRS en rideau
●Peuvent aider à protéger principalement la tête des occupants des
sièges latéraux
●Peuvent aider à empêcher les occupants d’tre éjectés du véhicule en
cas de tonneaux
3
4
5

LX570_OM_OM60T33U_(U)
606
9
For owners
Composants du système de coussins gonflables SRS
Coussins gonflables de protection
des genoux
Coussins gonflables en rideau
Coussin gonflable du passager
avant
Capteurs d’impact latéral (portière
avant)
Coussins gonflables latéraux avant
Lampe témoin SRS
Capteurs d’impact latéral (arrière)
Coussins gonflables latéraux arrière
(sièges latéraux de la deuxième
rangée de sièges)
Coussin gonflable du conducteur
Contacteur de boucle de ceinture
de sécurité du conducteur
Capteur de sûreté (arrière)Module de capteur de coussin
gonflable
Capteurs d’impact avant
Limiteurs de force et dispositifs de
tension des ceintures de sécurité
(sièges avant)
Capteur de position du siège du
conducteur
Voyants “AIR BAG ON” et “AIR
BAG OFF”
Contacteur de boucle de ceinture
de sécurité du passager avant
Système de classification de
l’occupant du siège du passager
avant (ECU et capteurs)
Dispositifs de tension des ceintures
de sécurité (sièges latéraux de la
deuxième rangée de sièges)1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
