1644-1. Before driving
for a more safe trailer hookup, the trailer
ball setup must be the proper height for the
coupler on the trailer.Coupler
Trailer ball
■Before towing
Check that the following conditions are
met:
●Ensure that your vehicle’s tires are prop-
erly inflated. ( P.448)
●Trailer tires are inflated according to the
trailer manufacturer’s recommendation.
●All trailer lights work as required by law.
●All lights work each time you connect
them.
●The trailer ball is set at the proper height
for the coupler on the trailer.
●The trailer is level when it is hitched.
Do not drive if the trailer is not level, and
check for improper tongue weight, over-
loading, worn suspension, or other possi-
ble causes.
●The trailer cargo is securely loaded.
●The rear view mirrors conform to all
applicable federal, state/provincial or local regulations. If they do not, install
rear view mirrors appropriate for towing
purposes.
■Adaptive Variable Suspension System
(if equipped)
The suspension can be switched for
improvement in driveability. ( P.275)
■Break-in schedule
If your vehicle is new or equipped with any
new power train components (such as an
engine, transaxle, transfer [AWD models],
rear differential [AWD models] or wheel
bearing), Lexus recommends that you do
not tow a trailer until the vehicle has been
driven for over 500 miles (800 km).
After the vehicle has been driven for over
500 miles (800 km), you can start towing.
However, for the next 500 miles (800 km),
drive the vehicle at a speed of less than 50
mph (80 km/h) when towing a trailer, and
avoid full throttle acceleration.
■Maintenance
●If you tow a trailer, your vehicle will
require more frequent maintenance due
to the additional load. (See “Warranty
and Services Guide”, “Owner’s Manual
Supplement” or “Scheduled Mainte-
nance”.)
●Retighten the fixing bolts of the towing
ball and bracket after approximately 600
miles (1000 km) of trailer towing.
■If trailer sway occurs
One or more factors (crosswinds, passing
vehicles, rough roads, etc.) can adversely
affect handling of your vehicle and trailer,
causing instability.
●If trailer swaying occurs:
• Firmly grip the steering wheel. Steer straight ahead.
Do not try to control trailer swaying by
turning the steering wheel.
• Begin releasing th e accelerator pedal
immediately but very gradually to reduce
speed.
Do not increase speed. Do not apply
vehicle brakes.
If you make no extreme correction with the
steering or brakes, your vehicle and trailer
should stabilize. (if enabled, Trailer Sway
A
B

4478-1. Specifications
8
Vehicle specifications
*: The fluid capacity is a reference quantity.If replacement is necessary, contact your Lexus dealer.
Your Lexus vehicle is filled with “Toyota Genuine Differential Gear Oil” at the fac-
tory. Use Lexus approved “Toyota Genuine Di fferential Gear Oil” or an equivalent
of matching quality to satisfy the above specification. Please contact your Lexus
dealer for further details.
Your Lexus vehicle is filled with “Toyota Genuine Differential Gear Oil” at the fac-
tory. Use Lexus approved “Toyota Genuine Di fferential Gear Oil” or an equivalent
of matching quality to satisfy the above specification. Please contact your Lexus
dealer for further details.
Automatic transmission
Fluid capacity*7.2 qt. (6.8 L, 6.0 Imp. qt.)
Fluid typeToyota Genuine ATF WS
NOTICE
■Transmission fluid type
Using transmission fluid other than the above type may cause abnormal noise or vibra-
tion, or damage the transmission of your vehicle.
Transfer (AWD models)
Oil capacity0.8 qt. (0.8 L, 0.7 Imp. qt.)
Oil type and viscosityToyota Genuine Differential gear oil LT 75W-85 GL-5
or equivalent
Rear differential (AWD models)
Oil capacity0.5 qt. (0.5 L, 0.4 Imp. qt.)
Oil type and viscosityToyota Genuine Differential gear oil LT 75W-85
GL-5 or equivalent
Brakes
Pedal clearance*3.4 in. (86 mm) Min.
Pedal free play0.04  0.24 in. (1.0  6.0 mm)

495Alphabetical Index
DifferentialRear differential oil .................................... 447
Dimension ...................................................... 442
Dinghy towing................................................. 173
Display Center Display............................................288
Dynamic radar cruise control with full-speed range .......................................227
Head-up display ...........................................88
Intuitive parking assist.............................. 244
LTA (Lane Tracing Assist)...................... 221
Multi-information display ............................81
RCTA ..............................................................250
Warning message....................................... 412
Distance until next engine oil change .... 80
Do-it-yourself maintenance ......................351
Door courtesy lights ................................... 309 Wattage.......................................................... 449
Door lock Power back door........................................ 103
Side doors ........................................................ 99
Smart access system with push-button start ................................................................... 115
Wireless remote control........................... 97
Door pockets ..................................................316
Doors Automatic door lock ing and unlocking
system ............................................................102
Door glasses .................................................. 144
Door lock warning buzzer .................... 100
Open door warning buzzer ..................102
Outside rear view mirrors ........................141
Rear door child-protectors ....................102
Side doors ........................................................ 99
Drive distance .................................................. 82
Driver’s seat position memory Driving position memory.........................133
Memory recall function ............................135
Power easy access system .....................133
Drive-start control ....................................... 155
Driving Break-in tips .................................................. 155 Correct driving posture ............................ 25
Driving mode select switch .................... 271
Procedures .................................................... 154
Winter drive tips ........................................ 280
Driving assist system information ............ 85
Driving information disp lay ........................ 82
Driving position memory............................133 Memory recall function............................ 135
Power easy access system .................... 133
Driving range ................................................... 82
Dynamic radar cruise control with full-speed range .........................................227Warning message .....................................235
Dynamic Torque Control AWD system .......................................................................... 275
E
Eco Driving Indicator............................83, 92
Eco Driving Indicator Light ........................ 83
EDR (Event data recorder) ............................7
Elapsed time ..................................................... 82
Electric Power Steering (EPS) .............. 275 Warning light .............................................. 405
Electronic key .................................................. 96 Battery-saving function.............................. 116
If the electronic key does not operate properly .........................................................431
Replacing the battery ............................... 379
Electronic sunshade Jam protection function ........................... 150
Operation ....................................................... 149
Emergency flashers .................................... 394
Emergency, in case of If a warning buzzer sounds.................. 403
If a warning light turns on...................... 403
If a warning message is displayed .......412
If the battery is discharged ....................433
If the electronic key does not operate properly .........................................................431
If the engine will not start........................428
If the fuel filler do or cannot be opened
......................................................................... 430

499Alphabetical Index
Interior lights list..........................................309
Rear interior lights .....................................309
Rear personal lights................................... 310
Replacing light bulbs............................... 385
Turn signal lever ...........................................182
Vanity lights .................................................. 333
Wattage.......................................................... 449
Lock steering column .................................. 175
LTA (Lane Tracing Assist) Operation........................................................ 216
Warning messages .................................. 224
Luggage cover .............................................. 318
M
Maintenance Do-it-yourself maintenance .................355
General maintenance ...............................351
Maintenance data...................................... 442
Maintenance requirements ................. 350
Malfunction indicator lamp ..................... 404
Master warning light .................................. 409
Menu icons..........................................................81
Meter Clock ................................................................... 77
Indicators ...........................................................74
Instrument panel light control ................80
Meter control switches .............................. 82
Meters ................................................................. 77
Multi-information display ............................81
Settings .............................................................. 85
Units .................................................................... 84
Warning lights .............................................403
Warning message....................................... 412
Micro dust and pollen filter ..................... 299
Mirrors Inside rear view mirror............................. 140
Outside rear view mirror defoggers294
Outside rear view mirrors ........................141
Vanity mirrors.............................................. 333
Moon roof Door lock linked moon roof operation........................................................................... 147 Door lock linked panoramic moon roof
operation ..................................................... 150
Jam protection function ............................147
Operation ....................................................... 146
Multi-information display ..............................81 Audio system-linked display ...................85
AWD Control ................................................83
Drive information .......................................... 82
Driving assist system information .........85
Driving information display ...................... 82
Dynamic radar cruise control with full-speed range ...................................... 227
Eco Driving Indicator..................................83
G-force ..............................................................84
LTA (Lane Tracing Assist) ...................... 221
Menu icons ....................................................... 81
Meter control switches .............................. 82
Navigation system-linked display ........85
Pop-up display ................................................ 81
Settings...............................................................85
Suggestion function .....................................86
Tire pressure ................................................ 367
Units.....................................................................84
Warning message .......................................412
N
Navigation system-linked display..... 85, 91
Noise from under vehicle ...............................6
O
“ODO TRIP” switch ...................................... 80
Odometer ......................................................... 80
Odometer and trip meter display Display items .................................................. 80
“ODO TRIP” switch ................................... 80
Pop-up display .............................................. 80
Oil Engine oil........................................................ 444
Rear differential oil......... ..................... ....... 447
Opener Fuel filler door ............................................. 200
