400 8-1. Specifications
LEXUS NX300h Owners Manu-
al_USA_OM78212U 8-1.Specifications
*1
:Unladen vehicle *2
: Vehicles with towing package
■
Vehicle identification number
The vehicle identification number
(VIN) is the legal identifier for your
vehicle. This is the primary identifica-
tion number for your Lexus. It is used in
registering the ownership of your vehi-
cle.
This number is stamped on the top left
of the instrument panel. This number is also on the Certification
Label.Maintenance data (fue l, oil level, etc.)
Dimensions and weight Overall length 182.7 in. (4640 mm)
Overall width 72.6 in. (1845 mm)
Overall height *1
64.8 in. (1645 mm)
Wheelbase 104.7 in. (2660 mm)
Tread Front 62.2 in. (1580 mm)
Rear 62.2 in. (1580 mm)
Vehicle capacity weight
(Occupants + luggage) 895 lb. (405 kg)
Trailer Weight Rating *2

(Trailer weight + cargo weight) 1500 lb. (685 kg)
Vehicle identification

412 8-1. Specifications
LEXUS NX300h Owners Manu-
al_USA_OM78212U conforms to applicable Federal Motor
Vehicle Safety Standards.
■
Typical tire size information
The illustration indicates typical tire
size.
Tire use
(P = Passenger car,
T = Temporary use)
Section width (millimeters)
Aspect ratio
(tire height to section width)
Tire construction code
(R = Radial, D = Diagonal)
Wheel diameter (inches)
Load index (2 digits or 3 digits)
Speed symbol (alphabet with one
letter) ■
Tire dimensions Section width
Tire height
Wheel diameter
Bead
Sidewall
Shoulder
Tread
Belt
Inner liner
Reinforcing rubber
Carcass
Rim lines
Bead wires
Chafer
This information has been prepared in
accordance with regulations issued by
the National Highway Traffic Safety
Administration of the U.S. Department
of Transportation.
It provides the purchasers and/or pro-
spective purchasers of Lexus vehicles
with information on uniform tire quality Tire size
A
B
C
D
E
F
G Tire section names
Uniform Tire Quality Grading A
B
C
A
B
C
D
E
F
G
H
I
J
K
