service indicator LEXUS RC F 2017 Owners Manual

4726-4. Using the other interior features
“SOS” button
LED light indicators
Microphone
LEXUS Enform Safety Connect∗∗
: If equipped
Safety Connect is a subscription-based telematics service that uses Global
Positioning System (GPS) data and embe dded cellular technology to provide
safety and security features to subscribers. Safety Connect is supported by
Lexus’ designated response center, wh ich operates 24 hours per day, 7 days
per week.
Safety Connect service is available by su bscription on select, telematics hard-
ware-equipped vehicles.
By using the Safety Connect service, you are agreeing to be bound by the
Telematics Subscription Service Agre ement and its Terms and Conditions, as
in effect and amended from time to time, a current copy of which is available
at Lexus.com. All use of the Safety Co nnect service is subject to such then-
applicable Terms and Conditions.
System components
1
2
3

4746-4. Using the other interior features
When the engine switch is turned to IGNITION ON mode, the red indicator
light comes on for 2 seconds then turns off. Afterward, the green indicator light
comes on, indicating that the service is active.
The following indicator light patterns indicate specific system usage conditions:
●Green indicator light on = Active service
●Green indicator light flashing = Safety Connect call in process
●Red indicator light (except at vehicle start-up) = System malfunction (contact
your Lexus dealer)
●No indicator light (off) = Safety Connect service not active
■Automatic Collision Notification
In case of either airbag deployment or severe rear-end collision, the system is
designed to automatically call the re sponse center. The responding agent
receives the vehicle’s location and attempts to speak with the vehicl\
e occu-
pants to assess the level of emergency. If the occupants are unable to commu-
nicate, the agent automatically treats the call as an emergency, contacts the
nearest emergency services provider to describe the situation, and requests
that assistance be sent to the location.
Safety Connect LED light Indicators
Safety Connect services

4917-2. Maintenance
7
Maintenance and care
General maintenance
Listed below are the general maintenance items that should be performed at
the intervals specified in the “Warranty and Service Guide” or “Owner’s
Manual Supplement”. It is recommende d that any problem you notice should
be brought to the attention of your Lexu s dealer or qualified service shop for
advice.
Engine compartment
ItemsCheck points
BatteryCheck the indicator (if equipped) and connections. (→ P. 513)
Brake fluidIs the brake fluid at the correct level? ( →P. 512)
Engine/intercooler coolantIs the engine/intercooler c oolant at the correct level?
( → P. 509)
Engine oilIs the engine oil at the correct level? ( →P. 504)
Exhaust systemThere should not be any fumes or strange sounds.
Radiator, condenser and
intercooler radiatorThe radiator, condenser and intercooler radiator
should be free from foreign objects. ( →P. 511)
Washer fluidIs there sufficient washer fluid? ( →P. 516)

4947-2. Maintenance
The OBD system determines that a problem exists somewhere in the emission
control system. Your vehicle may not pass the I/M test and may need to be
repaired. Contact your Lexus dealer to service the vehicle.
●When the battery is disconnected or discharged
Readiness codes that are set during ordinary driving are erased.
Also, depending on your driving habits , the readiness codes may not be com-
pletely set.
●When the fuel tank cap is loose
The malfunction indicator lamp comes on indicating a temporary malfunction
and your vehicle may not pass the I/M test.
The error code in the OBD system will not be cleared unless the vehicle \
is driven
40 or more times.
Contact your Lexus dealer to pr epare the vehicle for re-testing.
Emission inspection and maintenance (I/M)
programs
Some states have vehicle emission in spection programs which include OBD
(On Board Diagnostics) checks. The OBD system monitors the operation of
the emission control system.
If the malfunction indicator lamp comes on
Your vehicle may not pass the I/M te st in the following situations:
When the malfunction indicator lamp still remains on after several driv-
ing trips
If your vehicle does not pass the I/M test

6599-1. Specifications
9
Vehicle specifications
■Recommendation of the use of gasoline containing detergent additives
●Lexus recommends the use of gasoline that contains detergent additives to avoid the
build-up of engine deposits.
●All gasoline sold in the U.S.A. contains minimum detergent additives to clean and/or
keep clean intake systems, per EPA’s lowest additives concentration program.
●Lexus strongly recommends the use of Top Tier Detergent Gasoline. For more informa-
tion on Top Tier Detergent Gasoline and a lis t of marketers, please go to the official
website www.toptiergas.com.
■Recommendation of the use of low emissions gasoline
Gasolines containing oxygenates such as et hers and ethanol, as well as reformulated
gasolines, are available in some cities. Thes e fuels are typically acceptable for use, pro-
viding they meet other fuel requirements.
Lexus recommends these fuels, since the form ulations allow for reduced vehicle emis-
sions.
■Non-recommendation of the use of blended gasoline
●If you use gasohol in your vehicle, be sure that it has an octane ra ting no lower than 91.
●Lexus does not recommend the use of gasoline containing methanol.
■Non-recommendation of the use of gasoline containing MMT
Some gasoline contains an octane enhancing additive called MMT (Methylcyclopenta-
dienyl Manganese Tricarbonyl).
Lexus does not recommend the use of gasoline that contains MMT. If fuel containing
MMT is used, your emission control system may be adversely affected.
The malfunction indicator lamp on the instru ment cluster may come on. If this happens,
contact your Lexus dealer for service.
■If your engine knocks
●Consult your Lexus dealer.
●You may occasionally notice light knocking for a short time while accelerating or driv-
ing uphill. This is normal and there is no need for concern.
●Use only gasoline containing up to 15% etha-
nol.
DO NOT use any flex-fuel or gasoline that
could contain more than 15% ethanol, includ-
ing from any pump labeled E30, E50, E85
(which are only some examples of fuel con-
taining more than 15% ethanol).DO NOT use gasoline con-
taining more than 15% ethanol.
(30% ethanol)
(50% ethanol)
(85% ethanol)

713Alphabetical index
MaintenanceDo-it-yourself maintenance......... 495
General maintenance ...................... 491
Maintenance data ............................. 640
Maintenance requirements.......... 488
Maintenance system .................... 114, 126
Malfunction indicator lamp .............. 565
Master warning light ........................... 566
Meter Changing the display............... 99, 106
Indicators.....................................................91
Instrument panel light control ........................................ 100, 107
Meters.............................................. 96, 102
Multi-information display ........109, 117
Operating the meter control switches ........................................... 111, 118
Settings ............................................. 114, 126
Warning lights ........................................90
Warning message .............................. 571
Micro dust and pollen filter .............. 439
Mirrors Inside rear view mirror ..................... 178
Outside rear view mirror defoggers ...........................................439
Outside rear view mirrors ..............180
Vanity mirrors ..................................... 455 MMS (Multimedia messaging
service).................................................. 405
Mobile Assistant ................................... 345
Moon roof ................................................. 187 Door lock linked moon roof operation..................... 188
Jam protection function................... 188
Operation................................................187
MP3 disc ................................................. 369
Multi-information display........... 109, 117 Audio system-linked ................. 109, 117
Drive information.......................... 112, 119
Dynamic radar cruise control ..... 249
“F” content .................................................121
G-force .................................................... 124
Lap timer....................................................121
LDA (Lane Departure Alert)....... 264
Navigation system-linked ...... 109, 117
Settings ............................................ 114, 126 switch settings...................... 114, 126
Switching the display ................... 111, 118
Torque distribution ............................. 123
Warning message............................... 571
M
*: For vehicles with a naviga tion system, refer to the
“NAVIGATION SYSTEM OWNER’S MANUAL”.

717Alphabetical index
Seats, Front ...............................................164Adjustment ............................................. 164
Adjustment precautions .................. 166
Child seats/child restraint system installation............................. 58
Cleaning ................................................ 485
Driving position memory ................ 169
Head restraints ......................................173
Jam protection function ................... 165
Properly sitting in the seat ................ 32
Seat heaters ..........................................446
Seat position memory....................... 169
Seat ventilators .................................... 447
Seats, Rear ................................................ 167 Fold down the seatback ...................167
Luggage security system ................ 148
Sensor Automatic headlight system ......... 225
Automatic High Beam system ....................................................231
Inside rear view mirror ......................179
Intuitive parking assist ......................269
LDA (Lane Departure Alert) .......263
Radar sensor .................256, 307, 316
Rain-sensing windshield wipers ...................................................239
Service reminder indicators ............... 88 Shift lever ................................................... 213
Automatic transmission .................... 213
If the shift lever cannot be shifted from P ..............218
Shift lock system ..................................... 217
Shift position and gear position........................................... 96, 102
Side airbags ............................................... 40
Side marker lights .................................224 Light switch........................................... 224
Replacing light bulbs ...................... 550
Side mirrors ............................................. 180 Adjusting and folding ....................... 180
BSM (Blind spot monitor) .............. 313
Linked mirror function when reversing................................... 181
Mirror position memory ..................169
Side turn signal lights .......................... 220 Replacing light bulbs ...................... 550
Turn signal lever ................................. 220
Side windows ...........................................183
Slip indicator .......................................... 566
Smart access system with push-button start ....................... 152 Antenna location.................................. 152
Entry functions ..............................141, 147
Starting the engine ............................ 207

718Alphabetical index
SMS (Short message service)......... 405
Snow mode ............................................... 214
Snow tires ................................................ 334
Spare tire.................................................. 592Inflation pressure ................................652
Storage location ................................ 593
Spark plug ............................................... 648
Specifications ......................................... 640
Speed indicator ..............................98, 105
Speedometer .................................. 96, 102
Sport mode ............................................. 294
Steering lock ........................................... 210 Column lock release ......................... 210
Steering wheel ......................................... 176 Adjustment ..............................................176
Audio switches ....................................344
Auto tilt away.......................................... 177
Heated steering wheel ....................445
Steering wheel position memory.............................. 169
Stop lights Replacing light bulbs ....................... 550
Storage feature .......................................451
Stuck If the vehicle becomes stuck ....... 636
Sun shade ................................................. 188
Sun visors ................................................. 455 Switches
Active rear wing switch .................. 326
ASC (Active Sound Control) switch ....................................................222
Audio remote control switches .............................................. 344
Automatic High Beam system ....227
BSM (Blind spot monitor) switch ..................................................... 313
Cruise control switch .......... 245, 249
Door lock switches ............................. 143
Driving mode select switch .......... 294
Driving position memory switches ................................................169
Dynamic radar cruise control switch................................... 249
Emergency flashers switch ...........554
Engine switch ...................................... 207
Fog light switch ................................... 232
Garage door opener switches ..............................................460
Heated steering wheel switch ................................................... 445
Ignition switch...................................... 207
Intuitive parking assist switch....... 270
LDA (Lane Departure Alert) switch ................................................... 264
Light switches ...................................... 224
Meter control switches ............... 111, 118
