LEXUS RX450H 2020 Owners Manual

5306-4. Using the storage features
RX350/RX350L_U
Open (press the button)
Unlock with the mechanical key
Lock with the mechanical key
The glove box light turns on when the tail lights are on.
Push the knob.
Lift by hand to fully open the console
box.
●The console box light turns on when the tail lights are on.
Glove box
1
2
3
Console box
●A pen can be stored in the pen holder on the
underside of the lid.
●Remove the tray to access a storage space
under the tray.

5316-4. Using the storage features
6
Interior features
RX350/RX350L_U
Cup holders
Front seatsSecond-row seats (Type A)
Pull down the armrest and
Then press down the button.
Second-row seats (Type B)
Press in the button.

5326-4. Using the storage features
RX350/RX350L_U
The depth of the front cup holder can be changed. To store a water bottle, push down the bottom
of the cup holder.
To return the bottom to its original position,
press the button.
WARNING
●Do not place anything other than cups, aluminum cans, or water bottles in the cup
holders. Other items may be thrown out of the holders in the event of an accident or
sudden braking, possibly causing injury. If possible, cover hot drinks to prevent burns.
●Rear cup holder: When not in use, keep the cup holders are closed. Injuries may
result in the event of an accident or sudden braking.
NOTICE
To prevent damage to the rear cup holder, stow the cup holder before stowing the arm-
rest.
1
2

5336-4. Using the storage features
6
Interior features
RX350/RX350L_U
Door pockets
FrontRear
The door pockets can be opened and
closed.
WARNING
Front door pockets: Keep the door pockets closed while driving.
Injuries may result in the event of an accident or sudden braking.
Bottle holders

5346-4. Using the storage features
RX350/RX350L_U
●When storing a bottle, close the cap.
●The bottle may not be stored depending on its size or shape.
Press in the button.
NOTICE
Do not place open bottle, glass or paper cups containing liquid in the bottle holders.
Otherwise, contained liquid may be spilled. Glass cups may break if used in the bottle
holders.
Coin box
WARNING
Keep the coin box closed while driving.
Injuries may result in the event of an accident or sudden braking.

5356-4. Using the storage features
6
Interior features
RX350/RX350L_U
Auxiliary boxes
Type AType B
Press in the lid. Lift the lid.
Type C (if equipped)
Pull up the lever to release the lock, and
lift the lid.
WARNING
Type A: Do not store items he avier than 0.44 lb. (200 g).
Doing so may cause the auxiliary box to open and the items inside may fall out, result-
ing in an accident.

5366-4. Using the storage features
RX350/RX350L_U
Pull down the hook to use. The cargo hooks are provided for securing loose items.
To hang the cargo net, use the cargo
net hooks and rear cargo hooks.
Luggage compartment features
Cargo hooks
RX350RX350L
WARNING
To avoid injury, always return the hooks to their stowed positions when not in use.
Cargo net hooks
WARNING
To avoid injury, always return the hooks to their stowed positions when not in use.

5376-4. Using the storage features
6
Interior features
RX350/RX350L_U
To use the grocery bag hook, push it in.
■Removing the luggage cover unit (RX350L)
Remove the deck board and side
auxiliary box cover and take out the
luggage cover unit. (P. 541)
Grocery bag hooks
RX350RX350L
NOTICE
Do not hang any object heavier than 8. 8 lb. (4 kg) on the grocery bag hooks.
Luggage cover

5386-4. Using the storage features
RX350/RX350L_U
■Using the luggage cover
RX350L: Before installing the luggage cover, fold down the third-row seats.
( P. 157)
Insert either end of the luggage
cover into the recess, then com-
press the other end of the lug-
gage cover and insert it into the
recess.
Pull out the luggage cover and
hook it onto the anchors.
1
2

5396-4. Using the storage features
6
Interior features
RX350/RX350L_U
■Removing the luggage coverRelease the cover from the left
and right anchors and allow it to
retract.
Compress the end of the luggage
cover and lift the luggage cover
up.
RX350: After removing the luggage
cover, place it somewhere other than
the passenger compartment.
RX350L: Stow the luggage cover
under the deck board and side auxil-
iary box cover.
1
2
WARNING
●Do not place anything on the luggage cover. In the event of sudden braking or turn-
ing, the item may go flying and strike an occupant. This could lead to an unexpected
accident, resulting in death or serious injury.
●Do not allow children to climb on the lugg age cover. Climbing on the luggage cover
could result in damage to the luggage cove r, possibly causing death or serious injury
to the child.
