check engine LEXUS SC300 1999 Owner's Manual

IN CASE OF AN EMERGENCY
307
3. Insert your finger, the screwdriver or equivalent into the
hole to push down the shift lock override button. You can shift
out of ºPº position only while pushing the button.
4. Shift into ºNº position.
5. Insert the cover.
6. Start the engine. For your safety, keep the brake pedal
depressed.
Be sure to have the system checked by your Lexus dealer as
soon as possible.IF YOU LOSE YOUR KEYS ORLOCK YOURSELF OUT
Many Lexus dealers can make a new key if you can give
them the key number. Since your vehicle is equipped with
the engine immobiliser system, the dealer will also need
your master key.
See the suggestion given in ºKeysº on page 12.
If your keys are locked in the vehicle and you cannot get a
duplicate, many Lexus dealers can still open the door for you,
using their special tools. If you must break a window to get
in, we suggest breaking the smallest side window because it
is the least expensive to replace. Be extremely cautious to
avoid cuts from the glass.
Even if you lose only one key, contact your Lexus dealer to
make a new key. If you lose all your master keys, you cannot
make new keys; the whole system must be replaced.

MAINTENANCE
312
GENERAL MAINTENANCE
Listed below are the general maintenance items that should be
performed at the intervals specified. It is recommended that
any problem you notice be brought to the attention of your
Lexus dealer or qualified service shop for their advice.
CAUTION
Make these checks only where adequate ventilation can be
obtained if you run the engine.
Vehicle exterior
Items listed below should be performed from time to time,
unless otherwise specified.
Tire pressure
Check the pressure with a gauge every two weeks, or at least
once a month and adjust as shown on the tire pressure label.
See page 363 for additional information.
Tire surface
Check the tires carefully for cuts, damage or excessive wear.
See page 365 for additional information.
Wheel nuts
When checking the tires, make sure to check the nuts for
looseness. Tighten them if necessary. Tire rotation
Rotate the tires every 12000 km (7500 miles). See page 365
for additional information.
Fluid leaks
Check underneath for leaking fuel, oil, water or other fluid
after
the vehicle has been parked for a while. If you smell fuel
fumes or notice any leak, have the cause found and corrected
immediately.
Doors and engine hood
Check that all doors, including trunk lid, operate smoothly
and all latches lock securely. Make sure the engine hood
secondary latch secures the hood when the primary latch is
released.

MAINTENANCE
314
Engine compartment
Items listed below should be checked from time to time,
e.g. each time when refueling.
Washer fluid
Make sure there is sufficient fluid in the tank. See page 396
for additional information.
Engine coolant level
Make sure the coolant level is between the Upper and Lower
lines on the see±through reservoir when the engine is cold.
See page 347 for additional information.
Battery
Your Lexus has a maintenance free battery. You do not have
to add distilled water. For longer life of the battery, however,
see page 380 for additional information.
Brake fluid level
Make sure the brake fluid level is correct. See page 359 for
additional information.
Engine oil level
Check the level on the dipstick with the engine turned off and
the vehicle parked on a level spot. See page 342 for additional
information.Power steering fluid level
Check the level on the dipstick. The level should be in the
ºHOTº or ºCOLDº range depending on the fluid
temperature. See page 361 for additional information.
Engine fan fluid level
Check the level through the reservoir. The level should be in
ºHOTº or ºCOLDº range depending on the fluid
temperature. See page 349 for additional information.
Exhaust system
If you notice any change in the sound of the exhaust or smell
exhaust fumes, have the cause located and corrected
immediately. (See engine exhaust cautions in Section 3±1.)

MAINTENANCE
315
DOES YOUR VEHICLE NEEDREPAIRING?
Be on the alert for changes in performance and sounds, and
visual tip±offs that indicate service is needed. Some
important clues are:

Engine missing, stumbling, or pinging

Appreciable loss of power

Strange engine noises

A fluid leak under the vehicle (However, water dripping
from the air conditioning after use is normal.)

Change in exhaust sound (This may indicate a dangerous
carbon monoxide leak. Drive with the windows open and
have the exhaust system checked immediately.)

Flat±looking tires, excessive tire squeal when cornering,
uneven tire wear

Vehicle pulls to one side when driving straight on a level
road

Strange noises related to suspension movement

Loss of brake effectiveness, spongy feeling brake pedal,
pedal almost touches floors, vehicle pulls to one side when
braking

Engine coolant temperature continually higher than
normal
If you notice any of these clues, take your vehicle to your
Lexus dealer as soon as possible. It probably needs
adjustment or repair.

INTRODUCTION
325

Right after driving, the engine compartment ± the
engine, radiator, exhaust manifold and power
steering fluid reservoir, etc. ± will be hot. So be
careful not to touch them. Oil and other fluids may
also be hot.

Do not smoke, cause sparks or allow open flames
near fuel or the battery. Their fumes are fl ammable.

Be extremely cautious when working on the battery.
It contains poisonous and corrosive sulfuric acid.

Do not get under your vehicle with just the body jack
supporting it. Al ways use automotive jack stands or
other solid supports.

Use eye protection whenever you work on or under
your vehicle where you may be exposed to flying or
falling material, fluid spray, etc.
NOTICE

Remember that battery and ignition cables carry high
currents or voltages. Be careful of accidentally
causing a short circuit.

Before closing the engine hood, check to see that you
have not forgotten any tools, rags, etc.

Do not drive with the air cleaner removed, or excessive
engine wear could result. Also backfiring could cause
a fire in the engine compartment.

Do not overfill automatic transmission fluid, or the
transmission could be damaged.

Be careful not to scratch the glass surface with the
wiper frame.
PARTS AND TOOLS
Here is a list of parts and tools you will need to perform
do±it±yourself maintenance. Remember all Lexus parts are
designed in metric sizes, so your tools must be metric.
Checking the engine oil level
Parts (if level is low):

Use API grade SJ, ºEnergy±Conservingº multigrade
engine oil or ILSAC multigrade engine oil. For
recommended oil viscosity, see page 346.
Tools:

INTRODUCTION
326

Rag or paper towel

Funnel (only for adding oil)
Checking the engine coolant level
Parts (if level is low):

ºToyota Long Life Coolantº or equivalent
See ºChecking the engine coolant levelº on page 342 for
instructions.

Demineralized or distilled water
Tools:

Funnel (only for adding coolant)
Checking the engine fan fluid
Part (if level is low)

Automatic transmission fluid DEXRON
II or III
Tools:

Funnel (only for adding fluid)
Checking brake fluid
Parts (if level is low):

FMVSS No. 116 DOT 3 or SAE J1703 brake fluid
Tools:

Funnel (only for adding fluid)
Checking power steering fluid
Parts (if level is low):

Automatic transmission fluid DEXRON
II or III
Tools:

Rag or paper towel

Funnel (only for adding fluid)

SECTION 6 ± 2
329
SERVICE PROCEDURES AND
SPECIFICATIONS
Engine
Specifications (SC400) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
330
Specifications (SC300) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
334
Fuel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . .
337
Facts about engine oil consumption . . . . . . . . . . . . . . . . . . . .
339
Used engine oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
341
Checking the engine oil level . . . . . . . . . . . . . . . . . . . . . . . . .
342
Checking the engine coolant level . . . . . . . . . . . . . . . . . . . . .
347
Checking the engine fan fluid . . . . . . . . . . . . . . . . . . . . . . . . .
349
Spark plugs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . .
350

ENGINE
333
± ELECTRICAL SYSTEM
Battery ± Maintenance type battery Specific gravity reading at 20 C (68F):
Charging rates Quick charge Slow charge
± Non±maintenance battery Open voltage at 20C (68F):
Charging rates
1.260 Fully charged
1.160 Half charged
1.060 Discharged
15A max.
5A max.
12.7V Fully charged
12.3V Half charged
11.9V Discharged
[Voltage that is checked 20 minutes after the key is
removed with all the lights turned off]
5A max.

ENGINE
336± IGNITION SYSTEM
Spark plug ± Make DENSO NGK
± Gap
PK16TR11
BKR5EKPB11
1.1 mm (0.043 in.)
± ELECTRICAL SYSTEM
Battery ± Maintenance type battery Specific gravity reading at 20 C (68F):
Charging rates Quick charge Slow charge
± Non±maintenance battery Open voltage at 20C (68F):
Charging rates
1.260 Fully charged
1.160 Half charged
1.060 Discharged
15A max.
5A max.
12.7V Fully charged
12.3V Half charged
11.9V Discharged
[Voltage that is checked 20 minutes after the key is
removed with all the lights turned off]
5A max.

ENGINE
340The amount of engine oil consumed depends on the
viscosity of the oil, the quality of the oil and the way the
vehicle is driven.
More oil is consumed by high±speed driving and frequent
acceleration and deceleration.
A new engine consumes more oil, since its pistons, piston
rings and cylinder walls have not become conditioned.
When judging the amount of oil consumption, keep in
mind that the oil may have become diluted, making it
difficult to judge the true level accurately.
For example, if a vehicle is used for repeated short trips and
consumes a normal amount of oil, the dipstick may not show
any drop in the oil level at all, even after 1000 km (600 miles)
or more. This is because the oil is gradually becoming diluted
with fuel or moisture, making it appear that the oil level has
not changed.
The diluting ingredients evaporate out when the vehicle is
then driven at high speeds, as on an expressway, making it
appear that oil is excessively consumed after driving at high
speeds.
Importance of engine oil level check
One of the most important points in proper vehicle
maintenance is to keep the engine oil at the optimum level so
that
oil function will not be impaired. Therefore, it is essential
that the oil level be checked regularly. Lexus recommends
that the oil level be checked every time you refuel the vehicle.
NOTICE
Failure to check the oil level regularly could lead to
serious engine trouble due to insufficient oil.
For detailed information on oil level check, see ºChecking the
engine oil levelº on page 342.
