LEXUS RX350 2019 Owners Manual

170 3-3. Adjusting the seats
RX350/RX350L_U WARNING ■
Seat adjustment ●
Second-row seats: To reduce the risk of s liding under the lap belt during a collision,
do not recline the seat more than necessary.
If the seat is reclined excessively, the la p belt may slide past the hips and apply
restraint forces directly to the abdomen, or your neck may contact the shoulder belt,
increasing the risk of de ath or serious injury in the event of an accident.●
Adjustments should not be made while dr iving as the seat may unexpectedly move
and cause the driver to lose control of the vehicle. ■
After adjusting the rear seats
Observe the following precautions.
Failure to do so may result in death or serious injury.●
Manual seats: Make sure that the rear se atback is securely locked in position by
lightly pushing it back and forth. ●
Check that the seat belts are not twisted or caught between or behind in the rear
seatback. ■
Jam protection function (power seats)
Observe the following precautions.
Failure to do so may result in death or serious injury.●
Never use any part of your body to intentionally activate the jam protection function. ●
The jam protection function may not operate if something is caug ht just before the
fully folded position. Be careful so th at fingers, etc. do not get caught.●
The jam protection function may not operat e depending on the shape or position of
the obstruction. Be careful so that fingers, etc. do not get caught.■
Precautions for third-row seat (RX350L)
When operating a third-row seat, make sure to press and hold the sw itch until the third-
row seat seatback is complete ly folded/upright. Do not use a third-row seat in a posi-
tion other than the completely upright position, as doing so may lead to death or seri-
ous injury in an accident. (If the switch is released while the seatback is still moving, a
buzzer will sound continuously until the seatback is complete ly folded/upright.)

1713-3. Adjusting the seats
3
Operation of each component
RX350/RX350L_U NOTICE ■
Before folding a rear seat seatback ●
Second-row seats: Make sure to stow the center seat seat belt buckle and armrest
before folding the second-row seat seatbacks. (  P. 555)●
Third-row seats: Make sure th at the third-row seats and trays are free of obstructions
before folding the seatbacks. Otherwise the seat or tray may be damaged. ■
When moving the second-row seat for third-row seat access (RX350L)
Do not slide the second-row se at forward if an electronic device is connected to the
power outlet on the rear console. Otherwise, the second-row seat may contact the
electronic device, possibly resu lting in damage to the device.■
Before returning the third-row seat seatbacks to the upright position (RX350L)
If the luggage cover is insta lled in the luggage compartmen t, make sure to remove it
before returning the thir d-row seat seatbacks. (  P. 537) Otherwise, the luggage
cover may be damaged.

172 3-3. Adjusting the seats
RX350/RX350L_U The seat and steering wheel are automati cally adjusted to allow the driver to
enter and exit the vehicle easily.
When all of the following have been
performed, the seat and steering wheel
are automatically adjusted to a position
that allows driver to enter and exit the
vehicle easily.
• The shift lever has been shifted to P.
• The engine switch has been turned
off.
• The driver’s seat belt has been unfastened.
When any of the following has been performed, the seat and steering wheel
automatically return to their original positions.
• The engine switch has been turn ed to ACCESSORY mode or IGNITION
ON mode.
• The driver’s seat belt has been fastened. ■
Operation of the power easy access system
When exiting the vehicle, the power easy ac cess system may not operate if the seat is
already close to the rearmost position, etc. ■
Customization
Some functions can be customized. (  P. 722)Driving position memory 
 : If equippedThis feature automatically adjusts the driver’s seat (on some models), steering
wheel, outside rear view mirrors and head-up display (if equipped) to make
entering and exiting the vehicle easi er or to suit your preferences.
Power easy access system (driver’s side only)

1733-3. Adjusting the seats
3
Operation of each component
RX350/RX350L_U Your preferred driving position (the positi on of the driver’s seat, steering wheel,
outside rear view mirrors and head-up display
* ) can be recorded and recalled
by pressing a button.
Three different driving positions can be recorded into memory.
* : If equipped ■
Recording procedure
Check that the shift lever is in P.
Turn the engine switch to IGNITION ON mode.
Adjust the driver’s seat, steering wh eel, outside rear view mirrors and
head-up display (if equipped) to the desired positions.
While pressing the “SET” button,
or within 3 seconds after the
“SET” button is pressed, press
button “1”, “2” or “3” until the
buzzer sounds. If the selected button has already
been preset, the previously recorded
position will be overwritten.Driving position memory 1
2
3
4

174 3-3. Adjusting the seats
RX350/RX350L_U ■
Recall procedure
Check that the shift lever is in P.
Turn the engine switch to IGNITION ON mode.
Press one of the buttons for the
driving position you want to recall
until the buzzer sounds. ■
To stop the position recall operation part-way through
Perform any of the following: ●
Press the “SET” button. ●
Press button “1”, “2” or “3”. ●
Operate any of the seat adjustment switches (only cancels seat position recall). ●
Operate the tilt and telescopic steering control switch (only cancels steering wheel
position recall). ■
Seat positions that can be memorized (  P. 156)
The adjusted positions other than the position adjusted by lumbar support switch can be
recorded. ■
Operating the driving position memory after turning the engine switch off
Recorded seat positions can be activated up to 180 seconds after the driver’s door is
opened and another 60 seconds after it is closed again. ■
In order to correctly use the dr iving position memory function
If a seat position is already in the furthest po ssible position and the seat is operated in the
same direction, the recorded position may be slightly di fferent when it is recalled.1
2
3

1753-3. Adjusting the seats
3
Operation of each component
RX350/RX350L_U Each electronic key can be registered to recall your preferred driving position.■
Registering procedure
Record your driving position to button “1”, “2” or “3” before performing the
following:
Carry only the key you want to regist er, and then close the driver’s door.
If 2 or more keys are in the vehicle, the driving position cannot be recorded
properly.
Check that the shift lever is in P.
Turn the engine switch to IGNITION ON mode.
Recall the driving position that you want to record.
While pressing the recalled but-
ton, press and hold the door lock
switch (either lock or unlock) until
the buzzer sounds. If the button could not be registered,
the buzzer sounds continuously for
approximately 3 seconds.
■
Recall procedure
Make sure that the doors are locked before recalling the driving position.
Carry the electronic key that has been registered to the driving position,
and then unlock and open the driver’s door using the smart access system
with push-button start or wireless remote control. The driving position will move to the recorded position (not including the steering
wheel and head-up display
* ). However, the seat will move to a position slightly
behind the recorded position in order to make entering the vehicle easier.
If the driving position is in a position th at has already been recorded, the seat and
outside rear view mirrors will not move.
* : If equipped
Turn the engine switch to ACCESS ORY mode or IGNITION ON mode,
or fasten a seat belt. The seat, steering wheel and head-up display (if equipped) will move to the
recorded position.Memory recall function (driver’s side only) 1
2
3
4
1
2

176 3-3. Adjusting the seats
RX350/RX350L_U ■
Cancelation procedure
Carry only the key you want to cance l and then close the driver’s door.
If 2 or more keys are in the vehicle, the driving position cannot be canceled
properly.
Turn the engine switch to IGNITION ON mode.
While pressing the “SET” button, pr ess and hold the door lock switch
(either lock or unlock) un til the buzzer sounds twice.If it button could not be canceled, the buzzer sounds continuously for approxi-
mately 3 seconds.■
Recalling the driving position using the memory recall function●
Different driving positions can be registered for each electronic key. Therefore, the
driving position that is recalled may be di fferent depending on the key being carried.●
If a door other than the driver’s door is unlocked with the smart access system with
push-button start, the driving position cannot be recalled. In this case, press the driving
position button which has been set. ■
Customization
Some functions can be customized. (  P. 722)
WARNING ■
Seat adjustment caution
Take care during seat adjustment so that th e seat does not strike the rear passenger or
squeeze your body against the steering wheel. 1
2

1773-3. Adjusting the seats
3
Operation of each component
RX350/RX350L_U ◆ Vertical adjustment
Up Pull the head restraints up.
Down Push the head restraint down while
pressing the lock release button.
◆ Horizontal adjustment (if equipped)
The position of the head restraint
can be adjusted forward in 4 stages. If the head restrain t is pulled forward
from the foremost position, it will
return to the rearmost position.
Up Pull the head restraints up.
Down Push the head restraint down while
pressing the lock release button.Head restraints Head restraints are provided for all seats.
Front seats
Lock release button1
2
Second-row seats
Lock release button1
2

178 3-3. Adjusting the seats
RX350/RX350L_U Up Pull the head restraints up.
Down Push the head restraint down while
pressing the lock release button. ■
Removing the head restraints 
Front and second-row seats 
Third-row seats
■
Installing the head restraints 
Front and second-row seatsThird-row seats (RX350L)
Lock release button1
2
Pull the head restraint up while pressing the lock
release button.
If the head restraint to uches the ce iling, making
the removal difficult, change the seat height or
angle. (  P. 156, 157)
Pull the head restraint up while pressing the lock
release button.
If the head restraint to uches the ce iling, making
the removal difficult, change the seat angle.
(  P. 157)
Align the head restrain t with the installation
holes and push it down to the lock position.
Press and hold the lock release button when
lowering the head restraint. Lock release button
Lock release button
Lock release button

1793-3. Adjusting the seats
3
Operation of each component
RX350/RX350L_U 
Third-row seats ■
Adjusting the height of the head restraints
■
Adjusting the second-row center an d third-row seat head restraints
Always raise the head restraint one leve l from the stowed position when using.Align the head restrain t with the installation
holes and push it down to the lock position.
Press and hold the lock release button when
lowering the head restraint.
Make sure that the head restraints are adjusted
so that the center of the head restraint is closest
to the top of your ears.
WARNING ■
Head restraint precautions
Observe the following precautions regarding the head restraints.
Failure to do so may result in death or serious injury.●
Use the head restraints design ed for each respective seat.●
Adjust the head restraints to th e correct position at all times.●
After adjusting the head restraints, push down on them and make sure they are
locked in position. ●
Do not drive with the head restraints removed. Lock release
button
