service indicator LEXUS NX300 2020 Owners Manual

2
LEXUS NX300 Owners Manual_USA_M78389_en
TABLE OF CONTENTS
For your information ......................................
6
Reading this manual .................................... 10
How to search ................................................. 11
Pictorial index ................................................. 12
1-1. For safe use Before driving .................................... 24
For safe driving.................................. 25
Seat belts ............................................. 26
SRS airbags ........................................ 32
Front passenger occupant classifi- cation system ................................... 41
Exhaust gas precautions .............. 46
1-2. Child safety Riding with children........................ 48
Child restraint systems ................. 48
1-3. Lexus Enform Lexus Enform Safety Connect .... 61
Lexus Enform Remote .................. 66
Lexus Enform Service Connect 67
1-4. Theft deterrent system Engine immobilizer system ......... 68
Alarm.................................................... 70
2-1. Instrument cluster Warning lights and indicators ..... 74
Gauges and meters ....................... 79
Multi-information display............. 82
Head-up display .............................. 88
Fuel consumption information .... 923-1. Key information
Keys ....................................................... 96
3-2. Opening, closing and locking the doors
Side doors ........................................ 100
Back door......................................... 104
Smart access system with push-but- ton start ............................................ 116
3-3. Adjusting the seats Front seats......................................... 122
Rear seats.......................................... 123
Driving position memory ........... 128
Head restraints ................................ 131
3-4. Adjusting the steering wheel and mirrors
Steering wheel ............................... 133
Inside rear view mirror ................ 134
Outside rear view mirrors......... 136
3-5. Opening, closing the windows and moon roof
Power windows ............................. 138
Moon roof ........................................ 140
1For safety and security
2Vehicle status information and
indicators
3Before driving

611-3. Lexus Enform
LEXUS NX300 Owners Manual_USA_M78389_en
1
For safety and security
1-3.Lexus Enform
*:If equipped
Microphone
“SOS” button
LED light indicators
Lexus Enform Safety Con-
nect*
Safety Connect is a subscription-
based telematics service that uses
Global Positioning System (GPS)
data and embedded cellular tech-
nology to provide safety and secu-
rity features to subscribers. Safety
Connect is supported by Lexus’
designated response center, which
operates 24 hours per day, 7 days
per week.
Safety Connect service is available
by subscription on select, telemat-
ics hardware-equipped vehicles.
By using the Safety Connect ser-
vice, you are agreeing to be bound
by the Telematics Subscription Ser-
vice Agreement and its Terms and
Conditions, as in effect and
amended from time to time, a cur-
rent copy of which is available at
Lexus.com. All use of the Safety
Connect service is subject to such
then-applicable Terms and Condi-
tions.
System components
A
B
C

641-3. Lexus Enform
LEXUS NX300 Owners Manual_USA_M78389_en
When the engine switch is turned to
IGNITION ON mode, the red indica-
tor light comes on for 2 seconds then
turns off. Afterward, the green indica-
tor light comes on, indicating that the
service is active.
The following indicator light patterns
indicate specific system usage condi-
tions:
Green indicator light on = Active
service
 Green indicator light flashing =
Safety Connect call in process
 Red indicator light (except at vehi-
cle start-up) = System malfunction
(contact your Lexus dealer)
 No indicator light (off) = Safety
Connect service not active
■Automatic Collision Notification
In case of either airbag deployment or
severe rear-end collision, the system is
designed to automatically call the
response center. The responding agent
receives the vehicle’s location and
attempts to speak with the vehicle
occupants to assess the level of emer-
gency. If the occupants are unable to
communicate, the ag ent automatically
treats the call as an emergency, con-
tacts the nearest emergency services
provider to describe the situation, and
requests that assistance be sent to the
location.
■Stolen Vehicle Location
If your vehicle is stolen, Safety Connect
can work with local authorities to assist
them in locating and recovering the
vehicle. After filing a police report, call
the Safety Connect response center at
1-800-25-LEXUS (1-800-255-
3987) in the United States, 1-877-
539-8777 in Puerto Rico or 1-800-
265-3987 in Canada, and follow the
prompts for Safety Connect to initiate
this service.
In addition to assisting law enforce-
ment with recovery of a stolen vehicle,
Safety-Connect-equipped vehicle
location data may, under certain cir-
cumstances, be shared with third par-
ties to locate your vehicle. Further
information is available at Lexus.com.
■Emergency Assistance Button
(“SOS”)
In the event of an emergency on the
road, push the “SOS” button to reach
the Safety Connect response center.
The answering agent will determine
your vehicle’s location, assess the
emergency, and dispatch the neces-
sary assistance required.
If you accidentally press the “SOS” button,
tell the response-center agent that you are
not experiencing an emergency.
■Enhanced Roadside Assistance
Enhanced Roadside Assistance adds
GPS data to the already included war-
ranty- based Lexus roadside service.
Subscribers can press the “SOS” but-
ton to reach a Safety Connect
response-center agent, who can help
Safety Connect LED light Indi-
cators
Safety Connect services

3306-2. Maintenance
LEXUS NX300 Owners Manual_USA_M78389_en
The OBD system determines that a
problem exists somewhere in the emis-
sion control system. Your vehicle may
not pass the I/M test and may need to
be repaired. Contact your Lexus
dealer to service the vehicle.
When the battery is disconnected
or discharged
Readiness codes that are set during
ordinary driving are erased.
Also, depending on your driving
habits, the readiness codes may not
be completely set.
 When the fuel tank cap is loose
The malfunction indicator lamp
comes on indicating a temporary
malfunction and your vehicle may
not pass the I/M test. The error code in the OBD system will
not be cleared unless the vehicle is
driven 40 or more times.
Contact your Lexus dealer to prepare
the vehicle for re-testing.
Emission inspection and
maintenance (I/M) pro-
grams
Some states have vehicle emission
inspection programs which include
OBD (On Board Diagnostics)
checks. The OBD system monitors
the operation of the emission con-
trol system.
If the malfunction indicator lamp
comes on
Your vehicle may not pass the
I/M test in the following situa-
tions:
When the malfunction indicator
lamp still remains on after sev-
eral driving trips
If your vehicle does not pass the
I/M test

4168-1. Specifications
LEXUS NX300 Owners Manual_USA_M78389_en
■Gasoline quality
In very few cases, driveability problems may
be caused by the brand of gasoline you are
using. If driveability problems persist, try
changing the brand of gasoline. If this does
not correct the problem, consult your Lexus
dealer.
■Recommendation of the use of gasoline
containing detergent additives
●Lexus recommends the use of gasoline
that contains detergent additives to avoid
the build-up of engine deposits.
●All gasoline sold in the U.S.A. contains
minimum detergent additives to clean
and/or keep clean intake systems, per
EPA’s lowest additive s concentration pro-
gram.
●Lexus strongly recommends the use of
Top Tier Detergent Gasoline. For more
information on Top Tier Detergent Gaso-
line and a list of marketers, please go to
the official websit e www.toptiergas.com.
■Recommendation of the use of low
emissions gasoline
Gasolines containing oxygenates such as
ethers and ethanol, as well as reformulated
gasolines, are available in some cities.
These fuels are typically acceptable for use, providing they meet other fuel require-
ments.
Lexus recommends these fuels, since the
formulations allow for reduced vehicle
emissions.
■Non-recommendation of the use of
blended gasoline
●Use only gasoline containing up to 15%
ethanol.
DO NOT use any flex-fuel or gasoline
that could contain more than 15% etha-
nol, including from
any pump labeled
E30 (30% ethanol ), E50 (50% etha-
nol ), E85 (85% ethanol ) (which
are only some examples of fuel contain-
ing more than 15% ethanol).
●If you use gasohol in your vehicle, be sure
that it has an octane rating no lower than
91.
●Lexus does not recommend the use of
gasoline containing methanol.
■Non-recommendation of the use of gas-
oline containing MMT
Some gasoline contains an octane enhanc-
ing additive called MMT (Methylcyclopen-
tadienyl Manganese Tricarbonyl).
Lexus does not recommend the use of gas-
oline that contains MMT. If fuel containing
MMT is used, your emission control system
may be adversely affected.
The malfunction indicator lamp on the
instrument cluster may come on. If this hap-
pens, contact your Lexus dealer for service.
■If your engine knocks
●Consult your Lexus dealer.
●You may occasionally notice light knock-
ing for a short time wh ile accelerating or
driving uphill. This is normal and there is
Fuel information
You must only use unleaded gaso-
line in your vehicle.
Select premium unleaded gasoline
with an octane rating of 91
(Research Octane Number 96) or
higher required for optimum
engine performance and fuel econ-
omy. If the octane ra ting is less than
91,damage to the engine may occur
and may void the vehicle warranty.
At minimum, the gasoline you use
should meet the specifications of
ASTM D4814 in the U.S.A.
A
BC

LEXUS NX300 Owners Manual_USA_M78389_en
Alphabetical Index461
Lever
Auxiliary catch lever ................................. 333
Hood lock release lever......................... 333
Shift lever......................................................... 168
Turn signal lever ........................................... 172
Wiper lever.................................................... 184
Lexus Enform Remote.................................. 66
LEXUS Enform Safety Connect ................ 61
Lexus Enform Service Connect ................67
Lexus Safety System+ 2.0 Automatic High Beam ............................... 181
Dynamic radar cruise control with full-speed range .............................................. 225
LDA (Lane Departure Alert with steering control) ..........................................................215
LTA (Lane Tracing Assist)....................206
PCS (Pre-Collision System)..................199
RSA (Road Sign Assist) ......................... 223
License plate lights Light switch .....................................................178
Replacing light bulbs................................ 362
Light Automatic High Beam system............... 181
Cornering lights .......................................... 180
Fog light switch ............................................ 184
Headlight switch ..........................................178
Illuminated entry system.........................289
Interior light list ............................................289
Interior lights.................................................290
Personal lights .............................................290
Replacing light bulbs................................ 362
Turn signal lever ........................................... 172
Vanity lights .................................................. 299
Wattage............................................................415
Welcome light illumination control ..... 101
Light bulbs Replacing .............................................361, 362
Wattage............................................................415
LTA (Lane Tracing Assist) ....................... 206
Luggage cover ............................................. 297M
Maintenance Do-it-yourself maintenance .................. 331
General maintenance ............................. 327
Maintenance data ..................................... 408
Maintenance requirements ..................326
Malfunction indicator la mp ..................... 376
Meter Head-up display........................................... 88
Indicators........................................................... 74
Instrument panel light control.................. 81
Meters................................................................. 79
Multi-information display .......................... 82
Warning lights .............................................375
Warning messages.................................. 384
Micro dust and pollen filter ..................... 284
Mirrors Inside rear view mirror ..............................134
Outside rear view mirror defoggers280
Outside rear view mirrors...................... 136
Vanity mirrors ..............................................299
Moon roof Jam protection function ............................. 141
Operation ....................................................... 140
Warning message .......................... 142, 384
Multi-information display Clock................................................................... 79
Drive information ..........................................83
Dynamic radar cruise control with full-
speed range .............................................. 225
Language ...................................................... 430
LDA (Lane Departure Alert with steering control) ......................................................... 215
LTA (Lane Tracing Assist) ................... 206
Warning messages.................................. 384
N
Noise from under vehicle ...............................6
