3198-1. Specifications
RC350AWD_RC350_RC300AWD_RC30
0_OM_(U)_1810
8
Vehicle specifications
Outside temperature
Oil viscosity (0W-20 is explained here
as an example):
• The 0W in 0W-20 indicates the characteristic of the oil which allows
cold startability. Oils with a lower
value before the W allow for easier
starting of the engine in cold
weather.
• The 20 in 0W-20 indicates the vis- cosity characteristic of the oil when
the oil is at high temperature. An oil
with a higher viscosity (one with a
higher value) may be better suited if
the vehicle is operated at high
speeds, or under extreme load con- ditions.
How to read oil container label:
The International Lubricant Specifica-
tion Advisory Committee (ILSAC)
Certification Mark is added to some oil
containers to help you select the oil you
should use.
*: The fluid capacity is a reference quantity. If replacement is necessary, contact your Lexus dealer.
A
Cooling system
Capacity*
RC350/RC3
00 AWD10.0 qt. (9.5 L, 8.4 Imp. qt.)
RC300
Gasoline engine
8.5 qt. (8.0 L, 7.0 Imp. qt.)
Intercooler
3.3 qt. (3.1 L, 2.7 Imp. qt.)
Coolant type
Use either of the following:
 “Toyota Super Long Life Coolant”
 Similar high-quality ethylene glycol-based non-silicate,
non-amine, non-nitrite, and non-borate coolant with
long-life hybrid orga nic acid technology
Do not use plain water alone.

3338-1. Specifications
RC350AWD_RC350_RC300AWD_RC30
0_OM_(U)_1810
8
Vehicle specifications
cornering (turning) traction.
■Temperature A, B, C
The temperature grades are A (the
highest), B, and C, representing the
tire’s resistance to the generation of
heat and its ability to dissipate heat
when tested under controlled condi-
tions on a specified indoor laboratory
test wheel.
Sustained high temperature can cause the
material of the tire to degenerate and
reduce tire life, and excessive temperature
can lead to sudden tire failure. Grade C corresponds to
a level of perfor-
mance which all passenger car tires must
meet under the Fede ral Motor Vehicle
Safety Standard No. 109.
Grades B and A represent higher levels of
performance on the laboratory test wheel
than the minimum required by law.
Warning: The temperature grades of a tire
assume that it is properly inflated and not
overloaded.
Excessive speed, unde rinflation, or exces-
sive loading, either separately or in combi-
nation, can cause heat buildup and
possible tire failure.
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation pressure
Tire pressure when the vehicle has been parked for
three hours or more, or has not been driven more
than 1 mile or 1.5 km under that condition
Maximum inflation pressureThe maximum cold inflated pressure to which a tire
may be inflated, shown on the sidewall of the tire
Recommended inflation pressureCold tire inflation pressure recommended by a
manufacturer
Accessory weight
The combined weight (in excess of those standard
items which may be replaced) of automatic trans-
mission, power steering, power brakes, power win-
dows, power seats, radio and heater, to the extent
that these items are available as factory-installed
equipment (whether installed or not)
Curb weight
The weight of a motor vehicle with standard equip-
ment, including the maximum capacity of fuel, oil
and coolant, and if so equipped, air conditioning
and additional weight optional engine

3751-1. What to do if... (Troubleshooting)
RC350AWD_RC350_RC300AWD_RC30
0_OM_(U)_1810375Alphabetical Index
Doors Automatic door lock ing and unlocking
system .............................................................88
Door glasses ................................................... 110
Door lock.......................................................... 86
Open door warning buzzer87, 88, 285
Open door warning light ......................285
Outside rear view mirrors ..................... 108
Drive distance ...................................................72
Drive info 1/Drive info 2/Drive info 3.....72
Drive information ............................................72
Driver’s seat position memory Driving position memory........................ 100
Memory recall function ............................102
Power easy access system .................... 100
Drive-start control ......................................... 117
Driving Break-in tips .....................................................117
Correct driving posture .............................23
Driving mode select switch ................... 190
Procedures ...................................................... 116
Winter drive tips...........................................196
Driving assist system information display.... 76
Driving information display .........................72
Driving position memory........................... 100 Memory recall function ............................102
Power easy access system .................... 100
Driving range ....................................................72
DRS (Dynamic Rear Steering) ................192
Dynamic radar cruise control ................. 168 Warning message.......................... 175, 290
Dynamic Rear Steering (DRS) ................192
E
Eco Driving Indicator.....................................73
Eco Driving Indicator Light .........................73
EDR (Event data recorder) ............................6
Elapsed time ......................................................72
Electric Power Steering (EPS) ................192 Warning light ............................................... 284 Electronic key .................................................. 82
Battery-saving function.............................. 94
If the electronic key does not operate properly ...................................................... 304
Replacing the battery ...............................265
Emergency flashers .....................................274
Emergency, in case of If a warning buzzer sounds...................282
If a warning light turns on.......................282
If a warning message is displayed .... 290
If the battery is discharged ................... 306
If the electronic key does not operate properly ...................................................... 304
If the engine will not start......................... 301
If the fuel filler door cannot be opened ....
303
If the vehicle is trapped in rising water...... 275
If you have a flat tire .................................. 294
If you lose your keys ................................ 303
If you think something is wrong......... 280
If your vehicle becomes stuck .............. 313
If your vehicle has to be stopped in an emergency ................................................. 274
If your vehicle needs to be towed ..... 277
If your vehicle overheats ....................... 309
Engine ACCESSORY mode................................126
Compartment.............................................. 247
Engine switch ................................................ 125
Fuel pump shut off system...................... 281
Hood ................................................................245
How to start the engine ........................... 125
Identification number .................................317
If the engine will not start......................... 301
If your vehicle has to be stopped in an emergency ................................................. 274
Ignition switch (engine switch)............. 125
Overheating ................................................ 309
Tachometer ..................................................... 66
Engine coolant Capacity .......................................................... 319

376Alphabetical Index
RC350AWD_RC350_RC300AWD_RC30
0_OM_(U)_1810
Checking .......................................................250
Preparing and checking before winter .... 196
Engine coolant temperature gauge ....... 66
Engine immobilizer system .........................57
Engine oil Capacity .......................................................... 318
Checking ....................................................... 248
Preparing and checking before winter ....196
Warning light ............................................... 283
Engine oil maintenance data .................. 250
Engine oil pressure gauge ...........................74
Engine oil temperature gauge ...................74
Engine switch ..................................................125 Auto power off function ........................... 127
Changing the engine switch modes.. 126
If your vehicle has to be stopped in an
emergency ................................................ 274
EPS (Electric Power Steering) ................192 Warning light ............................................... 284
Event data recorder (EDR) ............................6
F
First-aid kit storage belt ..............................219
Flat tire Tire pressure warning system .............258
Vehicles with a spare tire ...................... 294
Floor mats ...........................................................22
Fluid Automatic transmission .......................... 320
Brake...................................................... 252, 321
Washer ........................................................... 254
Footwell light ...................................................215
Front passenger occupant classification system .............................................................. 36
Front position lights Wattage.......................................................... 326
Front seats Adjustment....................................................... 97
Cleaning......................................................... 235
Correct driving posture .............................23 Driving position memory ........................ 100
Head restraints............................................. 103
Memory recall function............................ 102
Power easy access system .................... 100
Seat heaters .................................................... 212
Seat position memory ..............................100
Seat ventilators .............................................. 212
Front side marker light Light switch .................................................... 136
Front turn signal lights Replacing light bulbs ................................270
Turn signal lever .......................................... 133
Wattage ..........................................................326
Fuel Capacity .......................................................... 318
Fuel gauge ........................................................ 66
Fuel pump shut off system...................... 281
Information .................................................... 327
Refueling.......................................................... 148
Type ................................................................... 318
Warning light .............................................. 286
Fuel consumption Average fuel economy .............................. 72
Current fuel consumption ........................ 72
Fuel filler door If the fuel filler door cannot be opened ....
303
Refueling.......................................................... 148
Fuel gauge ......................................................... 66
Fuel pump shut off system..........................281
Fuses ..................................................................267
G
Garage door opener ................................. 222
Gauges ............................................................... 66
Gear Position ................................................... 75
G-force................................................................74
Glove box ......................................................... 217
Glove box light ...............................................218

3771-1. What to do if... (Troubleshooting)
RC350AWD_RC350_RC300AWD_RC30
0_OM_(U)_1810377Alphabetical Index
H
Head restraints .............................................. 103
Headlight aim ................................................ 269
Headlights Automatic High Beam system............. 138
Light switch .....................................................136
Replacing light bulbs................................ 270
Wattage.......................................................... 326
Heated steering wheel ................................ 212
Heaters Automatic air conditioning system ...205
Heated steering wheel.............................. 212
Outside rear view mirrors ....................209
Seat heaters .................................................... 212
High mounted stoplight Replacing light bulbs................................ 270
Hill-start assist control .................................192
Hood Open ............................................................... 245
Hooks Cargo hooks.................................................. 219
Coat hooks ................................................... 220
Retaining hooks (floor mat)......................22
Horn ....................................................................107
I
I/M test ............................................................ 242
Identification Engine ............................................................... 317
Vehicle ..............................................................316
Ignition switch (engine switch).................125 Auto power off function ........................... 127
Changing the engine switch modes.. 126
If your vehicle has to be stopped in an
emergency ................................................ 274
Illuminated entry system ............................. 216
Indicators ........................................................... 64
Initialization Items to initialize ......................................... 349
Maintenance ................................... 238, 250
Power windows............................................. 110 Tire pressure warning system ............ 260
Inside rear view mirror ................................107
Instrument panel light co ntrol ..................... 71
Intercooler...................................................... 252
Intercooler coolant Capacity .......................................................... 319
Checking ...................................................... 250
Interior lights....................................................215 Front interior light ....................................... 215
Rear interior light......................................... 215
Intuitive parking assist Warning message ...................................... 178
J
JackPositioning a floor jack ............................245
Vehicle-equipped jack ........................... 294
Jack handle .................................................... 294
Jam protection function Moon roof ........................................................ 113
Power windows ............................................. 110
K
Keyless entrySmart access system with push-button start ................................................................... 93
Wireless remote control ...........................84
Keys Battery-saving function.............................. 94
Electronic key ................................................. 82
Engine switch ................................................ 125
If the electronic key does not operate properly ...................................................... 304
If you lose your keys ................................ 303
Key number plate ......................................... 82
Keyless entry ..........................................86, 93
Mechanical key .............................................. 82
Replacing the battery ...............................265
Warning buzzer ............................................ 93
Wireless remote control ...........................84
Knee airbags .................................................... 28

3831-1. What to do if... (Troubleshooting)
RC350AWD_RC350_RC300AWD_RC30
0_OM_(U)_1810383Alphabetical Index
Wireless remote control............................. 91
Trunk light ............................................................ 91
Turn signal lights Replacing light bulbs................................ 270
Turn signal lever ...........................................133
Wattage.......................................................... 326
V
Vanity lights...................................................... 221
Vanity mirrors ................................................. 221
Variable Gear Ratio Steering (VGRS) 192
VDIM (Vehicle Dynami cs Integrated Man-
agement)........................................................193
Vehicle data recording .... ............................... 5
Vehicle Dynamics Integrated Manage- ment (VDIM)................................................193
Vehicle identification number ..................316
Vehicle Stability Control (VSC) .............192
Vehicle sway warning display ....................75
Ventilators (seat ventilators)..................... 212
VGRS (Variable Gear Ratio Steering) 192
VSC (Vehicle Stabilit y Control) .............192
W
Warning buzzer
Open door warning.................................285
Warning buzzers Approach warning...................................... 173
Brake Override System ......................... 284
Downshifting ......................................... 131, 132
Drive-Start Control .................................. 284
Electric power steering .......................... 284
High coolant temperature .................... 282
LDA (Lane Departure Alert with steering control) ........................................................... 161
LDA (Lane Departure Alert)...............285
Low engine oil pressure......................... 283
Open door..............................................87, 88
Open window .................................................. 111
Parking brake .............................................. 284
Pre-collision braking................................. 155 Seat belt ......................................................... 286
Warning lights............................................... 282 ABS ...................................................................283
Brake Override System .........................284
Brake system................................................282
Charging system........................................282
Drive-Start Control...................................284
Electric power steering...........................284
High coolant temperature.....................282
LDA indicator ............................................. 285
Low engine oil pressure.........................283
Low fuel level .............................................. 286
Malfunction indicator lamp ...................283
Master warning light................................. 287
Open door warning ................................ 285
Parking brake indicator ..........................284
Pre-collision system................................. 285
Seat belt reminder light.......................... 286
Slip indicator ................................................ 285
SRS ....................................................................283
Tire pressure ................................................ 287
Warning message display............................76
Warning messages ..................................... 290
Washer Checking .......................................................254
Preparing and checking before winter.....196
Switch.................................................................. 141
Washing and waxing.................................. 232
Weight Cargo capacity .............................................123
Load limits .......................................................123
Weight.............................................................. 316
Wheels ............................................................. 263 Size .................................................................... 322
Window lock switch ........................................111
Windows Power windows ............................................. 110
Rear window defogger.......................... 209
Washer .............................................................. 141
Windshield wiper de-icer ........................ 209
Windshield wipers ......................................... 141
