glove box LEXUS NX300h 2021 Owners Manual

1093-1. Key information
LEXUS NX300h Owners Manual_USA_M78578_en
3
Before driving
■When required to leave the vehicle’s
key with a parking attendant
Lock the glove box as circumstances
demand. ( P.306)
Remove the mechanical key for your own
use and provide the attendant with the elec-
tronic key only.
■If you lose your mechanical keys
 P.411
■If a wrong key is used
The key cylinder rotates freely to isolate
inside mechanism.
■Card key
●If it is difficult to take out the mechanical
key, push down the release button using a
pen tip, etc. If it is still difficult to pull it out,
use a coin, etc.
●To store the mechanical key in the card
key, insert it while pressing the release
button.
NOTICE
■Handling the card key
Do not apply excess force when inserting
the mechanical key into the card key.
Doing so may damage the card key.

1283-2. Opening, closing and locking the doors
LEXUS NX300h Owners Manual_USA_M78578_en
tronic key from re
ceiving radio waves.
Press twice while pressing and
holding .
Confirm that the elec tronic key indicator
flashes 4 times. While the battery-saving
mode is set, the smar t access system with
push-button start cannot be used. To cancel
the function, press any of the electronic key
buttons.
■Conditions affe cting operation
The smart access system with push-button
start, wireless remote control and immobi-
lizer system use weak radio waves. In the
following situations, the communication
between the electronic key and the vehicle
may be affected, preventing the smart
access system with push -button start, wire-
less remote control and immobilizer system
from operating properly. (Ways of coping:
 P.412)
●When the electronic key battery is
depleted
●Near a TV tower, electric power plant,
gas station, radio stat ion, large display,
airport or other faci lity that generates
strong radio waves or electrical noise
●When the electronic key is in contact
with, or is covered by the following metal-
lic objects
• Cards to which aluminum foil is attached
• Cigarette boxes that have aluminum foil
inside
• Metallic wallets or bags
•Coins
• Hand warmers made of metal
• Media such as CDs and DVDs
●When other wireless ke ys (that emit radio
waves) are being used nearby
●When carrying the electronic key together with the following devices that
emit radio waves
• Portable radio, cellular phone, cordless
phone or other wireless communication
devices
• Another vehicle’s electronic key or a
wireless key that emits radio waves
• Personal computers or personal digital assistants (PDAs)
• Digital audio players
• Portable game systems
●If window tint with a metallic content or
metallic objects are attached to the rear
window
●When the electronic key is placed near a
battery charger or electronic devices
■Note for the entry function
●Even when the electronic key is within the
effective range (detection areas), the sys-
tem may not operate properly in the fol-
lowing cases:
• The electronic key is too close to the win-
dow or outside door handle, near the
ground, or in a high place when the doors
are locked or unlocked.
• The electronic key is near the ground or in a high place, or too close to the rear
bumper center when the back door is
opened.
• The electronic key is on the instrument panel, luggage room, floor, or in the door
pockets or glove box when the hybrid
system is started or power switch modes
are changed.
●Do not leave the electronic key on top of
the instrument panel or near the door
pockets when exiting the vehicle.
Depending on the radio wave reception
conditions, it may be detected by the
antenna outside the cabin and the door
will become lockable from the outside,
possibly trapping the electronic key
inside the vehicle.
●As long as the electronic key is within the
effective range, the doors may be locked
or unlocked by anyone.
●Even if the electronic key is not inside the
vehicle, it may be po ssible to start the
hybrid system if the el ectronic key is near
the window.
●The doors may unlock if a large amount

1594-1. Before driving
LEXUS NX300h Owners Manual_USA_M78578_en
4
Driving
WARNING
●Do not shift the shift lever to R while
the vehicle is moving forward.
Doing so can damage the transmission
and may result in a loss of vehicle con-
trol.
●Do not shift the shift lever to a driving
position while the vehicle is moving
backward.
Doing so can damage the transmission
and may result in a loss of vehicle con-
trol.
●Shifting the shift lever to N while the
vehicle is moving will disengage the
hybrid system.
Engine braking is not available when N
is selected.
●Be careful not to shift the shift lever
with the accelerator pedal depressed.
Shifting the shift lever to any position
other than P or N may lead to unex-
pected rapid acceleration of the vehi-
cle that may cause an accident and
result in death or serious injury.
■If you hear a squealing or scraping
noise (brake pad wear limit indica-
tors)
Have the brake pads checked and
replaced by your Lexus dealer as soon as
possible. Rotor damage may result if the
pads are not replaced when needed.
It is dangerous to drive the vehicle when
the wear limits of the brake pads and/or
those of the brake discs are exceeded.
■When the vehicle is stopped
●Do not depress the accelerator pedal
unnecessarily.
If the shift lever is in any position other
than P or N, the vehicle may acceler-
ate suddenly and unexpectedly, caus-
ing an accident.
●In order to prevent accidents due to
the vehicle rolling away, always keep
depressing the brake pedal while
stopped with the “READY” indicator is
illuminated, and apply the parking
brake as necessary.
●If the vehicle is stopped on an incline,
in order to prevent accidents caused
by the vehicle rolling forward or back-
ward, always depress the brake pedal
and securely apply the parking brake
as needed.
●Avoid revving or racing the engine.
Running the engine at high speed
while the vehicle is stopped may cause
the exhaust system to overheat, which
could result in a fire if combustible
material is nearby.
■When the vehicle is parked
●Do not leave glasses, cigarette lighters,
spray cans, or soft drink cans in the
vehicle when it is in the sun.
Doing so may result in the following:
• Gas may leak from a cigarette lighter or spray can, and may lead to a fire.
• The temperature inside the vehicle may cause the plastic lenses and plas-
tic material of glasses to deform or
crack.
• Soft drink cans may fracture, causing the contents to spray over the interior
of the vehicle, and may also cause a
short circuit in the vehicle’s electrical
components.
●Do not leave cigarette lighters in the
vehicle. If a cigare tte lighter is in a
place such as the glove box or on the
floor, it may be lit accidentally when
luggage is loaded or the seat is
adjusted, causing a fire.
●Do not attach adhesive discs to the
windshield or windows. Do not place
containers such as air fresheners on
the instrument panel or dashboard.
Adhesive discs or containers may act
as lenses, causing a fire in the vehicle.
●Do not leave a door or window open if
the curved glass is coated with a met-
allized film such as a silver-colored
one. Reflected sunlight may cause the
glass to act as a lens, causing a fire.

3045-4. Using the storage features
LEXUS NX300h Owners Manual_USA_M78578_en
5-4.Using the storage features
Glove box (P.306)
Bottle holders ( P.306)
Console box ( P.306)
Cup holders ( P.306)
Auxiliary box ( P.307)
List of storage features
Location of the storage features
A
B
C
D
E
WARNING
■Items that should not be left in the
vehicle
Do not leave glasses, lighters or spray
cans in the storage spaces, as this may
cause the following when cabin tempera-
ture becomes high:
●Glasses may be deformed by heat or
cracked if they come into contact with
other stored items.
●Lighters or spray ca ns may explode. If
they come into contact with other
stored items, the lighter may catch fire
or the spray can may release gas,
causing a fire hazard.
■When storage compartments are not
in use
When driving or when the glove box and
the console box are not in use, keep it
closed.
In the event of sudden braking or sudden
swerving, an accident may occur due to
an occupant being struck by an open lid
or the items stored inside.

3055-4. Using the storage features
LEXUS NX300h Owners Manual_USA_M78578_en
5
Interior features
1Open (press the button)
2 Unlock with the mechanical key
3 Lock with the mechanical key
■Glove box light
The glove box light turns on when the tail
lights are on.
1 Lift the lid while pushing the button
to release the lock. 2
Vehicles with wireless charger: Lift
the wireless charger.
■Console box tray (vehicles without wire-
less charger)
The tray slides forward/backward and can
be removed.
■Console box light
The console box light turns on when the tail
lights are on.
■Cup holders
Front
Rear Pull down the armrest and push the
release button.
Glove box
Console box
Cup holders/bottle holders

3686-3. Do-it-yourself maintenance
LEXUS NX300h Owners Manual_USA_M78578_en
1Turn the power switch off.
2 Open the glove box. Slide off the
damper.
3 Push in the glove box on the vehi-
cle’s outer side to disconnect the
claws. Then pull out the glove box
and disconnect the lower claws. 4
Remove the filter cover.
5 Remove the air conditioning filter
and replace it with a new one.
The “ UP” marks shown on the filter
should be pointing up.
■Checking interval
Inspect and replace the air conditioning fil-
ter according to the maintenance schedule.
In dusty areas or areas with heavy traffic
flow, early replacement may be required.
(For scheduled maintenance information,
please refer to the “Owner’s Manual Sup-
plement” or “Scheduled Maintenance”.)
■If air flow from the vents decreases dra-
matically
The filter may be clogged. Check the filter
and replace if necessary.
■Air conditioning filt er with deodorizing
function
When fragrances are placed in your vehi-
cle, the deodorizing effect may become
significantly weakened in a short period:
When an air conditioning odor comes out
continuously, replace the conditioning filter.
Air conditioning filter
The air conditioning filter must be
changed regularly to maintain air
conditioning efficiency.
Removal method

LEXUS NX300h Owners Manual_USA_M78578_en
Alphabetical Index475
Replacing light bulbs................................ 376
Wattage............................................................ 431
Front turn signal lights Replacing light bulbs.................... 375, 376
Turn signal lever .......................................... 183
Wattage............................................................ 431
Fuel Capacity ......................................................... 425
Fuel gauge ....................................................... 84
Gas station information..........................484
Information .................................................... 432
Refueling ........................................................ 203
Type.................................................................. 425
Warning light ............................................... 393
Fuel filler door ............................................... 203 Refueling ........................................................ 203
When the fuel filler door cannot be opened ............................................................411
Fuses ................................................................... 371
G
Garage door opener ................................. 322
Gas station information ............................ 484
Gauges ............................................................... 84
Glove box ....................................................... 306
Glove box light ............................................. 306
Grocery bag hooks .................................... 309
H
Head restraints ................................................ 141
Head-up display.............................................. 95
Headlights ....................................................... 190 Automatic headlight leveling .................. 191
Automatic High Beam ..............................193
Light switch .................................................... 190
Replacing light bulbs................................ 375
Heated steering wheel ..............................300
Heaters Automatic air conditioning system ..... 291
Heated steering wheel............................ 299
Outside rear view mirrors .................... 292 Seat heaters ................................................. 300
High mounted stoplight Replacing light bulb ..................................375
Hill-start assist control ............................... 273
Hood ................................................................. 346 Open................................................................346
Hooks Cargo hooks............................................... 308
Retaining hooks (floor mat) ..................... 24
Horn ....................................................................144
Hybrid battery (traction battery) Location ............................................................. 70
Specification ................................................. 426
Hybrid battery air vent ..................................72
Hybrid system ...................................................67 Acoustic vehicle alerting system...........69
Emergency shut off system...................... 73
Energy monitor/consumption screen99
EV drive mode............................................. 178
High voltage components ....................... 70
Hybrid System Indicator ........................... 87
Hybrid system precautions...................... 70
Hybrid vehicle driving tips .................... 277
If the hybrid system will not start ....... 409
Overheating .................................................. 418
Power switch..................................................174
Regenerative braking .................................68
Starting the hybrid system .......................174
Warning lights ............................................ 388
Hybrid System Indicator......................84, 87
Hybrid transmission..................................... 180
I
I/M test ............................................................ 342
Identification Engine..............................................................425
Vehicle ............................................................ 424
Ignition switch (Power switch) ................. 174
Illuminated entry system ........................... 302
Immobilizer system........................................ 75
Indicators ........................................................... 82
