DRIVING TIPS
477
Weight limits
Before towing, make sure the total trailer weight, gross
vehicle weight, gross axle weight and trailer tongue load
are all within the limits.
The total trailer weight and tongue load can be measured with
platform scales found at a highway weighing station, building
supply company, trucking company, junk yard, etc.
Certification label
CAUTION
The total trailer weight (trailer weight plus its cargo
load) must not exceed the following. Exceeding this
weight is dangerous. Without towing package 907 kg (2000 lb.)
With towing package 1588 kg (3500 lb.)
 If towing a trailer and cargo weighing over 907 kg
(2000 lb.), Lexus recommends to use a sway control
device with sufficient capacity. The gross
combination weight (sum of your vehicle weight plus
its load and the total trailer weight) must not exceed
the following. Without towing package 3286 kg (7245 lb.)
With towing package 3966 kg (8745 lb.)
 Trailer hitch assemblies have different weight
capacities established by the hitch manufacturer.
Even though the vehicle may be physically capable of
towing a higher weight, the operator must determine
the maximum weight rating of the particular hitch
assembly and never exceed the maximum weight
rating specified for the trailer hitch. Exceeding the
maximum weight rating set by the trailer hitch
manufacturer can cause an accident resulting in
serious personal injuries.

DRIVING TIPS
489
VEHICLE LOAD LIMITS
Vehicle load limits include total load capacity, seating
capacity, towing capacity and cargo capacity. Follow
the load limits shown below. Total load capacity and
seating capacity are also described on the tire and
loading information label. For location of the tire and
loading information label, see “Checking tire inflation
pressure” on page 570.
Total load capacity: 420 kg (925 lb.)
Total load capacity means combined weight of
occupants, cargo and luggage. Tongue load is
included when trailer towing.
Seating capacity: Total 5 (Front 2, Rear 3)
Seating capacity means the maximum number of
occupants whose estimated average weight is 68 kg
(150 lb.) per person. Depending on the weight of
each person, the seating capacity given may exceed
the total load capacity.
NOTICE
Even if the number of occupants are within the
seating capacity, do not exceed the total load
capacity.
Towing capacity:
Without towing package 907 kg (2000 lb.)
With towing package 1588 kg (3500 lb.)
Towing capacity means the maximum gross trailer
weight (trailer weight plus its cargo weight) that your
vehicle is able to tow.
Cargo capacity
Cargo capacity may increase or decrease depending
on the size (weight) and the number of occupants.
For details, see “Capacity and distribution” that
follows.
CAUTION
Do not apply the load more than each load limit.
That may cause not only damage to the tires,
but also deterioration to the steering ability and
braking ability, which may cause an accident.

DRIVING TIPS
491
Capacity and distribution
Cargo capacity depends on the total weight of the
occupants.
(Cargo capacity) = (Total load capacity) – (Total weight
of occupants)
Steps for determining correct load limit
1. Locate the statement “The combined weight of
occupants and cargo should never exceed XXX
pounds” on your vehicle’s placard.
2. Determine the combined weight of the driver and
passengers that will be riding in your vehicle.
3. Subtract the combined weight of the driver and
passengers from XXX kilograms or XXX pounds.
4. The resulting figure equals the available amount of
cargo and luggage load capacity. For example, if the
“XXX” amount equals 1400 lbs. and there will be five
150 lb. passengers in your vehicle, the amount of
available cargo and luggage load capacity is 650 lbs.
1400 – 750 (5 x 150) = 650 lbs.
5. Determine the combined weight of luggage and
cargo being loaded on the vehicle. That weight may
not safely exceed the available cargo and luggage
load capacity calculated in Step 4.6. If your vehicle will be towing a trailer, load from your
trailer will be transferred to your vehicle. Consult this
manual to determine how this reduces the available
cargo and luggage load capacity of your vehicle.
For details about trailer towing, see page 476.

BODY
617
— DIMENSIONS AND WEIGHTSWheelbase
2715 mm (107 in.)
Tread Tw o −wheel drive models
— Front
— Rear
Four−wheel drive models — Front
— Rear (with electronically
modulated air suspension)
— Rear (without electronically
modulated air suspension)
1580 mm (62.2 in.)
1565 mm (61.6 in.)
1575 mm (62.0 in.)
1560 mm (61.4 in.)
1555 mm (61.2 in.)
Vehicle capacity weight
(occupants + cargo)420 kg (925 lb.)
Towing capacity
(trailer weight + cargo weight)— Without towing package
— With towing package
907 kg (2000 lb.)
1588 kg (3500 lb.)
— FUEL TANK
Capacity
72.5 L (19.2 gal., 15.9 Imp. gal.)
