seat adjustment LEXUS NX300h 2018 Owners Manual

LEXUS NX300h Owners Manual_USA_OM78212U 1
2
3
4
5
6
7
8
9Pictorial index Search by illustration
For safety
and security Make sure to read through them
(Main topics: Child seat, theft deterrent system)
Vehicle status
information and
indicators Reading driving-related information
(Main topics: Meters, multi-information display)
Before driving Opening and closing the doors and windows,
adjustment before driving
(Main topics: Keys, doors, seats)
Driving Operations and advice which are necessary for driving
(Main topics: Starting hybrid system, refueling)
Interior features Usage of the interior features
(Main topics: Air conditioner, storage features)
Maintenance
and care Caring for your vehicle and maintenance procedures
(Main topics: Interior and exterior, light bulbs)
When trouble
arises What to do in case of malfunction and emergency
(Main topics: Battery discharge, flat tire)
Vehicle
specifications Vehicle specifications, customizable features
(Main topics: Fuel, oil, tire inflation pressure)
For owners Reporting safety defects for U.S. owners, and seat belt,
SRS airbag and headlight aim instructions for Canadian
owners
Index Search by symptom
Search alphabetically

251-1. For safe use
LEXUS NX300h Owners Manu-
al_USA_OM78212U 1
For safety and security
Adjust the angle of the seatback so
that you are sitting straight up and
so that you do not have to lean for-
ward to steer. ( → P.128)
Adjust the seat so that you can
depress the pedals fully and so that
your arms bend slightly at the
elbow when gripping the steering
wheel. ( → P.128, 139)
Lock the head restraint in place
with the center of the head restraint
closest to the top of your ears.
( → P.137)
Wear the seat belt correctly.
( → P.27) Make sure that all occupants are wear-
ing their seat belts before driving the
vehicle. ( → P.27)
Use a child restraint system appropri-
ate for the child until the child becomes
large enough to properly wear the
vehicle’s seat belt. ( → P.47)
Make sure that you can see the rear of For safe driving For safe driving, adjust the seat and
mirror to an appropriate position
before driving.
Correct driving posture
A
B
C
D WARNING
Observe the following precautions.
Failure to do so may result in death or
serious injury. ●
Do not adjust the position of the
driver’s seat while driving.
Doing so could cause the driver to lose
control of the vehicle. ●
Do not place a cushion between the
driver or passenger and the seatback.
A cushion may prevent correct pos-
ture from being achieved, and reduce
the effectiveness of the seat belt and
head restraint. ●
Do not place anything under the front
seats.
Objects placed under the front seats
may become jammed in the seat
tracks and stop the seat from locking in
place. This may lead to an accident
and the adjustment mechanism may
also be damaged. ●
Always observe the legal speed limit
when driving on public roads. ●
When driving over long distances, take
regular breaks before you start to feel
tired. Also, if you feel tired or sleepy
while driving, do not force yourself to
continue driving and take a break
immediately.
Correct use of the seat belts
Adjusting the mirrors

128 3-3. Adjusting the seats
LEXUS NX300h Owners Manu-
al_USA_OM78212U 3-3.Adjusting the seats
1 Seat position adjustment switch
2 Seat cushion (front) angle adjust-
ment switch
3 Vertical height adjustment switch
4 Seatback angle adjustment switch
5 Lumbar support adjustment switch
(for driver’s side) ■
Power easy access system
The driver’s seat and steering wheel move
in accordance with power switch mode and
the driver’s seat belt condition. ( → P.134)Front seats The seats can be adjusted (longitu-
dinally, vertically, etc.). Adjust the
seat to ensure the correct driving
posture.
Adjustment procedure WARNING■
When adjusting the seat position ●
Take care when ad justing the seat
position to ensure that other passen-
gers are not injured by the moving
seat. ●
Do not put your hands under the seat
or near the moving parts to avoid
injury.
Fingers or hands may become
jammed in the seat mechanism. ■
Seat adjustment
To reduce the risk of sliding under the lap
belt during a collision, do not recline the
seat more than necessary.
If the seat is too rec lined, the lap belt may
slide past the hips and apply restraint
forces directly to the abdomen, or your
neck may contact the shoulder belt,
increasing the risk of death or serious
injury in the event of an accident.
Adjustments should not be made while
driving as the seat may unexpectedly
move and cause the driv er to lose control
of the vehicle.

1293-3. Adjusting the seats
LEXUS NX300h Owners Manu-
al_USA_OM78212U 3
Before driving 
Manual seat
1 Reclining adjustment 
Power seat
1 Reclining adjustment ■
Operating conditions for reclining
adjustment (power seat)
When the following conditions are met,
switch operations are possible. ●
When the seatback position is within the
range in the following illustration from
the upright position.
●
When the other operation switches for
the seat being operated are not pressed. ■
Reclining adjustment (power seat)
Stop the seatback part way. To set the seat-
back to the rearmost position, press the
button again.
■
Power seat operations (if equipped)
If the seat has a cover or seat cushion, it may
not operate properly. Also, when folding
down the seat, check that there is nothing
on the rear seat that would interfere with
the operation.Rear seats Reclining adjustments and folding
the seat backs can be done with
either lever or switch operations.
Adjustment procedure
WARNING
■
When operating the seatback
Observe the following precautions.
Failure to do so may cause death or seri-
ous injury.
●
Keep other passenger s from being hit
with the seatback. A

130 3-3. Adjusting the seats
LEXUS NX300h Owners Manu-
al_USA_OM78212U ■
Before folding down the rear seat-
backs
1 Stow the rear center seat belt and
seat belt buckles. ( → P.30)
2 Lower the head restraint of the rear
seat. ( → P.137)■
Folding down rear seatbacks (man-
ual seat)
Pull the seatback angle adjustment
lever and fold down the seatback. ■
Folding down rear seatbacks
(power seat)
Press and hold the sw itch to fold down
the seatback. The buzzer sounds and operations start.
The buzzer sounds again when the opera-
tion is complete.
To stop the operation of a seat partway,
press either seat oper ation switch for that
seat, once more. Switches for that seat in
other locations can be used to stop the
operations. (buzzer sounds depending on
stopping position of the seatback) 
Instrument panel switchWARNING●
Do not bring your hands close to the
moving parts or between the seats, as
well as do not let any part of your body
get caught.●
Vehicles with power seat: Do not let
children operate the seatback as other
passengers may get caught in seat.●
Vehicles with power seat: Check that
there are no passengers sitting in the
seat before folding that seat forward.
Also, do let other passengers sit in the
seat while the seat is forward folding.■
Seat adjustment
To reduce the risk of sliding under the lap
belt during a collision, do not recline the
seat more than necessary.
If the seat is too reclined, the lap belt may
slide past the hips and apply restraint
forces directly to the abdomen, or your
neck may contact the shoulder belt,
increasing the risk of death or serious
injury in the event of an accident.
Adjustments should not be made while
driving as the seat may unexpectedly
move and cause the driver to lose control
of the vehicle.
Folding down the rear seatbacks

1353-3. Adjusting the seats
LEXUS NX300h Owners Manu-
al_USA_OM78212U 3
Before driving will be overwritten.
■
Seat positions that can be memorized
( → P.128)
The adjusted positions other than the posi-
tion adjusted by lumbar support switch can
be recorded. ■
In order to correctly use the driving
position memory function
If a seat position is already in the furthest
possible position and the seat is operated in
the same direction, the recorded position
may be slightly differen t when it is recalled.
1 Check that the shift lever is in P.
2 Turn the power switch to ON
mode. 3 Press one of the buttons for the
driving position you want to recall
until the buzzer sounds.
■
To stop the position recall operation
part-way through
Perform any of the following: ●
Press the “SET” button. ●
Press button “1”, “2” or “3”. ●
Operate any of the seat adjustment
switches (only cancels seat position
recall). ●
Operate the tilt and telescopic steering
control switch (onl y cancels steering
wheel position recall). ■
Operating the driving position memory
after turning the power switch off
Recorded seat positions can be activated
up to 180 seconds after the driver’s door is
opened and another 60 seconds after it is
closed again.
■
Registering procedure
Record your driving position to button
“1”, “2” or “3” before performing the
following:
Carry only the key yo u want to register,
and then close the driver’s door.
If 2 or more keys are in the vehicle, the WARNING■
Seat adjustment caution
Take care during seat adjustment so that
the seat does not strike the rear passen-
ger or squeeze your body against the
steering wheel.
Recalling a driving position
Registering/canceling/recall a
driving position to an electronic
key (memory recall function)

1373-3. Adjusting the seats
LEXUS NX300h Owners Manu-
al_USA_OM78212U 3
Before driving
■
Front seats
1 UpPull the head restraints up.
2 DownPush the head restraint down while press-
ing the lock release button . ■
Rear seats
1 Up Pull the head restraints up.
2 Down Push the head restra int down while press-
ing the lock release button .
■
Adjusting the heig ht of the head
restraints
Make sure that the head restraints are
adjusted so that the center of the head
restraint is closest to the top of your ears.
■
Adjusting the center rear seat head
restraint
Always raise the head restraint one level
from the stowed position when using.
Pull the head restraint up while press-
ing the lock release button .
If the head restraint touches the ceiling,
making the removal difficult, change
the seat height or angle. ( → P.128, 129)Head restraints Head restraints are provided for all
seats. WARNING■
Head restraint precautions
Observe the following precautions
regarding the head restraints.
Failure to do so may result in death or
serious injury. ●
Use the head restraints designed for
each respective seat.●
Adjust the head restraints to the cor-
rect position at all times.●
After adjusting the head restraints,
push down on them and make sure
they are locked in position.●
Do not drive with the head restraints
removed.
Vertical adjustment
ARemoving the head restraints A
A

1393-4. Adjusting the steering wheel and mirrors
LEXUS NX300h Owners Manu-
al_USA_OM78212U 3
Before driving 3-4.Adjusting the steering wheel and mirrors

Manual type
1 Hold the steering wheel and push
the lever down.
2 Adjust to the ideal position by mov-
ing the steering wheel horizontally
and vertically.After adjustment, pull the lever up to
secure the steering wheel.

Power type
Operating the switch moves the steer-
ing wheel in the following directions: 1 Up
2 Down
3 Toward the driver
4 Away from the driver ■
The steering wheel can be adjusted
when
The power switch is in ACCESSORY or
ON mode *
. *
: If the driver’s seat belt is fastened, the
steering wheel can be adjusted regard-
less of power switch mode. ■
Automatic adjustment of the steering
position (if equipped)
A desired steering posi tion can be entered
to memory and recalled automatically by
the driving position memory system.
( → P.134) ■
Power easy access system
The steering wheel and driver’s seat move
in accordance with power switch mode and
the driver’s seat belt condition. ( → P.134)
■
After adjusting the steering wheel
(manual type)
Make sure that the steering wheel is
securely locked.
The horn may not sound if the steering
wheel is not securely locked.Steering wheel
Adjustment procedure

274 5-2. Using the air conditio ning system and defogger
LEXUS NX300h Owners Manu-
al_USA_OM78212U To turn on the “DUAL” mode, perform
any of the following procedures:
 Press the “DUAL” button.
 Select “DUAL” on the option con-
trol screen.
 Adjust the temperature setting of
the passenger side with the passen-
ger side temperature adjustment
button. The indicator comes on when the “DUAL”
mode is on. ■
Location of air outlets
The air outlets and air volume changes
according to the selected air flow
mode.
■
Adjusting the position of and open-
ing and closing the air outlets 
Front
1 Direct air flow to the left or right, up
or down
2 Turn the knob to open or close the
ventNOTICE■
Humidity sensor
In order to detect fog on the windshield,
a sensor which monitors the temperature
of the windshield, the surround humidity,
etc., is installed.
Follow these points to avoid damaging
the sensor:
●
Do not disassemb le the sensor●
Do not spray the glass cleaner on the
sensor or subject it to strong impacts●
Do not stick anything on the sensor
Adjusting the temperature for
driver and passenger seats sepa-
rately (“DUAL” mode) Air outlet layout and operations

4018-1. Specifications
LEXUS NX300h Owners Manu-
al_USA_OM78212U 8
Vehicle specifications This number is also stamped under the
right-hand front seat. ■
Engine number
The engine number is stamped on the
engine block as shown.

FrontEngine Model 2.5 L 4-cylinder (2AR-FXE)
Type 4-cylinder in line, 4-cycle, gasoline
Bore and stroke 3.54 × 3.86 in. (90.0 × 98.0 mm)
Displacement 152.2 cu.in. (2494 cm 3
)
Valve clearance (engine cold) Automatic adjustment
Drive belt tension Automatic adjustment
Fuel Fuel type Unleaded gasoline only
Octane Rating 87 (Research Octane Number 91) or higher
Fuel tank capacity (Reference) 14.8 gal. (56 L, 12.3 Imp.gal.)
Electric motor (traction motor) Type Permanent magnet synchronous motor
Maximum output 105 kW
Maximum torque 199 ft•lbf (270 N•m, 27.5 kgf•m)
