4 TABLE OF CONTENTS
LEXUS NX300h Owners Manu-
al_USA_OM78212U 5-5. Using the other interior features
Other interior features .............. 288
Garage door opener.................. 298
Compass.......................................... 303
Lexus Enform Safety Connect 306
Lexus Enform Remote ................. 311
Lexus Enform Service Connect
............................................................ 312
6-1. Maintenance and care
Cleaning and protecting the vehi-
cle exterior .................................... 314
Cleaning and protecting the vehi-
cle interior ..................................... 317
6-2. Maintenance
Maintenance requirements ...... 319
General maintenance ................ 320
Emission inspection and mainte-
nance (I/M) programs ............ 322
6-3. Do-it-yourself maintenance
Do-it-yourself service precautions
........................................................... 324
Hood.................................................. 325
Positioning a floor jack............... 326
Engine compartment.................. 327
12-volt battery................................ 333
Tires ................................................... 336
Tire inflation pressure ................. 343
Wheels.............................................. 345
Air conditioning filter.................. 346
Electronic key battery ................ 347
Checking and replacing fuses 349
Headlight aim.................................. 351
Light bulbs ....................................... 353 7-1. Essential information
Emergency flashers .................... 358
If your vehicle has to be stopped in
an emergency ............................ 358
7-2. Steps to take in an emergency
If your vehicle needs to be towed
.......................................................... 360
If you think something is wrong
.......................................................... 363
If a warning light turns on or a warn-
ing buzzer sounds..................... 365
If a warning messa ge is displayed
.......................................................... 374
If you have a flat tire .................... 377
If the hybrid syst em will not start
.......................................................... 385
If you lose your keys.................... 386
If the fuel filler door cannot be
opened .......................................... 387
If the electronic key does not oper-
ate properly ................................. 387
If the 12-volt battery is discharged
.......................................................... 390
If your vehicle overheats ........... 394
If the vehicle becomes stuck ... 397
8-1. Specifications
Maintenance data (fuel, oil level,
etc.) ................................................. 40
0
Fuel information ............................ 408
Tire information ............................. 4106
Maintenance and care 7
When trouble arises
8
Vehicle specifications

13Pictorial index
LEXUS NX300h Owners Manu-
al_USA_OM78212U Precautions against winter season ............................................................................ P.257
To prevent freezing (windshield wiper de-icer) .................................................. P.273
Precautions against car wash ....................................................................................... P.315
Fuel filler door .......................................................................................................... P.196
Refueling method .............................................................................................................. P .196
Fuel type/fuel tank capacity ...... .................................................................................... P.401
Tires.......................................................................................................................... ..P.336
Tire size/inflation pressure ...........................................................................................P.406
Winter tires/tire chain .................................................................................................... P.25 7
Checking/rotation/tire pressure warning system.............................................. P.336
Coping with flat tires........................................................................................................ P .377
Hood ......................................................................................................................... P. 325
Opening ........................................................................................................................ ....... P.325
Engine compartment cover .........................................................................................P.328
Engine oil ..................................................................................................................... ......... P.402
Coping with overheat ..................................................................................................... P.394
Warning messages .......................................................................................................... P.374
Headlights .................................................................................................................P.18 3
Parking lights/daytime running lights...............................................................P.183
Fog lights....................................................................................................................P .189
Turn signal lights ...................................................................................................... P.176
Tail lights .................................................................................................................... P.183
License plate lights .................................................................................................P.183
Back-up light
Shifting the shift lever to R ...............................................................................................P.1 73
Side marker lights ...................................................................................................P.183 *
:If equipped Light bulbs of the exterior lights for driving
(Replacing method: P.353, Watts: P.407) E
F
G
H
I
J
K
L
M
N
O

46 1-1. For safe use
LEXUS NX300h Owners Manu-
al_USA_OM78212U WARNING●
Do not modify or replace the uphol-
stery of the front seat.
Safety information for chil-
dren Observe the following precautions
when children are in the vehicle.
Use a child restraint system appro-
priate for the child, until the child
becomes large enough to properly
wear the vehicle’s seat belt.
 It is recommended that children
sit in the rear seats to avoid acci-
dental contact with the shift lever,
wiper switch, etc.
 Use the rear door child-protector
lock or the window lock switch to
avoid children opening the door
while driving or operating the
power window accidentally.
( → P.109, 145)
 Do not let small children operate
equipment which may catch or
pinch body parts, such as the
power window, hood, back door,
seats etc. WARNING
■
When children are in the vehicle
Never leave children unattended in the
vehicle, and never allow children to have
or use the key.
Children may be able to start the vehicle
or shift the vehicle into neutral. There is
also a danger that children may injure
themselves by playing with the windows,
the moon roof (if equipped) or other fea-
tures of the vehicle. In addition, heat
build-up or extremely cold temperatures
inside the vehicle can be fatal to children.

711-3. Theft deterrent system
LEXUS NX300h Owners Manu-
al_USA_OM78212U 1
For safety and security
■
Items to check before locking the
vehicle
To prevent unexpected triggering of
the alarm and vehicle theft, make sure
of the following:
 Nobody is in the vehicle.
 The windows and moon roof (if
equipped) are closed before the
alarm is set.
 No valuables or other personal
items are left in the vehicle. ■
Setting
Close the doors and hood, and lock all
the doors. The system will be set auto-
matically after 30 seconds. The indicator light changes from being on
to flashing when the system is set. ■
Canceling or stopping
Do one of the following to deactivate
or stop the alarms:
 Unlock the doors.
 Turn the power switch to ACCES-
SORY or ON mode, or start the
hybrid system. (The alarm will be
deactivated or stopped after a few
seconds.) ■
System maintenance
The vehicle has a maintenance-free type
alarm system. ■
Triggering of the alarm
The alarm may be triggered in the following
situations:
(Stopping the alarm deactivates the alarm
system.) ●
A person inside the vehicle opens a door
or hood, or unlocks the vehicle using an
inside lock button.
●
The 12-volt battery is recharged or
replaced when the vehicle is locked.
( → P.392)Alarm The alarm uses light and sound to
give an alert when an intrusion is
detected.
The alarm is triggered in the follow-
ing situations when the alarm is set:
 A locked door is unlocked or
opened in any way other than
using the entry function, wireless
remote control or mechanical
key. (The doors will lock again
automatically.)
 The hood is opened.
Setting/canceling/stopping the
alarm system

1073-2. Opening, closing and locking the doors
LEXUS NX300h Owners Manu-
al_USA_OM78212U 3
Before driving
For vehicles with alarm: To prevent unin-
tended triggering of the alarm, unlock the
doors using the wirele ss remote control and
open and close a door once after the set-
tings have been changed. (If a door is not
opened within 60 seconds after is
pressed, the doors will be locked again and
the alarm will automatically be set.)
In a case that the alarm is triggered, imme-
diately stop the alarm. ( → P.71)■
Locking the doors from the outside with-
out a key
1 Move the inside lock button to the lock
position.
2 Close the door.
The door cannot be locked if the power
switch is in ACCESSORY or ON mode, or
the electronic key is le ft inside the vehicle.
The key may not be detected correctly and
the door may be locked.
■
Impact detection door lock release sys-
tem
In the event that the vehicle is subject to a
strong impact, all the doors are unlocked.
Depending on the force of the impact or the
type of accident, however, the system may not operate. ■
Operation signals
Doors:
A buzzer sounds and the emergency flash-
ers flash to indicate that the doors have
been locked/unlocked. (Locked: Once;
Unlocked: Twice)
Windows:
A buzzer sounds to indicate that all win-
dows are opening. ■
Security feature
If a door is not opened within approximately
60 seconds after the vehicle is unlocked,
the security feature automatically locks the
vehicle again. ■
Open door warning buzzer
If the vehicle speed reaches 3 mph (5 km/
h), the master warning light flashes and a
buzzer sounds to indicate that door(s) or
the hood in not fully closed.
The open door(s) or hood is displayed on
the multi-information display. ■
Welcome light illumination control
The side marker, parking, tail and license
plate lights automatically turn on at night
when the doors are unlocked using the
entry function or wireless remote control if
the light switch is in the “AUTO” position. ■
When the door cannot be locked by the
lock sensor on the surface of the door
handle
When the door cannot be locked even if the
lock sensor on the surface of the door han-
dle is touched by a finger, touch the lock
sensor with the palm.
When gloves are being worn, remove the
gloves.Multi-information
display/Beep Unlocking function
Exterior: Beeps 3
times
Interior: Pings
once Holding the driver’s
door handle unlocks
only the driver’s door.
Holding any of the
passenger door han-
dles unlocks all the
doors.
Exterior: Beeps
twice
Interior: Pings
once Holding a door han-
dle unlocks all the
doors.

210 4-5. Using the driving support systems
LEXUS NX300h Owners Manu-
al_USA_OM78212U with snow, etc.
• When the part of the windshield in front
of the camera sensor is fogged up or cov-
ered with condensation or ice (Defog-
ging the windshield: → P.269)
• If the camera sensor is obstructed, such
as when the hood is open or a sticker is
attached to the windshield near the cam-
era sensor●
If the PCS warning ligh t continues to flash
or remains illuminated or the warning
message does not disappear even
though the vehicle has returned to nor-
mal, the system may be malfunctioning.
Have the vehicle inspected by your Lexus
dealer immediately.■
If VSC is disabled●
If VSC is disabled ( → P.251), the pre-col-
lision brake assist and pre-collision brak-
ing functions are also disabled.●
The PCS warning light will turn on and
“VSC Turned Off Pre-Collision Brake
System Unavailable” will be displayed on
the multi-information display.
■
Lane departure alert function
When the system determines that the
vehicle might depart from its lane, a
warning is displayed on the multi-infor-
mation display, and either the warning
buzzer sounds or the steering wheel
vibrates to alert the driver. When the warning buzzer sounds or the
steering wheel vibrates, check the sur-
rounding road situation and carefully oper-
ate the steering wheel to move the vehicle
back to the center of the lane.LDA (Lane Departure Alert
with steering control) When driving on highways and
freeways with white (yellow) lines,
this function alerts the driver when
the vehicle might depart from its
lane and provides assistance by
operating the steering wheel to
keep the vehicle in its lane.
The LDA system recognizes visible
white (yellow) lines with the camera
sensor on the upper portion of the
front windshield.
Functions included in LDA sys-
tem

3256-3. Do-it-yourself maintenance
LEXUS NX300h Owners Manu-
al_USA_OM78212U 6
Maintenance and care 1 Pull the hood lock release lever. The hood will pop up slightly.
2 Pull up the auxiliary catch lever and
lift the hood.WARNING●
Be careful not to touch the engine,
power control unit, radiator, exhaust
manifold, etc. right after driving as they
may be hot. Oil and other fluids may
also be hot.●
Do not leave anything that may burn
easily, such as paper and rags, in the
engine compartment.●
Do not smoke, cause sparks or expose
an open flame to fuel. Fuel fumes are
flammable.■
When working near the electric cool-
ing fans or radiator grille
Be sure the power switch is off.
With power switch in ON mode, the
electric cooling fans may automatically
start to run if the air conditioning is on
and/or the coolant temperature is high.
( → P.331)■
Safety glasses
Wear safety glasses to prevent flying or
falling material, fluid spray, etc. from get-
ting in your eyes.
NOTICE■
If you remove the air cleaner filter
Driving with the air cleaner filter
removed may cause excessive engine
wear due to dirt in the air. Hood
Opening the hood
WARNING
■
Pre-driving check
Check that the hood is fully closed and
locked.
If the hood is not locked properly, it may
open while the vehicle is in motion and
cause an accident, which may result in
death or serious injury.

354 6-3. Do-it-yourself maintenance
LEXUS NX300h Owners Manu-
al_USA_OM78212U Before replacing, check the wattage of
the light bulb to be replaced.
( → P.407) ■
Front side marker lights (bulb type)
1 Turn the bulb base counterclock-
wise.
2 Remove the light bulb.
3 When installing, reverse the steps
listed. ■
Front turn signal lights (bulb type)
1 Open the hood and remove the
cover for engine compartment
cover. ( → P.325, 328) 2 Remove the cover.
Push the center of the clip.
Remove the clip and cover.
3 Turn the bulb base counterclock-
wise.
4 Remove the light bulb.Replacing light bulbs
A
B

390 7-2. Steps to take in an emergency
LEXUS NX300h Owners Manu-
al_USA_OM78212U If you have a set of jumper (or booster)
cables and a second vehicle with a 12-
volt battery, you can jump start your
vehicle by following the steps below.
1 Confirm that the electronic key is
being carried.When connecting the jumper (or booster)
cables, depending on the situation, the
alarm may activate and the doors may lock.
( → P.72) 2 Open the hood ( → P.325) and fuse
box cover.
3 Open the exclusive jump starting
terminal cover.
4 Remove the engine cover.If the 12-volt battery is dis-
charged The following procedures may be
used to start the hybrid system if the
vehicle’s 12-volt battery is dis-
charged.
You can also call your Lexus dealer
or a qualified repair shop.
Restarting the hybrid system

396 7-2. Steps to take in an emergency
LEXUS NX300h Owners Manu-
al_USA_OM78212U Water can be used in an emergency if
coolant is unavailable.
6 After stopping the hybrid system
and waiting for 5 minutes or more,
start the hybrid system again and
check if “Hybrid System Over-
heated” is shown on the multi-infor-
mation display.If the message does not disappear:
Stop the hybrid system and contact your
Lexus dealer.
If the message is not displayed:
The hybrid system temperature has
dropped and the vehicle may be driven
normally.
However, if the message appears again fre-
quently, contact your Lexus dealer.
WARNING■
To prevent an accident or injury when
inspecting under the hood of your
vehicle
Observe the following precautions.
Failure to do so may result in serious
injury such as burns.
●
If steam is seen coming from under the
hood, do not open the hood until the
steam has subsided. The engine com-
partment may be very hot. ●
After the hybrid system has been
turned off, check that the “READY”
indicator is off. When the hybrid sys-
tem is operating, the gasoline engine
may automatically start, or the cooling
fan may suddenly operate even if the
gasoline engine stops. Do not touch or
approach rotating parts such as the
fan, which may lead to fingers or cloth-
ing (especially a tie, a scarf or a muf-
fler) getting caught, resulting in serious
injury. ●
Do not loosen the coolant reservoir
cap while the hybrid system and radia-
tor are hot.
High temperature steam or coolant
could spray out.
NOTICE■
When adding engine/power control
unit coolant
Add coolant slowly after the hybrid sys-
tem has cooled down sufficiently. Adding
cool coolant to a hot hybrid system too
quickly can cause dama ge to the hybrid
system. ■
To prevent damage to the cooling sys-
tem
Observe the following precautions: ●
Avoid contaminating the coolant with
foreign matter (such as sand or dust
etc.).
●
Do not use any coolant additive.
