Page 2 of 48
GENERAL INFORMATION
²After transport of the vehicle by a tow truck, car train or in a car
ferry, the navigation system may need a few minutes outdoors for
exact repositioning.
²After the vehicle battery has been disconnected, the system may need
up to 15 minutes for exact repositioning. The vehicle has to be
situated outdoors and the system has to be switched on to receive the
GPS satellites.
²The system is fully operational even without valid GPS data, but the
accuracy of positioning may decrease.
²As soon as sufficient GPS data is received, the color of the satellite
icon in the GPS window changes from red to green.
²On highways, the distance indications of the navigation system for
exits are different from those on the highway signs. The highway signs
refer to the distance to the beginning of the exit, whereas the
navigation system refers to the end of the exit. This is the point where
you must turn.
²When the vehicle is moving, only the five buttons on the console will
be active. The rotary button will be active only after selecting one of
the five buttons and only if applicable to the menu available.
Introduction
2
Page 7 of 48
SHORT-CUTS
The navigation system has five ªshort-cutº buttons that can be found on
the center console control unit.
REPEAT
Press ªrepeatº to receive the last
vocal guidance advice. This will only
give advice if the ªguidanceº has
been activated.
MAP
In certain screens the ªMapº button
has a screen toggle effect.
²On a digitized road it is possible
to switch between Guidance Screen, Map display and Split screen.
DETOUR
When the ªdetourº button is
pressed, the system checks whether
or not the ªguidanceº is activated. If
the system is in guidance mode, the
detour entry screen is shown. This screen only allows use of the rotary
control to select ªdetour distanceº. The ªRepeatº and ªOn/Offº buttons
are the only other functional buttons during this operation.
Refer to theAlternative Routechapter for more information on selecting
an alternative route.
VOLUME
When the ªVolumeº button is
pressed, the volume adjustment
screen is shown. The ªRepeatº and
ªOn/Offº buttons are the only
buttons that are functional when the volume screen is active.
Refer to theVolumesection of theSystem Settingschapter for more
information on volume settings.
REPEAT
MAP
DETOUR
VOLUME
Controls
7
Page 9 of 48
MENUS
The individual functions are represented in the menus (identified by
titles in the oval field at the top of the screen) as labeled, rectangular
buttons. The current cursor position
is marked in red.
1.Menu title
2.Buttons:Highlighted options can
be selected. Options, which are
currently not available, are skipped
automatically.
3.Status line:The following
information is available to be
displayed on the left or right of the
status line (only two of the following can be selected at once, one on the
left of the screen and one on the right of the screen):
²Clock
²Date
²Estimated time of arrival (for example ª* 9:28º)
²Remaining travel time (for example ª *0:46hº)
Further information that is always displayed by the system:
²
: hour-glass (system is calculating; for example during route
planning)
²
: audible info (voice messages) disabled
²
: route planning criterion
²:
motion lockout active
For further information on the status line and additional selections refer
to theRoute Selectionin theSystem Settingschapter.
4.Selected function:(cursor position). By turning the rotary control,
the cursor will move to the next button.
Menus
9
Page 14 of 48
Address book:To store or recall destination addresses from a private or
business database. It also allows the last 10 used destination addresses
on a first in first out basis.
Via points:To specify via points (intermediate stops) along the way to
the entered destination address.
Delete destination:To delete the last entered destination address.
Return:To return to the Start Menu.
How to enter a destination address
Most features are locked out while
the vehicle is moving, however the
five buttons on the console and the
directly supporting features remain
active. The destination address can
be entered four different ways:
²Letter-by-letter by means of a
ªkeyboardº (the keyboard is
displayed on the screen and
selections are made by turning
the rotary control and pressing
ENTER).
²CHOOSE points of interest (hotels, gas stations, etc.) from the map
CD
²Input by means of a map and crosshairs
²CHOOSE from the Address Book.
Direct entry of destination address
With the keyboard, you can enter the city, road and the address number
letter by letter. Alternatively you may choose a nearby intersection. Here
a city name starting with ªFRANº is entered by not completed.
1. CHOOSE ªNavigationº in the Start menu. The ªNavigationº menu
appears.
2. CHOOSE ªCountryº only if you wish to change it.
3. CHOOSE ªCityº or the displayed city name. The keyboard window will
open.
4. Enter the city name.
5. To delete a character previously entered, choose ªDeleteº.
Navigation menu
14
