LEXUS NX300 2020 Owners Manual

2915-3. Using the interior lights
LEXUS NX300 Owners Manual_USA_M78389_en
5
Interior features

2925-4. Using the storage features
LEXUS NX300 Owners Manual_USA_M78389_en
5-4.Using the storage features
Glove box (P.293)
Bottle holders ( P.293)
Console box ( P.293)
Cup holders ( P.293)
Auxiliary box ( P.294)
List of storage features
Location of the storage features
A
B
C
D
E
WARNING
■Items that should not be left in the
vehicle
Do not leave glasses, lighters or spray
cans in the storage spaces, as this may
cause the following when cabin tempera-
ture becomes high:
●Glasses may be deformed by heat or
cracked if they come into contact with
other stored items.
●Lighters or spray ca ns may explode. If
they come into contact with other
stored items, the lighter may catch fire
or the spray can may release gas,
causing a fire hazard.
■When storage compartments are not
in use
When driving or when the glove box and
the console box are not in use, keep it
closed.
In the event of sudden braking or sudden
swerving, an accident may occur due to
an occupant being struck by an open lid
or the items stored inside.

2935-4. Using the storage features
LEXUS NX300 Owners Manual_USA_M78389_en
5
Interior features
1Open (press the button)
2 Unlock with the mechanical key
3 Lock with the mechanical key
■Glove box light
The glove box light turns on when the tail
lights are on.
1 Lift the lid while pushing the button
to release the lock. 2
Vehicles with wireless charger: Lift
the wireless charger.
■Console box tray (vehicles without wire-
less charger)
The tray slides forward/backward and can
be removed.
■Console box light
The console box light turns on when the tail
lights are on.
■Cup holders
Front
Glove box
Console box
Cup holders/bottle holders

2945-4. Using the storage features
LEXUS NX300 Owners Manual_USA_M78389_en
Rear
Pull down the armrest and push the
release button.
■Bottle holders
Front
Rear
■Cup holders/bottle holders
●When storing a bottle, close the cap.
●The bottle may not be stored depending
on its size or shape.
Remove the lid using the strap .
■Auxiliary box lid
●The removed auxiliary box lid can be
stored on the tray in the console box.
WARNING
■Items unsuitable for the cup hold-
ers/bottle holders
Do not place anything other than cups or
aluminum cans in the cup holders.
Other items may be thrown out of the
holders in the event of an accident or
sudden braking, causing injury. If possi-
ble, cover hot drinks to prevent burns.
NOTICE
■To prevent damage to the rear cup
holder
Stow the cup holder before stowing the
armrest.
■Bottle holders
Do not place open bottles or glass and
paper cups containing liquid in the bottle
holders. The contents may spill and
glasses may break.
Auxiliary box
A

2955-4. Using the storage features
LEXUS NX300 Owners Manual_USA_M78389_en
5
Interior features
●The back side of the auxiliary box lid can
be used as a vanity mirror.
Raise the hook to use.
The cargo hooks are provided for securing
loose items.
Raise the hook to use.
The cargo net can be hanged, using the
hook.
Luggage compartment fea-
tures
Cargo hooks
WARNING
■When cargo hooks are not in use
To avoid injury, always return the hooks
to their stowed positions when not in use.
Cargo net hooks

2965-4. Using the storage features
LEXUS NX300 Owners Manual_USA_M78389_en
Lift the deck board and attach the
hook. (P.296) The following item
can be stowed. First-aid kit and other items
Accessories
Warning reflector
*
*: The warning reflec
tor itself is not
included as an original equipment.
1Open the back door.
2
Pull the lever upwards and open the
deck board.
WARNING
■When cargo net hooks are not in use
To avoid injury, always return the hooks
to their stowed positions when not in use.
Grocery bag hooks
NOTICE
■To prevent damage to the grocery
bag hooks
Do not hang any object heavier than 11 lb.
(5 kg) on the grocery bag hooks.
Deck under tray
Deck board
A
B
C

2975-4. Using the storage features
LEXUS NX300 Owners Manual_USA_M78389_en
5
Interior features
3Lift the deck board and remove the
hook on the backside of the deck
board.
4
Use the hook to secure the deck
board as shown in the illustration.
■When attaching the side deck board
When attaching the side deck board, attach
it so that the “ FRONT” mark points to
the front side of the vehicle.
1Unhook the cords.
2
Fold up the luggage cover.
WARNING
■If the deck boards are opened or
removed
Return them to their original positions
before driving. In the event of sudden
braking, an accident may occur due to an
occupant being struck by the deck
boards or the items stored in the deck
under tray.
Stowing the luggage cover

2985-4. Using the storage features
LEXUS NX300 Owners Manual_USA_M78389_en
3Pull the lever upwards and open the
deck board.
4
Remove the luggage cover.
When the seatback for the rear seat is col-
lapsed to the rear, remove the cover after
the cover most upright position. ( P.123)
5Stow the luggage cover in the deck
under tray while lifting the deck
board.
WARNING
■Luggage cover
●Do not place anything on the luggage
cover. In the event of sudden braking
or turning, the item may go flying and
strike an occupant. This could lead to
an unexpected accident, resulting in
death or serious injury.
●Do not allow children to climb on the
luggage cover. Climbing on the lug-
gage cover could result in damage to
the luggage cover, possibly causing
death or serious injury to the child.

2995-5. Using the other interior features
LEXUS NX300 Owners Manual_USA_M78389_en
5
Interior features
5-5.Using the other interior features
1To set the visor in the forward posi-
tion, flip it down.
2
To set the visor in the side position,
flip down, unhook, and swing it to
the side.
3
To use the side extender, place the
visor in the side position, then slide
it backward.
■Sun visors
Slide the cover to open.
The light turns on when the cover is
opened.
■Auxiliary box
Remove the lid of auxiliary box using the strap . (
P.294)
There is a vanity mirror on the back side of
the lid.
■Automatic light off to prevent battery
discharge
If the vanity lights remain on when the
engine switch is turned off, the lights will go
off automatically after 20 minutes.
The GPS clock’s time is automatically
adjusted by utilizing GPS time infor-
mation.
For details, refer to the “NAVIGA-
TION AND MULTIMEDIA SYSTEM
OWNER’S MANUAL”.
Other interior features
Sun visors
Vanity mirrors
NOTICE
■To prevent damage to the vanity mir-
ror
When the lid of auxiliary box is removed,
do not subject it to strong impacts or set
heavy objects on top of it.
■To prevent battery discharge
Do not leave the vanity lights on for
extended periods while the engine is off.
Clock
A

3005-5. Using the other interior features
LEXUS NX300 Owners Manual_USA_M78389_en
Please use a power supply for elec-
tronic goods that use less than 12
VDC/10 A (power consumption of
120 W).
When using electronic goods, make
sure that the power consumption of all
the connected power outlets is less
than 120 W.
■Console box
Open the lid.
■Luggage compartment
Open the lid.
■The power outlet can be used when
The engine switch is in ACCESSORY or
IGNITION ON mode.
■When turning the engine switch off
Disconnect electrical devices with charging
functions, such as mobile battery packs. If
such devices are left connected, the engine
switch may not be turned off normally.
■Using power outlet
The notch in console box allows power
cables to be passed through even when the
console box is closed.
Power outlet (12 VDC)
NOTICE
■When power outlet is not in use
To avoid damaging the power outlet,
close the power outlet lid when the
power outlet is not in use.
Foreign objects or li quids that enter the
power outlet may cause a short circuit.
■To prevent battery discharge
Do not use the power outlet longer than
necessary when the engine is off.
