Page 151 of 320
When this button is pressed, the Lincoln Security
Response Center relays details of your situation and
your location to the United States Auto Club
(USAC) via a three-way phone call. The response
center/USAC will: dispatch the appropriate service vehicle to your
location. provide the service vehicle's estimated time of
arrival. call back approximately three minutes after the
service vehicle's estimated time of arrival to
confirm that assistance has arrived.
Ambulance Button
(Emergency Assistance)
The ambulance button should be selected if
emergency assistance is required. This feature
should be used: if you have been involved in an accident
148 to report a crime or fire when medical attention is required to receive assistance in any emergency
situationThe Emergency Assistance button
When this button is pressed, the Lincoln
Security Response Center relays details of your
situation and your location to local 911 or other
emergency services via a three-way phone call.
The response center/emergency services will: dispatch the appropriate emergency help to
your location
Page 155 of 320
Location Data Retransmit Capability
During an activation, the Lincoln Security Response
Center operator has the capability to initiate a
retransmission of the electronic data message. This
may be necessary to ensure a more precise
determination of vehicle location or to track a
vehicle that is moving. To accomplish the
retransmit, a special tone is sent to the vehicle by the
response center. In this situation you will
temporarily lose voice contact with the operator and
the messages "SENDING LOCATION DATA" and
"DATA RECEIVED" will respectively be displayed
on the Message Center. After the data
retransmission is complete, voice communication
will be restored and the CID, LAT, LON and HDG
message will again alternately toggle on the
Message Center display.
152Global Positioning System
Vehicle location is continuously updated via
Global Positioning System (GPS) technology.
GPS was developed by the U.S. Department of
Defense for worldwide navigational and
positioning purposes. It utilizes a constellation
of 24 orbiting satellites located more than 20
thousand kilometers above the earth. At any
given time, several of the 24 satellites should be
visible to the vehicle's GPS receiver. Based on
the time for signals emitted by these satellites to
reach the receiver, an on-board computer will
determine the vehicle's location, typically within
100 feet. In addition to latitude and longitude,
the system also determines heading and speed.
Vehicle positioning information is relayed to the
Lincoln Security Response Center ONLY
during roadside or emergency requests. The
response center will not be able to track your
location while in an inactive state.
Page 272 of 320
Fuse
Location Fuse Amp
RatingDescription910A
· Blower motor relay coil
· EATC control
· Airbag diagnostic1030A
· Windshield wiper motor
· Windshield wiper control
module (washer pump motor)1110A
· PCM power relay coil
· Ignition coil125A
· SCP network1315A
· Stand alone clock
illumination
· Right and left rear side
marker lamps
· License lamps
· Right and left tail lamps
(on decklid)
· Left rear stop/turn lamps
· Left turn indicator
· Left front turn lamp1415A
· Front cigar lighter270Fuse
LocationFuse Amp
RatingDescription1510A
· Navigation display
· Navigation module
· Heated seat control switches1630A
· power moonroof switch
· Moonroof motor17(Not used)185A
· SCP network1910A
· LH low beam2010A
· Multi-function switch (Flash
to pass and hazard signal to
LCM)
· LH & RH cornering lamps2110
· ABS control module22(Not used)23(Not used)245A
· SCP network25
· RH low beam2610A
· Instrument cluster power
· EATC power27(Not used)
Page 276 of 320
Fuse
LocationMaxi-Fuse
Amp
RatingDescriptionFuse
LocationMaxi-Fuse
Amp RatingDescription1
2
340A
60A
60A· EATC blower motor
· Engine cooling fans
· Air suspension compressor relay1330A
· DSM
· Heated seats
· Driver 4-way power
lumbar seats460A
· ABS module
· EVAC and fill14 30A
· Passenger power seat
· Passenger 4-way power560A
· Fuse panel to LCM
· OBD 111530A
· Luxury radio
· Sub woofer amplifier
· CD player660A
· Fuse panel to LCM CD player1620A
· HI beam730A
· VDM1720A
· Horn840A
· Heated mirrors
· Heated backlight1810A
· Air bags940A
· DDM
· LH power windows
· Door locks19Not used1040A
· RH power windows2010A
· PCM KAPWR1140A
· Ignition switch to fuse panel2110A
· Alternator sensor
· Alternator field supply1240A
· Ignition switch to fuse panel
274
Page 277 of 320
Fuse
LocationMaxi-Fuse
Amp RatingDescription22Not used23Relay
· HI beam headlamps relay2420A
· Fuel pump2520A
· Thermactor pump26Relay
· EATC blower motor relay2730A
· PCM
· STC28Not used29Relay
· Horns relay30Relay
· Powertrain control module
relayChecking and Replacing Fuses
If you need to check a fuse, follow these steps:
1. Find the fuse panel underneath the instrument
panel to the left of the steering column.
Squeeze together the two areas indicated by
the arrows and pull down to remove the
cover.
2. Find the fuse you want to check (fuses are
numbered on the fuse panel) and remove it
with the fuse pulling tool that is provided.
3. Check the fuse to see if it is blown. Look
through the clear side of the fuse to see if the
metal wire inside is separated. If it is, the fuse
should be replaced.
