Page 451 of 724
451
6
Interior features
6-3. Using the storage features
List of storage features
Glove box (→P. 452)
Cup holders (if equipped) (→P. 453) Console box (→
P. 452)
WARNING
●Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause
the following when cabin temperature becomes high:
• Glasses may be deformed by heat or cracke d if they come into contact with other
stored items.
• Lighters or spray cans may explode. If they come into contact with other stored
items, the lighter may catch fire or the spray can may release gas, causing a fire
hazard.
●When driving or when the storage compartments are not in use, keep the lids closed.
In the event of sudden braking or sudden swerving, an accident may occur due to an
occupant being struck by an open lid or the items stored inside.
1
2
3
Page 452 of 724
4526-3. Using the storage features
Open (press the button)
Unlock with the mechanical key
Lock with the mechanical key
●The glove box light turns on when the engine switch is in ACCESSORY or IGNITION
ON mode.
●The trunk opener main switch is located in the glove box. (→P. 148)
Push the knob.
Lift by hand to fully open the console
box.
Glove box
1
2
3
●The insert inside the glove box can be
removed.
Console box
Page 453 of 724
4536-3. Using the storage features
6
Interior features
●The rubber mats at the bottom of the front cup holders can be removed.
Cup holders
FrontRear (RC F)
●Rear cup holder insert can be removed.
WARNING
■Items unsuitable for the cup holder
Do not place anything other than cups or aluminum cans in the cup holders.
Other items may be thrown out of the holders in the event of an accident or sudden
braking, causing injury. If possible, cover hot drinks to prevent burns.
■When not in use (rear)
Keep the cup holders closed. In the event of sudden braking, an accident may occur
due to an occupant being struck by the items stored inside.
Page 454 of 724
4546-3. Using the storage features
Raise the hooks when needed.
The cargo hooks are provided for
securing loose items.
Loosen the belt
Tighten the belt
Trunk features
Cargo hooks
WARNING
To avoid injury, always return the cargo hooks to their stow ed positions when not in use.
First-aid kit storage belt
1
2
Page 455 of 724
455
6
Interior features
6-4. Using the other interior features
To set the visor in the forward posi-
tion, flip it down.
To set the visor in the side position,
flip down, unhook, and swing it to the
side.
To use the side extender, place the
visor in the side position, then slide it
backward.
Slide the cover to open.
The light turns on when the cover is
opened.
If the vanity lights remain on when the engine switch is turned off, the lights will go off
automatically after 20 minutes.
Other interior features
Sun visors
1
2
3
Vanity mirrors
NOTICE
To prevent battery discharge, do not leave th e lights on longer than necessary when the
engine is off.
Page 456 of 724
4566-4. Using the other interior features
The clock can be adjusted.Pressing and holding will move the
clock hands backward.
Pressing and holding will move the
clock hands forward.
Please use as a power supply for electronic goods that use less than 12 VDC/10
A (power consumption of 120 W).
Open the lid.
Clock
1
2
Power outlet
Page 457 of 724
4576-4. Using the other interior features
6
Interior features
●The power outlet can be used when the engine switch is in ACCESSORY or IGNI-
TION ON mode.
Fold down the armrest for use.
●The shape of the console box rim allows power
cables to be passed through when the console
box lid is closed.
NOTICE
●To avoid damaging the power outlet, close the power outlet lid when the power outlet
is not in use. Foreign objects or liquids th at enter the power outlet may cause a short
circuit.
●To prevent battery discharge, do not use the power outlet longer than necessary
when the engine is off.
Armrest (RC F)
NOTICE
To prevent damage to the armrest, do not apply too much load on the armrest.
Page 458 of 724
4586-4. Using the other interior features
Long objects can be loaded in the vehicle by utilizing the trunk space and rear
seat area.Pull down the armrest.
Separate the fastener and turn back
the trunk door cover.
Open the inside trunk door from the
trunk and load ba ggage or other
items.
Trunk storage extension (RC F)
1
2
3
WARNING
■When not in use
Ensure that the inside trunk door is closed.
In the event of sudden braking, items stor ed in the trunk may be thrown forward into
the cabin, resulting in injury.
Page 459 of 724
4596-4. Using the other interior features
6
Interior features
An assist grip installed on the ceiling
can be used to support your body while
sitting on the seat.
To use the coat hook, push it in.
Assist grips
WARNING
Do not use the assist grip when getting in or out of the vehicle or rising from your seat.
NOTICE
To prevent damage to the assist grip, do not put a heavy load on the assist grip.
Coat hooks
WARNING
Do not hang coat hangers or other hard or sharp objects on the hook. If the SRS cur-
tain shield airbags deploy, these items may become projectiles, causing death or seri-
ous injury.
Page 460 of 724

4606-4. Using the other interior features
The HomeLink® wireless control system in your vehicle has 3 buttons which can
be programmed to operate 3 different de vices. Refer to the programming meth-
ods on the following pages to determine the method which is appropriate for the
device.
HomeLink
® indicator light
Garage door operation indicators
HomeLink
® icon
Illuminates while HomeLink® is operat-
ing.
Buttons
■Before programming HomeLink®
●During programming, it is possible that garage doors, gates, or other
devices may operate. For this reason, make sure that people and objects
are clear of the garage door or othe r devices to prevent injury or other
potential harm.
●It is recommended that a new batter y be placed in the remote control
transmitter for more accurate programming.
●Garage door opener motors manufa ctured after 1995 may be equipped
with rolling code protection. If this is the case, you may need a stepladder
or other sturdy, safe device to reach the “Learn” or “Smart” button on the
garage door opener motor.
Garage door opener
The garage door opener can be programmed to operate garage doors, gates,
entry doors, door locks, home lightin g systems, security systems, and other
devices.
Programming the HomeLink®
1
2
3
4
