3957-2. Steps to take in an emergency
LEXUS NX300h Owners Manu-
al_USA_OM78212U 7
When trouble arises coolant is unavailable.
6 Start the hybrid system and turn the
air conditioning system on to check
that the radiator cooling fans oper-
ate and to check for coolant leaks
from the radiator or hoses.The fans operate when the air conditioning
system is turned on immediately after a
cold start. Confirm that the fans are oper-
ating by checking the fan sound and air
flow. If it is difficult to check these, turn the
air conditioning system on and off repeat-
edly.
(The fans may not oper ate in freezing tem-
peratures.)
7 If the fans are not operating:
Stop the hybrid system immediately
and contact your Lexus dealer.
If the fans are operating:
Have the vehicle inspected at the
nearest Lexus dealer.
8 Check if “Engine Coolant Temp
High” is shown on the multi-infor-
mation display.
If the message does not disappear:
Stop the hybrid system and contact
your Lexus dealer.
If the message is not displayed:
Have the vehicle inspected at the
nearest Lexus dealer. 
If “Hybrid System Overheated” is
shown on the multi-information dis-
play
1 Stop the vehicle in a safe place.
2 Stop the hybrid system and care-
fully lift the hood.
3 After the hybrid system has cooled
down, inspect the hoses and radia-
tor core (radiato r) for any leaks.
Radiator
Cooling fans If a large amount of coolant leaks, immedi-
ately contact your Lexus dealer.
4 The coolant level is satisfactory if it
is between the “FULL” and “LOW”
lines on the reservoir.
Reservoir
“FULL” line
“LOW” line
5 Add coolant if necessary. A
B
A
B
C

396 7-2. Steps to take in an emergency
LEXUS NX300h Owners Manu-
al_USA_OM78212U Water can be used in an emergency if
coolant is unavailable.
6 After stopping the hybrid system
and waiting for 5 minutes or more,
start the hybrid system again and
check if “Hybrid System Over-
heated” is shown on the multi-infor-
mation display.If the message does not disappear:
Stop the hybrid system and contact your
Lexus dealer.
If the message is not displayed:
The hybrid system temperature has
dropped and the vehicle may be driven
normally.
However, if the message appears again fre-
quently, contact your Lexus dealer.
WARNING■
To prevent an accident or injury when
inspecting under the hood of your
vehicle
Observe the following precautions.
Failure to do so may result in serious
injury such as burns.
●
If steam is seen coming from under the
hood, do not open the hood until the
steam has subsided. The engine com-
partment may be very hot. ●
After the hybrid system has been
turned off, check that the “READY”
indicator is off. When the hybrid sys-
tem is operating, the gasoline engine
may automatically start, or the cooling
fan may suddenly operate even if the
gasoline engine stops. Do not touch or
approach rotating parts such as the
fan, which may lead to fingers or cloth-
ing (especially a tie, a scarf or a muf-
fler) getting caught, resulting in serious
injury. ●
Do not loosen the coolant reservoir
cap while the hybrid system and radia-
tor are hot.
High temperature steam or coolant
could spray out.
NOTICE■
When adding engine/power control
unit coolant
Add coolant slowly after the hybrid sys-
tem has cooled down sufficiently. Adding
cool coolant to a hot hybrid system too
quickly can cause dama ge to the hybrid
system. ■
To prevent damage to the cooling sys-
tem
Observe the following precautions: ●
Avoid contaminating the coolant with
foreign matter (such as sand or dust
etc.).
●
Do not use any coolant additive.

3977-2. Steps to take in an emergency
LEXUS NX300h Owners Manu-
al_USA_OM78212U 7
When trouble arises 1 Stop the hybrid system. Shift the
shift lever to P and set the parking
brake.
2 Remove the mud, snow or sand
from around the front wheels.
3 Place wood, stones or some other
material under the front wheels to
help provide traction.
4 Restart the hybrid system.
5 Shift the shift lever to D or R,
release the parking brake. Then,
while exercising caution, depress
the accelerator pedal. ■
When it is difficult to free the vehicle
Press to turn off TRAC. ( → P.251)If the vehicle becomes stuck Carry out the following proce-
dures if the tires spin or the vehicle
becomes stuck in mud, dirt or snow:
Recovering procedure WARNING■
When attempting to free a stuck vehi-
cle
If you choose to push the vehicle back
and forth to free it, make sure the sur-
rounding area is clear to avoid striking
other vehicles, obje cts or people. The
vehicle may also lunge forward or lunge
back suddenly as it becomes free. Use
extreme caution. ■
When shifting the shift lever
Be careful not to shif t the shift lever with
the accelerator pedal depressed.
This may lead to un expected rapid accel-
eration of the vehicle that may cause an
accident resulting in death or serious
injury.
NOTICE■
To avoid damage to the hybrid trans-
mission and other components ●
Avoid spinning the front wheels and
depressing the accelerator pedal
more than necessary. ●
If the vehicle remains stuck even after
these procedures are performed, the
vehicle may require towing to be freed.

4278-2. Customization
LEXUS NX300h Owners Manu-
al_USA_OM78212U 8
Vehicle specifications ■
Power back door *1
( → P.110)
*1
: If equipped *2
: Configured by operating the sw itch of the lower back door. ( → P.120)*3
: While carrying the electronic key on your person, press the back door opener switch.*4
: When the towing hitch is installe d, the kick sensor does not work
■
Vehicle customization●
When the speed linked d oor locking function and shift po sition linked door locking func-
tion are both on, the door lock operates as follows.
• When shifting the shift lever to any position other than P, all the doors will be locked.
• If the vehicle is started with all the doors locked, the speed linked door locking function
would not operate.
• If the vehicle is started with any door unlock ed, the speed linked door locking function will
operate.
●
When the smart access system wi th push-button start is off, smart door unlocking cannot
be customized.
●
When the doors remain closed after unlock ing the doors and the automatic door lock
function is activat ed, the signals will be generated in accordance with the Operation sig-
nal (buzzer) and the Operation sign al (emergency flashers) settings.
■
In the following situations, customize mode in which the settings can be changed
through the multi-information display will automatically be turned off.
●
A warning message appears after the cu stomize mode screen is displayed.
●
The power switch is turned off. Function Default setting Customized set-
ting
Set at the desired Position
(height) *2
Back Door Automatic Open
and Stop Position Initial settings
Position Stop at the
desired position
(height) — — — O
5 step configuration
Back Door Automatic Open
and Stop Position 5 1 to 5 O — — —
Back door opener switch
operations When the back
door is locked *3
When the back
door is unlocked — — O —
Power back door operations On Off — O — —
Operation buzzer volume 3 1
— O — —
2
Kick Sensor *1, 4
On Off — O — — A B C D

445What to do if... (Troubleshooting)
LEXUS NX300h Owners Manu-
al_USA_OM78212U 445What to do if... (Troubleshooting)
If you cannot release the shift lever
by depressing the brake pedal with
the power switch in ON mode
( → P.174)
 It is locked automatically to prevent
theft of the vehicle. ( → P.169)
 Is the window lock switch pressed?
The power window except for the
one at the driver’s seat cannot be
operated if the window lock switch
is pressed. ( → P.145)
 The auto power off function will be
operated if the vehicle is left in
ACCESSORY or ON mode (the
hybrid system is not operating) for a
period of time. ( → P.170)
 The seat belt reminder light is flash-
ing
Are the driver and the front passen-
ger wearing the seat belts?
( → P.369)
 The parking brake indicator is on
Is the parking brake released? ( → P.177)
Depending on the situation, other
types of warning buzzer may also
sound. ( → P.365, 374)
 Did anyone inside the vehicle open
a door during setting the alarm?
The sensor detects it and the alarm
sounds. ( → P.71)
To stop the alarm, turn the power
switch to ON mode or start the hybrid
system.
 Is the message displayed on the
multi-information display?
Check the message on the multi-
information display. ( → P.374)
 When a warning light turns on or a
warning message is displayed, refer
to P.365, 374.
 Stop the vehicle in a safe place and
replace the flat tire with the spare The steering wheel cannot be
turned after the hybrid system is
stopped
The windows do not open or
close by operating the power
window switches
The power switch is turned off
automatically
A warning buzzer sounds during
driving An alarm is activated and the
horn sounds
A warning buzzer sounds when
leaving the vehicle
A warning light turns on or a
warning message is displayed
When a problem has occurred If you have a flat tire

449What to do if... (Troubleshooting)
LEXUS NX300h Owners Manu-
al_USA_OM78212U Alphabetical Index
449Defogger
Outside rear view mirrors .................... 269
Rear window ................................................ 269
Windshield .................................................... 269
Differential ...................................................... 405
Dimension ......................................................400
Dinghy towing................................................. 167
Display
Drive information .......................................... 86
Dynamic radar cruise control with full-
speed range ................................................ 217
Energy monitor.............................................. 94
LDA (Lane Departure Alert with steering
control) ..........................................................210
Multi-information display .......................... 85
Warning messages .................................. 375
Do-it-yourself maintenance .................... 324
Doors
Automatic door lock ing and unlocking
system ........................................................... 109
Back door......................................................... 110
Door glasses .................................................. 144
Door lock........................................................ 106
Outside rear view mirrors ...................... 142
Rear door child-protectors ................... 109
Side doors ...................................................... 106
Drive information ........................................... 86
Drive-start control ............................... 151, 173
Driver’s seat belt remi nder light ............ 369
Driver’s seat position memory .................134
Driving
Break-in tips .................................................... 151
Correct posture ............................................ 25
Driving mode select switch .................. 249
Hybrid vehicle driving tips .................... 255
Procedures .................................................... 150
Winter drive tips......................................... 257
Driving position memory............................134
Memory recall function ............................135
Dynamic radar cruise control with full-
speed range
Function ............................................................ 217 Warning message ..................................... 374 E
E-Four .............................................................. 250
ECB (Electronically Controlled Brake Sys-
tem) ................................................................ 250
Eco mode........................................................ 249
EDR (Event data recorder) ............................7
Electric motor
Location ...............................................................61
Specification .................................................. 401
Electric Power Steering (EPS)
Function ......................................................... 250
Warning light ............................................... 367
Electronic key
Battery-saving function.............................123
If the electronic key does not operate
properly .......................................................387
Replacing the battery ............................... 347
Electronically Controlled Brake System
(ECB) ............................................................ 250
Emergency flashers ....................................358
Emergency, in case of
If a warning buzzer sounds.................. 365
If a warning light turns on...................... 365
If a warning message is displayed ..... 374
If the 12-volt battery is discharged ... 390
If the electronic key does not operate
properly .......................................................387
If the fuel filler do or cannot be opened
..........................................................................387
If the hybrid system will not start ....... 385
If you have a flat tire .................................. 377
If you lose your keys ....................... 103, 105
If you think something is wrong..........363
If your vehicle becomes stuck ............. 397
If your vehicle has to be stopped in an
emergency ................................................ 358
If your vehicle needs to be towed .... 360
If your vehicle overheats ........................394
Energy monitor ............................................... 94
Engine

450 Alphabetical Index
LEXUS NX300h Owners Manu-
al_USA_OM78212U Accessory mode .........................................170
Compartment ............................................. 327
Engine switch................................................ 168
Hood................................................................ 325
How to start the hybrid system ........... 168
Identification number ................................ 401
If your vehicle has to be stopped in an
emergency ............................................... 358
Ignition switch (power switch) ............. 168
Overheating................................................. 394
Power switch ................................................ 168
Engine compartment cover .................... 328
Engine coolant
Capacity .........................................................403
Checking .......................................................330
Preparing and checking before winter
......................................................................... 257
Warning light ...............................................366
Engine coolant temperature gauge ........79
Engine oil
Capacity ......................................................... 402
Checking ....................................................... 328
Warning light ...............................................366
Engine oil maintenance data .................. 329
Engine switch ................................................. 168
EPS (Electronic Power Steering)
Function ..........................................................250
Warning light ............................................... 367
EV drive mode................................................. 171
EV indicator ...................................................... 62
Event data recorder (EDR) ............................7 F
Flat tire ..............................................................377
Tire pressure warning system ............ 338
Floor mats .......................................................... 24
Fluid
Brake ............................................................... 405
Transmission................................................ 404
Washer ........................................................... 332
Fog lights
Replacing light bulbs ................................353
Switch................................................................ 189
Front passenger occupant classification
system ................................................................ 41
Front passenger’s seat belt reminder light
.......................................................................... 369
Front seats ........................................................128
Adjustment ..................................................... 128
Cleaning ...........................................................317
Correct driving posture ............................ 25
Driving position memory .........................134
Head restraints..............................................137
Power easy access system .....................134
Seat heaters .................................................. 276
Seat position memory ...............................134
Front side marker lights
Light switch .................................................... 183
Replacing light bulbs ................................354
Wattage ..........................................................407
Front turn signal lights
Replacing light bulbs ................... 353, 354
Turn signal lever ...........................................176
Wattage ..........................................................407
Fuel
Capacity .......................................................... 401
Fuel gauge ........................................................ 79
Gas station information ......................... 460
Information ................................................... 408
Refueling.......................................................... 196
Type ................................................................... 401
Warning light .............................................. 369
Fuel filler door .................................................196

451What to do if... (Troubleshooting)
LEXUS NX300h Owners Manu-
al_USA_OM78212U Alphabetical Index
451Refueling ..........................................................196
When the fuel filler door cannot be
opened ........................................................ 387
Fuses ................................................................. 349 G
Garage door opener ................................. 298
Gas station information ............................ 460
Gauges ................................................................79
Glove box ....................................................... 282
Glove box light ............................................. 282
Grocery bag hooks .................................... 285 H
Head restraints ............................................... 137
Head-up display.............................................. 90
Headlights ....................................................... 183
Automatic headlight leveling ................ 184
Automatic High Beam ............................. 186
Light switch .................................................... 183
Replacing light bulbs................................ 353
Heated steering wheel ...............................276
Heaters
Automatic air conditioning system ...268
Heated steering wheel............................ 275
Outside rear view mirrors .................... 269
Seat heaters .................................................. 275
High mounted stoplight
Replacing light bulb..................................353
Hill-start assist control ............................... 250
Hood ................................................................. 325
Warning message........................... 107, 374
Hooks
Cargo hooks................................................ 284
Retaining hooks (floor mat)......................24
Horn ................................................................... 140
Hybrid battery (traction battery)
Location............................................................. 64
Specification ................................................. 402
Hybrid battery air vent ................................. 66
Hybrid system .................................................... 61 Emergency shut off system...................... 67
Energy monitor/consumption screen 94
EV drive mode............................................... 171
High voltage components ....................... 64
Hybrid System Indicator ........................... 82
Hybrid system precautions...................... 64
Hybrid vehicle driving tips ....................255
If the hybrid system will not start ....... 385
Overheating .................................................394
Power switch................................................. 168
Regenerative braking ................................. 62
Starting the hybrid system ...................... 168
Vehicle proximity noti fication system. 63
Hybrid System Indicator.............................. 82
Hybrid transmission...................................... 173
I
I/M test ............................................................ 322
Identification
Engine............................................................... 401
Vehicle ........................................................... 400
Ignition switch (Power switch) ................ 168
Illuminated entry system ........................... 278
Immobilizer system........................................ 69
Indicators ............................................................74
Initialization
Engine oil maintenance data................329
Items to initialize ......................................... 429
Tire pressure warning system ...............341
Inside rear view mirror ............................... 140
Instrument panel light control ................... 84
Interior lights.................................................. 278
Intuitive parking assist
Function .......................................................... 227
Warning message ..................................... 229
