451-1. For safe use
LEXUS NX300h Owners Manu-
al_USA_OM78212U 1
For safety and security WARNING■
Front passenger occupant classifica-
tion system precautions
Observe the following precautions
regarding the front passenger occupant
classification system. Failure to do so may
cause death or serious injury. ●
Wear the seat belt properly.●
Make sure the fron t passenger’s seat
belt plate has not been left inserted
into the buckle before someone sits in
the front passenger seat.●
Make sure the “AIR BAG OFF” indi-
cator light is not illuminated when
using the seat belt extender for the
front passenger seat. If the “AIR BAG
OFF” indicator light is illuminated, dis-
connect the extender tongue from the
seat belt buckle, and reconnect the
seat belt. Reconnect the seat belt
extender after making sure the “AIR
BAG ON” indicator light is illumi-
nated. If you use the seat belt extender
while the “AIR BAG OFF” indicator
light is illuminated, the SRS airbags for
the front passenger will not activate,
which could cause death or serious
injury in the event of a collision.●
Do not apply a heavy load to the front
passenger seat or equipment (e.g.
seatback pocket).
●
Do not put weight on the front passen-
ger seat by putting your hands or feet
on the front passenger seat seatback
from the rear passenger seat.
●
Do not let a rear passenger lift the
front passenger seat with their feet or
press on the seatback with their legs.
●
Do not put objects under the front pas-
senger seat. ●
Do not recline the front passenger
seatback so far that it touches a rear
seat. This may cause the “AIR BAG
OFF” indicator light to be illuminated,
which indicates that the SRS airbags
for the front passenger will not activate
in the event of a severe accident. If the
seatback touches the rear seat, return
the seatback to a position where it
does not touch the rear seat. Keep the
front passenger seatback as upright as
possible when the vehicle is moving.
Reclining the seatback excessively
may lessen the effectiveness of the
seat belt system. ●
If an adult sits in the front passenger
seat, the “AIR BAG ON” indicator
light is illuminated. If the “AIR BAG
OFF” indicator is illuminated, ask the
passenger to sit up straight, well back
in the seat, feet on the floor, and with
the seat belt worn co rrectly. If the “AIR
BAG OFF” indicator still remains illu-
minated, either ask the passenger to
move to the rear seat, or if that is not
possible, move the front passenger
seat fully rearward. ●
When it is unavoidable to install a for-
ward-facing child re straint system on
the front passenger seat, install the
child restraint system on the front pas-
senger seat in the proper order.
( → P.50)
●
Do not modify or remove the front
seats.
●
Do not kick the front passenger seat or
subject it to severe impact. Otherwise,
the SRS warning light may come on to
indicate a malfunction of the front pas-
senger occupant clas sification system.
In this case, contact your Lexus dealer
immediately.
●
Child restraint systems installed on the
rear seat should not contact the front
seatbacks.
●
Do not use a seat accessory, such as a
cushion and seat cover, that covers the
seat cushion surface.

50 1-1. For safe use
LEXUS NX300h Owners Manu-
al_USA_OM78212U ■
When installing a child restraint
system to a passenger seat
For the safety of a child, install child
restraint systems to a rear seats. When
installing child restraint system to a
front passenger seat is unavoidable,
adjust the passenger seat as follows
and install the child restraint system.
 Raise the seatback as much as pos-
sible
 Move the seat to the rearmost posi-
tion
 Raise the seat to the upper most
position
 If the head restraint interferes with
the child restraint system installa-
tion and the head restraint can be
removed, remove the head restraintWhen using a child restraint sys-
tem on a passenger seat WARNING■
When installing a child restraint sys-
tem
Observe the following when installing
child restraint system to the front passen-
ger seat if it is unavoidable. The front pas-
senger SRS air bag inflates with
considerable speed and force that if not
observed may lead to death or serious
injury to the child. ●
Never install a rear-facing child
restraint system on the front passenger
seat even if the “AIR BAG OFF” indi-
cator light is illuminated. In the event of
an accident, the force of the rapid infla-
tion of the front passenger airbag can
cause death or serious injury to the
child if the rear-fac ing child restraint
system is installed on the front passen-
ger seat. ●
A forward-facing child restraint system
may be installed on the front passen-
ger seat only when it is unavoidable. A
child restraint system that requires a
top tether strap should not be used in
the front passenger seat since there is
no top tether strap anchor for the front
passenger seat. ●
A forward-facing child restraint system
may be installed on the front passen-
ger seat only when it is unavoidable.
When installing a forward-facing child
restraint system on the front passenger
seat, move the seat as far back as pos-
sible, and raise the seat to the upper
most position, even if the “AIR BAG
OFF” indicator light is illuminated. If
the head restraint interferes with the
child restraint system installation and
the head restraint can be removed,
remove the head restraint.

58 1-1. For safe use
LEXUS NX300h Owners Manu-
al_USA_OM78212U Anchor bracket
Anchor bracket for rear center seat
Anchor bracket for rear outboard
seats ■
Fixing the top tether strap to the
anchor bracket
Install the child restraint system in
accordance to the operation manual
enclosed with the child restraint sys-
tem. 
Outboard rear seats
1 Adjust the head restraint to the
upmost position.If the head restraint interferes with the child
restraint system insta llation and the head
restraint can be removed, remove the head
restraint. ( → P.137)
2 Open the anchor bracket cover,
latch the hook onto the anchor
bracket and tighten the top tether
strap.
Make sure the top tether strap is securely latched.
When installing the ch ild restraint system
with the head restraint being raised, be
sure to have the top tether strap pass
underneath the head restraint.
Top tether strap
Hook 
Rear center seat
1 Adjust the head restraint to the
downmost position. If the head restraint interferes with the child
restraint system instal lation and the head
restraint can be remove d, remove the head
restraint. ( → P.137)
2 Open the anchor bracket cover,
latch the hook onto the anchor
bracket and tighten the top tether
strap. Make sure the top tether strap is securely
latched.
When installing the ch ild restraint system
with the head restraint being lower, be sure
to have the top tether strap pass over the A
B
C
A
B

651-2. Hybrid system
LEXUS NX300h Owners Manu-
al_USA_OM78212U 1
For safety and security ( → P.369) go off. If th ere is only a small
amount of fuel, the hybrid system may not
be able to start. (The standard amount of
fuel is about 2.7 gal. [10.1 L, 2.2 Imp.gal.],
when the vehicle is on a level surface. This
value may vary when the vehicle is on a
slope. Add extra fuel when the vehicle is
inclined.) ■
Electromagnetic waves●
High voltage parts and cables on hybrid
vehicles incorporate electromagnetic
shielding, and ther efore emit approxi-
mately the same amount of electromag-
netic waves as conventional gasoline
powered vehicles or home electronic
appliances.●
Your vehicle may cause sound interfer-
ence in some third party-produced radio
parts.■
Hybrid battery (traction battery)
The hybrid battery (traction battery) has a
limited service life. The lifespan of the
hybrid battery (traction battery) can
change in accordance with driving style and
driving conditions.
WARNING■
High voltage precautions
This vehicle has high voltage DC and AC
systems as well as a 12-volt system. DC
and AC high voltage is very dangerous
and can cause severe burns and electric
shock that may result in death or serious
injury. ●
Never touch, disassemble, remove or
replace the high voltage parts, cables
or their connectors.
●
The hybrid system will become hot
after starting as the system uses high
voltage. Be careful of both the high
voltage and the high temperature, and
always obey the warning labels
attached to the vehicle. ●
Never try to open the service plug
access hole located underneath the
rear seats. The service plug is used
only when the vehicle is serviced and is
subject to high voltage.
■
Road accident cautions
Observe the following precautions to
reduce the risk of de ath or serious injury:●
Pull your vehicle off the road, shift the
shift lever to P, apply the parking brake,
and turn the hybrid system off. ●
Do not touch the high voltage parts,
cables and connectors. ●
If electric wires ar e exposed inside or
outside your vehicle, an electric shock
may occur. Never touch exposed elec-
tric wires. ●
If a fluid leak occurs, do not touch the
fluid as it may be st rong alkaline elec-
trolyte from the hybrid battery (trac-
tion battery). If it comes into contact
with your skin or eyes, wash it off
immediately with a large amount of
water or, if possible, boric acid solu-
tion. Seek immediate medical atten-
tion.
●
If a fire occurs in the hybrid vehicle,
leave the vehicle as soon as possible.
Never use a fire extinguisher that is not
meant for electric fires. Using even a
small amount of water may be danger-
ous.

66 1-2. Hybrid system
LEXUS NX300h Owners Manu-
al_USA_OM78212U The cooling air intake and discharge
vents for the hybrid battery (traction
battery) are located under the rear
seats and between the rear seats and
deck board, respectively. If the air
intake vents are blocked, it could lead
to a reduction in hybrid battery (trac-
tion battery) output. The hybrid battery (traction battery) out-
put will not be reduced, even if the space
between the upper part of the air dis-
charge vents on the back of the rear seat
and deck board is blocked with luggage,
etc.WARNING●
If your vehicle needs to be towed, do
so with four wheels raised. If the
wheels connected to the electric
motor (traction motor) are on the
ground when towing, the motor may
continue to generate electricity. This
may cause a fire. ( → P.360)●
Carefully inspect the ground under the
vehicle. If you find that liquid has
leaked onto the ground, the fuel sys-
tem may have been damaged. Leave
the vehicle as soon as possible.■
Hybrid battery (traction battery)●
Never resell, hand over or modify the
hybrid battery. To prevent accidents,
hybrid batteries that have been
removed from a disposed vehicle are
collected through Lexus dealers. Do
not dispose of the battery yourself.
Unless the battery is properly collected,
the following may occur, resulting in
death or serious injury:
• The hybrid battery may be illegally dis-
posed of or dumped, and it is hazard-
ous to the environment or someone
may touch a high voltage part, result-
ing in an electric shock.
• The hybrid battery is intended to be
used exclusively with your hybrid vehi-
cle. If the hybrid battery is used outside
of your vehicle or modified in any way,
accidents such as electric shock, heat
generation, smoke generation, an
explosion and electrolyte leakage may
occur.
When reselling or handing over your
vehicle, the possibility of an accident is
extremely high because the person
receiving the vehicle may not be aware
of these dangers. ●
If your vehicle is disposed of without
the hybrid battery having been
removed, there is a danger of serious
electric shock if hi gh voltage parts,
cables and their connectors are
touched. In the event that your vehicle
must be disposed of, the hybrid battery
must be disposed of by your Lexus
dealer or a qualified service shop. If
the hybrid battery is not disposed of
properly, it may cause electric shock
that can result in death or serious
injury.
Hybrid battery (traction bat-
tery) air intake and discharge
vents

1373-3. Adjusting the seats
LEXUS NX300h Owners Manu-
al_USA_OM78212U 3
Before driving
■
Front seats
1 UpPull the head restraints up.
2 DownPush the head restraint down while press-
ing the lock release button . ■
Rear seats
1 Up Pull the head restraints up.
2 Down Push the head restra int down while press-
ing the lock release button .
■
Adjusting the heig ht of the head
restraints
Make sure that the head restraints are
adjusted so that the center of the head
restraint is closest to the top of your ears.
■
Adjusting the center rear seat head
restraint
Always raise the head restraint one level
from the stowed position when using.
Pull the head restraint up while press-
ing the lock release button .
If the head restraint touches the ceiling,
making the removal difficult, change
the seat height or angle. ( → P.128, 129)Head restraints Head restraints are provided for all
seats. WARNING■
Head restraint precautions
Observe the following precautions
regarding the head restraints.
Failure to do so may result in death or
serious injury. ●
Use the head restraints designed for
each respective seat.●
Adjust the head restraints to the cor-
rect position at all times.●
After adjusting the head restraints,
push down on them and make sure
they are locked in position.●
Do not drive with the head restraints
removed.
Vertical adjustment
ARemoving the head restraints A
A

2735-2. Using the air conditio ning system and defogger
LEXUS NX300h Owners Manu-
al_USA_OM78212U 5
Interior features “A/C” button or selecting “A/C” will
dehumidify the air from the outlets and
defog the windshield effectively.●
If you turn “A/C” off, the windows may
fog up more easily.●
The windows may fog up if the recircu-
lated air mode is used.■
Windshield wiper de-icer (if equipped)
This feature is used to prevent ice from
building up on the wi ndshield and wiper
blades.
Select on the option control screen.
When the windshield wiper de-icer on,
is displayed on the air conditioning
control screen.
The windshield wiper de-icer will automati-
cally turn off after a period of time. ■
Eco air conditioning mode
When Eco mode is selected using the drive
mode select switch, eco air conditioning
mode turns on. When a drive mode other
than Eco mode is selected, eco air condi-
tioning mode may turn off. ■
S-FLOW mode
Priority for airflow is given to the front seats,
and the airflow and air conditioning for the
rear seats is effectively controlled.
Select on the option control screen.
The indicator comes on when S-FLOW
mode is on.
Press again to return to the previ-
ous mode. ■
Micro dust and pollen filter
Pollen is removed from the air and the air
flows to the upper part of the body.
Select on the option control screen.
When the micro dust and pollen filter is on,
is displayed on the air conditioning
control screen.
In order to prevent the windshield from fog-
ging up when the outside air is cold, the
dehumidification function may operate.
The pollens are filtered out even if the micro
dust and pollen filter is turned off. 1 Press the “AUTO” button.
2 Adjust the temperature setting.
3 To stop the operation, press the
“OFF” button.
If the fan speed setting or air flow
modes are operated, the automatic
mode indicator goes off. However,
automatic mode for functions other
than that operated is maintained. ■
Using automatic mode
Fan speed is adjusted automatically accord-
ing to the temperature setting and the
ambient conditions.
Therefore, the fan may stop for a while until
warm or cool air is ready to flow immedi-
ately after the “AUTO” button is pressed or
“AUTO” is selected. ■
Windshield fog detection function
When automatic mode is set, the humidity
sensor ( → P.274) detects fog on the wind-
shield and controls the air conditioning sys-
tem to prevent fog.
■
Air conditioning filter
→ P.346
■
Customization
Settings (e.g. A/C automatic mode switch
operation) can be changed.
(Customizable features: → P.424)WARNING■
To prevent burns (vehicles with wind-
shield wiper de-icer)
Do not touch the glass at lower part of
the windshield or to the side of the front
pillars when the windshield wiper de-icer
is on.
Using automatic mode

3176-1. Maintenance and care
LEXUS NX300h Owners Manu-
al_USA_OM78212U 6
Maintenance and care  Remove dirt and dust using a vac-
uum cleaner. Wipe dirty surfaces
with a cloth dampened with luke-
warm water.
 If dirt cannot be removed, wipe it off
with a soft cloth dampened with
neutral detergent diluted to approx-
imately 1%. Wring out any excess
water from the cloth and thoroughly
wipe off remaining traces of deter-
gent and water. ■
Shampooing the carpets
There are several commercial foaming-type
cleaners available. Use a sponge or brush
to apply the foam. Rub in overlapping cir-
cles. Do not use water. Wipe dirty surfaces
and let them dry. Excellent results are
obtained by keeping the carpet as dry as
possible. ■
Handling the seat belts
Clean with mild soap and lukewarm water
using a cloth or spon ge. Also check the
belts periodically for excessive wear, fraying
or cuts.
■
Front side windows with UV protective
coating (vehicles with UV protective
coating)
The front side windows have UV protective
coating. To prevent any damage to the UV
protective coating, observe the following:
●
If the windows are dirty, gently wipe them
with a cloth soaked in water or lukewarm
water as soon as possible. ●
If the windows are very dirty, do not open
and close them repeatedly.
Cleaning and protecting the
vehicle interior Perform cleaning in a manner
appropriate to each component
and its material.
Protecting the vehicle interior WARNING■
Water in the vehicle ●
Do not splash or spill liquid in the vehi-
cle, such as on the floor, in the hybrid
battery (traction battery) air vents, and
in the luggage compartment.
Doing so may cause the hybrid battery,
electrical components, etc. to mal-
function or catch fire. ●
Do not get any of the SRS components
or wiring in the vehicle interior wet.
( → P.32)
An electrical malfunction may cause
the airbags to deploy or not function
properly, resulting in death or serious
injury. ■
Cleaning the interior (especially
instrument panel)
Do not use polish wax or polish cleaner.
The instrument panel may reflect off the
windshield, obstructin g the driver’s view
and leading to an accident, resulting in
death or serious injury.
NOTICE■
Cleaning detergents ●
Do not use the following types of
detergent, as they may discolor the
vehicle interior or cause streaks or
damage to painted surfaces:
• Non-seat portions: Organic sub-
stances such as benzene or gasoline,
alkaline or acidic solutions, dye, and
bleach
• Seats: Alkaline or acidic solutions,
such as thinner, benzene, and alcohol
●
Do not use polish wax or polish
cleaner. The instrument panel’s or
other interior part’s painted surface
may be damaged.

448 Alphabetical Index
LEXUS NX300h Owners Manu-
al_USA_OM78212U Brake
Brake Hold .................................................... 180
Fluid ..................................................................405
Parking brake ................................................ 177
Regenerative braking ................................. 62
Warning light ...............................................366
Brake assist .................................................... 250
Brake Hold ...................................................... 180
Break-in tips...................................................... 151
Brightness control
Instrument panel light control ................ 84
BSM (Blind Spot Monitor)......................... 241
Blind Spot Monitor function................. 243
Rear Cross Traffic Alert function....... 246
BSM (Blind Spot Monitor) main switch241
C
Card key ...........................................................102
Care
Aluminum wheels ........................................314
Exterior ............................................................. 314
Interior ............................................................... 314
Seat belts.......................................................... 317
Cargo capacity...................................155, 400
Cargo hooks ................................................. 284
Cargo net hooks .......................................... 284
Chains .............................................................. 258
Child restraint system....................................47
Booster seats installation .......................... 53
Convertible seats installation.................. 52
Front passenger occupa nt classification
system ............................................................... 41
Infant seats definition................................... 49
Infant seats installation .................................. 51
Installing CRS with LATCH anchors . 55
Installing CRS with seat belts.................... 51
Installing CRS with top tether strap..... 57
LATCH anchors ........................................... 55
Child safety ....................................................... 46
12-volt battery precautions .......334, 393
Airbag precautions.......................................37
Back door precautions.............................. 110 Child restraint system ................................. 47
How your child should wear the seat belt
............................................................................. 28
Installing child restraints............................. 47
Moon roof precautions............................ 148
Power window lock switch .................... 145
Power window precautions .................. 145
Rear door child-protectors ................... 109
Removed key battery precautions... 348
Seat belt extender precautions.............. 28
Seat belt precautions .................................. 46
Seat heater precautions.......................... 275
Child-protectors........................................... 109
Cleaning .................................................. 314, 317
Aluminum wheels ........................................314
Exterior..............................................................314
Interior ...............................................................317
Seat belts ..........................................................317
Clock ................................................................288
Compass ......................................................... 303
Condenser .......................................................331
Console box .................................................. 282
Consumption screen .................................... 94
Coolant
Capacity ........................................................ 403
Checking ...................................................... 330
Preparing and checking before winter
.......................................................................... 257
Warning light .............................................. 366
Cooling system............................................. 330
Hybrid system overheating ..................394
Cruise control
Dynamic radar cruise control with full-
speed range ............................................... 217
Cup holders ................................................... 282
Curtain shield airbags .................................. 32
Customizable features ................................419
D
Daytime running light system .................. 184
Deck board .................................................... 285
Deck under tray ........................................... 285
