AUDIO
296
“Automatic program selection” button: The automatic
program selection feature allows you to program your cassette
player to skip forward or backward to locate the song you want
to hear. You can skip up to 9 programs at a time.
Push this button on the “
” side to skip forward. “FF” and the
number will appear on the display. Push the button until the
number you want to skip appears on the display. After that, the
player will automatically skip forward.
When the end of the tape is reached, the player automatically
reverses sides and resumes normal play. Push this button on the “
” side to skip backward. Push the
button until “REW” and the number you want to skip appear on
the display.
 If you set “REW 1”, the player will rewind to the beginning
of the current program.
 When c ounting the number of programs you want to rewind,
remember to count the current program as well. For
example, if you want to rewind to a song that is two before
the song you are listening to, push this button until “REW
3” appears on the display.
When a beginning of the tape is reached, the player
automatically resumes normal play.
There must be at least 3 seconds of blank space between
programs for this feature to work correctly.
“RPT” and “Automatic program selection” features:
These features may not work well with some spoken word, live
or classical recordings.

AUDIO
297
CD player operation
(a) Inserting or ejecting CDs
The ignition switch must be in the “ACC” or “ON” position.
Your CD player with changer can store up to 6 CDs.
Setting a single CD:
1. Push the “LOAD” button briefly.
The umber indicators at both ends of the slot start blinking and
“WAIT” appears on the display. After the blinking indicators
change to green and stay on, and “WAIT” changes to the
“LOAD”, the CD door opens. 2. Insert only one CD while the CD door is open.
You can set a CD at the lowest empty CD number.
After insertion, the set CD is automatically loaded.
If the label faces down, the CD cannot be played. In this case,
“ERROR 1” and CD number appear on the display.
If you need to insert the next CD, repeat the same procedure
to insert another CD.

Setting all the CDs:
1. Push the “LOAD” button until you hear a beep.
The umber indicators at both ends of the slot start blinking and
“WAIT” appears on the display. After the blinking indicators
change to green and stay on, and “WAIT” changes to the
“LOAD”, the CD door opens.
2. Insert only one CD while the CD door is open.
The CD door closes and “WAIT” appears again.
3. Insert the next CD after the “WAIT” changes to the
“LOAD” and the CD door opens.
4. Repeat this procedure until you insert all the CDs.
To cancel the operation, push the “LOAD” or “DISC” button.
If you do not insert CDs within 15 seconds after pushing the
“LOAD” button and “LOAD” is displayed, the operation will be
canceled automatically.

AUDIO
298
NOTICE
Do not insert one CD stacked on top of another one or
feed them in continuously, to prevent CDs from getting
stuck in the player.
 Ejecting a single CD alone:
1. Push the “
” or “” button to display the CD number
you want to eject.
2. Push the “
” (eject) button for the CD briefly.
At this time, the display shows “EJECT” and the indicators at
both ends of the slot as well as CD number light up.
 Ejecting all the CDs:
Push the “
” (eject) button for the CD until you hear a
beep.

AUDIO
299
(b) Playing a CD
Push the “DISC” button if the CDs are already loaded in
the player.
“CD” appears on the display.
The CDs set in the player are played continuousl
y, starting with
the last CD you inserted. The CD number of the CD currently
being played, the track number and the time from the beginning
of the program appear on the display.
When play of one CD ends, the first track of the following CD
starts. When play of the final CD ends, play of the first CD
starts again.
The player will skip any empty CD trays. (c) Selecting a desired CDSearching for a desired CD:
Push the “
” or “” button to select the CD number.
Push the button several times until the desired CD number
appears on the display.

AUDIO
300(d) Searching for a desired track or CD
Searching for a desired track:
Push the “SCAN” button briefly. “SCAN” will appear on the
display.
The CD player will play the next track for 10 seconds,
then scan again. To select a track, push the “SCAN” button a
second time. If the player reaches the end of the CD, it will
continue scanning at track 1.
After all the tracks are scanned in one pass, normal play
resumes. Searching for a desired CD:
Push
the “SCAN” button until you hear a beep. With “
”
on the display, the program at the beginning of each CD will be
played for 10 seconds. To continue listening to the program of
your choice, push the button a second time.
After all the CDs in the automatic changer are scanned in one
pass, the scan function is cancelled.

AUDIO
301
(e) Selecting a desired track
“TRACK” button: Use for direct access to a desired track.
Push either
side of the “TRACK” button several times until the
desired track number appears on the display. As you release
the button, the player will start playing the selected track from
the beginning.
“Fast forward” button: Push the “ ” button and hold it to
fast forward the CD. When you release the button, the CD
player will resume playing from that position.
“Reverse” button: Push the “ ” button and hold it to
reverse the CD. When you release the button, the CD player
will resume playing. (f) Repeating a track or a CD“RPT” button:
There are 2 repeat features — you can either
replay a CD track or a whole CD.
Repeating a track: Push the “RPT” button briefly while the
track is playing. “
” will appear on the display. When the
track ends, it will automatically be replayed. This process will
be continued until you push the button again to turn off the
repeat feature.
Repeating a CD: Push and hold “RPT” until you hear a beep.
“
” will appear on the display. The player will repeat all
the tracks on the CD you are listening to. When the CD ends,
the player will automatically go back to the first track on the CD
and replay. To turn off the repeat feature, push this button
again.

AUDIO
302(g) Random playing
“RAND” button: There are 2 random features — you can
either
listen to the tracks on all the CDs in the player in random
order, or only listen to the tracks on a specific CD in random
order.
Random playing for the tracks on a CD: Push the “RAND”
button briefly. “
” will appear on the display and play
the CD you are listening to in random order. Random playing for all the tracks in the automatic
changer:
Push the “RAND” button and hold it until you hear a
beep. “
” will appear on the display and the player will
perform all the tracks on all the CDs in the changer in random
order. To turn off the random feature, push “RAND” a second
time.
When a track is skipped or the system is inoperative, push the
button to reset.

AUDIO
303
(h) CD text
When you push the “TEXT” button while the CD with CD
text display function (the logo “CD TEXT” marked on the
CD) is being played, the track number, elapsed time, CD
title and then track title appear on the display.
When you push this button if the CD does not have a text
display function, “NO TITLE” appears on the display.
The display can show up to 12 letters at once. If the CD title
or music title is longer than 12 letters, hold down the button until
you hear a beep. The letters after the 12th one are shown.
However, 24
letters at maximum can be shown on the display. When you push this button until you hear a beep or play no
operation
for about 6 seconds with the letters after the 13th one
on the display, the display returns and shows the first 12 letters.
Even if the CD title or music title is longer than 24 letters, the
display can show up to 24 letters.

AUDIO
304(i) If the player malfunctions
If the player or another unit equipped with the player
malfunctions, your audio system will display following error
messages.
If “WAIT” appears on the display:
It indicates that the inside
of the player unit may be too hot due to the very high ambient
temperature. Remove the CD from the player and allow the
player to cool down.
If “ERROR 1” appears on the display: It indicates that the CD
is dirty, damaged, or it was inserted up −side down. Clean the
CD or insert it correctly.
If “ERROR 3” or “ERROR 4” appears on the display: It
indicates there is a trouble inside the system. Eject the CD.
If the malfunction is not rectified: Take your vehicle to your
Lexus dealer.
AUDIO REMOTE CONTROLS
The switches are installed on the left side of the steering wheel.
“MODE” switch: Use this switch to turn on or off the audio
system, or change the audio mode.
 To turn on the system, push the switch briefly. To turn off the
system, push and hold the switch until you hear a beep.
 To change the audio mode, turn on the system and push the
switch briefly. If a tape or CD is not inserted, the “T APE” or
“CD” mode is skipped.
The DVD player will be selectable if a rear seat entertainment
system is installed in your vehicle.

AUDIO
306
REAR SEAT ENTERTAINMENTSYSTEM1Front audio system
2Headphone volume control dial
3Headphone input jack
4DVD player
5Rear seat entertainment system display
6Rear seat entertainment system remote control
7Input terminal adapter
8Power outlet
9Power outlet main switch
