Page 31 of 660
311-1. For safe use
1
For safety and security
RX450h_U_OM0E013U WA R N I N G
Observe the following precautions.
Failure to do so may result in death or serious injury.●
Do not adjust the position of the driver’s seat while driving.
Doing so could cause the driver to lose control of the vehicle. ●
Do not place a cushion between the driver or passenger and the seatback.
A cushion may prevent correct posture from being achieved, and reduce the effec-
tiveness of the seat be lt and head restraint.●
Do not place anything under the front seats.
Objects placed under the front seats may be come jammed in the seat tracks and stop
the seat from locking in place. This may lead to an accident and the adjustment mech-
anism may also be damaged. ●
When driving over long distances, take regular breaks before you start to feel tired.
Also, if you feel tired or sleepy while drivin g, do not force yourself to continue driving
and take a break immediately.
Page 164 of 660
164
RX450h_U_OM0E013U 3-3. Adjusting the seats
Seat position adjustment switch
Seat cushion (front) angle adjust-
ment switch
Vertical height adjustment switch
Seatback angle adjustment switch
Lumbar support firmness adjust-
ment switch
Lumbar support height adjustment
switch (if equipped)
Seat cushion length adjustment
switch (if equipped) ■
Power easy access system
The driver’s seat and steering wheel move in accordance with power switch mode and
the driver’s seat belt condition. ( P. 1 74 )Front seats Adjustment procedure 1
2
3
4
5
6
7
WA R N I N G ■
When adjusting the seat position ●
Take care when adjusting the seat position to ensure that other passengers are not
injured by the moving seat. ●
Do not put your hands under the seat or near the moving parts to avoid injury.
Fingers or hands may become jammed in the se at mechanism.●
Make sure to leave enough space around the feet so they do not get stuck.■
Seat adjustment
To reduce the risk of sliding under the lap belt during a co llision, do not recline the seat
more than necessary.
If the seat is too rec lined, the lap belt may slide past the hips and apply restraint forces
directly to the abdomen, or your neck may contact the shoulder belt, increasing the risk
of death or serious injury in the event of an accident.
Adjustments should not be ma de while driving as the seat may unexpectedly move and
cause the driver to lose control of the vehicle.
Page 172 of 660
172 3-3. Adjusting the seats
RX450h_U_OM0E013U WA R N I N G ■
When folding down the rear seatbacks and when the rear seatbacks are folded
Observe the following precautions.
Failure to do so may result in death or serious injury.●
Do not fold down the rear seatbacks while driving. ●
Stop the vehicle on level ground, apply the parking brake and shift the shift lever to P.●
Do not allow anyone to sit on a folded re ar seatback or in th e luggage compartment
while driving. ●
Do not allow children to enter the luggage compartment. ■
When operating the rear seatback
Observe the following precautions.
Failure to do so may result in death or serious injury.●
Keep other passengers from being hit by the rear seatback. ●
Do not put your hands between the seats or near the moving parts, or let any part of
your body get caught. ●
Power seat: Do not let children operate the rear seatback. Other passengers may get
caught in the seat. ●
Power seat: Check that there are no passengers sitting in a seat before folding it
down. Do not let passengers sit in the seat while it is being folded down.■
Seat adjustment
To reduce the risk of sliding under the lap belt during a co llision, do not recline the seat
more than necessary.
If the seat is reclined excessively, the lap be lt may slide past the hips and apply restraint
forces directly to the abdomen, or your ne ck may contact the shoulder belt, increasing
the risk of death or serious inju ry in the event of an accident.
Adjustments should not be ma de while driving as the seat may unexpectedly move and
cause the driver to lose control of the vehicle. ■
After returning the rear seatback to the upright position
Observe the following precautions.
Failure to do so may result in death or serious injury.●
Make sure that the rear seatback is secure ly locked in position by lightly pushing it
back and forth. ●
Check that the seat belts are not twisted or caught between or behind in the rear
seatback.
Page 176 of 660
176 3-3. Adjusting the seats
RX450h_U_OM0E013U ■
Recall procedure
Check that the shift lever is in P.
Turn the power switch to ON mode.
Press one of the buttons for the
driving position you want to recall
until the buzzer sounds. ■
To stop the position recall operation part-way through
Perform any of the following: ●
Press the “SET” button. ●
Press button “1”, “2” or “3”. ●
Operate any of the seat adjustment switch es (only cancels seat position recall).●
Operate the tilt and telescopic steering co ntrol switch (only ca ncels steering wheel
position recall). ■
Seat positions that can be memorized ( P. 1 6 4 )
The adjusted positions other than the position adjusted by lumbar support switch can be
recorded. ■
Operating the driving position memory after turning the power switch off
Recorded seat positions can be activated up to 180 seconds after the driver’s door is
opened and another 60 seconds after it is closed again. ■
In order to correctly use the dr iving position memory function
If a seat position is already in the furthest po ssible position and the seat is operated in the
same direction, the recorded position may be slightly different when it is recalled.1
2
3
Page 178 of 660
178 3-3. Adjusting the seats
RX450h_U_OM0E013U ■
Cancelation procedure
Carry only the key you want to cancel and then close the driver’s door.
If 2 or more keys are in the vehicle, the driving position cannot be canceled
properly.
Turn the power switch to ON mode.
While pressing the “SET” button, press and hold the door lock switch
(either lock or unlock) unt il the buzzer sounds twice.If it button could not be canceled, the buzzer sounds continuously for approxi-
mately 3 seconds.■
Recalling the driving position using the memory recall function ●
Different driving positions can be registered for each electronic key. Therefore, the
driving position that is recalled may be different depending on the key being carried. ●
If a door other than the driver’s door is unlocked with the smart access system with
push-button start, the driving position cannot be recalled. In this case, press the driving
position button which has been set. ■
Customization
Some functions can be customized. ( P. 6 0 7 )
WA R N I N G ■
Seat adjustment caution
Take care during seat adjustment so that th e seat does not strike the rear passenger or
squeeze your body against the steering wheel. 1
2
Page 182 of 660
182 3-4. Adjusting the steering wheel and mirrors
RX450h_U_OM0E013U ■
The steering wheel can be adjusted when
The power switch is in ACCESSORY or ON mode
* .
* : If the driver’s seat belt is fastened, the steering wheel can be adjusted regardless of
power switch mode. ■
Automatic adjustment of the steering position
A desired steering position can be entered to memory and recalled automatically by the
driving position memory system. ( P. 1 74 )■
Power easy access system
The steering wheel and driver’s seat move in accordance with power switch mode and
the driver’s seat belt condition. ( P. 1 74 )■
Customization
Some functions can be customized. ( P. 6 0 7 )
WA R N I N G
Do not adjust the steering wheel while driving.
Doing so may cause the driver to mishandle the vehicle and cause an accident, result-
ing in death or serious injury.
Page 408 of 660
408 5-2. Using the air conditio ning system and defogger
RX450h_U_OM0E013U ■
Side display operation screen (Vehicles with 12.3-inch display)
Select the air flow mode
Adjust the left-hand side temper-
ature setting
Adjust the fan speed setting
Adjust the right-hand side tem-
perature setting
Select to set auto mode on/off
Select to set cooling and dehu-
midification function on/off
Adjust the temperature for driver and passenger seats separately (“DUAL”
mode) ( P. 4 0 8 )■
Using the automatic mode
Press the “AUTO” button or select “AUTO” on the air conditioning control
screen.
Press to switch to automatic air intake mode. (if equipped)
The air conditioning system automati cally switches between outside air
and recirculated air modes.
Adjust the temperature setting.
To stop the operation, press the “OFF” button.■
Automatic mode indicator
If the fan speed setting or air flow modes are operated, the automatic mode
indicator goes off. However, automati c mode for functions other than that
operated is maintained. ■
Adjusting the temperature for driver and passenger seats separately
(“DUAL” mode)
To turn on the “DUAL” mode, perform any of the following procedures: ●
Select “DUAL” on the air co nditioning control screen.●
Select “DUAL” on the side display operation screen. (Vehicles with 12.3-
inch display) ●
Adjust the temperature setting of the passenger side with the passenger
side temperature adjustment button. The indicator comes on when the “DUAL” mode is on. 1
2
3
4
5
6
Air conditioning controls 7
1
2
3
4
Page 511 of 660
5116-3. Do-it-yourself maintenance
6
Maintenance and care
RX450h_U_OM0E013U Adjustment bolt A
Adjustment bolt B
Make sure the vehicle has a full tank of gasoline and the area around the
headlight is not deformed.
Park the vehicle on level ground.
Sit in the driver’s seat.
Bounce the vehicle several times.Headlight aim (vehicles with single-beam head-
lights) Vertical movement adjusting bolts 1
2
Before checking the headlight aim 1
2
3
4
