odometer LEXUS RX450h 2021 Owners Manual

842-1. Instrument cluster
Shift position display (P.191)
Odometer and trip meter display ( P.87)
F SPORT models
The units used on the meters may differ depending on the target region.
Outside temperature
Displays the outside temperature within the range of -40°F (-40°C) to 122°F (50°C). Low
outside temperature indicator comes on when the ambient temperature is 37°F (3°C) or
lower.
Multi-information display
Presents the driver with a variety of vehicle data ( P.88)
Displays warning messages in case of a malfunction (P.428)
Hybrid System Indicator
Displays hybrid system outp ut or regeneration level (P.85)
This display changes to a tachometer depending on the drive mode, and can be set to show
the tachometer in any drive mode on the settings display. ( P.92, 281)
Speedometer
Engine coolant temperature gauge
Displays the engine coolant temperature
Fuel gauge
Displays the quantity of fuel remaining in the tank
Shift position display ( P.191)
Odometer and trip meter display ( P.87)
Clock
Time displayed is linked to the analog clock on the instrument panel. (P.343)
H
I
A
B
C
D
E
F
G
H
I

872-1. Instrument cluster
2
Vehicle status information and indicators
■Display items
 Odometer
Displays the total distance the vehicle has
been driven.
Trip meter A/trip meter B
Displays the distance the vehicle has been
driven since the meter was last reset. Trip
meters A and B can be used to record and
display different distances independently.
 Distance until next engine oil
change
Displays the distance the vehicle can be
driven until an oil change is necessary.
■Changing the display
Each time the “ODO TRIP” switch is
pressed, the displayed item will be changed. When the trip meter is dis-
played, pressing and holding the switch
will reset the trip meter.
■Pop-up display
Distance until next engine oil change
Displays the distance until the next engine
oil change. This display will be displayed in
the following situations:
 When the power switch is turned to
ON mode.
 When a warning message indicating
that oil maintenance should be per-
formed soon or is required is dis-
played.
The brightness of the instrument panel
lights can be adjusted.
If the brightness is adjusted when the sur-
roundings are bright and the tail lights are
on (day mode bright ness adjustment), the
brightness level of night mode will be
adjusted at the same time.
WARNING
For example, there is a lag between the
driver’s shifting and the new gear number
appearing on the display. This lag could
cause the driver to downshift again,
causing rapid and excessive engine brak-
ing and possibly an accident resulting in
death or injury.
NOTICE
■To prevent damage to the engine and
its components
●Do not let the indicator needle of the
tachometer enter the red zone, which
indicates the maximum engine speed.
●The engine may be overheating if the
engine coolant temperature gauge is
in the red zone (H). In this case, imme-
diately stop the vehicle in a safe place,
and check the engine after it has
cooled completely. ( P.454)
Odometer and trip meter dis-
play
Changing the instrument panel
light brightness

520Alphabetical Index
Dynamic radar cruise control with full-speed range ...................................... 238
Energy monitor............................................ 100
G-force................................................................ 91
LTA (Lane Tracing Assist).................... 232
Menu icons ...................................................... 89
Meter control switches .............................. 89
Navigation system-linked display ........ 92
Pop-up display...............................................88
Settings .............................................................. 92
Suggestion function..................................... 93
Tire pressure ................................................ 382
Units ...................................................................... 91
Warning message..................................... 428
N
Navigation system-linked display....92, 98
Noise from under vehicle ...............................6
O
“ODO TRIP” switch ...................................... 87
Odometer ......................................................... 87
Odometer and trip meter display Display items ................................................... 87
“ODO TRIP” switch .................................... 87
Pop-up display............................................... 87
Oil Engine oil ....................................................... 463
Rear differential oil ....................................465
Opener Fuel filler door..................................................211
Hood................................................................369
Outer foot lights Location............................................................ 321
Outside door handle lights........................321
Outside rear view mirrors Adjustment..................................................... 150
BSM (Blind Sport Monitor) ................. 247
Folding ............................................................... 151
Linked mirror functi on when reversing
.......................................................................... 150 Mirror position memory ...........................142
Outside rear view mirror defoggers306
RCTA function ..............................................261
Outside temperature.................................... 83
Overheating .................................................. 454
P
Paddle shift switches ..........................192, 193
Panic mode ......................................................107
Panoramic moon roof Jam protection function ........................... 159
Operation ....................................................... 158
Parking assist sensors (intuitive parking assist) ............................................................. 255
Parking brake Operation ....................................................... 195
Parking brake engaged warning buzzer............................................................................197
Warning light ............................................... 424
Warning message .......................................197
Parking lights Light switch .................................................. 200
Replacing light bulbs ............................... 400
Parking Support Brake function (for rear-crossing vehicles) ...........................277Function .......................................................... 277
Parking Support Brake function (static objects) ........................................................... 271Function ............................................................ 271
PCS (Pre-Collision System) Function ..........................................................220
PCS OFF switch ........................................ 222
Warning light ............................................... 424
Personal lights.................................................321
PKSA (Parking Support Alert) .............. 253
PKSB (Parking Support Brake)............. 266 Warning message ..................................... 270
Power back door ............................................ 113 Hands Free Power Back Door ............. 116
Smart access system with push-button start ................................................................... 114
Power control unit.......................................... 69
