automatic transmission LEXUS NX300h 2018 Owners Manual

3TABLE OF CONTENTS
LEXUS NX300h Owners Manu-
al_USA_OM78212U 1
2
3
4
5
6
7
8
94-1. Before driving
Driving the vehicle ........................ 150
Cargo and luggage ...................... 155
Vehicle load limits ......................... 158
Trailer towing (vehicles with towing
package) ........................................ 159
Trailer towing (vehicles without
towing package) ......................... 167
Dinghy towing ................................ 167
4-2. Driving procedures
Power (ignition) switch ............... 168
EV drive mode ................................ 171
Hybrid transmission ..................... 173
Turn signal lever............................. 176
Parking brake ................................. 177
Brake Hold....................................... 180
ASC (Active Sound Control) ... 181
4-3. Operating the lights and wipers
Headlight switch ............................ 183
Automatic High Beam ................ 186
Fog light switch .............................. 189
Windshield wipers and washer 189
Rear window wiper and washer
............................................................ 194
4-4. Refueling
Opening the fuel tank cap......... 196 4-5. Using the driving support systems
Lexus Safety System+ ................. 198
PCS (Pre-Collision System) ... 203
LDA (Lane Departure Alert with
steering control) ......................... 210
Dynamic radar cruise control with
full-speed range........................... 217
Intuitive parking assist ................. 227
Parking Support Brake function (for
static objects)............................... 232
BSM (Blind Spot Monitor) ......... 241
Driving mode select switch ..... 249
Driving assist systems ................ 250
4-6. Driving tips
Hybrid vehicle driving tips ....... 255
Winter driving tips ....................... 257
Utility vehicle precautions........ 259
5-1. Remote Touch
Remote Touch............................... 264
5-2. Using the air conditioning system
and defogger
Automatic air conditioning system
.......................................................... 268
Heated steering wheel/seat heat-
ers/seat ventilators................... 275
5-3. Using the interior lights
Interior lights list ........................... 278
5-4. Using the storage features
List of storage features ............... 281
Luggage compartment features
.......................................................... 2844
Driving
5
Interior features

149
LEXUS NX300h Owners Manu-
al_USA_OM78212U 4 4
Driving Driving4-1. Before driving
Driving the vehicle ..................... 150
Cargo and luggage ................... 155
Vehicle load limits ...................... 158
Trailer towing (vehicles with tow-
ing package).............................. 159
Trailer towing (vehicles without
towing package) ...................... 167
Dinghy towing ............................. 167
4-2. Driving procedures
Power (ignition) switch ............ 168
EV drive mode ............................. 171
Hybrid transmission .................. 173
Turn signal lever.......................... 176
Parking brake .............................. 177
Brake Hold.................................... 180
ASC (Active Sound Control) 181
4-3. Operating the lights and wipers
Headlight switch ......................... 183
Automatic High Beam ............. 186
Fog light switch ........................... 189
Windshield wipers and washer
......................................................... 189
Rear window wiper and washer
......................................................... 194
4-4. Refueling
Opening the fuel tank cap...... 196 4-5. Using the driving support sys-
tems
Lexus Safety System+ .............. 198
PCS (Pre-Collision System) 203
LDA (Lane Departure Alert with
steering control) ...................... 210
Dynamic radar cruise control with
full-speed range........................ 217
Intuitive parking assist .............. 227
Parking Support Brake function
(for static objects) .................. 232
BSM (Blind Spot Monitor) ...... 241
Driving mode select switch .. 249
Driving assist systems.............. 250
4-6. Driving tips
Hybrid vehicle driving tips .... 255
Winter driving tips .................... 257
Utility vehicle precautions..... 259

1734-2. Driving procedures
LEXUS NX300h Owners Manu-
al_USA_OM78212U 4
Driving *1
: To improve fuel efficiency and reduce
noise, shift the shift lever to D for normal
driving.
You can choose gear range suitable for
your driving situation by operating the
paddle shift switches. *2
: By selecting shift ra nges using S mode,
you can control accelerating force and
engine braking force.
■
S mode●
When the shift range is 4 or lower, hold-
ing the shift lever towa rd “+” sets the shift
range to 6.
●
Automatically selects a higher shift range
before the engine speed becomes too
high.
■
When driving with dynamic radar cruise
control with full-speed range activated
Even when performing the following
actions with the intent of enabling engine
braking, engine braking will not activate
because dynamic radar cruise control with
full-speed range will not be canceled. ●
While driving in S mode, downshifting to
5 or 4. ( → P.176)●
When switching the driving mode to
sport mode while driving in D position.
( → P.249)■
Restraining sudden start (Drive-Start
Control)
When the following unusual operation is
performed, the hybrid system output may
be restrained. ●
When the shift lever is shifted from R to D,
D to R, N to R, P to D, or P to R (D
includes S) with the accelerator pedal
depressed, a warning message appears
on the multi-information display. If a
warning message is shown on the multi-
information display, read the message
and follow the instructions. ●
When the accelerator pedal is depressed
too while the vehicle is in reverse.Hybrid transmission Select the shift position depending
on your purpose and situation.
Shift position purpose and func-
tions Shift posi-
tion Objective or function
P Parking the vehicle/starting
the hybrid system
R Reversing
N Neutral
D Normal driving *1
S S mode driving *2
( → P.176)
WARNING■
When driving on slippery road sur-
faces
Be careful of downsh ifting and sudden
acceleration, as this could result in the
vehicle skidding to the side or spinning.
NOTICE■
Hybrid battery (t raction battery)
charge
If the shift lever is in N, the hybrid battery
(traction battery) will not be charging,
even when the engine is running. There-
fore, if the vehicle is left with the shift
lever in N for a long period of time, the
hybrid battery (traction battery) will dis-
charge, and this may re sult in the vehicle
not being able to start.

451What to do if... (Troubleshooting)
LEXUS NX300h Owners Manu-
al_USA_OM78212U Alphabetical Index
451Refueling ..........................................................196
When the fuel filler door cannot be
opened ........................................................ 387
Fuses ................................................................. 349 G
Garage door opener ................................. 298
Gas station information ............................ 460
Gauges ................................................................79
Glove box ....................................................... 282
Glove box light ............................................. 282
Grocery bag hooks .................................... 285 H
Head restraints ............................................... 137
Head-up display.............................................. 90
Headlights ....................................................... 183
Automatic headlight leveling ................ 184
Automatic High Beam ............................. 186
Light switch .................................................... 183
Replacing light bulbs................................ 353
Heated steering wheel ...............................276
Heaters
Automatic air conditioning system ...268
Heated steering wheel............................ 275
Outside rear view mirrors .................... 269
Seat heaters .................................................. 275
High mounted stoplight
Replacing light bulb..................................353
Hill-start assist control ............................... 250
Hood ................................................................. 325
Warning message........................... 107, 374
Hooks
Cargo hooks................................................ 284
Retaining hooks (floor mat)......................24
Horn ................................................................... 140
Hybrid battery (traction battery)
Location............................................................. 64
Specification ................................................. 402
Hybrid battery air vent ................................. 66
Hybrid system .................................................... 61 Emergency shut off system...................... 67
Energy monitor/consumption screen 94
EV drive mode............................................... 171
High voltage components ....................... 64
Hybrid System Indicator ........................... 82
Hybrid system precautions...................... 64
Hybrid vehicle driving tips ....................255
If the hybrid system will not start ....... 385
Overheating .................................................394
Power switch................................................. 168
Regenerative braking ................................. 62
Starting the hybrid system ...................... 168
Vehicle proximity noti fication system. 63
Hybrid System Indicator.............................. 82
Hybrid transmission...................................... 173
I
I/M test ............................................................ 322
Identification
Engine............................................................... 401
Vehicle ........................................................... 400
Ignition switch (Power switch) ................ 168
Illuminated entry system ........................... 278
Immobilizer system........................................ 69
Indicators ............................................................74
Initialization
Engine oil maintenance data................329
Items to initialize ......................................... 429
Tire pressure warning system ...............341
Inside rear view mirror ............................... 140
Instrument panel light control ................... 84
Interior lights.................................................. 278
Intuitive parking assist
Function .......................................................... 227
Warning message ..................................... 229
