4147-2. Steps to take in an emergency
■Charging system warning light*
*: Except F SPORT models: This light illuminates on the multi-information display.
F SPORT models: This light illuminates on the meter.
■Low engine oil pressure warning light* (warning buzzer)
*: This light illuminates on the multi-information display.
■Malfunction indicator lamp
■SRS warning light
Warning lightDetails/Actions
Indicates a malfunction in the vehicle’s charging system
Immediately stop the vehicle in a safe place and contact your Lexus
dealer. Continuing to drive the vehicle may be dangerous.
Warning lightDetails/Actions
Indicates that the engine oil pressure is too low
 Immediately stop the vehicle in a safe place and contact your Lexus
dealer.
Warning lightDetails/Actions
(U.S.A.)
or
(Canada)
Indicates a malfunction in:
 The electronic engine control system;
 The electronic throttle control system; or
 The electronic automatic transmission control system
 Have the vehicle inspected by your Lexus dealer immediately.
Warning lightDetails/Actions
Indicates a malfunction in:
The SRS airbag system;
 The front passenger occupant classification system; or
 The seat belt pretensioner system
 Have the vehicle inspected by your Lexus dealer immediately.

4227-2. Steps to take in an emergency
WARNING
TPMS (tire pressure warning system)
malfunctions may occur for a variety of
reasons, including the installation of
replacement or alternate tires or wheels
on the vehicle that prevent the TPMS
(tire pressure warning system) from func-
tioning properly. Always check the
TPMS (tire pressure warning system)
malfunction telltale after replacing one
or more tires or wheels on your vehicle to
ensure that the replacement or alternate
tires and wheels allow the TPMS (tire
pressure warning system) to continue to
function properly.
NOTICE
■To ensure the tire pressure warning
system operates properly
Do not install tires wi th different specifi-
cations or makers, as the tire pressure
warning system may not operate prop-
erly.
If a warning message is dis-
played
The multi-information display
shows warnings of system malfunc-
tions, incorrectly performed opera-
tions, and messages that indicate a
need for maintenance. When a
message is shown, perform the cor-
rection procedure appropriate to
the message.
Except F SPORT models:
Master warning light
The master warning light also comes on
or flashes in order to indicate that a mes-
sage is currently be ing displayed on the
multi-information display.
Multi-information display
Follow the instructions of the message
on the multi-information display.
If any of the warning messages are
shown again after the appropriate
actions have been performed, contact
your Lexus dealer.
F SPORT models:
A
B

4728-2. Customization
*2: The default setting varies according to country.
*3:Except F SPORT models
*4:F SPORT models
■Head-up Display*( P.86)
*:If equipped
■Door lock ( P.97, 441)
FunctionDefault settingCustomized setting
Gauge informationNo content
Eco Driving Indica-
tor
—O—
Tachometer
Route guidance to destina-
tion/street nameOnOff—O—
Driving support system displayOnOff—O—
CompassOnOff—O—
Audio system operation statusOnOff—O—
FunctionDefault settingCustomized setting
Unlocking using a mechanical
key
Driver’s door
unlocked in one step, all doors
unlocked in two step
All doors unlocked in one step——O
Automatic door locking func-
tionShift position linked
door locking opera- tionOff
O—OSpeed linked door locking operation
Automatic door unlocking
functionShift position linked door unlocking operationOff
O—ODriver’s door linked door unlocking operation
ABC
ABC

4808-2. Customization
■PKSB (Parking Support Brake)* ( P.258)
*:If equipped
■Driving mode select switch ( P.274)
*:If equipped
■Front automatic air conditioning system ( P.296)
*:If equipped
■Seat heaters*/seat ventilators* ( P.310)
*:If equipped
FunctionDefault settingCustomized setting
PKSB (Parking Support Brake)
functionOnOff—O—
FunctionDefault settingCustomized setting
Powertrain control in custom-
ized mode
*NormalPowerO——Eco
Chassis control in customized
mode
*NormalSportO——
Air conditioning operation in
customized mode
*NormalEcoO——
FunctionDefault settingCustomized setting
A/C auto switch operationOnOffO—O
Exhaust gas sensor sensitivity*Standard-3 to 3O—O
FunctionDefault settingCustomized setting
Driver’s seat temperature pref-
erence in automatic modeStandard-2 (cooler) to 2
(warmer)O—O
Front passenger’s seat tem-
perature preference in auto-
matic mode
Standard-2 (cooler) to 2 (warmer)O—O
ABC
ABC
ABC
ABC

510Alphabetical Index
Outside rear view mirrorsAdjustment...................................................... 142
BSM (Blind Sport Monitor) ................. 239
Folding .............................................................. 143
Linked mirror functi on when reversing
........................................................................... 142
Mirror position memory...........................134
Outside rear view mirror defoggers298
RCTA function ............................................ 253
Outside temperature.....................................75
Overheating ...................................................447
P
Paddle shift switches ......................... 182, 183
Panic mode ....................................................... 95
Panoramic moon roof Jam protection function............................. 151
Operation....................................................... 150
Parking assist sensors (intuitive parking assist) ..............................................................247
Parking brake Operation....................................................... 185
Parking brake engaged warning buzzer...........................................................................187
Warning light .................................................419
Warning message.......................................187
Parking lights Light switch .................................................... 190
Replacing light bulbs................................395
Parking Support Brake function (for rear-crossing vehicles) .......................... 270Function .......................................................... 270
Parking Support Brake function (static objects) ......................................................... 264Function .......................................................... 264
PCS (Pre-Collision System) Function ..............................................................211
PCS OFF switch .......................................... 213
Warning light ................................................ 418
Personal lights.................................................313
PKSA (Parking Support Alert) .............. 245 PKSB (Parking Support Brake)............. 258
Warning message .....................................263
Power back door ............................................ 101 Hands Free Power Back Door ........... 104
Smart access system with push-button start ................................................................. 102
Power easy access system ........................134
Power outlets ................................................ 336
Power steering (Elect ric power steering
system) .......................................................... 278 Warning light ................................................ 415
Power windows Door lock linked window operation . 146
Jam protection function ........................... 145
Operation ....................................................... 145
Window lock switch...................................147
Pre-Collision System (PCS) Function ............................................................. 211
PCS OFF switch ..........................................213
Warning light ................................................ 418
R
Radar cruise control (dynamic radar cruise control with full-speed range)............. 230
Radiator ........................................................... 368
RCTA Function ..........................................................253
Warning message .....................................254
RCTA (Rear Cross Traffic Alert) ......... 245
RCTA function ............................................. 255
Rear automatic air conditioning system .......................................................................... 307
Rear Cross Traffic Alert (RCTA) ......... 253
Rear door sunshades ................................. 338
Rear fog lights Switch................................................................ 195
Rear seats .........................................................123 Adjustment ......................................................124
Folding down the rear seatbacks ........124
Head restraints..............................................137
Seat heaters ................................................... 310

512Alphabetical Index
Side doors...........................................................97
Side marker lightsLight switch .................................................... 190
Replacing light bulbs................................395
Side mirrors Adjustment...................................................... 142
BSM (Blind Sport Monitor) ................. 239
Folding .............................................................. 143
Linked mirror functi on when reversing
........................................................................... 142
Mirror position memory...........................134
RCTA function ............................................ 253
Side turn signal lights Replacing light bulbs................................395
Turn signal lever .......................................... 184
Side windows ..................................................145
Smart access system with push-button startAntenna location........................................... 113
Entry functions...................................... 97, 102
Starting the engine ...................................... 176
Smartphone holder...................................... 318
Snow tires ....................................................... 283
Spare tire......................................................... 426 Storage location ......................................... 427
Spark plug ...................................................... 455
Specifications ................................................ 452
Speedometer ....................................................75
Steering lock Column lock release.................................. 177
Steering lock system warning message........................................................................... 177
Steering wheel Adjustment..................................................... 140
Heated steering wheel............................. 310
Meter control switches ..............................80
Power easy access system .....................134
Steering wheel position memory ........ 134
Stop lights Replacing light bulbs................................395
Storage features ............................................316 Stuck
If the vehicle becomes stuck ................449
Suggestion function....................................... 84
Sun visors ........................................................ 337
Sunshade Panoramic moon roof .............................. 150
Roof.................................................................... 148
Switches Automatic High Beam switch .............. 193
Brake Hold switch......................................188
Door lock switches ......................................99
Driving mode select switch .................. 274
Driving position memory switches .....134
Dynamic radar cruise control with full-speed range switch .......................230
Electronic sunshade switch ................... 150
Emergency flashers switch .................. 404
Engine switch .................................................176
Fog light switch ............................................ 195
Garage door opener switches...........339
Heated steering wheel switch .............. 310
HUD (Head-up display) switch ............ 87
Ignition switch ................................................176
Instrument panel light control switches ............................................................................. 78
Intuitive parking assist switch ...............248
Light switches ............................................... 190
LTA (Lane Tracing Assist) switch ..... 223
Meter control switches ............................. 80
Moon roof switches....................................147
“ODO TRIP” switch .................................... 78
Outside rear view mi rror switches .....142
Paddle shift switches .......................182, 183
Panoramic moon roof switches .......... 150
Parking brake switch................................. 185
PCS OFF switch ..........................................213
PKSB (Parking Support Brake) switch ..........................................................................259
Power window switches ......................... 145
RCTA switch ................................................254
Rear window and outside rear view mir- ror defoggers switch ............................296
