navigation system LEXUS RX350 2020 Owner's Manual

4708-2. Customization
8-2.Customization
■Changing by using the Remote
Touch
1 Press the “MENU” button on the
Remote Touch.
2 Select “Setup” on the menu screen
and select “Vehicle”.
3 Select “Vehicle Customization” or
“Drive Mode Customization”.
Various setting can be changed. Refer to
the list of settings that can be changed for
details.
This system can also be operated by the
touch screen.
For details on the Remote Touch, refer
to the “NAVIGATION AND MULTI-
MEDIA SYSTEM OWNER’S MAN- UAL”.
■Changing by using the meter con-
trol switches
1 Press or to select .
2 Operate the meter control
switches to select the desired item
to be customized.
3 According to the display, select the
desired setting and then press
.
To go back to the previous screen or exit
the customize mode, press .
Some function settings are changed simultaneously with other functions being cus-
tomized. Contact your Lexus dealer for further details.
Settings that can be changed using the Remote Touch
Settings that can be changed using the meter control switches
Settings that can be changed by your Lexus dealer
Definition of symbols: O = Available, — = Not available
Customizable features
Your vehicle includes a variety of
electronic features that can be per-
sonalized to suit your preferences.
The settings of these features can
be changed by using the meter con-
trol switches, the Remote Touch, or
at your Lexus dealer.
Customizing vehicle features
WARNING
■During customization
As the engine needs to be running
during customization, ensure that the
vehicle is parked in a place with ade-
quate ventilation. In a closed area such as
a garage, exhaust gases including harm-
ful carbon monoxide (CO) may collect
and enter the vehicle. This may lead to
death or a serious health hazard.
NOTICE
■During customization
To prevent battery discharge, ensure that
the engine is running while customizing
features.
Customizable Features
A
B
C

507Alphabetical Index
FuelCapacity ......................................................... 454
Fuel gauge ....................................................... 75
Fuel pump shut off system ...................... 412
Information ....................................................459
Refueling ........................................................ 202
Type.................................................................. 454
Warning light .................................................416
Fuel consumption Average fuel economy ..............................80
Current fuel consumption........................80
Fuel filler door If the fuel filler door cannot be opened.........................................................................440
Refueling ........................................................ 202
Fuel gauge ..........................................................75
Fuel pump shut off system.......................... 412
Fuses ...................................................................391
G
Garage door opener ................................. 339
Gauges ................................................................75
G-force............................................................... 82
Glove box ........................................................ 318
Glove box light .............................................. 318
Grocery bag hooks .................................... 322
H
Hands Free Power Back Door ............... 104
Head restraints ............................................... 137
Headlight aim ................................................ 392
Headlights Adaptive Front-lighting System (AFS)........................................................................... 192
Automatic High Beam system..............193
Light switch .................................................... 190
Replacing light bulbs................................395
Head-up display.............................................. 86 Driving information display area........... 86
Eco Driving Indicator ................................. 90
HUD (Head-up display) switch............ 87 Navigation system-linked display ........89
Settings.............................................................. 88
Heated steering wheel ............................... 310
Heaters Front automatic air conditioning system..........................................................................296
Heated steering wheel ............................. 310
Outside rear view mirrors.................... 298
Rear automatic air conditioning system
..........................................................................307
Seat heaters ................................................... 310
High mounted stoplight Replacing light bulbs ............................... 395
Hill-start assist control ............................... 278
Hood Open................................................................363
Hooks Cargo hooks................................................ 322
Cargo net hooks ........................................ 322
Coat hooks ...................................................336
Front passenger footwell hooks........ 338
Grocery bag hooks.................................. 322
Retaining hooks (floor mat) ..................... 24
Horn ................................................................... 140
HUD (Head-up display) switch ................ 87
I
I/M test ............................................................ 360
Identification Engine..............................................................453
Vehicle ............................................................452
If your vehicle has to be stopped in an emergency .................................................. 404
Ignition switch (engine switch)................. 176 Auto power off function............................179
Changing the engine switch modes ..179
If your vehicle has to be stopped in an emergency ................................................ 404
Indicators ............................................................72
Initialization Items to initialize ........................................ 483
Maintenance.................................... 356, 367

509Alphabetical Index
Turn signal lever .......................................... 184
Vanity lights ..................................................338
Wattage..........................................................458
Lock steering column .................................. 177
LTA (Lane Tracing Assist) Operation........................................................218
Warning messages .................................. 226
Luggage cover ............................................. 323
M
Maintenance Do-it-yourself maintenance ...................361
General maintenance ............................. 357
Maintenance data...................................... 452
Maintenance requirements ..................356
Malfunction indicator lamp .......................414
Master warning light ....................................419
Menu icons.........................................................79
Meter Clock .................................................................. 75
Indicators ...........................................................72
Instrument panel light control ................ 78
Meter control switches ..............................80
Meters ................................................................ 75
Multi-information display .......................... 79
Settings .............................................................. 83
Units .................................................................... 82
Warning lights ............................................... 413
Warning message..................................... 422
Micro dust and pollen filter ..................... 303
Mirrors Inside rear view mirror................................141
Outside rear view mirror defoggers298
Outside rear view mirrors ...................... 142
Vanity mirrors..............................................338
Moon roof Door lock linked moon roof operation.......................................................................... 148
Door lock linked panoramic moon roof operation ....................................................... 151
Jam protection function........................... 148
Operation........................................................ 147 Multi-information display .............................79
Audio system-linked display ...................83
AWD Control ................................................. 81
Drive information ......................................... 80
Driving assist system information .........83
Driving information display ..................... 80
Dynamic radar cruise control with full-speed range ......................................230
Eco Driving Indicator................................... 81
G-force .............................................................. 82
LTA (Lane Tracing Assist) .................... 223
Menu icons ...................................................... 79
Meter control switches ............................. 80
Navigation system-linked display ........83
Pop-up display ............................................... 79
Settings...............................................................83
Suggestion function .....................................84
Tire pressure ................................................ 373
Units..................................................................... 82
Warning message ..................................... 422
N
Navigation system-linked display... 83, 89
Noise from under vehicle ...............................6
O
“ODO TRIP” switch ...................................... 78
Odometer ......................................................... 78
Odometer and trip meter display Display items ................................................... 78
“ODO TRIP” switch .................................... 78
Pop-up display ............................................... 78
Oil Engine oil........................................................454
Rear differential oil......... ..................... ...... 456
Opener Fuel filler door ..............................................202
Hood ................................................................363
Outer foot lights Location ........................................................... 313
Outside door handle lig hts........................313

515Alphabetical Index
Wireless charger ......................................... 328
Wireless remote controlBattery-Saving Function ............................114
Locking/Unlocking ..................................... 95
Replacing the battery...............................389
For information regarding the equipment listed below, refer to
the “NAVIGATION AND MULTI-
MEDIA SYSTEM OWNER’S
MANUAL”.
· Navigation system
· Audio/visual system
· Panoramic view monitor
· Lexus parking assist monitor
