3117-2. Steps to take in an emergency
7
When trouble arises
The warning lights and warning buzzers operate as follows depending on the con-
tent of the message. If a message indicates the need for inspection by a dealer, have
the vehicle inspected by your Lexus dealer immediately.
 In some situations, the master warning light and warning buzzer may not oper-
ate as specified. In this case, follow the instructions displayed in the warning
message.
 If a warning light comes on or flashes at the same time that a warning message is
displayed, take corrective actio n according to the warning light. ( P.302)
*: A buzzer sounds the first time a message is shown on the multi-information display.
■Warning messages
The warning messages explained below
may differ from the actual messages
according to operation conditions and vehi-
cle specifications.
■Warning buzzer
In some cases, the bu zzer may not be heard
due to being in a noisy location or audio
sound.
■If “Engine Oil Level Low Add or
Replace” is displayed
The engine oil level is low. Check the level
of the engine oil, and add if necessary. This message ma
y appear if the vehicle is
stopped on a slope. Move the vehicle to a
level surface and chec k to see if the mes-
sage disappears.
■If “Engine Stopped Steering Power
Low” is displayed
This message is displayed if the engine is
stopped while driving.
When steering wheel operations are
heavier than usual, gr ip the steering wheel
firmly and operate it using more force than
usual.
■If “Power Turned Off to Save Battery” is
displayed
Power was turned off due to the automatic
Messages and warnings
Warning buzzer*Warning
Comes onSounds
Indicates an important situat ion, such as when a sys-
tem related to driving is ma lfunctioning or that dan-
ger may result if the co rrection procedure is not
performed
FlashesSoundsIndicates a situation, such as when damage to the
vehicle or danger may result
Comes onDoes not sound
Indicates a condition, such as malfunction of electri-
cal components, their cond ition, or indicates the
need for maintenance
FlashesDoes not sound
Indicates a situation, such as when an operation has
been performed incorrectly, or indicates how to
perform an operation correctly

3187-2. Steps to take in an emergency
3Lower the vehicle.
4 Firmly tighten each wheel nut two
or three times in the order shown in
the illustration.
Tightening torque:
76 ft•lbf (103 N•m, 10.5 kgf•m)
5Stow the flat tire, tire jack and all
tools.
■The spare tire
●Use the spare tire temporarily, and only in
an emergency.
●Make sure to check the tire inflation pres-
sure of the spare tire. ( P.347)
■When using the spare tire
As the spare tire is not equipped with a tire
pressure warning valve and transmitter, low
inflation pressure of the spare tire will not be
indicated by the tire pressure warning sys-
tem. Also, if you replace the spare tire after
the tire pressure warning light comes on,
the light remains on.
*:If equipped
■When the spare tire is equipped
The vehicle becomes lower when driving
with the spare tire compared to when driv-
ing with standard tires.
WARNING
■When using the spare tire
●Remember that the sp are tire provided
is specifically designed for use with
your vehicle. Do not use your spare
tire on another vehicle.
●Do not use more than one spare tire
simultaneously.
●Replace the spare tire with a standard
tire as soon as possible.
●Avoid sudden acceleration, abrupt
steering, sudden br aking and shifting
operations that cause sudden engine
braking.
■When the spare tire is attached
The vehicle speed may not be correctly
detected, and the following systems may
not operate correctly:
• ABS & Brake assist
•VSC
•TRAC
• Dynamic radar cruise control
•PCS
•EPS
• Adaptive Variable Suspension System
• LDA (Lane Departure Alert with steering control)
• VDIM (Vehicle Dynamics Integrated Management)
• Tire pressure warning system
• Lexus parking assist monitor
• Intuitive parking assist (if equipped)
• Navigation system (if equipped)

3458-1. Specifications
8
Vehicle specifications
If replacement is necessary, contact your Lexus dealer.
■Spark plug
*: The fluid capacity is a reference quantity.If replacement is necessary, contact your Lexus dealer.
Ignition system (spark plug)
MakeDENSO FK20HBR-J8
Gap0.031 in. (0.8 mm)
NOTICE
■Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust the spark plug gap.
Electrical system (battery)
Open voltage at 68°F (20°C):
12.3 V or higher
If the voltage is lower than the standard value,
charge the battery.
(Voltage is checked 20 minutes after the engine
and all lights are turned off.)
Charging rates5 A max.
Automatic transmission
Fluid capacity*11.8 qt. (11.2 L, 9.9 Imp. qt.)
Fluid typeToyota Genuine ATF WS
NOTICE
■Automatic transmission fluid type
Using transmission fluid other than the above type may cause abnormal noise or vibra-
tion, or damage the transmission of your vehicle.

391What to do if... (Troubleshooting)
Is the engine switch in IGNITION
ON mode?
If you cannot release the shift lever by
depressing the brake pedal with the engine
switch in IGNITION ON mode. ( P.133)
 It is locked automatically to prevent
theft of the vehicle. ( P.128)
 Is the window lock switch pressed?
The power window except for the one at
the driver’s seat cannot be operated if the
window lock switch is pressed. ( P.113)
 The auto power off function will be
operated if the vehicle is left in
ACCESSORY or IGNITION ON
mode (the engine is not running) for
a period of time. ( P.131)
 The seat belt reminder light is flash-
ing
Are the driver and the front passenger
wearing the seat belts? ( P.306)
 The parking brake indicator is on
Is the parking brake released? ( P.137)
Depending on the situation, other
types of warning buzzer may also
sound. ( P.302, 310)
 Did anyone inside the vehicle open
a door during setting the alarm?
The sensor detects it and the alarm sounds.
( P.58)
Do one of the following to deactivate
or stop the alarm:
 Unlock the doors.
 Open the trunk using the entry
function or wireless remote control.
 Turn the engine switch to ACCES-
SORY or IGNITION ON mode, or
start the engine.
 Is the message displayed on the
multi-information display?
Check the message on the multi-informa-
tion display. ( P.310)
 When a warning light turns on or a
warning message is displayed, refer
to P.302, 310.
The steering wheel cannot be
turned after the engine is
stopped
The windows do not open or
close by operating the power
window switches
The engine switch is turned off
automatically
A warning buzzer sounds during
driving
An alarm is activated and the
horn sounds
A warning buzzer sounds when
leaving the vehicle
A warning light turns on or a
warning message is displayed

395Alphabetical Index
Door glasses ....................................................112
Door lock.......................................................... 92
Open door warning buzzer93, 94, 306
Open door warning light ......................306
Outside rear view mirrors ....................... 110
Drive distance ...................................................75
Drive info 1/Drive info 2/Drive info 3.....75
Drive information ............................................75
Driver’s and front passenger’s seat belt reminder light............................................. 306
Driver’s seat position memory Driving position memory........................ 105
Memory recall function ........................... 106
Power easy access system .................... 105
Drive-start control ......................................... 119
Driving Break-in tips .................................................... 119
Correct driving posture .............................23
Driving mode select switch .................... 192
Procedures ...................................................... 118
Winter drive tips......................................... 204
Driving information display .........................75
Driving position memory........................... 105 Memory recall function ........................... 106
Power easy access system .................... 105
Driving range ....................................................75
Driving support system information display ...............................................................................81
Dynamic radar cruise control ................... 171 Warning message.......................................178
E
Eco Driving Indicator.....................................76
Eco Driving Indicator Light .........................76
EDR (Event data recorder) ............................7
Elapsed time ......................................................75
Electric Power Steering (EPS) ..............200Electric power steer ing system warning
light ................................................................304
Electronic key .................................................. 88 Battery-saving function ............................. 99 If the electronic key does not operate
properly ....................................................... 332
Replacing the battery ...............................283
Emergency flashers .................................... 294
Emergency tire puncture ...........................319
Emergency, in case of If a warning buzzer sounds...................302
If a warning light turns on.......................302
If a warning message is displayed ...... 310
If the battery is discharged ....................334
If the electronic key does not operate properly ....................................................... 332
If the engine will not start........................329
If the fuel filler do or cannot be opened
........................................................................... 331
If the vehicle is trapped in rising water ..........................................................................295
If you have a flat tire ......................... 313, 319
If you lose your keys .................................. 331
If you think something is wrong......... 300
If your vehicle becomes stuck .............339
If your vehicle has to be stopped in an emergency ................................................. 294
If your vehicle needs to be towed ..... 297
If your vehicle overheats ........................ 337
Engine ACCESSORY mode............................... 130
Compartment.............................................. 267
Engine switch ................................................ 128
Fuel pump shut off system...................... 301
Hood ................................................................ 264
Identification number ...............................343
If the engine will not start........................329
If your vehicle has to be stopped in an emergency ................................................. 294
Ignition switch (engine switch)............. 128
Overheating ................................................. 337
Tachometer ..................................................... 66
Engine coolant Capacity .........................................................344
Checking .......................................................269

396Alphabetical Index
Preparing and checking before winter......................................................................... 204
Engine coolant temperature gauge ....... 66
Engine immobilizer system .........................57
Engine oil Capacity ......................................................... 343
Checking ....................................................... 267
Low engine oil pressure warning light.........................................................................303
Preparing and checking before winter ......................................................................... 204
Engine switch ..................................................128 Auto power off function ............................ 131
Changing the engine switch modes. 130
If your vehicle has to be stopped in an
emergency ................................................ 294
EPS (Electric Power Steering) ..............200 Electric power steer ing system warning
light ................................................................304
Event data recorder (EDR) ............................7
F
First-aid kit storage belt .............................227
Flat tire Tire pressure warning system ............. 275
Vehicles with a spare tire ........................313
Vehicles without a spare tire .................319
Floor mats ...........................................................22
Fluid Automatic transmission .......................... 345
Brake.................................................... 270, 346
Washer ............................................................272
Footwell light ................................................. 223
Front passenger occupant classification system .............................................................. 36
Front seats Adjustment..................................................... 103
Cleaning......................................................... 245
Correct driving posture .............................23
Driving position memory........................ 105
Memory recall function ........................... 106
Power easy access system .................... 105 Seat heaters .................................................... 221
Seat position memory .............................. 105
Seat ventilators .............................................. 221
Front side marker light Light switch .................................................... 138
Front turn signal lights Replacing light bulbs ............................... 289
Turn signal lever .......................................... 136
Fuel Capacity .........................................................343
Fuel gauge ........................................................ 66
Fuel pump shut off system...................... 301
Information ....................................................349
Low fuel level warning light ................. 306
Refueling.......................................................... 150
Type ..................................................................343
Fuel consumption Average fuel economy .............................. 75
Current fuel consumption ........................ 75
Fuel filler door If the fuel filler do or cannot be opened
........................................................................... 331
Refueling.......................................................... 150
Fuel gauge ......................................................... 66
Fuel pump shut off system......................... 301
Fuses ................................................................. 285
G
Garage door opener ...................................231
Gauges ............................................................... 66
Gear Position ....................................................76
G-force................................................................79
Glove box ....................................................... 226
Glove box light ............................................. 226
H
Headlight aim ................................................ 287
Headlights Automatic High Beam system ............. 140
Light switch .................................................... 138
Replacing light bulbs ............................... 289

399Alphabetical Index
“F” content ......................................................... 77
Gear Position ................................................. 76
G-force.............................................................. 79
History (Lap timer) ...................................... 78
Lap timer ............................................................ 77
LDA (Lane Departure Alert with steering control) ..........................................................166
Menu icons .......................................................74
Meter control switches ...............................74
Navigation system-linked display ..........81
Pop-up display................................................73
Settings ................................................................81
Tire pressure ........................................76, 275
Torque distribution ...................................... 78
Units .................................................................... 76
Vehicle sway warning ................................ 76
Warning message...................................... 310
Warning message display .........................81
N
Navigation system-linked display..............81
Noise from under vehicle ...............................6
O
“ODO TRIP” switch .......................................72
Odometer ..........................................................72
Odometer and trip meter display ............72 Display items ....................................................72
“ODO TRIP” switch .....................................72
Oil Differential oil ............................................... 346
Engine oil ....................................................... 343
Opener Fuel filler door............................................... 150
Hood................................................................ 264
Trunk ................................................................... 96
Outer foot lights Location.......................................................... 223
Outside rear view mirrors Adjustment....................................................... 110
BSM (Blind Spot Monitor) ..................... 179 Folding.................................................................. 111
Linked mirror functi
on when reversing111
Mirror position memory .......................... 105
Outside rear view mirror defoggers . 217
RCTA function ..............................................179
Outside temperature.................................... 66
Overheating .................................................. 337
P
Paddle shift switches ..........................134, 135
Panic mode ....................................................... 90
Parking brake Operation ........................................................137
Parking brake engaged warning buzzer............................................................................137
Parking brake warning light ................ 304
Warning message .......................................137
Parking lights Light switch .................................................... 138
Replacing light bulbs ............................... 289
PCS (Pre-Collision System) Function ............................................................157
PCS OFF switch ......................................... 159
PCS warning light .................................... 305
Personal lights............................................... 223
Power control unit coolant Preparing and checking before winter..........................................................................204
Power easy access system ....................... 105
Power outlet .................................................. 228
Power steering (Elect ric power steering
system) ..........................................................200 Electric power steering system warning light ............................................................... 304
Power windows Door lock linked window operation ... 113
Jam protection function ............................. 112
Operation ......................................................... 112
Window lock switch.................................... 113
Pre-Collision System (PCS) Function ............................................................157
PCS OFF switch ......................................... 159

402Alphabetical Index
Tilt and telescopic steering control switch.......................................................................... 108
Tire pressure warning reset switch .. 278
Trunk opener main switch ....................... 98
Trunk opener switch ................................... 96
TVD (Toruqe Vector ing Differential)
switch............................................................. 198
VSC OFF switch .......................................200
Window lock switch ................................... 113
Windshield wiper and washer switch143
Windshield wiper de-icer switch ........ 217
T
Tachometer....................................................... 66 Rev indicator ................................................... 70
Rev peak ............................................................. 71
Tail lights Light switch .................................................... 138
Replacing light bulbs................................289
Theft deterrent system Alarm ..................................................................58
Engine immobilizer system ..................... 57
Theft prevention labels............................... 60
Tire inflation pressure Maintenance data...................................... 347
Tire inflation pressu re display function
......................................................................... 275
Tire pressure warning light ................... 307
Tire information ..............................................351 Glossary......................................................... 354
Size.................................................................... 352
Tire identification number ..................... 352
Uniform Tire Quality Grading............353
Tire infration pressure ...................................76
Tire pressure display .................................. 275
Tire pressure warning system Function .......................................................... 275
Initializing ........................................................277
Installing tire pressure warning valves and transmitters .......................................277
Registering ID codes ............................... 278
Tire pressure warning light ................... 307 Tires
Chains ............................................................ 205
Checking ....................................................... 273
Emergency tire puncture repair kit.... 319
If you have a flat tire ......................... 313, 319
Inflation pressure ........................................ 279
Information ..................................................... 351
Replacing ........................................................ 313
Rotating tires ................................................ 275
Size .................................................................... 347
Snow tires ......................................................204
Spare tire ......................................................... 313
Tire inflation pressure display function.......................................................................... 275
Tire pressure warning light ...................307
Tire pressure warning system ............. 275
Tools........................................................ 314, 320
Top tether strap........................................ 43, 51
Toruqe Vectoring Differential (TVD) .. 198
Total load capacity ...................................... 342
Towing Dinghy towing ............................................... 127
Emergency towing.................................... 297
Towing eyelet...............................................299
Trailer towing ................................................. 127
TRAC (Traction Control) ........................200
Traction Control (TRAC) ........................200
Trailer towing .................................................. 127
Transmission Automatic transmission ............................132
Driving mode select switch ....................192
M mode ........................................................... 135
Paddle shift switches ....................... 134, 135
Trip meters .........................................................72
Trunk .................................................................... 95 Smart access system with push-button start ...................................................................96
Trunk features .............................................. 227
Trunk grip ......................................................... 97
Trunk light ......................................................... 97
Trunk opener main switch........................98
Trunk opener switch ................................... 96

403Alphabetical Index
Trunk storage extension ........................ 228
Wireless remote control........................... 97
Turn signal lights Replacing light bulbs................................289
Turn signal lever ...........................................136
TVD (Toruqe Vectorin g Differential) .. 198
V
Vanity lights.................................................... 230
Vanity mirrors ............................................... 230
VDIM (Vehicle Dynami cs Integrated Man-
agement)......................................................200
Vehicle data recording . ...................................6
Vehicle Dynamics Integrated Manage- ment (VDIM)..............................................200
Vehicle identification number ................ 342
Vehicle Stability Control (VSC) .............199
Vehicle sway warning display ....................76
Ventilators (seat ventilators)..................... 221
VSC (Vehicle Stabilit y Control) .............199
W
Warning buzzer
Open door....................................................306
Warning buzzers Approach warning...................................... 176
Brake Override System .........................304
Downshifting ..................................................135
Driver’s and front passenger’s seat belt.........................................................................306
Drive-Start Control ..................................304
Electric power steering ..........................304
High coolant temperature .................... 302
LDA (Lane Departure Alert with steering control) ..........................................................164
Low engine oil pressure.........................303
Open door.............................................. 93, 94
Open window ................................................ 113
Parking brake ..............................................304
Pre-collision braking................................. 158
Rear passengers’ seat belt .................... 307 Warning lights............................................... 302
ABS .................................................................. 303
Automatic headlight leveling system306
Brake Override System ........................ 304
Brake system................................................302
Charging system........................................302
Driver’s and front passenger’s seat belt reminder light .......................................... 306
Drive-Start Control.................................. 304
Electric power steering.......................... 304
High coolant temperature.....................302
LDA indicator ............................................. 305
Low engine oil pressure........................ 303
Low fuel level .............................................. 306
Malfunction indicator lamp .................. 303
Master warning light.................................307
Open door warning ................................ 306
Parking brake indicator ......................... 304
Pre-collision system................................. 305
Rear passengers’ seat belt reminder lights ..............................................................307
Slip indicator ................................................ 305
SRS ................................................................... 303
Tire pressure ................................................307
Warning message ........................................ 310
Warning message display.............................81
Washer Checking ....................................................... 272
Preparing and checking before winter..........................................................................204
Switch.................................................................143
Washing and waxing.................................. 240
Weight Cargo capacity .............................................126
Load limits .......................................................126
Weight............................................................. 342
Wheels ...............................................................281 Size .................................................................... 347
Window lock switch ...................................... 113
Windows Power windows ............................................. 112
Rear window defogger............................. 217
