oil pressure LEXUS NX300h 2021 Owners Manual

1
2
3
4
5
6
7
8
9
LEXUS NX300h Owners Manual_USA_M78578_en
Pictorial indexSearch by illustration
For safety
and securityMake sure to read through them
(Main topics: Child seat, theft deterrent system)
Vehicle status
information and
indicatorsReading driving-related information
(Main topics: Meters, multi-information display)
Before drivingOpening and closing the doors and windows,
adjustment before driving
(Main topics: Keys, doors, seats)
DrivingOperations and advice which are necessary for driving
(Main topics: Starting hybrid system, refueling)
Interior featuresUsage of the interior features
(Main topics: Air conditioner, storage features)
Maintenance
and careCaring for your vehicle and maintenance procedures
(Main topics: Interior and exterior, light bulbs)
When trouble
arisesWhat to do in case of malfunction and emergency
(Main topics: Battery discharge, flat tire)
Vehicle
specificationsVehicle specifications, customizable features
(Main topics: Fuel, oil, tire inflation pressure)
For ownersReporting safety defects for U.S. owners, and seat belt,
SRS airbag and headlight aim instructions for Canadian
owners
IndexSearch by symptom
Search alphabetically

4TABLE OF CONTENTS
LEXUS NX300h Owners Manual_USA_M78578_en
Luggage compartment features
........................................................... 308
5-5. Using the other interior features Other interior features ............... 312
Garage door opener.................. 322
Compass.......................................... 328
6-1. Maintenance and care Cleaning and protecting the vehi-cle exterior ................................... 332
Cleaning and protecting the vehi- cle interior .................................... 335
6-2. Maintenance Maintenance requirements ..... 339
General maintenance ................ 340
Emission inspection and mainte- nance (I/M) programs ............ 342
6-3. Do-it-yourself maintenance Do-it-yourself service precautions........................................................... 344
Hood.................................................. 346
Positioning a floor jack............... 346
Engine compartment.................. 348
12-volt battery................................ 354
Tires ................................................... 357
Tire inflation pressure ................. 365
Wheels.............................................. 367
Air conditioning filter..................368
Electronic key battery ................ 369
Checking and replacing fuses . 371
Headlight aim................................. 373
Light bulbs ....................................... 3757-1. Essential information
Emergency flashers .................... 380
If your vehicle has to be stopped in an emergency ............................ 380
If the vehicle is trapped in rising water ............................................... 381
7-2. Steps to take in an emergency If your vehicle needs to be towed.......................................................... 383
If you think something is wrong .......................................................... 386
If a warning light turns on or a warn- ing buzzer sounds..................... 388
If a warning messa ge is displayed
.......................................................... 398
If you have a flat tire .................... 402
If the hybrid syst em will not start
.......................................................... 409
If you lose your keys....................... 411
If the fuel filler door cannot be opened ............................................. 411
If the electronic key does not oper- ate properly ................................... 412
If the 12-volt battery is discharged ............................................................ 414
If your vehicle overheats ............ 418
If the vehicle becomes stuck ..... 421
8-1. Specifications Maintenance data (fuel, oil level, etc.) .................................................. 424
Fuel information .

........................... 432
Tire information ............................ 434
6Maintenance and care
7When trouble arises
8Vehicle specifications

13Pictorial index
LEXUS NX300h Owners Manual_USA_M78578_en
Windshield wipers ........................................................................................ P.196, 201
Precautions against winter season ................... ......................................................... P.279
To prevent freezing (windshield wiper de-icer) .................................................. P.296
Precautions against car wash ...................................................................................... P.333
Fuel filler door ........................................................................................................ P.203
Refueling method .............................................................................................................P. 203
Fuel type/fuel tank capacity ...... ................................................................................... P.425
Tires.......................................................................................................................... ..P.357
Tire size/inflation pressure ...........................................................................................P.430
Winter tires/tire chain .................................................................................................... P.27 9
Checking/rotation/tire pressure warning system.............................................. P.357
Coping with flat tires........................................................................................................ P .402
Hood ..........................................................................................................................P.346
Opening ........................................................................................................................ ....... P.346
Engine compartment cover ......................................................................................... P.349
Engine oil ..................................................................................................................... ......... P.426
Coping with overheat ...................................................................................................... P.418
Warning messages ..........................................................................................................P.398
Headlights .................................................................................................................P.19 0
Parking lights/daytime running lights...............................................................P.190
Fog lights.................................................................................................................... P .196
Cornering lights
*.................................................................................................................P.192
Turn signal lights ......................................................................................................P.183
Tail lights .................................................................................................................... P.190
License plate lights .................................................................................................P.190
Back-up light
Shifting the shift lever to R .............................................................................................. P.18 0
Light bulbs of the exterior lights for driving
(Replacing method: P.375, Watts: P.431)
D
E
F
G
H
I
J
K
L
M
N

802-1. Instrument cluster
LEXUS NX300h Owners Manual_USA_M78578_en
2-1.Instrument cluster
For the purpose of explanatio n, the following illustration displays all warning lights
and indicators illuminated.
The units used on the meter and some in dicators may differ depending on the tar-
get region.
Warning lights inform the driver of mal-
functions in any of the vehicle’s sys-
tems.
Warning lights and indicators
The warning lights and indicators inform th e driver of the status of the vehicle’s
various systems.
Instrument cluster
Warning lights
(U.S.A.)
Brake system warning light*1
(  P.388)
(Red)
(Canada)
Brake system warning light*1
(  P.388)
Charging system warning
light
*2 (  P.388)
Output control warning light*2
(  P.388, 399)
Low engine oil pressure warn-
ing light
*2 (  P.389)
High coolant temperature
warning light
*2 (  P.389)
(Yellow)
Brake system warning light*1
(  P.389)
(U.S.A.)
Malfunction indicator lamp*1
(  P.389)

902-1. Instrument cluster
LEXUS NX300h Owners Manual_USA_M78578_en
will be shown.
Call sending/receiving and history
display
Linked with the hands-free system, sending
or receiving call is displayed. For details
regarding the hands-fr
ee system, refer to
the “NAVIGATION AND MULTIMEDIA
SYSTEM OWNER’S MANUAL”.
■Content displayed as drive infor-
mation
Select to display various drive data.
Items displayed can be switched by
pressing or of the meter con-
trol switches to select and pressing
or .
 Current fuel consumption
*1
Displays the current rate of fuel consump-
tion
Average fuel consumption (after
reset
*2/after start/after refuel)*1
Displays the average fuel consumption
since the function was reset, the hybrid sys-
tem was started, and the vehicle was refu-
eled, respectively
Use the displayed average fuel consump-
tion as a reference.
 Average vehicle speed (after
reset
*2/after start)*1
Displays the average vehicle speed since
the function was reset and the hybrid sys-
tem was started, respectively
Elapsed time (after reset*2/after
start)
*1
Displays the elapsed time since the func-
tion was reset and the hybrid system was
started, respectively
 Distance (driving range/after start)*1
Displays the estimated maximum distance
that can be driven with the quantity of fuel
remaining and the distan ce driven after the
hybrid system was started respectively.
• This distance is computed based on your average fuel consumption. As a result,
the actual distance that can be driven
may differ from that displayed.
• When only a small amount of fuel is added to the tank, the display may not be
updated.
When refueling, turn the power switch
off. If the vehicle is refueled without turn-
ing the power switch off, the display may
not be updated.
*1: Displayed when the it em is set in “Drive
Info 1”, “Drive Info 2” and “Drive Info 3”.
*2: The function can be reset by pressing
the of the meter control switches
for longer than 1 second when the item
to reset is displayed.
If there is more than one item that can
be reset, the item selection screen will
appear.
■Energy monitor
 P.99
■G monitor (if equipped)
Displays the acceleration forces of the
front, back, left and right of the vehicle.
Also displays the turning angle of the
steering wheel, brake oil pressure,
accelerator opening.
 The actual vehicle conditions may
differ from those on the display
Drive information
E

932-1. Instrument cluster
LEXUS NX300h Owners Manual_USA_M78578_en
2
Vehicle status information and indicators
which sounds when the parking support
alert is operated.
■ PKSB (Parking Support
Brake function) (if equipped)
(  P.253)
 PKSB on/off
Select to enable/dis able the parking sup-
port brake function (for static objects).
■ RSA (Road Sign Assist) (if
equipped) ( P.235)
Select to set up the following items.
 Road Sign Assist
Select to enable/disable road sign assist.
Over Speed
Select to set the over speed alert on/off.
Level of Over Speed
Select to set the over speed alert level.
Others
Select to set the other road sign assist.
■Clock
Select to switch between 12-hour dis-
play and 24-hour display.
■Vehicle Settings
 PBD (Power Back Door)
*1
(  P.114)
Select to set up the following items.
•System settings
Select to enable/dis able the power back
door system.
•Volume
Select to set the volume of the buzzer
which sounds when the power back door
system. • Kick Sensor
*2
Select to enable/dis
able the kick sensor.
*1: Vehicles with power back door
*2: Vehicles with Hand s Free Power Back
Door
 TPMS (Tire Pressure Warning Sys-
tem) ( P.359)
Select to initialize the tire pressure warning
system.
 Scheduled Maintenance ( P.339)
Select to initialize the scheduled mainte-
nance.
 Oil maintenance ( P.350)
Select to reset the engine oil maintenance
information (message indicating mainte-
nance is required and distance until the
next oil change) after engine oil mainte-
nance is performed.
■Meter settings
 Language
Select to change the language on the dis-
play.
 Units
Select to change the unit of measure for
fuel consumption.
 EV Indicator ( P.68)
Select to set the EV indicator on/off.
 Switch settings ( P.89)
Displays a procedure to register a desired
screen to
.
You can register 1 screen as a shortcut,
which can be displayed by pressing
.
 Drive information screen ( P.90)

2794-6. Driving tips
LEXUS NX300h Owners Manual_USA_M78578_en
4
Driving
Use fluids that are appropriate to
the prevailing outside temperatures.
•Engine oil
• Engine/power control unit coolant
•Washer fluid
Have a service technician inspect
the condition of the 12-volt battery.
 Have the vehicle fitted with four
snow tires or purchase a set of tire
chains for the front tires
*.
Ensure that all tires are the same size and
brand, and that chains match the size of the
tires.
*: Tire chains cannot be mounted on the
225/60R18 tires.
Perform the following according to the
driving conditions:
 Do not try to forcibly open a window
or move a wiper that is frozen. Pour
warm water over the frozen area to
Winter driving tips
Carry out the necessary prepara-
tions and inspections before driving
the vehicle in winter. Always drive
the vehicle in a manner appropriate
to the prevailing weather condi-
tions.
Preparation for winter
WARNING
■Driving with snow tires
Observe the following precautions to
reduce the risk of accidents. Failure to do
so may result in a loss of vehicle control
and cause death or serious injury.
●Use tires of the specified size.
●Maintain the recommended level of air
pressure.
●Do not drive in excess of 75 mph (120
km/h), regardless of the type of snow
tires being used.
●Use snow tires on all, not just some
wheels.
■Driving with tire chains
Observe the following precautions to
reduce the risk of accidents. Failure to do
so may result in the vehicle being unable
to be driven safely, and may cause death
or serious injury.
●Do not drive in excess of the speed
limit specified for the tire chains being
used, or 30 mph (50 km/h), which-
ever is lower.
●Avoid driving on bumpy road surfaces
or over potholes.
●Avoid sudden acceleration, abrupt
steering, sudden br aking and shifting
operations that cause sudden engine
braking.
●Slow down sufficiently before entering
a curve to ensure that vehicle control is
maintained.
●Do not use LDA (Lane Departure
Alert with steering control) (if
equipped).
●Do not use LTA (Lane Tracing Assist)
(if equipped).
NOTICE
■Repairing or replacing snow tires
Request repairs or replacement of snow
tires from Lexus dealers or legitimate tire
retailers. This is be cause the removal and
attachment of snow tires affects the
operation of the tire pressure warning
valves and transmitters.
Before driving the vehicle

3326-1. Maintenance and care
LEXUS NX300h Owners Manual_USA_M78578_en
6-1.Maintenance and care
Working from top to bottom, liber-
ally apply water to the vehicle body,
wheel wells and underside of the
vehicle to remove any dirt and dust.
 Wash the vehicle body using a
sponge or soft cloth, such as a
chamois.
 For hard-to-remove marks, use car
wash soap and rinse thoroughly with
water.
 Wipe away any water.
 Wax the vehicle when the water-
proof coating deteriorates.
If water does not bead on a clean surface,
apply wax when the vehicle body is cool.
■Self-restoring coat
The vehicle body has a self-restoring coat-
ing that is resistant to small surface
scratches caused in a car wash etc.
●The coating lasts for 5 to 8 years from
when the vehicle is delivered from the
plant.
●The restoration time differs depending on
the depth of the scratch and outside tem-
perature. The restoration time may
become shorter when the coating is
warmed by applying warm water.
●Deep scratches caused by keys, coins,
etc. cannot be restored.
●Do not use wax that contain abrasives.
■Automatic car washes
●Before washing the vehicle:
• Fold the mirrors
• Turn off the power back door (if equipped)
Start washing from the front of the vehicle.
Extend the mirrors before driving.
●Brushes used in automatic car washes
may scratch the vehicle surface, parts
(wheel, etc.) and harm your vehicle’s
paint.
●Rear spoiler may not be washable in
some automatic car washes. There may
also be an increased risk of damage to
vehicle.
■High pressure car washes
As water may enter the cabin, do not bring
the nozzle tip near the gaps around the
doors or perimeter of the windows, or spray
these areas continuously.
■Note for a smart access system with
push-button start
●If the door handle becomes wet while the
electronic key is within the effective
range, the door may lock and unlock
repeatedly. In that case, follow the follow-
ing correction procedures to wash the
vehicle:
• Place the electronic key in a location 6 ft. (2 m) or more away from the vehicle.
(Take care to ensure that the key is not
stolen.)
• Set the electronic key to battery-saving mode to disable the smart access system
with push-button start. ( P.127)
■Wheels and wheel ornament
●Remove any dirt immediately by using a
neutral detergent.
●Wash detergent off with water immedi-
ately after use.
●To protect the paint from damage, make
sure to observe the following precau-
tions.
• Do not use acidic, alkaline or abrasive detergent
• Do not use hard brushes
• Do not use detergent on the wheels when they are hot, such as after driving or park-
Cleaning and protecting the
vehicle exterior
Perform cleaning in a manner
appropriate to each component
and its material.
Cleaning instructions

3346-1. Maintenance and care
LEXUS NX300h Owners Manual_USA_M78578_en
NOTICE
■To prevent paint deterioration and
corrosion on the body and compo-
nents (aluminum wheels etc.)
●Wash the vehicle immediately in the
following cases:
• After driving near the sea coast
• After driving on salted roads
• If coal tar or tree sap is present on the paint surface
• If dead insects, in sect droppings or
bird droppings are present on the
paint surface
• After driving in an area contaminated with soot, oily smoke, mine dust, iron
powder or chemical substances
• If the vehicle becomes heavily soiled with dust or mud
• If liquids such as benzene and gasoline are spilled on the paint surface
●If the paint is chip ped or scratched,
have it repaired immediately.
●To prevent the wheels from corroding,
remove any dirt and store in a place
with low humidity when storing the
wheels.
■Cleaning the exterior lights
●Wash carefully. Do not use organic
substances or scrub with a hard brush.
This may damage the surfaces of the
lights.
●Do not apply wax to the surfaces of the
lights.
Wax may cause damage to the lenses.
■To prevent damage to the windshield
wiper arms
When lifting the wiper arms away from
the windshield, pull the driver side wiper
arm upward first, and repeat for the pas-
senger side. When returning the wipers
to their original position, do so from the
passenger side first.
■When using an automatic car wash
(vehicles with rain-sensing windshield
wipers)
Set the wiper switch to the off position.
If the wiper switch is in “AUTO”, the wip-
ers may operate and the wiper blades
may be damaged.
■When using a high pressure car wash
●When washing the vehicle, do not let
water of the high pressure washer hit
directly or the vicinity of the camera.
Due to the shock from the high pres-
sure water, it is possible the device may
not operate as normal.
●Do not bring the nozzle tip close to
boots (rubber or resin manufactured
cover), connectors or the following
parts. The parts may be damaged if
they come into contact with high-pres-
sure water.
• Traction related parts
•Steering parts
• Suspension parts
• Brake parts
●Keep the cleaning nozzle at least 11.9
in. (30 cm) away from the vehicle
body. Otherwise resin section, such as
moldings and bumpers, may be
deformed and damaged. Also, do not
continuously hold the nozzle in the
same place.
●Do not spray the lower part of the
windshield continuously. If water
enters the air conditioning system
intake located near the lower part of
the windshield, the air conditioning
system may not operate correctly.
●Do not wash the underside of the vehi-
cle using a high pressure car washer.

3456-3. Do-it-yourself maintenance
LEXUS NX300h Owners Manual_USA_M78578_en
6
Maintenance and care
Tire inflation
pressure
( P.365)• Tire pressure gauge
• Compressed air source
Washer fluid
( P.353)
• Water or washer fluid
containing antifreeze
(for winter use)
• Funnel (used only for adding water or washer
fluid)
WARNING
The engine compartment contains many
mechanisms and fluids that may move
suddenly, become hot, or become elec-
trically energized. To avoid death or seri-
ous injury, observe the following
precautions.
■When working on the engine com-
partment
●Make sure that the “IGNITION ON”
on the multi-information display and
the “READY” indicator are both off.
●Keep hands, clothi ng and tools away
from the moving fan and engine drive
belt.
●Be careful not to touch the engine,
power control unit, radiator, exhaust
manifold, etc. right after driving as they
may be hot. Oil and other fluids may
also be hot.
●Do not leave anything that may burn
easily, such as paper and rags, in the
engine compartment.
●Do not smoke, cause sparks or expose
an open flame to fuel. Fuel fumes are
flammable.
ItemsParts and tools■When working near the electric cool-
ing fans or radiator grille
Be sure the power switch is off.
With power switch in ON mode, the
electric cooling fans may automatically
start to run if the air conditioning is on
and/or the coolant temperature is high.
(  P.352)
■Safety glasses
Wear safety glasses to prevent flying or
falling material, fluid spray, etc. from get-
ting in your eyes.
NOTICE
■If you remove the air cleaner filter
Driving with the air cleaner filter
removed may cause excessive engine
wear due to dirt in the air.
