check engine LEXUS RX330 2006 Owner's Manual

STARTING AND DRIVING
448In the following cases, there is a problem somewhere in the
electronically
modulated air suspension, in which case the “N”
mode is automatically selected. Although there is no problem
to continue driving normally, have the electronically modulated
air suspension checked by your Lexus dealer as soon as
possible.
 The height control “OFF” indicator light does not come on
when the ignition switch is turned on.
 The height control “OFF” indicator light blinks.
(g) Operating noise of the electronically
modulated air suspension
You may hear an operating noise in the following cases. There
is no problem in the electronically modulated air suspension.
Selecting vehicle height with the height select switch
 Adjusting vehicle height according to the number of
occupants or the luggage load
 Changing vehicle height by selecting the easy access mode
when the engine is stopped
 Changing vehicle height by selecting the easy access mode
when the vehicle speed exceeds 12 km/h (8 mph)
 Changing the vehicle height by selecting the “HI” mode
when the vehicle speed exceeds 50 km/h (31 mph) or
driving at a speed of 30 km/h (19 mph) for 10 seconds or
more
 Lowering the vehicle’s height automatically when the
vehicle is moving at high speed
 Returning the vehicle height after high speed driving

STARTING AND DRIVING
450
Normal driving mode
Slip indicator light
Leave the system on during the ordinary driving so that it
can operate when needed.
You may hear a sound in the engine compartment for a few
seconds just after the vehicle begins to move. This means that
the traction control system is in the self− check mode, but does
not indicate a malfunction. When the traction control system is operating, the following
conditions occur:

The system controls the spinning of the front wheels. At this
time, the slip indicator light blinks.
 You may feel vibration or noise in your vehicle, caused by
operation of the brakes. This indicates the system is
functioning properly.
The slip indicator light comes on for a few seconds when the
ignition key is turned to “ON”. If the indicator light does not
come on when the ignition is turned on, contact your Lexus
dealer.

STARTING AND DRIVING
453
TRACTION CONTROL SYSTEM
(fourwheel drive modes)
The traction control system automatically helps prevent
the spinning of 4 wheels when the vehicle is started or
accelerated on slippery road surfaces.
When the ignition key is turned to “ON”, the system
automatically turns on.
CAUTION
Under certain slippery road conditions, full traction of
the vehicle and power against 4 wheels cannot be
maintained, even though the traction control system is
in operation. Do not drive the vehicle under any speed
or maneuvering conditions which may cause the
vehicle to lose traction control. In situations where the
road surface is covered with ice or snow, your vehicle
should be fitted with snow tires or tire chains. Always
drive at an appropriate and cautious speed for the
present road conditions.
Normal driving mode
 Slip indicator light
Leave the system on during the ordinary driving so that it
can operate when needed.
You may hear a sound in the engine compartment for a few
seconds just after the vehicle begins to move. This means that
the traction control system is in the self− check mode, but does
not indicate a malfunction.

STARTING AND DRIVING
455
In the following cases, contact your Lexus dealer:

The warning light does not come on after the ignition key is
turned to “ON”.
 The warning light remains on after the ignition key is turned
to “ON”.
 The warning light comes on while driving.
VEHICLE STABILITY CONTROL
SYSTEM
The vehicle stability control system helps provide
comprehensive control of the systems such as antilock
brake system, traction control, engine control, etc. This
system automatically controls the brakes and engine to
help prevent the vehicle from skidding when cornering on
a slippery road surface or operating steering wheel
abruptly.
This system activates when the vehicle speed is about more
than 15 km/h (9 mph).
You may hear a sound in the engine compartment for a few
seconds just after the vehicle begins to move. This means that
the system is in the self −check mode, but does not indicate a
malfunction.

STARTING AND DRIVING
459
Antilock brake system
The antilock brake system is designed to help prevent
lockup of the wheels during a sudden braking or braking
on slippery road surfaces. This assists in providing
directional stability and steering performance of the
vehicle under these circumstances.
Effective way to press the ABS brake pedal: When the
anti−lock brake system function is in action, you may feel the
brake pedal pulsating and hear a noise. In this situation, to
let the anti−lock brake system work for you, just hold the
brake pedal down more firmly. Do not pump the brake in a
panic stop. This will result in reduced braking performance.
The anti−lock brake system becomes operative after the
vehicle has accelerated to a speed in excess of approximately
10 km/h (6 mph). It stops operating when the vehicle
decelerates to a speed below approximately 5 km/h (3 mph).
Depressing the brake pedal on slippery road surfaces such as
on a manhole cover, a steel plate at a construction site, joints
in a bridge, etc. on a rainy day tends to activate the anti −lock
brake system.
You may hear a click or motor sound in the engine
compartment for a few seconds just after the vehicle begins to
move. This means that the anti −lock brake system is in the
self−check mode, and does not indicate a malfunction. When the antilock brake system is activated, the
following conditions may occur. They do not indicate a
malfunction of the system:

You may hear the anti −lock brake system operating and feel
the brake pedal pulsating and the vibrations of the vehicle
body and steering wheel. You may also hear the motor
sound in the engine compartment even after the vehicle is
stopped.
 At the end of the anti−lock brake system activation, the
brake pedal may move a little forward.
CAUTION
Do not overestimate the antilock brake system:
Although the antilock brake system assists in
providing vehicle control, it is still important to drive
with all due care and maintain a moderate speed and
safe distance from the vehicle in front of you, because
there are limits to the vehicle stability and effectiveness
of steering wheel operation even with the antilock
brake system on.
If tire grip performance exceeds its capability, or if
hydroplaning occurs during high speed driving in the
rain, the antilock brake system does not provide
vehicle control.

STARTING AND DRIVING
462
Brake assist system
If you slam the brakes on such as in an emergency or
apply the brakes more firmly than usual such as when
descending the hill with the designated number of
occupants in the vehicle, the brake assist system
provides more powerful braking.
If you slam the brakes on or apply the brakes more firmly, more
powerful braking will be applied. At this time, you may hear a
sound in the engine compartment and feel the vibrations of the
brake pedal. This does not indicate a malfunction.
The brake assist system becomes operative after the vehicle
has accelerated to a speed in excess of approximately 10 km/h
(6 mph). It stops operating when the vehicle decelerates to a
speed below approximately 5 km/h (3 mph).
For an explanation of this system’s warning light, see “ABS
warning light” on page 81 or 460.
TIRE PRESSURE WARNING SYSTEM
The tire pressure warning system is designed to provide
warning when tire inflation pressure is critically low while
the vehicle is moving. The low tire pressure warning light
comes on to inform you that such low tire pressure may
hamper driving.
This system is not designed to operate when the vehicle is
stopped. Therefore, check the tire inflation pressure regularly.
The recommended cold tire inflation pressure, tire size and the
vehicle capacity weight are on the tire and loading information
label. (For instructions, see “Checking tire inflation pressure”
on page 570.)
Installed tires should be of the specified size. They should be
of the same size and construction. If tires other than the
specified size are used, or if tires of different sizes or
constructions are mixed, the tire pressure warning system will
not function properly.

DRIVING TIPS
471
CAUTION
Before driving off, make sure the parking brake is
fully released and that the parking brake reminder
light is off.
 Do not leave your vehicle unattended while the
engine is running.
 Do not rest your foot on the brake pedal while driving.
It can cause dangerous overheating, needless wear,
and poor fuel economy.
 To drive down a long or steep hill, reduce your speed
and downshift. Remember, if you ride the brakes
excessively, they may overheat and not work
properly. See page 392 or 403.
 Be careful when accelerating, upshifting,
downshifting or braking on a slippery surface. The
abrupt change in engine speed, such as sudden
acceleration or engine braking, could cause the
vehicle to skid or spin.
Do not drive in excess of the speed limit. Even if the
legal speed limit permits it, do not drive over 140 km/h
(85 mph) unless your vehicle has highspeed
capability tires. Driving over 140 km/h (85 mph) may
result in tire failure, loss of control and possible
injury. Be sure to consult a tire dealer to determine
whether the tires on your vehicle are highspeed
capability tires or not before driving at such speeds.
 Do not continue normal driving when the brakes are
wet. If they are wet, your vehicle will require a longer
stopping distance, and it may pull to one side when
the brakes are applied. Also, the parking brake will
not hold the vehicle securely.
 Vehicles with electronically modulated air
suspension: If you drive through water, such as when
crossing swallow streams, first check the depth of
the water and the bottom of the river bed of firmness,
put the vehicle height in the “HI” (high) mode with the
height select switch and then turn off the
electronically modulated air suspension by pushing
the height control switch. Drive your vehicle at 30
km/h (19 mph) or lower speed.

DRIVING TIPS
473
After driving through tall grass, mud, rock, sand,
rivers, etc., check that there is no grass, bush, paper,
rags, stone, sand, etc. adhering or trapped on the
underbody. Clear off any such matter from the
underbody. If the vehicle is used with these materials
trapped or adhering to the underbody, a breakdown
or fire could occur.
 In a rollover crash, an unbelted person is
significantly more likely to die than a person wearing
a seat belt. Therefore, the driver and all passengers
should fasten their seat belts whenever the vehicle is
moving.
 When driving offroad or in rugged terrain, do not
drive at excessive speeds, jump, make sharp turns,
strike objects, etc. This may cause loss of control or
vehicle rollover causing death or serious injury. You
are also risking expensive damage to your vehicle’s
suspension and chassis.NOTICE
 If driving through water, such as when crossing
shallow streams, first check the depth of the water
and the bottom of the river bed for firmness. Drive
slowly and avoid deep water.
 Take all necessary safety measures to ensure that
water damage to the engine or other components
does not occur.
Water entering the engine air intake will cause severe
engine damage.
Water can wash the grease from wheel bearings,
causing rusting and premature failure, and may also
enter the differentials, transmission and transfer
case, reducing the gear oil’s lubricating qualities.
 Sand and mud that has accumulated in brake drums
and around brake discs may affect braking ef ficiency
and may damage brake system components.
 Always perform a maintenance inspection after each
day of offroad driving that has taken you through
rough terrain, sand, mud, or water. For scheduled
maintenance information, refer to the “Owner’s
Manual Supplement / Scheduled Maintenance”.

DRIVING TIPS
474
WINTER DRIVING TIPS
Make sure your coolant is properly protected against
freezing.
Only use “Toyota Super Long Life Coolant” or similar high
quality ethylene glycol based non−silicate, non −amine,
non− nitrite, and non −borate coolant with long− life hybrid
organic acid technology. (Coolant with long −life hybrid organic
acid technology is a combination of low phosphates and
organic acids.)
See “Checking the engine coolant level” on page 559 for
details of coolant type selection.
For the U.S.A. — “T oyota Super Long Life Coolant” is a mixture
of 50% coolant and 50% deionized water. This coolant
provides protection down to about −35C (− 31F).
For Canada — “Toyota Super Long Life Coolant” is a mixture
of 55% coolant and 45% deionized water. This coolant
provides protection down to about −42C (− 44F).
NOTICE
Do not use plain water alone.
Check the condition of the battery and cables.
Cold temperatures reduce the capacity of any battery, so it
must be in top shape to provide enough power for winter
starting. Page 601 tells you how to visually inspect the battery.
Your Lexus dealer and most service stations will be pleased to
check the battery charge level.
Make sure the engine oil viscosity is suitable for the cold
weather.
See page 558 for recommended viscosity. Leaving a heavy
summer oil in your vehicle during winter months may cause
harder starting. If you are not sure about which oil to use, call
your Lexus dealer — they will be pleased to help.
Check the electronic ignition system for loose
connections or obvious damage.
Keep the door locks from freezing.
Squirt lock de− icer or glycerine into the locks to keep them from
freezing.
Use a washer fluid containing an antifreeze solution.
This product is available at your Lexus dealer and most auto
parts stores. Follow the manufacturer’s directions for how
much to mix with water.
NOTICE
Do not use engine antifreeze or any other substitute
because it may damage your vehicle’s paint.

DRIVING TIPS
483
Trailer lights
 Socket for trailer lights
Your vehicle is equipped with a wire harness stored in the rear
end underbody. Models with tow hitch receiver are fitted with
a socket for trailer lights under the rear bumper. Use either of
them to connect and operate the trailer lights. However, the
trailer lights must comply with federal, state/provincial and
local regulations. See your local recreational vehicle dealer or
rental agency for the correct type of wiring and relays for your
trailer. Check for correct operation of the turn signals and stop
lights each time you hitch up. Direct splicing may damage your
vehicle’s electrical system and cause a malfunction of your
lights.
Breakin schedule
 Lexus recommends that you do not tow a trailer with a new
vehicle or a vehicle with any new power train component
(engine, transmission, differential, wheel bearing, etc.) for
the first 800 km (500 miles) of driving.
Maintenance
 If you tow a trailer, your vehicle will require more frequent
maintenance due to the additional load. For this
information, please refer to the scheduled maintenance
information in the “Owner’s Manual Supplement /
Scheduled Maintenance”.
 Retighten all fixing bolts of the towing ball and bracket after
approximately 1000 km (600 miles) of trailer driving.
Connecting a trailer (models with
electronically modulated air suspension)
Stop your vehicle and a trailer in line and perform the following:
1. Put the electronically modulated air suspension in the “LO”
mode. Turn the ignition switch off or push the height control
switch to turn off the electronically modulated air suspension.
2. Connect a trailer.
3. Turn the ignition switch on or push the height control switch
to turn on the electronically modulated air suspension. Select
the “N” (normal) mode with the height select switch.
