cluster LEXUS SC300 1999 User Guide

STARTING AND DRIVING
220
2. Set the driving pattern selector switch to the ºNormalº
position.
Your transmission has a driving pattern selector switch which
allows you to select ºPowerº, ºNormalº or ºSnowº mode to
suit your driving condition. For ordinary driving, Lexus
recommends that you use the ºNormalº position to improve
fuel economy.
3. For more powerful acceleration and sporty driving,
use the ºPowerº position.
In the ºPowerº position, the ºECT PWRº light in the
instrument cluster is on and the transmission is shifted up at
higher vehicle speeds and shifted down more responsively
than in the ºNormalº position.
For ºSnowº mode, see ºElectronic Throttle Control
Systemº on page 241.

STARTING AND DRIVING
230

The shift position is displayed on the instrument cluster.
P: Parking, engine starting and key removal position
R: Reverse position
N: Neutral position
D: Normal driving position (Shifting into overdrive
possible)
3: Position for engine braking (Shifting into overdrive
not possible)
When the cruise control is being used, even if you
downshift from ºDº to º3º, engine braking will not be
applied because the cruise control is not cancelled. For
the operation to decrease the vehicle speed, see page
245.
2: Position for more powerful engine braking
L: Position for maximum engine braking Correct use of the automatic transmission is explained in
the following parts.
(a) Normal driving
(b) Using engine braking
(c) Using the º2º and ºLº positions
(d) Backing up
(e) Parking
(f) Good driving practice
(g) Rocking your vehicle if stuck
(h) If you cannot shift the selector lever

STARTING AND DRIVING
232
2. Set the driving pattern selector switch to the ºNormalº
position.
Your transmission has a driving pattern selector switch which
allows you to select ºPowerº, ºNormalº or ºSnowº mode to
suit your driving condition. For ordinary driving, Lexus
recommends that you use the ºNormalº position to improve
fuel economy.
3. For more powerful acceleration and sporty driving,
use the ºPowerº position.
In the ºPowerº position, the ºECT PWRº light in the
instrument cluster is on and the transmission is shifted up at
higher vehicle speeds and shifted down more responsively
than in the ºNormalº position.
For ºSnowº mode, see ºElectronic Throttle Control
Systemº on page 241.

STARTING AND DRIVING
242In the power mode, the ºECT PWRº light in the instrument
cluster is on and the transmission is shifted up at higher
vehicle speeds and shifted down more responsively than in
the normal mode.
To return to the normal mode, push the driving pattern
selector switch lightly on the ºSNOWº side.
Snow mode: For slippery road surfaces such as in snow. In
this mode, the spinning of the rear wheels is controlled
appropriately.
When you push the driving pattern selector switch on the
ºSNOWº side, the snow mode is turned on and the ºECT
SNOWº light in the instrument cluster comes on.
To return to the normal mode, push the driving pattern
selector switch on the ºSNOWº side again.
When you turn the ignition switch off in the snow mode, the
mode automatically changes to the normal mode.
CRUISE CONTROL
The cruise control allows you to cruise the vehicle at a
desired
speed over 40 km/h (25 mph) with your foot off the
accelerator pedal.
Your cruising speed can be maintained although a slight speed
change may occur when driving up or down a gradient, within
the limits of engine performance. On steeper hills, a great
speed change will occur so it is better to drive without the
cruise control.
When the cruise control is on, the driving pattern of the
automatic transmission is fixed in the normal position,
regardless of the position of the selector switch.
CAUTION
 To help maintain maximum control of your vehicle, do not
use the cruise control when driving in heavy or varying
traffic, or on slippery (rainy, icy or snow±covered) or
winding roads.
 Avoid vehicle speed increases when driving downhill. If the
vehicle speed is too fast in relation to the cruise control set
speed, cancel the cruise control then downshift the
transmission to use engine braking to slow down.

STARTING AND DRIVING
243
Turning on the system
To operate the cruise control, push the main switch. This
turns the system on. The indicator light in the instrument
cluster shows that you can now set your desired cruising
speed. Another push on the switch will turn the system
completely off.
When the ignition key is turned off, the main switch is also
automatically turned off. To use the cruise control again, push
the main switch again to turn it on.
CAUTION
To avoid accidental cruise control engagement, keep the main
switch off when not using the cruise control.

STARTING AND DRIVING
245
If the vehicle speed falls below about 40 km/h (25 mph), the
preset speed will be automatically cancelled.
If the vehicle speed drops 16 km/h (10 mph) below the preset
speed, the preset speed will also automatically be cancelled.
If the preset speed automatically cancels out for other than
these reasons, have your vehicle checked by your Lexus
dealer at the earliest opportunity.
Resetting to a faster speed
Press the control lever upward in the ºRES/ACCº direction
and hold it. Release the lever when the desired speed is
attained. While the lever is held upward, the vehicle will
gradually gain speed.
When
the difference between the actual vehicle speed and the
set speed is less than 5 km/h (3 mph), the set speed can be
increased 1.6 km/h (1 mph) each time by pressing the control
lever upward in the ºRES/ACCº direction quickly within 0.6
seconds.
However, a quicker way to reset is to accelerate the vehicle
and then press the control lever downward in the
ºSET/COASTº direction.
Resetting to a slower speed
Press the control lever downward in the ºSET/COASTº
direction and hold it. Release the lever when the desired
speed is attained. While the lever is held downward, the
vehicle speed will gradually decrease. When
the difference between the actual vehicle speed and the
set speed is less than 5 km/h (3 mph), the set speed can be
lowered 1.6 km/h (1 mph) each time by pressing the control
lever downward in the ºSET/COASTº direction quickly
within 0.6 seconds.
However, a quicker way to reset is to depress the brake pedal
and then press the control lever downward in the
ºSET/COASTº direction.
Even if you downshift the transmission from ºDº to º4º
(SC400) or from ºDº to º3º (SC300) with the cruise control
on, engine braking will not be applied because the cruise
control is not cancelled. To decrease the vehicle speed, reset
to a slower speed with the cruise control lever or depress the
brake pedal. If you use the brake pedal, cruise control is
cancelled.
Resuming the preset speed
If the preset speed is cancelled by pulling the control lever or
by depressing the brake pedal, pushing the lever up in the
ºRES/ACCº direction will restore the speed set prior to
cancellation. However, once the vehicle speed falls below
about 40 km/h (25 mph), the preset speed will not be resumed.
Cruise control failure warning
If the ºCRUISEº indicator light in the instrument cluster
flashes five times and then goes out when using the cruise
control, it means that there is trouble in the cruise control
system. Contact your Lexus dealer.

ENGINE
338
Gasolines containing MTBE
Gasolines that contain MTBE (Methyl Tertiary±Butyl
Ether) are available in the market. If you use a gasoline
mixed with MTBE, make certain that it does not contain
more than 15% of MTBE.
Gasolines containing MMT
Some gasolines contain an octane±enhancing additive
called MMT (methylcyclopentadienyl manganese
tricarbonyl).
Lexus does not recommend the use of gasolines that contain
MMT. If fuels containing MMT are used, your emission
control system may be adversely affected. The Malfunction
Indicator Lamp on the instrument cluster may come on. If this
happens, contact your Lexus dealer for service.
Gasolines containing alcohol
Gasohol is a mixture of gasoline and ethanol. If you use
gasohol in your Lexus, be sure that it is unleaded, has an
octane rating no lower than 87 and does not contain more
than 10% ethanol. Lexus does not recommend the use of
gasolines containing methanol.
If you use gasoline containing methanol, use only gasoline
meeting the requirements above and also containing less than
5% methanol with cosolvents and corrosion inhibitors for
methanol.
