Adjustment bolt A
Adjustment bolt B
 Make sure the vehicle has a full tank
of gasoline and the area around the
headlight is not deformed.
 Park the vehicle on level ground.
 Make sure the tire inflation pressure
is at the specified level.
 Have someone sit in the driver’s
seat.
 Bounce the vehicle several times.
1 Using a Phillips-head screwdriver,
turn bolt A in either direction.
Remember the turning direction and the
WARNING
■To prevent system breakdowns and
vehicle fire
Observe the following precautions.
Failure to do so may cause damage to
the vehicle, and possibly a fire or injury.
●Never use a fuse of a higher amperage
rating than that indicated, or use any
other object in place of a fuse.
●Always use a genuine Lexus fuse or
equivalent.
Never replace a fuse with a wire, even
as a temporary fix.
●Do not modify the fuses or fuse boxes.
NOTICE
■Before replacing fuses
Have the cause of electrical overload
determined and repaired by your Lexus
dealer as soon as possible.
Headlight aim
Vertical movement adjusting
bolts
Before checking the headlight
aim
Adjusting the headlight aim
A
B

2886-4. Do-it-yourself maintenance
number of turns.
2Turn bolt B the same number of
turns and in the same direction as
step 1.
If the headlight cannot be adjusted using
this procedure, take the vehicle to your
Lexus dealer to adjust the headlight aim.
Check the wattage of the light bulb to
be replaced. ( P.348)
Rear turn signal light
■Bulbs that need to be replaced by
your Lexus dealer
 Headlights
 Parking lights and daytime running
lights
 Front turn signal lights
 Side marker lights
 Side turn signal lights
Light bulbs
You may replace the following bulbs
by yourself. The difficulty level of
replacement varies depending on
the bulb. If necessary bulb replace-
ment seems difficult to perform,
contact your Lexus dealer.
For more information about replac-
ing other light bulbs, contact your
Lexus dealer.
Preparing for light bulb replace-
ment
Bulb locations
A

2896-4. Do-it-yourself maintenance
6
Maintenance and care
Stop/tail lights
 Back-up lights
 High mounted stoplight
 License plate lights
■LED light bulbs
The lights other than the rear turn signal
lights each consist of a number of LEDs. If
any of the LEDs burn out, take your vehicle
to your Lexus dealer to have the light
replaced.
■Condensation build-up on the inside of
the lens
Temporary condensation build-up on the
inside of the headlight lens does not indi-
cate a malfunction. Contact your Lexus
dealer for more information in the following
situations:
●Large drops of water ha ve built up on the
inside of the lens.
●Water has built up inside the headlight.
■When replacing light bulbs
 P.287
■Rear turn signal lights
1 Open the trunk and apply protec-
tive tape to the peripheral of the
taillight and the vehicle body
around the taillight.
Use masking tape, etc. Do not use duct
tape, as it may leave residue or damage the paint when removed.
2
Using a flathead screwdriver,
remove the cover.
To prevent scratching the vehicle, wrap the
tip of the flathead scre wdriver with a cloth,
etc.
3 Remove the 2 screws.Replacing light bulbs

393Alphabetical Index
Alphabetical Index
A
A/CAir conditioning filter ............................... 282
Automatic air conditioning system ..... 213
Micro dust and pollen filter..................... 217
ABS (Anti-lock Brake System)................199 ABS warning light .....................................303
Active rear wing.............................................195
Adaptive Variable Suspension System200
Air conditioning filter ................................. 282
Air conditioning system Air conditioning filter ............................... 282
Automatic air conditioning system ..... 213
Micro dust and pollen filter..................... 217
Airbags Airbag operating conditions................... 30
Airbag precautions for your child .........32
Correct driving posture .............................23
Curtain shield airbag operating condi-tions .................................................................. 30
Curtain shield airbag precautions ........32
Front passenger occupant classification system ............................................................. 36
General airbag precautions ....................32
Locations of airbags.................................... 28
Modification and disposal of airbags . 35
Side airbag operating conditions ......... 30
Side airbag precautions .............................32
Side and curtain shield airbags operating conditions...................................................... 30
Side and curtain shield airbags precau- tions ...................................................................32
SRS airbags ..................................................... 28
SRS warning light ......................................303
Alarm ................................................................... 58 Warning buzzer ......................................... 302
Anchor brackets ...................................... 43, 51
Antennas (smart access system with push-button start)........................................ 98
Anti-lock Brake System (ABS)................199 ABS warning light .....................................303 Approach warning........................................ 176
Armrest............................................................ 228
Assist grips ..................................................... 229
Audio system-linked display ........................81
Automatic air conditioning system ........213
Automatic headlight leveling system ....139
Automatic headlight leveling system warning light............................................. 306
Automatic High Beam ............................... 140
Automatic light control system............... 138
Automatic transmission ..............................132 M mode ........................................................... 135
Paddle shift switches ....................... 134, 135
Average fuel economy................................. 75
Average vehicle speed ................................ 75
B
Back-up light Replacing light bulbs ............................... 289
Battery Battery checking .......................................... 271
Charging system warning light...........302
If the battery is discharged ....................334
Preparing and checking before winter..........................................................................204
Blind Spot Monitor (BSM)......................... 179
Brake Brake system warning light ..................302
Fluid...................................................................346
Parking brake ................................................137
Brake assist ......................................................199
Break-in tips...................................................... 119
Brightness control Instrument panel light control................. 73
BSM (Blind Spot Monitor)......................... 179
C
Card key ............................................................ 88
Care Exterior................................... 240, 248, 252
Interior .............................................................245

396Alphabetical Index
Preparing and checking before winter......................................................................... 204
Engine coolant temperature gauge ....... 66
Engine immobilizer system .........................57
Engine oil Capacity ......................................................... 343
Checking ....................................................... 267
Low engine oil pressure warning light.........................................................................303
Preparing and checking before winter ......................................................................... 204
Engine switch ..................................................128 Auto power off function ............................ 131
Changing the engine switch modes. 130
If your vehicle has to be stopped in an
emergency ................................................ 294
EPS (Electric Power Steering) ..............200 Electric power steer ing system warning
light ................................................................304
Event data recorder (EDR) ............................7
F
First-aid kit storage belt .............................227
Flat tire Tire pressure warning system ............. 275
Vehicles with a spare tire ........................313
Vehicles without a spare tire .................319
Floor mats ...........................................................22
Fluid Automatic transmission .......................... 345
Brake.................................................... 270, 346
Washer ............................................................272
Footwell light ................................................. 223
Front passenger occupant classification system .............................................................. 36
Front seats Adjustment..................................................... 103
Cleaning......................................................... 245
Correct driving posture .............................23
Driving position memory........................ 105
Memory recall function ........................... 106
Power easy access system .................... 105 Seat heaters .................................................... 221
Seat position memory .............................. 105
Seat ventilators .............................................. 221
Front side marker light Light switch .................................................... 138
Front turn signal lights Replacing light bulbs ............................... 289
Turn signal lever .......................................... 136
Fuel Capacity .........................................................343
Fuel gauge ........................................................ 66
Fuel pump shut off system...................... 301
Information ....................................................349
Low fuel level warning light ................. 306
Refueling.......................................................... 150
Type ..................................................................343
Fuel consumption Average fuel economy .............................. 75
Current fuel consumption ........................ 75
Fuel filler door If the fuel filler do or cannot be opened
........................................................................... 331
Refueling.......................................................... 150
Fuel gauge ......................................................... 66
Fuel pump shut off system......................... 301
Fuses ................................................................. 285
G
Garage door opener ...................................231
Gauges ............................................................... 66
Gear Position ....................................................76
G-force................................................................79
Glove box ....................................................... 226
Glove box light ............................................. 226
H
Headlight aim ................................................ 287
Headlights Automatic High Beam system ............. 140
Light switch .................................................... 138
Replacing light bulbs ............................... 289

398Alphabetical Index
Launch control................................................194
LDA (Lane Departure Alert with steering control)Operation........................................................164
Warning message.......................................169
LDA (Lane Departure Alert with steering control) switch .............................................166
Lever Auxiliary catch lever ................................. 264
Hood lock release lever......................... 264
Shift lever.......................................................... 132
Turn signal lever ...........................................136
Wiper lever.....................................................143
Lexus Enform Safety Connect.................. 53
Lexus Safety System + Automatic High Beam ............................. 140
Dynamic radar cruise control .................171
LDA (Lane Departure Alert with steering control) ..........................................................164
PCS (Pre-Collision System).................. 157
License plate lights Light switch .................................................... 138
Replacing light bulbs................................289
Light bulbs Replacing .......................................................288
Lights Automatic High Beam system............. 140
Front interior lights .................................... 223
Headlight switch ......................................... 138
Interior lights................................................. 223
Interior lights list.......................................... 223
Personal lights ............................................. 224
Rear interior lights ..................................... 223
Replacing light bulbs................................289
Trunk light......................................................... 97
Turn signal lever ...........................................136
Vanity lights .................................................. 230
Wattage..........................................................348
Lock steering column ..................................128M
Maintenance Do-it-yourself maintenance ................. 262
General maintenance ............................ 258
Maintenance date ...................................... 342
Maintenance requirements .................. 257
Malfunction indicator la mp ..................... 303
Master warning light .................................. 307
Matte paint care guide ....... 248, 252, 254
Menu icons.........................................................74
Meter Changing the display.................................... 71
Indicators........................................................... 63
Instrument panel light control................. 73
Meter control switches .............................. 74
Meters................................................................. 66
Multi-information display .......................... 73
Settings................................................................ 81
Units..................................................................... 76
Warning lights .............................................302
Warning message ...................................... 310
Micro dust and pollen filter ....................... 217
Mirrors Inside rear view mirror ............................. 109
Outside rear view mirror defoggers . 217
Outside rear view mirrors........................ 110
Vanity mirrors ..............................................230
Moon roof Door lock linked moon roof operation............................................................................. 115
Jam protection function ............................. 115
Operation ......................................................... 114
Multi-information display .............................73 Audio system-linked display .................... 81
Drive information 1/Drive information 2/Drive information 3 ............................. 75
Drive information display .......................... 75
Driving support system information dis- play..................................................................... 81
Dynamic radar cruise control................. 171
Eco Driving Indicator.................................. 76
